Force1 rogue F72 User manual

USER MANUAL
Visit us online at force1rc.com for product information, replacement parts, and ight tutorials.
FOR MORE INFORMATION
Altitude Hold VideoPhotoHeadless
Mode
3 SpeedFlight Path
Mode
FPV Mode One Key
Lift/Land
360
°
360°
Inversion

ATTENTION:
PLEASE WATCH THIS
FLIGHT INSTRUCTION
VIDEO BEFORE
FLYING YOUR DRONE.
https://youtu.be/tk3qzsUwoWs

FORCE1
2
CONTENTS
Welcome & General Safety Precautions·······················3
LI-PO Battery Care ·······················································4
Drone Battery Charging ···············································5
Contents & Transmitter Battery Installation··················6
Drone Overview ··························································· 7
LCD Overview and Phone Clip····································· 8
Throttle Modes Overview·············································9
Drone Assembly ·························································10
Preflight Operations ···················································12
Preflight Checklist·······················································13
Basic Flight Controls···················································14
Trim Adjustments························································15
Functions ····································································16
Force1 F72 App Installation ······································20
App Icons Overview ···················································21
App Controls ······························································24
Aerial Photography & Video······································· 26
Troubleshooting ·························································27
Spare Parts ·································································28

F72 Rogue User Manual
3
WELCOME!
SAFETY PRECAUTIONS
Welcome to the Force 1 Team, and thank you for your Force1 drone purchase. Please read this manual
carefully before drone operation.
(1) This drone is not a toy! It’s a pro-level drone suitable for experienced RC drone users aged 14 years and
older. You accept all liability for operation.
(2) This drone does not require FAA registration or permitting, but FAA rules still apply. Please download
the B4UFLY mobile app for the most up-to-date zoning info, and heed all local government ordinances.
(3) The ying eld must be legally approved by your local government.
Any questions? We’d love to hear from you! Please contact us at [e-mail] any time and we’ll
be happy to help.
*Please use only original Force1 parts and accessories.
*Please keep the packaging and this user manual for future reference.
This drone is suitable for experienced RC drone operators aged 14 years and older. It contains small
parts, and should be kept out of reach of small children.
Please follow these safety procedures:
(1) Flight Zone
This drone does not require FAA registration or permitting, but FAA rules still apply. Please download
the B4UFLY mobile app for the most up-to-date zoning info, and heed all local government
ordinances.
(2) Avoid Moisture
Humidity and water can damage your drone, which in turn may cause accidents.
(3) Fly Safely
Please operate your drone as your skill level allows. User fatigue, impairment and improper operation
can cause accidents.
(4) Avoid Moving Parts & Hot Motors
Do not touch propellers, motors or other moving parts while your drone is on.
(5) Avoid Heat
Keep your drone away from heat and prolonged exposure to direct sunlight to avoid damage.

FORCE1
4
LI-PO BATTERY CARE
Avoid Overheating
Your batteries will sometimes be warm/hot to the touch after use. This is normal, but beware that battery
components will fail if not allowed to cool down between uses. Also, do not leave batteries exposed to
direct sunlight.
Store Properly
Store batteries at room temperature, between 5C°/40°F and 27°C/80°F.
Use Carefully
• Leave time between charging and using the battery
• To extend the lifetime of the battery, always keep about 20% of the power remaining in the drone
battery (rather than completely draining it)
• If the battery is pushed beyond its limits, the battery could get hot and the performance will drop
• When using the battery for a long time, the battery will increase in temperature. If it is sealed, the air
inside will inate rapidly causing further heating
Charging
• DO NOT overcharge the battery; never charge batteries unattended, and stop charging as soon as your
batteries indicate they are charged
• DO NOT attempt to charge batteries that appear damaged in any way (cracking, swelling, discoloration, etc.)
• If you feel a battery isn’t charging properly, try using another charger if possible. If you nd your battery
or charger is defective, please visit force1rc.com for a replacement, or email us at [e-mail]
• To inspect a battery, remove it from the device and examine the battery, battery pins and contacts. If
you notice damage, please visit force1rc.com for a replacement, or email us at [e-mail]
• Check your battery and connections after every crash
• Please use genuine factory parts and replacements from force1rc.com
WARNING:
DO NOT LEAVE BATTERY
CHARGING UNSUPERVISED

F72 Rogue User Manual
5
DRONE BATTERY CHARGING
LI-PO BATTERY DISPOSAL & RECYCLING
Do not put lithium-polymer batteries in household trash. Please contact your
local waste management agency or LI-PO battery recycling center for more info.
1. First, attach your USB cable to the drone battery, then connect it to your preferred charging
source.
2. When the battery is charging, a red indicator light on the USB appears. When the battery is fully
charged, a green indicator light appears. The battery charging time is around 70-85 minutes.
NOTE
Use a 5V 2A AC adapter (not included) for faster charging.

FORCE1
6
PHONE CLIP
BOX CONTENTS
DRONE WITH CAMERA TRANSMITTER PROPELLERS (4)
USB CHARGER
SD CARD READER DRONE TOOLS
7.4v 350mAh
LITHIUM BATTERY (2)
TRANSMITTER BATTERY INSTALLATION
Open the battery cover and insert 4 AA batteries as shown below (not included).
• The transmitter needs 4 AA batteries to work
• Insert batteries in correct polarity (+) and (-)
• Don’t mix old and new batteries
• Don’t mix alkaline, standard (carbon-zinc) and rechargeable (nickel-cadmium) batteries
• Remove rechargeable batteries before charging
• Only charge batteries under adult supervision
• Remove spent batteries from the transmitter
• Regularly inspect the charging cable, cord, plug, enclose and other parts; if you notice damage, please
visit Force1rc.com for a replacement, or email us at [e-mail]
CAUTION:

F72 Rogue User Manual
7
DRONE OVERVIEW
FRONT
PROPELLER B
COUNTERCLOCKWISE
PROPELLER A
CLOCKWISE
PROPELLER A
CLOCKWISE
PROPELLER GUARD
PROPELLER B
COUNTERCLOCKWISE
REAR
LANDING GEAR
[1] MOTOR
[2] CAMERA
[3] FRONT INDICATOR LIGHT
[4] BATTERY COMPARTMENT
[5] REAR INDICATOR LIGHT
[1]
[3]
[4]
[5]
[2]

FORCE1
8
1. Insert the clip vertically, down into the transmitter in front of the antennae (Fig. 1). There will be a
click when the clip is firmly in place.
2. Put the phone into the clip and then release the clamp; the clamp should hold your phone
tightly.
3. Use the right silver knob to modify the angle of the phone clip (Fig. 2).
PHONE CLIP ATTACHMENT & USE
FIGURE 1 FIGURE 2
DIRECTIONAL TRIMMINGROTATIONAL TRIMMING
LCD SCREEN
ALTITUDE
HOLD
DIRECTION
DISPLAY ICON
THROTTLE
DISPLAY ICON
MODE 2 DISPLAY
FORWARD/
BACKWARD TRIM
(MODE 1)
4 AXIS FLIGHT ICON
HEADLESS MODE ICON
HIGH/MED/LOW
SPEED ICONS
MODE 1 DISPLAY
TRANSMITTER
BATTERY LEVEL
FORWARD/
BACKWARD TRIM
(MODE 2)
THROTTLE
DISPLAY ICON

F72 Rogue User Manual
9
ONE-KEY
TAKE OFF
Mode 2 (Default)
Mode 1
ROTATE
LEFT/RIGHT
ROTATIONAL
TRIM
RECORD BUTTON
ONE-KEY
TAKE OFF
SPEED MODE
360°FLIP
ONE-KEY
LANDING
ONE-KEY
LANDING
THROTTLE
CAMERA BUTTON
FORWARD
THROTTLE
BACKWARD
LEFT/RIGHT
TRIM
ROTATIONAL
TRIM
FORWARD/
BACKWARD TRIM
HEADLESS
MODE
HEADLESS
MODE
LEFTWARD/
RIGHTWARD
ROTATE
LEFT/RIGHT
360°FLIP
SPEED
BUTTON
POWER
BUTTON
POWER
BUTTON
FORWARD
BACKWARD
LEFT/RIGHT
TRIM
FORWARD/
BACKWARD TRIM
LEFTWARD/
RIGHTWARD
THROTTLE MODES
CAMERA BUTTON
RECORD BUTTON

FORCE1
10
BATTERY REMOVAL
Make sure the drone power switch is in the “OFF” position. Open the battery cover using a
screwdriver and disconnect the wire of the battery from the receiver wire.
DRONE ASSEMBLY
PROPELLER GUARD INSTALLATION
Attach the propeller guard as shown in figure 5. Make sure that all three prongs are snapped into place.
Install a screw to the center prong to secure the guard completely.
BATTERY INSTALLATION
1. Open the battery cover using a screwdriver and insert the battery into the power port (Fig. 3).
2. Connect the wire of the 7.4v 350mAh lithium battery to the receiver wire in the power port (Fig. 4).
3. Replace the battery cover, and move the power switch to the “ON” position.
FIGURE 5
Install the battery rmly; failure to do so may affect ight safety.
CAUTION:
FIGURE 3
FIGURE 4

F72 Rogue User Manual
11
DRONE ASSEMBLY
FRONT
REAR
A B
AB
FIGURE 8
NOTE
• Be sure to install the correct propellers matching A and B (Fig. 8)
• Be careful with the propellers, as they can be sharp
• Purchase extra propellers at Force1rc.com
• To remove propeller, use a screwdriver to remove the propeller screw (Fig. 6)
• The replacement propeller should have the same rotational direction; reinsert the screw and
tighten (Fig. 7)
FIGURE 6 FIGURE 7

FORCE1
12
Mode 1: Right-Hand Throttle
Push the ne-tuning button and the power button simultaneously. The LCD transmitter indicator will
ash slowly. Move the accelerator (right stick) up, and then down. The indicator will ash and indicate
Mode 1. This means that frequency connection AND pairing are complete, and the drone can y
normally in Mode 1.
PREFLIGHT OPERATIONS
THROTTLE MODE SELECTION & PAIRING
Mode 2: Left-Hand Throttle (Default)
Insert batteries and push the power button. Move the accelerator (left stick by default) up, and then
down (Fig. 9). The LCD transmitter indicator should come on, and show as Mode 2. This means that
frequency connection AND pairing are complete, and the drone can y normally in Mode 2.
NOTE
Be sure to select throttle mode and pair your drone while standing within 5 meters of it to
avoid interference.
FIGURE 9
FIGURE 10

F72 Rogue User Manual
13
LOCK/UNLOCK YOUR DRONE
UNLOCK
Place the drone on a flat surface. Move the left and right sticks down and inward simultaneously (Fig.
12). Drone propellers will rotate, indicating it is unlocked and ready to fly.
LOCK
Move the left and right sticks down and outward simultaneously (Fig. 13). Propellers will stop rotating,
and the drone is now locked.
FIGURE 13FIGURE 12
PREFLIGHT CHECKLIST
1. Fly in an open area and abide by all local and federal guidelines. Check the FAA’s B4UFLY mobile app
for up-to-date drone flight info.
2. Make sure your drone and transmitter batteries are fully charged.
3. Put the left stick of the transmitter in the middle position.
4. Follow the Mode Selection and Calibration instructions closely. Always turn ON your transmitter first
before flying, and turn OFF the drone first when you’re finished.
5. Make sure the connection is solid between your battery and motor; vibration may cause loosening.
6. Make sure the propellers are installed correctly and the motors are working normally after unlocking.
NOTE
After the drone is unlocked, it can operate normally. Otherwise, it can’t be operated.
FIGURE 11
CALIBRATION
Move both sticks down and to the left (Fig. 11) and drone fuselage
lights will ash, and then stay on. This means calibration is nished
and the drone is ready to y.
PREFLIGHT OPERATIONS

FORCE1
14
BASIC FLIGHT CONTROLS
HOVER UP AND DOWN
Push the THROTTLE/RUDDER STICK up to y
the drone up, and pull the THROTTLE/RUDDER
STICK down to y the drone down.
FLY FORWARD OR BACKWARD
Push the DIRECTION CONTROL STICK up to
y the drone forward, and pull the DIRECTION
CONTROL STICK down to y the drone
backward.
FLY LEFT OR RIGHT
Move the DIRECTION CONTROL STICK to
the left to y the drone to the left, and move
the DIRECTION CONTROL STICK to the
right to y the drone to the right.
ROTATE LEFT OR RIGHT
Move the THROTTLE/RUDDER STICK to the
left to rotate the drone to the left, and move
the THROTTLE/RUDDER STICK to the right to
rotate the drone to the right.

F72 Rogue User Manual
15
TRIM ADJUSTMENTS
FORWARD/BACKWARD TRIM
Adjust the FORWARD/BACKWARD TRIMMER
backwards if the drone drifts forward when
taking off, and adjust the FORWARD/
BACKWARD TRIMMER forwards if drone
drifts backwards. In Mode 1, the FORWARD/
BACKWARD TRIMMER is on the left side.
LEFT/RIGHT TRIM
Adjust the LEFT/RIGHT FLYING TRIMMER to
the right if the drone drifts to the left when
taking off, and adjust the LEFT/RIGHT FLYING
TRIMMER to the left if drone drifts to the right.
LEFT OR RIGHT ROTATION TRIM
Adjust the LEFT/RIGHT RUDDER TRIMMER to
the right if the drone rotates to the left when
taking off, and adjust the LEFT/RIGHT RUDDER
TRIMMER to the left if drone rotates to the
right.

FORCE1
16
Press the top-right corner button (back) to enter Headless Mode
before takeoff (Fig. 16). Your transmitter will beep every two seconds,
the drone lights will flash 3 times to indicate mode selection and
the LCD Headless Mode indicator will appear. You can now fly your
drone without knowing its orientation, because it will be fixed in the
direction you set it. Press button again to exit mode.
FUNCTIONS
ONE-KEY TAKEOFF
ONE-KEY LANDING
HEADLESS MODE
Place the drone on a at surface. Move the left and right sticks
down and inward simultaneously to unlock – propellers should
start rotating. Press the top-left corner button (Fig. 14) – the drone
should lift off and hover at about 1.5 meters.
Press the top-left corner button (back) while the drone is aloft to
land it (Fig. 15).
Setting Headless Mode Drone Direction
You must verify your drone’s flight direction before entering Headless Mode:
• Be sure your drone is facing away from you (Fig. 17)
• Move the left and right sticks down and to the left for about 2 seconds (Fig. 18)
• Drone lights will flash quickly for and then stay on, indicating direction is verified
FIGURE 14
FIGURE 15
FIGURE 16
FRONT
REAR
RIGHTLEFT
FRONT
REAR
RIGHTLEFT
✔✖
FIGURE 17

F72 Rogue User Manual
17
HEADLESS MODE (CONT.)
FIGURE 18
TIP: Do not change the transmitter orientation after
entering Headless Mode. Otherwise, you will lose track
of the set orientation (i.e., that you and your transmitter
are facing “forward.”)
NOTE
You may calibrate your drone while in Headless Mode to
ensure normal flight control if you notice any variation.
FUNCTIONS
MEMORY CARD INSTALLATION
Insert an SD card (not included) into the SD slot
on the underside of the drone, at the back of
the camera casing (Fig. 19). To remove, press in
slightly to release.
You can adjust the angle of this drone’s camera between 0° and 35° (Fig. 20).
FIGURE 19
FIGURE 20
CAMERA ANGLE ADJUSTMENT
SD CARD SLOT

FORCE1
18
FUNCTIONS
NOTE
This will cause the drone to fall from the sky; use only in case of emergency.
LOW BATTERY WARNING
LOW/MEDIUM/HIGH SPEED MODES
Your drone’s lights will flash and the transmitter will beep in midflight when the battery is low. This means
you have 30 seconds to land your drone before you lose power.
The Rogue has three speed modes: low (30%), medium (default 60%) and high (100%). To switch
speeds, press straight down on the accelerator stick as if it were a button. See Figure 22 for Mode 1
and Mode 2 operation.
EMERGENCY STOP
Press the one-key takeoff (top-left corner) and the top right corner buttons (Fig. 21) simultaneously to
initiate an emergency stop – this will cut power and stop the propellers immediately.
Mode 2 (Default) Mode 1
FIGURE 21
FIGURE 22
