Fuji Electric ZKM User manual

Instruction Manual
INZ-TN1ZKMe-E
ZIRCONIA OXYGEN
ANALYZER CONVERTER
Type: ZKM

- i -
INZ-TN1ZKM-E
PREFACE
We are grateful for your purchase of Fuji Direct Insertion Type Zirconia Oxygen Analyzer Converter (ZKM).
First read this instruction manual carefully until an adequate understanding is acquired, and
then proceed to installation, operation and maintenance of the converter. Improper handling
may result in accidents or injury.
The specifications of this converter will be changed without prior notice for further product
improvement.
Modification of this converter is strictly prohibited unless a written approval is obtained
from the manufacturer. Fuji will not bear any responsibility for a trouble caused by such a
modification.
This instruction manual shall be stored by the person who actually uses the converter.
After reading through the manual, be sure to keep it near at hand for future reference.
This product falls within category 9 (Monitoring and control instruments including indus-
trial monitoring and control instruments) of Annex 1 of EU RoHS directive (2011/65/EU).
Please do not use it for consumer use.
This instruction manual should be delivered to the end user without fail.
Manufacturer: Fuji Electric Co., Ltd.
Type: Described in the nameplate put on the main body
Date of manufacture: Described in the nameplate put on the main body
Product nationality: Japan
Related instruction manual
Direct insertion type zirconia oxygen analyzer detector (Type: ZFK8)··············INZ-TN5ZFK8-E
Fuji Electric Co., Ltd. 2008
Notice Issued in October 2008
Revised in December 2008
Revised in May 2009
Revised in July 2009
Revised in April 2011
Revised in September 2013
It is prohibited to transfer part or all of this manual without Fuji
Electric’s permission in written format.
Description in this manual is subject to change without prior no-
tice.

- ii - INZ-TN1ZKM-E
SAFETY PRECAUTIONS
First of all, read this “SAFETY PRECAUTIONS” carefully, and then use in the correct way.
Installation, transportation, wiring, use, maintenance of this product shall be carried out by suitably trained
personnel.
First-time users should operate the instrument under the supervision of a fully competent person in the
operation.
Be sure to observe the instructions shown below, because they describe important information on safety.
Those safety precautions are ranked in 3 levels, “DANGER”, “CAUTION” and “PROHIBITION”.
DANGER
If operation is incorrect, a dangerous situation may occur, resulting in
death or serious injuries.
CAUTION
If handled wrongly, a dangerous situation may occur, and medium trou-
ble or slight injury may be caused and only property damage may be
caused.
PROHIBITION
Items which must not be done are noted.
The items noted under “
CAUTION
” may also result in serious trouble depending on circumstances.
All the items are important and must be fully observed.
Caution on installation and transportation
DANGER
This unit is not explosion-proof type. Do not use it in an atmosphere
of explosive gases. Otherwise serious accidents such as explosion or
fire may result.
CAUTION
This unit should be installed in a place which conforms to the condi-
tions noted in the instruction manual. Otherwise, it may cause electric
shocks, fire, failure or malfunction of the unit.
During installation work, care should be taken to keep the unit free
from entry of cable chips or other foreign objects. Otherwise, it may
cause fire, failure or malfunction of the unit.
For installation, observe the rule on it given in the instruction manual
and select a place where the weight of converter can be endured. In-
stallation at an unsuited place may cause turnover or fall and there is a
risk of injury.
Be sure to wear gloves when handling the unit.
Bare hands may invite an injury.
Before transport, fix the door so that it will not open. Otherwise, the
door may be separated and fall to cause an injury.

- iii -
INZ-TN1ZKM-E
Cautions on wiring
CAUTION
Be sure to turn off all the power before performing wiring. Otherwise
electric shock may result.
Be sure to perform class D grounding work.
Otherwise, electric shock or failure may result.
Select a proper wiring material that satisfies the ratings of the instru-
ment. Otherwise, electric shock or fire may result.
Connect power source of correct rating. Connection of a power source
of incorrect rating may lead to a risk of fire.
Cautions on use
DANGER
If unusual smell or sound has been produced, immediately stop the
instrument. Any discharge produced may cause a fire.
CAUTION
Leaving the converter unused for a long time or restarting it after dis-
use requires procedures different from normal operation or suspension
procedures. Be sure to follow the instructions in each instruction man-
ual. Otherwise, intended performance may not be achieved, or acci-
dents or injury may result.
Do not operate the converter for a long time with its door left open.
Otherwise, dust, foreign matter, etc. may stick on internal walls, there-
by causing failure.
PROHIBITION
Do not touch the input/output terminals with metal or finger. Other-
wise, failure, electric shock or injury may result.
Caution on maintenance and inspection
CAUTION
Before maintenance and check, be sure to turn off the main power
supply and wait until the detector is cooled adequately. Otherwise,
you may suffer a burn.
Before removing the detector from the flue for maintenance and
check, make sure the furnace is stopped. Otherwise, you may suffer a
burn.
Before working, take off a wrist watch, finger ring or the like metallic
accessories. And never touch the instrument with a wet hand. Other-
wise, you will have electric shocks.
If the fuse is blown, eliminate the cause, and then replace it with the
one of the same capacity and type as before. Otherwise, it may cause
electric shocks or failure.
Others
CAUTION
If the cause of a failure cannot be identified by referring to the instruc-
tion manual, be sure to contact your dealer or Fuji’s technician in
charge of adjustment. Disassembling the instrument carelessly may
result in electric shock or injury.
Do not use a replacement part other than specified by the instrument
maker. Otherwise, adequate performance will not be provided. Be-
sides, an accident or failure may be caused.
Replacement parts such as a maintenance part should be disposed of
as incombustibles.

- iv - INZ-TN1ZKM-E

- v -
INZ-TN1ZKM-E
Contents
PREFACE ..........................................................................................................................................................i
SAFETY PRECAUTIONS............................................................................................................................. ii
CHECKING OF CONTENTS OF THE PACKAGE................................................................................ viii
STORAGE CONDITIONS.......................................................................................................................... viii
1. GENERAL....................................................................................................................................................1
1.1 Direct insertion type zirconia oxygen analyzer ........................................................................................1
2. OPERATING PARTS AND THEIR FUNCTIONS...................................................................................2
2.1 External appearance..................................................................................................................................2
2.1.1 Outline Drawing.................................................................................................................................2
2.1.2 Terminal block....................................................................................................................................3
2.2 OPERATING PARTS AND THEIR FUNCTIONS..................................................................................4
2.2.1 External appearance ...........................................................................................................................4
2.2.2 Internal constitution ...........................................................................................................................5
2.3 Description on display/operation panel ....................................................................................................6
3. INSTALLATION..........................................................................................................................................7
3.1 Installation site..........................................................................................................................................7
3.2 How to install the converter......................................................................................................................8
3.2.1 Mounting on panel surface (ZKM1).................................................................................................8
3.2.2 Pipe mounting (ZKM1)......................................................................................................................8
3.2.3 Mounting on panel surface (ZKM2).................................................................................................9
3.2.4 Pipe mounting (ZKM2)....................................................................................................................9
4. WIRINGAND PIPING..............................................................................................................................10
4.1 Before wiring..........................................................................................................................................10
4.2 Wiring to terminals .................................................................................................................................11
4.2.1 O2sensor input / Input method of O2sensor thermocouple .............................................................11
4.2.2 Cable gland and input and output lines ............................................................................................11
4.2.3 Allocation of the terminal block.......................................................................................................12
4.3 Wiring and piping diagram .....................................................................................................................13
4.4 Handling of standard gas (An article on separate order) ........................................................................17
5. OPERATION..............................................................................................................................................18
5.1 Preparation for operation ........................................................................................................................18
5.2 Key operation flow diagram (outline) ....................................................................................................19
5.3 Initial parameter value table ...................................................................................................................23
5.3.1 Parameters related to measurement..................................................................................................23
5.3.2 Parameters related to calibration......................................................................................................23
5.3.3 Parameters related to blowdown (displayed if the option is provided)............................................24
5.3.4 Parameters related to maintenance...................................................................................................24
5.3.5 Other parameters ..............................................................................................................................25
6. OPERATION START AND STOP ..........................................................................................................27
6.1 Operation start ........................................................................................................................................27
6.2 Operation stop.........................................................................................................................................27
6.3 Actions during operation.........................................................................................................................28
6.4 Check the contents of display .................................................................................................................29
6.4.1 Check of state information ...............................................................................................................29
6.4.2 Checking the error information........................................................................................................30

- vi - INZ-TN1ZKM-E
6.4.3 Checking the alarm information...................................................................................................... 30
6.5 Oxygen detector standard output voltage............................................................................................... 31
7. CALIBRATION......................................................................................................................................... 32
7.1 Preparation ............................................................................................................................................. 32
7.2 Manual calibration ................................................................................................................................. 33
7.3 Auto calibration (option)........................................................................................................................ 35
7.4 Remote calibration ................................................................................................................................. 37
7.5 All calibration (option)........................................................................................................................... 39
8. BLOWDOWN (OPTION)......................................................................................................................... 40
8.1 Preparation for blowdown...................................................................................................................... 40
8.2 Manual blowdown.................................................................................................................................. 40
8.3 Automatic blowdown ............................................................................................................................. 41
8.4 Remote blowdown ................................................................................................................................. 43
9. MAINTENANCE AND CHECK.............................................................................................................. 45
9.1 Checking ................................................................................................................................................ 45
9.2 Consumable parts................................................................................................................................... 45
9.3 Spare parts.............................................................................................................................................. 45
9.4 Replacement of fuse............................................................................................................................... 46
9.5 Troubleshooting ..................................................................................................................................... 47
10. SETTINGAND OPERATING OF PARAMETER............................................................................... 49
10.1 Measured menu.................................................................................................................................... 49
10.1.1 Display range setting screen.......................................................................................................... 49
10.1.2 Decimal point position setting screen............................................................................................ 50
10.1.3 Full scale setting screen................................................................................................................. 51
10.1.4 Setting screen for calculation time of maximum and minimum values appears ........................... 52
10.2 Calibration menu.................................................................................................................................. 53
10.2.1 Automatic calibration setting (option)........................................................................................... 53
10.2.2 Date and time for starting automatic calibration (option) ............................................................. 54
10.2.3 Cycle time setting of automatic calibration (option).....................................................................55
10.2.4 Performing all calibration (option)................................................................................................ 56
10.2.5 Performing a manual span calibration........................................................................................... 57
10.2.6 Performing a manual zero calibration ........................................................................................... 58
10.2.7 Calibration gas setting ................................................................................................................... 59
10.2.8 Calibration waiting setting (option)............................................................................................... 60
10.2.9 Calibration error clear ................................................................................................................... 61
10.2.10 Operation setting screen of calibration range.............................................................................. 62
10.3 Blowdown menu (option) .................................................................................................................... 63
10.3.1 Automatic blowdown setting......................................................................................................... 63
10.3.2 Date and time setting of automatic blowdown ..............................................................................64
10.3.3 Automatic blowdown cycle setting ............................................................................................... 65
10.3.4 Procedure for setting blowdown time............................................................................................ 66
10.3.5 Perfoming manual blowdown........................................................................................................ 67
10.4 Maintenance menu ............................................................................................................................... 68
10.4.1 Error log display............................................................................................................................ 68
10.4.2 Clearing error logs......................................................................................................................... 70
10.4.3 Alarm log display .......................................................................................................................... 71
10.4.4 Clearing alarm logs ....................................................................................................................... 72
10.4.5 Operation log display .................................................................................................................... 73
10.4.6 Clearing operation logs ................................................................................................................. 75
10.4.7 Sensor check setting for calibration (option)................................................................................. 76
10.4.8 Sensor recovery setting for calibration (option)............................................................................ 77
10.4.9 Performing a manual sensor check................................................................................................ 78
10.4.10 Performing manual sensor recovery............................................................................................ 79
10.4.11 Cell internal resistance display .................................................................................................... 80

- vii -
INZ-TN1ZKM-E
10.4.12 Maintenance mode setting...........................................................................................................81
10.4.13 Password setting...........................................................................................................................82
10.4.14 PID auto tuning ............................................................................................................................83
10.5 Parameter menu ....................................................................................................................................84
10.5.1 Current date and time setting .........................................................................................................84
10.5.2 Contact input setting ......................................................................................................................85
10.5.3 Selection of alarm contact output...................................................................................................86
10.5.4 High limit setting of oxygen concentration....................................................................................87
10.5.5 Lower limit setting of oxygen concentration .................................................................................88
10.5.6 HH limit setting of oxygen concentration......................................................................................89
10.5.7 LL limit setting of oxygen concentration .......................................................................................90
10.5.8 Hysteresis Setting...........................................................................................................................91
10.5.9 Hold treatment setting (maintenance hold) ...................................................................................93
10.5.10 Hold value setting (maintenance hold)........................................................................................94
10.5.11 Setting of hold setting value (maintenance hold) ........................................................................95
10.5.12 Setting of measurement recovery time (maintenance hold)........................................................96
10.5.13 Hold treatment setting (error hold)..............................................................................................97
10.5.14 Hold value setting (error hold).....................................................................................................98
10.5.15 Setting of hold setting value (error hold) ....................................................................................99
10.5.16 Setting of key lock .....................................................................................................................100
10.5.17 LCD brightness adjustment........................................................................................................101
10.5.18 Setting of automatic OFF time ...................................................................................................102
10.5.19 Station number setting................................................................................................................103
10.5.20 Adjustment screen for analog output 0% ...................................................................................104
10.5.21 Adjustment screen for analog output 100% ...............................................................................105
10.5.22 Fuel coefficient setting (option) .................................................................................................106
10.6 Factory menu ......................................................................................................................................107
10.6.1 Password setting screen................................................................................................................107
11. HOW TO CHANGE THE SETTING...................................................................................................108
11.1 How to change the setting of converter ZKM depending on detector type ........................................108
12. SPECIFICATIONS................................................................................................................................109
12.1 Specifications......................................................................................................................................109
12.2 Code symbols......................................................................................................................................111

- viii - INZ-TN1ZKM-E
CHECKING OF CONTENTS OF THE PACKAGE
Check that all of the following are contained in the delivered package.
(1) Zirconia Oxygen Analyzer Converter main unit 1 unit
(2) Accessories 1 set (Refer to the table below.)
Table 1 Standard accessories
No. Item Quantity Remarks
1 Tube type fuse (250 V T 0.5 A) 2 For main unit (F1)
2 Tube type fuse (250 V T 2.5 A) 2 For heater (F2)
3 Instruction manual 1
The “Japanese,” “English” or “Chinese”
manual is attached.
(As specified)
4 Communication Manual 1
The instruction manual of “MODBUS” is
attached.
(As specified)
5 Mounting bracket 1 set
The “panel attachment bracket” and “pipe
attachment bracket” are attached.
(As specified)
STORAGE CONDITIONS
Store the unit in a location that meets the following conditions:
(1) Vibration, dust, dirt, and humidity are minimal.
(2) A place not subjected to radiated heat from a heating furnace, etc.
(3) The atmosphere is non-corrosive.
(4) A place where ambient temperature and humidity are –30 to +70°C (non condensing) and 95% RH or
less.

- 1 -
INZ-TN1ZKM-E
1. GENERAL
This manual describes the installation, operation, and the maintenance of the zirconia oxygen analyzer con-
verter. Read it carefully before using the converter. For the detector, flow guide tube and ejector used with
the converter, refer to relevant instruction manuals.
1.1 Direct insertion type zirconia oxygen analyzer
The direct insertion type zirconia oxygen analyzer consists of a direct insertion type zirconia detector (type
ZFK) and converter (type ZKM).
The analyzer intended for the measurement of oxygen concentration in exhaust gas is used for combustion
control.
Caution
Power voltage for the converter must conform to that for the detector to be connected. Don’t use any
power voltage different from the power specifications of the detector. Otherwise it may result in damage
to the detector.
100/120V AC50/60Hz for ZFK8R1
200/240V AC50/60Hz for ZFK8R3
Operating environment
1) Operating temperature: -20 to 55°C
2) Operating humidity: 95%RH or less, non condensing
3) Power voltage: 100 to 120V AC 50/60Hz or 200 to 240V AC 50/60Hz
4) Pollution degree: 2
5) Installation category: II

- 2 - INZ-TN1ZKM-E
2. OPERATING PARTS AND THEIR FUNCTIONS
2.1 External appearance
2.1.1 Outline Drawing
ZKM1
Small case (IP66)
Mtg. Plate
Earth terminal (M4)
For power supply
For communication
For output
Mounting for
2B pipe
U bolts M8
(option)
Mounting plate (option)
Valve (option)
For sensor (coupling)
For ø23.5/ø15.8 tube
For ø23.5/ø15.8
For contact Input/output
2.5
2.5
75
M
E
A
S
.
S
N
Z
O
ZKM
Oxygen Analyzer
MODE ESC
ENTER
POWER
Calibration gas outlet
(for ø6 tube)
Zero gas inlet
(for ø6 tube)
Span gas inlet
(for ø6 tube)
Oxygen Analyzer
100
72
1010 170
270
100
55
153
35
62.5
Finish color: Case; Silver
Cover; PANTONE Cool Gray 1C-F
Material: Aluminum die cast
Mass: Approx.2.0kg
ZKM2
Large case (IP67)
Mounting for
2B pipe
Mounting plate (option)
For φ23.5/φ15.8 tube
For sensor (coupling)
For φ23.5/φ15.8 tube
For sensor (coupling)
U bolts M8 (option)
U bolts M8 (option)
95
Bracket
5.7
MODE ESC ENTER
POWER
For contact Input/output
(G1/2)
For communication
(G1/2)
For output
(G1/2)
For power supply
(G1/2)
Valve (option)
324
195
72
498 312
220 20
14 230
59
55
953.2
39
40 40 40 40
65
M
E
A
S
.
S
N
Z
O
Calibration gas outlet
(for φ6 tube)
Zero gas inlet
(for φ6 tube)
Span gas inlet
(for φ6 tube)
Earth terminal (M4)
Finish color: Case; Silver
Cover; Munsell GPB 3.5/10.5 (blue)
Material: Aluminum die cast
Mass: Approx. 4.5kg

- 3 -
INZ-TN1ZKM-E
2.1.2 Terminal block
COMMUNICATION TERMINAL (TM2) / INSERTION TERMINAL
RS232C
RS485
Terminal number
TXD
TRX+
1
RXD
TRX–
2
GND
GND
3Remarks
Standard
Option
EXTERNAL TERMINAL (TM1) / M3 SCREW
1
15
2 3 4 5 6 7 8 9 10 11 12 13 14
16 17 18 19 20 21 22 23 24 25 28
26 27



O
2
TC1 AO
FAULT
TC2 DI1 DI2 DI3 DICOM
ALARM MAINTE
BLOW
AC
LSVCOM AC N
or
HEATER
ZV
ZERO
GAS
SPAN
GAS
O
2
sensor
input
O
2
sensor
heater power
output
Analog
output
4-20mA DC
or 0-1V DC
Fault
contact output
250V AC/3A
30V DC/3A
Blow contact
output
250V AC/3A
30V DC/3A
O
2
sensor
thermocouple
input
Thermocouple
input
(combustion input)
M4 SCREW
Ground
terminal
M4
Contact input
Short : ON (Current 5mA)
Open : OFF (Voltage between 2 terminals 5V)
Alarm
contact output
250V AC/3A
30V DC/3A
Calibrating gas
contact output
250V AC/3A
30V DC/3A Power supply
input
100V to120V AC
200V to 240V AC
Note 1) The heater power supply is the same
as the converter power supply.
Note 2) Be sure to connect the shield of the
cable to the ground in the main body.
Maintenance
contact output
250V AC/3A
30V DC/3A
COM
Exclusive
cable

- 4 - INZ-TN1ZKM-E
2.2 OPERATING PARTS AND THEIR FUNCTIONS
2.2.1 External appearance
ZKM1＜ IP66＞
M
E
A
S
.
S
N
Z
O
ZKM
Oxygen Analyzer
MODE ESC ENTER
POWER
Oxygen Analyzer
(3)
(2)
(4)
(5)
(6)
(1)
ZKM2＜
IP67＞
MODE ESC
ENTER
POWER
M
E
A
S
.
S
N
Z
O
(2)
(4)
(1)
(5)
(6)
Name Explanation
(1) Door fixing screw Fixes the front door. (4-M5)
(2) Display/operation panel Displays or operates the concentration value or setting values.
(3) Specification nameplate Ddescribes the equipment identification number, specifications or
the like.
(4) Cable gland The wiring hole for the power wire and output line
(5) Cock Selects zero or span gas (available at option).
(6) Flow meter Use to adjust the quantity of the zero/span gas.

- 5 -
INZ-TN1ZKM-E
2.2.2 Internal constitution
ZKM1＜ IP66＞
HEATER
POWER
FUSE T
250V T 0.5A
POWER
ON
OFF
FUSE T
250V T 2.5A
Power supply must be selected
the same voltage of detector.
CAUTION
1
15
2 3 4 5 6 7 8 9 10 11 12 13 14
16 17 18 19 20 21 22 23 24 25 2826 27
O2TC1 AO FAULT BLOW ZV HEATER
TC2 DI1 DI2 DI3 DI- ALARM MAIN- COM SV AC
LN
COM TENANCE
1
TXD
TRX
2
RXD
TRX
3
GND
GND
TM2
RS232C
RS485
PS3
(2) I/O board
(6) Tube type fuse (F1)
(5) Tube type fuse (F2)
(4) Power switch
(3) Terminal block
(7) Earth terminal
(1) CPU board
ZKM2＜
IP67＞
SHSH
MODE ESC ENTER
POWER
RS232C
RS485
123
GND
GND
RXD
TRX㧙
TXD
TRX㧗
TM2
HEATER
POWER
FUSE T
250V T 0.5A
POWER
ON
OFF
FUSE T
250V T 2.5A
1
15
2 3 4 5 6 7 8 9 10 11 12 13 14
16 17 18 19 20 21 22 23 24 25 2826 27
㧗㧙
O
2
㧗㧙
TC1
㧗㧙
AO FAULT BLOW ZV HEATER
㧗㧙
TC2 DI1 DI2 DI3
DI-
ALARM
MAIN-
COM SV AC
LN
COM TENANCE
ᄌ឵ེ߳ଏ⛎ߔࠆ㔚Ḯ㔚࿶ߪޔធ⛯ߐࠇࠆ
ᬌ಴ེߩ㔚Ḯ㔚࿶ߦวࠊߖߡߊߛߐ޿ޕ
Power supply must be selected
the same voltage of detector.
CAUTION
ᵈᗧ
Oxygen Analyzer
(1) CPU board
(2) I/O board
(6) Tube type fuse (F1)
(5) Tube type fuse (F2)
(4) Power switch
(3) Terminal block
(7) Earth terminal
Name Explanation
(1) CPU board The liquid crystal display and the memory circuit are installed.
(2) I/O board The input/output circuit and the power circuit are installed.
(3) Terminal block Terminal block for various input/output signals.
(4) Power switch Turns ON/OFF this converter. (“–”: OFF, “”: ON)
(5) Tube type fuse (F2) Fuse for the heater. (250 V T 2.5 A)
(6) Tube type fuse (F1) Fuse for the main unit (250 V T 0.5 A)
(7) Earth terminal Used as frame gland (FG).

- 6 - INZ-TN1ZKM-E
2.3 Description on display/operation panel
(2) MODE key
(1) Display unit
(6) ENTER key
(4) Digit key
(3) ESC key (5) UP key
Name Explanation
(1) Display unit Displays the concentration value and setting values.
(2) MODE key Used to switch measurement display and mode display.
(3) ESC key Used to return to the previous screen or exit the setting.
(4) Digit key
(5) Up key Used to change the setting values.
(6) ENTER key Used to determine the setting values.

- 7 -
INZ-TN1ZKM-E
3. INSTALLATION
DANGER
This unit is not explosion-proof type. Do not use it in an atmosphere of explosive gases. Otherwise
serious accidents such as explosion or fire may result.
CAUTION
For installation, observe the rule on it given in the instruction manual and select a place where the
weight of converter can be endured. Installation at an unsuited place may cause turnover or fall and
there is a risk of injury.
Before transport, fix the door so that it will not open. Otherwise, the casing may be separated and fall
to cause an injury.
During installation work, care should be taken to keep the unit free from entry of cable chips or other
foreign objects. Otherwise, it may cause fire, failure or malfunction.
3.1 Installation site
Install the converter in a place that satisfies the following conditions.
(1) Space for periodic inspection and wiring work is available.
(2) Vibration, dust, dirt, and humidity are minimal.
(3) A place not subjected to radiated heat from a heating furnace, etc.
(4) The atmosphere is non-corrosive.
(5) Away from electrical devices that may cause noise trouble (such as motor and transformer), and
equipment that may cause electromagnetic or electrostatic induction trouble.
(6) A place where ambient temperature and humidity are -20 to +55°C and 95%RH or less.
Secure at least 100 mm of space between the converter and nearby wall. Also secure a space of opening the
front cover for maintenance.
Secure a cable wiring space under the case.
Ｏ
Ｐ
Ｅ
Ｎ
147147
400 or more
Unit: mm
100
or
more
Top view of mounting (ZKM1: small case)
Ｏ
Ｐ
Ｅ
Ｎ
240
100
or
more
240
580 or more
Unit: mm
Top view of mounting (ZKM2: Large case)

- 8 - INZ-TN1ZKM-E
3.2 How to install the converter
3.2.1 Mounting on panel surface (ZKM1)
Unit: mm
Mounting dimensions Installation
72
4-M8
250
1
43
Accessories of
converter
Panel face
2
OUTPUT DC
TYPE
POWER AC
Fuji Electric systems Co.,Ltd.
Made in Japan
50/60Hz 60VA
SER. NO.
MFD
OXYGEN TRANSM ITTER
No. Name Quantity
1 Converter 1
2 Pan head screw
(M8×12) 4
3 Spring washer (M8) 4
4 Plain washer (M8) 4
Code Standard tightening torque
M8 12.5 [N･m]
3.2.2 Pipe mounting (ZKM1)
Installation
2B-pipe
formounting
5
6
1
2
3,4
No. Name Quantity
1 Converter 1
2 Hexagon nut (M8) 4
3 Spring washer (M8) 4
4 Plain washer (M8) 4
5 U bolt (M8) 2
6 Support panel 2
Code Standard tightening torque
M8 12.5 [N･m]

- 9 -
INZ-TN1ZKM-E
3.2.3 Mounting on panel surface (ZKM2)
Unit: mm
Mounting dimensions Installation
4-M8 72
312
1
2
Panel face
3.2
t
No. Name Quantity
1 Converter 1
2 Pan head screw
(M8×12) 4
Code Standard tightening torque
M8 12.5 [N･m]
3.2.4 Pipe mounting (ZKM2)
Installation
Pipe for
mounting
5
6
1
2
3,4
52
3,4
No. Name Quantity
1 Converter 1
2 Hexagon nut (M8) 4
3 Spring washer (M8) 4
4 Plain washer (M8) 4
5 U bolt (M8) 2
6 Support panel 2
Code Standard tightening torque
M8 12.5 [N･m]

- 10 - INZ-TN1ZKM-E
4. WIRING AND PIPING
CAUTION
: Wiring work must be carried out with all power supplies turned off. Otherwise electric
shock may result.
: Be sure to ground the Converter. (Class D grounding)
4.1 Before wiring
(1) Power voltage for the converter must conform to that for the detector to be connected.
(2) Power supply wiring
Use 1.25sq 600V vinyl insulated cable (JISC3307) or equivalent as power supply cable.
Use the main ground wire longer than the L1 and L2 lines.
Fix the part of the AC cable sheath that is more inner than the cord bushing by 3 mm or more.
Use a solderless terminal for the end of the AC cable. For the main ground wire, use the solderless
terminal whose core wire and sheath are caulked separately (double caulking).
Connect the ground wire to the following:
M4 screw / round terminal of the main ground wire / tooth lock washer / casing
Note
• Use the cable more than 0.75mm
2
for main ground (earth) line.
• For solderless terminal , doubly caulk the core and the sheath
separately.
The core should be poked from 0.5 to 1.0 mm.
The core should be so as not to
be seen or not to be come apart.
The crimping (vary by tools)
should clearly be in the
normal place.
No space required between
the insulating material and
the wire.
• Use “ ” type of solderless terminal .
Attach the solderless terminals to
the grounding terminals with them
b
etween the tooth lock washer and
screw with washer .
:euqrotgninethgitdednemmocer(
1.8 N·m)
Screw with washer M4
Tooth lock washer
Double caulking
(3) Provide adequate protection of the exclusive cable (6 cores in total), which connects the detector to
converter, using wire protection tube, etc. Separate these cables from the power cable (noise preven-
tion).
(4) Keep the wire for output signals as far as possible (more than 30cm) from the power line and heavy
current lines to prevent induced noise. Also, wherever possible use a shielded cable and earth one
point of the shield.
Note) For connection of the lines to the external terminals, use of ring crimp solderless terminal
with insulation sleeve is recommended.

- 11 -
INZ-TN1ZKM-E
4.2 Wiring to terminals
4.2.1 O2sensor input / Input method of O2sensor thermocou-
ple
_POWER.
0.5A
HEATER.
POWER. ON
OFF
123
TM2
2.5A
1
15
2 3 4 5 6 7 8 9 10 11 12 13 14
16 17 18 19 20 21 22 23 24 25 2826 27
O
2
TC1 AO FAULT
COM SV
ZV HEATER
TC2 DI1 DI2 DI3
DICOM
ALARM MAINTE
BLOW
AC
LN
+
Exclusive cable (Option)
Terminal block
for communication cable
(TM2)
External terminal
(TM1)
L1
Power cable
TM1
10mm or less
3mm or more, 10mm or less
Earth terminal
(Note 2)
Main ground
wire
(Grounding)
(Note 2)
L2
Note 1: Fix the exclusive cable (O2sensor input / O2sensor thermocouple input) with the cable gland so
that its sheath is 10 mm or less.
When attaching the nut, turn it by hand until it does not move and then tighten it with a spanner
by about 1/4 turn.
Note 2: Wire a protective earth to earth terminal of above figure. (Class D, grounding resistance: 100
or less)
4.2.2 Cable gland and input and output lines
Earth terminal (M4)
Mounting plate
For contact
input/output cable
For sensor cable (Coupling) For communication cable
For power supply cable
For output cable
