Z3 Technology ZCube-SC User manual

Users Guide
Model Name: ZCube-SC
DOC-USR-0265-01
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2023 Z3 Technology, LLC. All rights reserved.
Z3 Technology and ZEUS are registered trademarks of Z3 Technology, LLC.
This document contains proprietary information of Z3 Technology, LLC ("Z3"). This document may not be used, reproduced, disclosed, or
disseminated to anyone without the prior written approval of an authorized representative of Z3. Z3 reserves the right to change this product at
any time and without notice. All product names, trademarks, trade names, service marks, or service names mentioned in this document are the
property of their respective owners.

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
2
REVISION HISTORY
Version
Date
Change Note
Author
01
02/14/23
Original Document for ZCube-SC
NC

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
3
TABLE OF CONTENTS
1.0 GENERAL DESCRIPTION.................................................................................................7
2.0 FEATURES ................................................................................................................8
2.1 Supported Resolutions ............................................................................................... 9
3.0 PACKAGE OPTIONS ......................................................................................................9
4.0 OPERATING CONTROLS ............................................................................................... 10
5.0 GETTING STARTED WITH THE ZCube-SC ........................................................................... 12
5.1 Access the User Interface Using ZFinder .........................................................................12
6.0 STREAMING CONTROL ................................................................................................ 14
6.1 Stream UDP...........................................................................................................14
6.2 Stream RTP ...........................................................................................................17
6.3 Stream RTSP ..........................................................................................................19
6.4 Stream RTMP .........................................................................................................22
6.5 Tuning for Latency...................................................................................................31
6.6 Stream Multiple Resolutions........................................................................................33
6.7 Setting NTP ...........................................................................................................33
6.8 Record to USB ........................................................................................................34
6.9 Dual Stream and Record ............................................................................................36
6.10 Microphone Input...................................................................................................37
6.11 Composite Pass-Through ..........................................................................................38
7.0 ONVIF PROFILE S AND T ............................................................................................ 40
8.0 PERFORMING OTHER OPERATIONS WITH THE ZCube-SC ......................................................... 41
8.1 Save Current Settings ...............................................................................................41
8.2 Advanced Settings Mode ............................................................................................42
8.3 Encoder ROI...........................................................................................................44
8.4 Overlay Timestamp ..................................................................................................44
8.5 Upgrade Firmware ...................................................................................................45
8.6 User Management....................................................................................................46
8.7 Factory Reset.........................................................................................................47
8.8 Using Wi-Fi......................................................................... Error! Bookmark not defined.
9.0 DECODE OPTIONS ..................................................................................................... 48
9.1 PC Configuration for HD HEVC/H.265 Decode ...................................................................48
9.2 ZEUS SME-01 Decode ...............................................................................................51
9.3 ZEUS® DMD-4K .......................................................................................................51
10.0 SUMMARY OF OPTIONS .............................................................................................. 52
10.1 The System Setup Tab .............................................................................................52

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
4
10.2 The User Presets Tab...............................................................................................55
10.3 User Tab .............................................................................................................56
10.4 The Status Tab ......................................................................................................56
10.5 The Video Tab.......................................................................................................57
10.6 The Term Tab........................................................................................................58
10.7 The CH1 Tab (Channel 1) ..........................................................................................60
10.8 The CH2 & CH3 Tabs (Channels 2 & 3)...........................................................................68
10.9 Values Appearing at the Bottom of All Tabs ....................................................................69
10.10 ZFinder .............................................................................................................70
APPENDIX A: Finding the IP Address of Your Computer............................................................... 71
APPENDIX B: Configuring the Wowza Server for RTMP .............................................................. 73
APPENDIX C: Example Camera Controller Application .............................................................. 75
APPENDIX D: Support and Troubleshooting............................................................................ 79
Appendix D: Support .....................................................................................................79
Appendix D: Troubleshooting ...........................................................................................79
Appendix D: Warranty ...................................................................................................80

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
5
LIST OF FIGURES
Figure 1 ZCube-SC Board Stack Dimensions .............................................................................. 7
Figure 2 ZCube-SC Package Options ...................................................................................... 9
Figure 3 ZCube-SC Back Interfaces ......................................................................................10
Figure 4 ZCube-SC Front Interfaces ......................................................................................11
Figure 5 ZFinder with the ZCube-SC Selected..........................................................................12
Figure 6 ZCube-SC User Interface – CH1 Tab............................................................................13
Figure 7 CH1 Tab Configuration – UDP ...................................................................................15
Figure 8 VLC Open Network Stream Screen for UDP ..................................................................16
Figure 9 Example of Video Streaming to VLC (UDP) ...................................................................16
Figure 10 CH1 Tab Configuration – RTP ..................................................................................17
Figure 11 Example of Encoded Video Streaming to VLC (RTP) .......................................................18
Figure 12 CH1 Tab Configuration – RTSP.................................................................................19
Figure 13 Finding your Camera’s IP Address ............................................................................20
Figure 14 Force multicast RTP via RTSP..................................................................................21
Figure 15 VLC Open Network Stream Screen for RTP .................................................................21
Figure 16 Example of Z3 Video Streaming to VLC (RTSP) .............................................................22
Figure 17 CH1 Tab Configuration – RTMP Streaming to Wowza Streaming Engine™ ...............................24
Figure 18 Navigating to the Wowza Test Player ........................................................................25
Figure 19 Viewing Streamed Content on Wowza Test Player .........................................................26
Figure 20 YouTube Live Dashboard – Encoder Setup ...................................................................27
Figure 21 CH1 Tab Configuration – RTMP Streaming to YouTube Live ...............................................28
Figure 22 Facebook “Create Post” dialog box...........................................................................29
Figure 23 Facebook Live Streaming Dialog ..............................................................................29
Figure 24 Facebook Live Stream Encoder Settings .....................................................................30
Figure 25 Enable TS Lowlat Mode ........................................................................................31
Figure 26 VLC Media Player Tools Menu ..................................................................................32
Figure 27 VLC Media Player Advanced Preferences.....................................................................32
Figure 28 Recommended Settings ........................................................................................33
Figure 29 Create Additional Output Channels ..........................................................................33
Figure 30 Setting NTP.......................................................................................................34
Figure 31 USB Connection .................................................................................................34
Figure 32 CH1 Tab Configuration – TSFILE ...............................................................................35
Figure 33 Microphone Connection........................................................................................37
Figure 34 CH1 Tab Configuration – Microphone Audio Settings.......................................................38

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
6
Figure 35 Composite Connection .........................................................................................38
Figure 36 Set Composite Pass-Through Resolution.....................................................................39
Figure 37 The User Presets Tab ...........................................................................................41
Figure 38 Entering a User Preset Name .................................................................................41
Figure 39 Saving a User Preset............................................................................................41
Figure 40 Accessing Advanced Settings..................................................................................43
Figure 41 Default RTSP Settings (Left) and Advanced RTSP Settings (Right) .......................................43
Figure 42 Channel 1 Tab with ROI.........................................................................................44
Figure 43 CH1 Tab Overlay Timestamp ...................................................................................45
Figure 44 Updating Device Firmware ....................................................................................45
Figure 45 Software Updater Screen......................................................................................46
Figure 46 User Management ..............................................................................................47
Figure 47 User Table .......................................................................................................47
Figure 48 Pinhole Reset.....................................................................................................48
Figure 49 Display of Network Options ................................................. Error! Bookmark not defined.
Figure 50 Example of encoder showing up on ZFinder application ............... Error! Bookmark not defined.
Figure 51 ZFinder page showing “Available Networks” dropdown ................ Error! Bookmark not defined.
Figure 52 LAV Filters Configuration ......................................................................................49
Figure 53 Disable Hardware Decoding in VLC ..........................................................................50
Figure 54 ZEUS SME-01 H.264 Decoder ..................................................................................51
Figure 55 ZEUS DMD-4K Decoder ..........................................................................................51
Figure 56 Term Tab Configuration.........................................................................................58
Figure 57 Using the Command Prompt to Determine Your PC’s IP Address..........................................71
Figure 58 Locating Your Computer’s IP Address .........................................................................72
Figure 59 Wowza Performance Settings ..................................................................................73
Figure 60 Wowza Security Settings .......................................................................................74
Figure 61 Running the Example Application .............................................................................75

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
7
1.0 GENERAL DESCRIPTION
The ZCube-SC is a compact encoder system. It is a H.265/H.264 and MJPEG video encoder designed for easy
and portable use. It is capable of accepting 3G-SDI or Composite video and producing IP stream over
ethernet. The hardware consists of encoder boards capable of encoding H.265/H.264 video in HD
resolutions. The ZCube-SC features on-board interfaces including gigabit Ethernet, USB 3.1, RS-485, RS-422,
Audio Input and HDMI Out.
Figure 1 ZCube-SC Dimensions
61 mm
65 mm
38 mm

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
8
2.0 FEATURES
•ZCube-SC Features:
oEncode and stream up to 1080p at 60 fps
oEncode modes of operation: HEVC/H.265, H.264 and MJPEG
oLow bandwidth, low latency video encoding
oSimultaneously output two different resolutions from a single video source
oRemote camera control via HTTPS-based interface or pass VISCA camera control
commands over IP
oInputs: Composite in, 3G-SDI, MIC line level audio
oOutputs: RTP, RTSP, RTMP, MPEG-2 TS, TS-File, MP4, TS-RTP, RTMPS
oAdditional Interfaces include Gigabit Ethernet, USB 3.1, RS-485, RS422 and RS-232 Serial
oSupports unicast and multicast streaming
oCompatible with CDN’s including Wowza Streaming Engine™*, YouTube Live* and Facebook
Live*
oRecord a compressed .ts/.mp4 file to a USB storage device
oONVIFprofile S and T compliant
oCompatible with the ZEUSZ3-SME-01 H.264 decoder* and Z3-DMD-4K H.265 decoder (also
available from Z3 Technology)
oHTTP-based configuration software for user-friendly configuration, control and update
oRS-232 serial port for technical configuration and control
oSupports Power over Ethernet (PoE) PoE 802.3af/at class 0 when present
oOperating Temp: -5 to 65 degrees C at 20-80% relative humidity (non-condensing) with
proper thermal solution
oStorage Temp: -10 to 75 degrees C at 20-80% relative humidity (non-condensing)
oMeasurements: 65 x 61 x 38 mm
oWeight: 270g

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
9
2.1 Supported Resolutions
The ZCube-SC supports simultaneous output of up to three streams encoded at different resolutions,
frame rates and bitrates. Supported stream resolutions are:
1080p (2MP), 1280x1024, 720p (1MP), 480p, 576p, 1024x576, 704x576, 640x480, 640x360, 420x380,
352x576, 352x288, 352x240, 320x240, and 320x180
In addition to scaling the resolution, the camera is also capable of scaling down the frame rate to save
bandwidth. Each channel can select from full frame rate, half frame rate, quarter or sixth frame rate.
For example, it is possible to configure a primary stream of 1920x1080 at 60 fps simultaneously with a
secondary stream at 480p at 10 fps.
The maximum performance for two channels is two 1080p60 streams.
3.0 PACKAGE OPTIONS
Figure 2 ZCube-SC Package Options
*NOTE: Contact Sales for more information about available cables and compatible cameras.
ZCube-SC
12V 1 Amp AC Adapter
Serial Cable
Null Modem Adapter
BNC-to-BNC Cable
(CBL-0006-01)

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
10
4.0 OPERATING CONTROLS
1: RS-232 Serial Port 5: Status Light
1
2: USB 3.1 6: Serial I/O (RS-485, RS-422, RS-232)
3: Microphone Input 7: 12V Power or POE
4: Gigabit Ethernet
1
LED light will blink green when streaming.
Figure 3 ZCube-SC Back Interfaces

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
11
1: 3G-SDI In
2: Composite/CVBS In
3: HDMI Out
Figure 4 ZCube-SC Front Interfaces

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
12
5.0 GETTING STARTED WITH THE ZCube-SC
5.1 Access the User Interface Using ZFinder
ZFinder is a PC utility that allows you to find any Z3 Technology product on your network. If you have
not yet downloaded this to your computer, you can find this program at in your User Account at
Z3Technology.com
(1) Verify your PC is set to DHCP. If it is set to a static IP address, ZFinder may be unable to discover
your camera.
Note: The ZCube-SC is set to DHCP by default. If no DHCP server is available on the network, a static IP address of
192.168.0.120 and a netmask of 255.255.0.0 will be assigned. The IP address can be manually entered as
the URL in a browser window to access the user interface.
(2) Run the ZFinder PC utility on your PC. You may need to allow it past any firewalls or security
programs on your PC. The ZFinder window appears and completes a scan of the network. ZFinder
then lists all Z3 systems connected to the network. The ZCube-SC appears.
(3) Click on the ZCube-SC entry in the window to select it. This will cause the Edit Device, Open Device
and Flash LEDs buttons to activate.
Figure 5 ZFinder
Note: Selecting Edit Device allows for manual changes to network settings. See Section 10.10, ZFinder, for more
information.
Note: If the device appears in red, there is a network error, and network settings will need to be modified in
order to access the user interface.
(4) Click on Open Device. An internet browser window is opened in your default web browser (for best
results, Firefox or Chrome are recommended).
(5) The user interface will appear with the CH1 tab open.

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
13
(6) By default, the system will have automatically started encoding. Click on the CH1 tab for channel
one configuration settings. If the encoder status message in the bottom right corner of the screen
shows RUNNING, you will need to click the stop or Stop All button in order to change any settings.
Figure 6 ZCube-SC User Interface – CH1 Tab

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
14
6.0 STREAMING CONTROL
This section gives step-by-step instructions on setting the ZCube-SC to output and stream video using each
of the output format options: UDP, RTP, RTSP and RTMP. In addition to the ZCube-SC, a Windows PC with the
VLC media player
2
downloaded is required. Please see Section 9.0, Decode Options, for more information on
compatible decoders and PC configuration and requirements for H.265/HEVC decode at HD resolutions.
6.1 Stream UDP
6.1.1 UDP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) If necessary, click on the Stop button in the Channel Controls section of the user interface CH1 tab
or the Stop All button in the lower right corner of the screen of any tab.
(2) Verify the Output Resolution is set to Follow Input to output a HD stream. If a lower resolution
output is desired, select this in the dropdown menu and resizing will occur.
(3) Select the Video Codec you would like to use for your video encoding. In the pictured example
H265(HEVC) is selected.
(4) Under Output Setup, select UDP in the Output Format dropdown menu.
(5) Set Dest Address to:
a. the IP address of your PC that will be running the VLC media player. To determine the correct
IP address of your PC, see APPENDIX A: Finding the IP Address of Your Computer. In the
example pictured, 192.168.0.6 is used.
b. or a multicast address. An example multicast address would be 225.1.2.3. If you are on a
shared network, check with your Network Administrator.
(6) Make note of the value listed for Dest Port. This will be 8600 by default when your system is first
received.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.2, “Advanced Settings Mode”, for more information on accessing additional settings.
2
VLC is an open source media player from the VideoLAN organization that can be downloaded for free online.

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
15
(7) Click on the Start button. After a moment, the encoder status will change to RUNNING and the fields
above will appear in dark grey. The status LED on the unit will blink green when streaming.
6.1.2 Run VLC to View UDP Stream
Note: Verify your PC is set up to handle decode of H.265 content at HD resolutions. See Section 9.1, “PC
Configuration for HD HEVC/H.265 Decode”, for more information.
(1) Open the VLC media player on your PC.
(2) Select the Media menu.
(3) Select Open Network Stream.
(4) Under the Network tab, enter “udp://@Dest_Address:Dest_Port” for the network URL.
a. Dest_Address will be values of the IP address or multicast address entered in the Dest
Address field in the user interface CH1 tab. The IP address used in this example is
192.168.0.6.
Figure 7 CH1 Tab Configuration – UDP
(4) Change
to “UDP”
(1) If necessary, click “Stop”
(7) Click “Start”
(2) Verify is
“Follow input”
(3) Verify is
“H265(HEVC)”
(5) Set to PC
IP Address or
Multicast Address
(6) Note value

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
16
b. Dest_Port will match the value found in the Dest Port field in the Encoder tab. The default
value is 8600.
c. In this example, the full network URL would be “udp://@192.168.0.6:8600”.
(5) Press Enter or click Play.You will see your camera’s video streaming to VLC.
Figure 9 Example of Video Streaming to VLC (UDP)
Figure 8 VLC Open Network Stream Screen for UDP

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
17
6.2 Stream RTP
6.2.1 RTP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) Return to the user interface, and if necessary, click on the Stop button in the Channel Controls
section of the user interface CH1 tab or the Stop All button in the lower right corner of the screen of
any tab.
(2) Verify Output Resolution is set to Follow Input to output a HD stream. If a lower resolution output is
desired, select this in the dropdown menu and resizing will occur.
(3) Select the codec you would like to use for your video encoding. In the pictured example,
H265(HEVC) is selected.
(4) Under Output Setup, select RTP in the Output Format dropdown menu.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(5) Click on the Start button. After a moment, the encoder status will change to RUNNING and the fields
above will appear in dark grey. The status LED on the unit will blink green when streaming.
Figure 10 CH1 Tab Configuration – RTP
(4) Change
to “RTP”
(1) If necessary, click “Stop”
(5) Click “Start”
(2) Verify is
“Follow Input”
(3) Note value

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
18
6.2.2 Run VLC to View RTP Stream
An SDP file is needed to view an RTP stream from the ZCube-SC in the VLC media player. If you have not
yet downloaded these files to your computer, you can find them on your Z3 account.
Note: Verify your PC is set up to handle decode of H.265 content at HD resolutions. See Section 9.1, “PC
Configuration for HD HEVC/H.265 Decode”, for more information.
(1) Open the VLC media player on your PC.
(2) Select the Media menu.
(3) Select Open File.
(4) Find and select the SDP file corresponding to the video codec you selected previously.
a. H265(HEVC) video: use the SDP file entitled “z3-h265-he4k-dck.sdp”
b. H264(AVC) video: use the SDP file entitled “z3-h264-he4k-dck.sdp”
(5) Press Enter or click Open. You will see your camera’s video streaming to VLC.
Figure 11 Example of Encoded Video Streaming to VLC (RTP)

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
19
6.3 Stream RTSP
6.3.1 RTSP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) Return to the user interface, and if necessary, click on the Stop button in the Channel Controls
section of the user interface CH1 tab or the Stop All button in the lower right corner of the screen of
any tab.
(2) Verify Output Resolution is set to Follow Input to output a HD stream. If a lower resolution output is
desired, select this in the dropdown menu and resizing will occur.
(3) Select the codec you would like to use for your video encoding. In the pictured example,
H265(HEVC) is selected.
(4) Under Output Setup, select RTSP in the Output Format dropdown menu.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(5) Click on the Start button. After a moment, the encoder status will change to RUNNING and the fields
above will appear in dark grey. The status LED on the unit will blink green when streaming.
Figure 12 CH1 Tab Configuration – RTSP
(4) Change
to “RTSP”
(1) If necessary, click “Stop”
(5) Click “Start”
(3) Note value
(2) Verify is
“Follow Input”

ZCube-SC User Guide
DOC-USR-0265-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
20
6.3.2 Run VLC to View RTSP Stream
Note: Verify your PC is set up to handle decode of H.265 content at HD resolutions. See Section 9.1, “PC
Configuration for HD HEVC/H.265 Decode”, for more information.
(1) Open the VLC media player on your PC.
(2) Select the Media menu.
(3) Select Open Network Stream.
(4) Enter “rtsp:// IP_Address/z3-#.sdp” for the network URL.
a. IP_Address will be the IP address of your ZCube-SC. If your camera is set to DHCP (This is the
default setting when it is first received.), you can find this in ZFinder or the web browser
with your user interface open. If you have set your encoder to a static IP address, this should
match the Local IP Address field in the System Setup tab. In the example pictured, the
encoder was assigned 192.168.0.120 at start up.
b. z3-# corresponds to the number of the channel tab of the user interface. For example, if the
CH1 tab is used, “z3-1” is entered.
Figure 13 Finding your Camera’s IP Address
Current IP Address of
your ZCube-SC
