FujiFilm Vevo 3100 User manual

Quick Start Guide
Vevo 3100 Imaging Platform
TOUCH|CUSTOMIZE|VISUALIZE

PN 51359 Quick Start Guide for the Vevo 3100 Imaging Platform Rev 1.0
Page 2of 8
INTRODUCTION
This quick start tutorial could be very useful:
If you are familiar with how ultrasound systems work and want to give it a
try before the scheduled training;
If you haven't used the system in a while and want a refresher tutorial.
Before you begin
Ensure that you have connected a transducer to the transducer port on the
front of the cart.
If you are imaging an animal, ensure that the animal is properly prepared on
the animal platform and that the physiological data monitoring system is
functional and properly connected to the system.
To acquire and analyze a B-Mode image and export your analysis
1. Press the Main Power switch “ON” located at the back of the system.
Note: Ensure the system is plugged in.
2. Press the Power button to start-up the system.
3. Log in, or tap the Guest button.
4. Choose an application from the transducer panel. The B-Mode imaging window appears and
the system begins acquiring B-Mode data.
5. In the background, the system creates a New Study and Series. You can change the Study
or Series Name, or add information to the Study or Series by going to the Study Browser.
6. Select a Preset from the Mode Presets fly-out and refine your image using the various
mode controls such as the Image Depth, Gain or Dynamic Range.
7. Tap Freeze to stop the data acquisition.
8. Tap Save Clip to save the cineloop in the Series.
9. Slide the Slide to Scan control to resume the data acquisition.
10. Continue image acquisition by pressing Freeze and Save Clip as required.
WARNING: Before using the VEVO 3100 any operator must read and observe the
Safety Warnings and Precautions in the Product Safety section of this document.

PN 51359 Quick Start Guide for the Vevo 3100 Imaging Platform Rev 1.0
Page 3of 8
11. Tap the Current Series navigation button to view all your saved images for the current
series. You can also review these images in the Study Browser.
12. Tap a thumbnail to open the image for review. The B-Mode window appears and plays the
stored clip. You can navigate through the images stored in the series using the
Next/Previous arrow buttons.
13. Pause the clip and navigate to a frame where you would like to place a measurement.
14. Tap the measurement you would like to place from the controls bar. To see more
measurements, tap the More Controls button.
15. The measurement appears on the image. Place the measurement by dragging the calipers.
A completed measurement will automatically save the image.
16. The measurement will also be displayed on the measurement panel on the left side of the
control panel. Use the controls here to edit or delete the measurement.
17. Return to either the Current Series page or the Study Browser. The thumbnail of your image
now shows the measurements you have completed.
18. On either the Current Series page or the Study Browser, tap the More button and then the
Report button to view the Report.
19. From the Study Browser, tap the Export button to:
Export To Vevo LAB the whole study for review and further analysis.
Export to Other File Types to export clips, images, and other files to use outside the
Vevo 3100 Imaging System.
With the study exported for analysis in VevoLab you have access to advanced analysis
applications that are only available in VevoLAB offline software.

PN 51359 Quick Start Guide for the Vevo 3100 Imaging Platform Rev 1.0
Page 4of 8
Product Safety
Note: This product has been tested to the requirements of CAN/CSA-C22.2 No. 61010-1, second
edition, including Amendment 1, or a later version of the same standard incorporating the same
level of testing requirements.
This section contains information required by regulatory agencies, including information about the
ALARA (as low as reasonably achievable) principle, the output display standard, acoustic power and
intensity tables, and other safety information. The information applies to the ultrasound system,
transducer, accessories, and peripherals.
Please read the safety information before using the Vevo 3100 Imaging System. The following
information applies to the Vevo 3100 Imaging System and supporting equipment.
This equipment is intended to be used by qualified research scientists.
Read all warnings and cautionary notes carefully before you use this equipment.
Warnings
Warning: THIS EQUIPMENT IS NOT APPROVED FOR USE ON HUMANS. The Vevo 3100
Imaging System has been designed and tested for use on laboratory research animals.
This equipment must not be used on any living human being.
Warning: Where available, always use the lowest power settings necessary to obtain
diagnostically acceptable images.
High levels of transmitted ultrasound energy can damage tissue. Never tamper with or
alter the Vevo 3100 Imaging System in any way such that the acoustic power level is
increased.
Warning: Use ONLY VisualSonics transducers with the Vevo 3100 Imaging System. The use
of other transducers may affect safety and system performance.
Electric Shock
Warning: Before connecting the Vevo 3100 Imaging System to the mains, verify that the
specified voltage on the rear panel matches the power source voltage.
An incorrect power source voltage could cause an electrical hazard and could cause
serious damage to the equipment.
Warning: Before connecting the Vevo 3100 Imaging System to the mains, always check
that the mains cable is undamaged.

PN 51359 Quick Start Guide for the Vevo 3100 Imaging Platform Rev 1.0
Page 5of 8
Warning: Do not remove any panels from the Vevo 3100 Imaging System. Do not remove
the outer transducer housing.
Service to the system is to be performed by qualified personnel only. No user-
serviceable parts are located inside the system.
Any internal adjustments, replacements or modifications to the Vevo Imaging System
electronics or to the transducers should be made only by qualified VisualSonics
Technical Support Representatives.
Warning: If the system is not properly grounded or earthed, it becomes a possible
electrical shock hazard. Protection against electrical shock has been provided through
an isolation transformer and chassis grounding via a plug to an appropriate power
source.
DO NOT remove the ground wires from any part of the Vevo 3100 Imaging System for
any reason.
Warning: Ensure that all power sources, whether a UPC or a wall outlet, are properly
grounded or earthed.
Warning: Disconnect the system from the power source before cleaning the system or
performing any maintenance operations.
Warning: Connection of equipment not authorized by VisualSonics to the Vevo 3100
Imaging System isolation transformer could result in an electrical hazard.
Warning: Do not immerse the transducer in coupling medium beyond the lowest ring on
the transducer housing.
The housing of the transducer is not watertight. If the transducer is immersed beyond
the lowest ring on the transducer housing, the electrical safety features may be
compromised.
Warning: DO NOT spray or drip any liquid into the system or onto the keyboard, as this
could affect reliable operation and electrical safety.
Warning: Before connecting the system ensure the voltage is correct. Ensure the power
cable is undamaged before plugging the system directly into the wall outlet. Do not
connect the system’s power supply to an MPSO or extension cord.

PN 51359 Quick Start Guide for the Vevo 3100 Imaging Platform Rev 1.0
Page 6of 8
Electromagnetic Interference
Warning: The Vevo 3100 Imaging System should never be used where safety could be
affected by the malfunction of medical devices.
The Vevo 3100 Imaging System is designed for use in preclinical laboratories and is not
cleared for use with or in the vicinity of active medical devices. High levels of
electromagnetic energy may interfere with the operation of the Vevo 3100 Imaging
System. Furthermore, the Vevo 3100 Imaging System could affect the safe operation of
sensitive medical devices.
Caution: To avoid the risk of increased electromagnetic emissions or decreased
immunity, use only accessories and peripherals recommended by VisualSonics.
Connection of accessories and peripherals not recommended by VisualSonics could
cause your ultrasound system to malfunction or cause other medical electrical devices in
the area to malfunction.
Caution: The use of accessories, transducers and cables other than those specified
(with the exception of transducers and cables sold by VisualSonics as replacement parts
for internal components) may result in increased emissions or decreased immunity of
the Vevo 3100 Imaging System.
Chemicals
Warning: If any part of the Vevo 3100 Imaging System is in contact with hazardous
chemicals or biological materials, appropriate precautions must be taken by all who
come into contact with the Vevo 3100 Imaging System until the device is declared
completely free of harmful contamination.
Cart Movement
Warning: The Vevo 3100 Imaging System is both delicate and heavy.
Careless moving and rough handling can damage the system and cause injury to others
(e.g., rolling over feet, colliding with people or walls). Never use the system if there is
damage to the cart, cables or accessories.
Warning: Do not position the cart and its accessories in a way that makes it difficult to
disconnect the plug from the socket.
Magnetic Field Sensitivity
Caution: DO NOT situate the Vevo 3100 Imaging System close to large clinical magnets
as the magnetic fields may affect the performance of the Vevo 3100 Imaging System
and cause distortion in the acquired image.

PN 51359 Quick Start Guide for the Vevo 3100 Imaging Platform Rev 1.0
Page 7of 8
Labeling and Verification
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference; and
This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
Warning: Changes or modifications not expressly approved by VisualSonics could void the
user’s authority to operate the equipment.

PN 51359 Quick Start Guide for the Vevo 3100 Imaging Platform Rev 1.0
Page 8of 8
FUJIFILM VisualSonics, Inc.
T.1.416.484.5000
Toll Free (North America) 1.866.416.4636
Toll Free (Europe) +800.0751.2020
www.visualsonics.com
VisualSonics, Vevo, MicroMarker, RMV, EKV, MicroScan, Insight Through In Vivo Imaging are
trademarks and registered trademarks of FUJIFILM SonoSite, Inc. in various jurisdictions. All
other trademarks are the property of their respective owners.
