Fuji Spray TAN9620 User manual

USER
MANUAL
TAN9620 Contour Applicator

1
CONTENTS
Safety Precautions 2
Pars Diagram 3
Spray Patterns 4
Proper Assembly 5
Troubleshooting 6 - 7
Warranty Information 8

2
Please read these instructions carefully before using the equipment.
SAFETY PRECAUTIONS
FIRE AND EXPLOSION HAZARD
• Do not spray lammable or combustible materials near an open
lame or sources of ignition such as cigarettes, motors, and
electrical equipment.
• Keep spray area well-ventilated. Keep a good supply of fresh air
moving through the area. Keep turbine in a well-ventilated area. Do
not spray turbine.
• Never use 1,1,1-trichloroethane, methylene chloride, other
halogenated hydrocarbon solvents or luids containing such solvents
in equipment with aluminum wetted pars. Such use could result in a
serious chemical reaction, with the possibility of explosion. Consult
your luid suppliers to ensure that the luids being used are
compatible with aluminum pars.
TOXIC FLUID OR FUMES HAZARD
Toxic luids or fumes can cause serious injury or death if splashed in
the eyes or on skin, inhaled, or swallowed.
• Always wear appropriate gloves and eye protection.
• Always wear a mask. Read all instructions of the respirator or mask
to ensure that it will provide the necessary protection against the
inhalation of harmful vapors. Please check with the local jurisdiction.
• Tanning Solution and other materials may be harmful if inhaled.
EQUIPMENT MISUSE HAZARD
Misuse of equipment can cause serious injury or death.
• Do not operate or spray near children. Keep children away from
equipment at all times.
• Do not overreach or stand on an unstable suppor. Keep efective
footing and balance at all times.
• Stay aler and watch what you are doing.
• Do not operate the unit when fatigued or under the inluence of
drugs or alcohol.
• Check the hose, hose connectors and power cord daily. Any worn
or damaged pars should be replaced immediately.
• Use only genuine Fuji Spray replacement pars.

3
TAN9620 CONTOUR APPLICATOR
16 17
19
18
ITEM NAME ITEM NAME
1 Collar 11 Fluid Coupler*
2 Air Cap 12 Hose Connector*
3 Air Cap Plate 13 Needle Assembly
4 Air Cap Spring 14 Needle Spring
5 Fluid Nozzle 15 Fluid Control Knob
6 Needle Packing Screw* 16 Cup Assembly
7 Needle Packing* 17 Pressure Tube with Check Valve
8 Trigger* 18 Cup Lid Gasket
9 Gun Body 19 Pick Up Tube
10 90 Degree Nipple*
1234567
8
11
10
12
13 14 15
9
Pars indicated with * are not removable.

4
SPRAY PATTERNS
A B C
A. This pattern is used
when spraying from side
to side.
B. This pattern is used
when spraying up and
down.
C. This pattern is used
for contouring and
touch-ups.
If you turn the fan pattern to a round spray pattern, you will have to
reduce the volume amount of tanning solution by turning the Fluid
Knob #15. If you do not do this, you will get runs. You can use this
much smaller pattern to “touch up” areas such as bikini strap lines or
to enhance cerain areas such as the abdominals and other muscular
features. For best results, hold the Applicator closer to your subject
(as close as 1 inch or less).
Three diferent pattern settings can be chosen on the Applicator
depending on the use.
To set your Applicator to a speciic spray pattern, rotate the Aircap
#2 to the desired position. Always make sure the Collar is snug tight.
Do not over-tighten.
To produce a verical fan pattern, rotate the Aircap #2 in a horizontal
position. To produce a horizontal fan pattern, rotate the Aircap #2 in
a verical position. For a smaller circular pattern, rotate the Aircap
#2 in a 45 degree angle position, then adjust luid output in tandem.
To lush out any debris that may have accumulated during assembly or
shipping, we recommend spraying a small quantity of water through
the Applicator. Before staring any spray tanning, we suggest you
experiment with plain water until you become familiar with all the
controls.

5
AIRCAP HORNS
4 HOLES FACING THE FRONT
SPRING PLATE
MATCHING
POINTS
FRONT END OF
APPLICATOR
PROPER ASSEMBLY
When assembling the applicator aer a thorough clean, be sure to
properly install the components as shown in these instructions, as
failure to do so will result in spray problems.
It is best to position the applicator facing upwards so that the front
end components can easily be put in place.
• Once the Fluid Nozzle #5 and Aircap Spring #4 are in place, locate
the small tab on the edge of the Spring Plate #3.
• Position the Spring Plate so that the 4 holes face outward
• As the Spring Plate rests on the Aircap Spring, the Spring Plate’s tab
must match the groove on the le edge of the front of the Gun Body
• Carefully slot in the Aircap #2, the base of the Aircap must be lush
with Spring Plate.
• Place Collar #1 over the Aircap, but do not thread in yet
• With your index and middle inger, gently press on the Aircap
Horns all the way then thread in the Collar until snug tight. Do not
over-tighten.
Be sure to install the Needle #13, Spring #14 and Fluid Knob #15 aer
the components of the front of the Applicator are in place.
DO NOT SOAK THE WHOLE APPLICATOR IN ANY LIQUID – THIS IS
NEVER NECESSARY OR ADVISABLE.

6
2) Uneven pattern when spraying
• Check and clean Nozzle #5
• Check and clean Air Cap #2. Use a so cleaning brush. Never use
metal objects to clean holes in the Air Cap
4) Excessive overspray
• Reduce luid volume low or adjust fan pattern
• Applicator is being held too far away
• Install an extraction fan
5) Leaking from the Solution Cup Rim
• Ensure that the Cup is tightened fully
• Replace Cup Lid Seal (Gasket) #18 as it may be worn.
6) Fluid at the Air Cap Holes
• The Fluid Nozzle #5 is loose and solution is leaking around it – tighten
the Nozzle using the supplied Wrench
3) Poor Spray Pattern
• Damaged Needle #13 or Fluid Nozzle #5. This will require
replacement
• Check Fluid Nozzle and Air Holes in Air Cap #2. This will require
cleaning
• Applicator too far from surace
TROUBLESHOOTING
1) Solution coming out from nozzle without Trigger engaged
• Check and clean Fluid Nozzle #5. If damaged, it will require
replacement
• Check and clean the Needle #13. If damaged, it will require
replacement

7
7) Applicator Sprays in a pulsating manner
• The Solution Cup is almost empty. Add more solution
• Clean the Fluid Coupler #11 thoroughly
• Inspect Pressure Tube #17 and Cup Gasket 18. Replace if damaged
8) Little to no solution coming out
•FluidKnob#15isturnedintoofar-turnouttoallowmoresolutionlow
• Fluid Coupler is clogged:
a) Remove the Cup Assembly
b) Use a cleaning brush to unclog the inside of the Fluid Coupler with
soapy water
c) Use the brush to also clean the out the solution passage at the
bottom of the Cup

8
Fuji Spray® 12 Month Limited Warranty
Fuji Industrial Spray Equipment Ltd. (“Fuji”) provides a 12 month
limited warranty on the product to the original purchaser efective
from the date of purchase against defects in materials and
workmanship.
The warranty does not cover damage or defects arising as a result of
abuse, misuse, accident, negligence, malfunction, corrosion, normal
wear and tear, inadequate or lack of spray gun or other aspects of
maintenanceof theproduct,damage arising fromimproper assembly,
installation or operation, damage arising from the product being
used with pars that are not genuine Fuji Spray® pars, or damage
arising from the product being used for a purpose other than that for
which it was designed or intended. The warranty is void if repairs to
the product are made or attempted by anyone other than Fuji or its
authorized agent, or if any modiications to the product are made or
attempted.
Purchasers located in Norh America must obtain a Return Material
Authorization number by calling Fuji at 1-800-650-0930 before
returning the product to Fuji or its designated representative.
Purchasers located outside Norh America must contact the vendor
from which they purchased the product. In all instances purchasers
must return the product together with proof of purchase and with
shipping prepaid. For valid warranty claims the product will be
returned to the purchaser with shipping prepaid.
This is the only warranty provided by Fuji with respect to the product
and is in lieu of any other warranties, express or implied, including
but not limited to any warranty of merchantability or itness for a
paricular purpose. Fuji’s sole obligation under this warranty shall,
at its option, be to either repair or replace a product determined
by Fuji to be defective. In no event shall Fuji be liable for loss of
proits, incidental or consequential damages, injury to any person
or propery, or any other damages of whatsoever nature.

FUJI SPRAY® SUNLESS
CONNECT WITH US!
@FUJISPRAYSUNLESS
@FUJISPRAYSUNLESS
@FUJISPRAY
SUPPORT@FUJISPRAY.COM
+1 (800) 650 0930
FUJISPRAY.COM
FUJISPRAYSUNLESS.COM
NEED HELP?
Fuji Industrial Spray Equipment Ltd.
40 Magnetic Drive, #48, Toronto, ON, Canada M3J 2C4
