Thank youfor yourpurchase ofThe Fujimoto CP-31 Imageprocessor.
Beforeattempting to operate this equipment,pleaseread allofthe information
contained in thismanualcarefully.This will help the equipmentdemonstrate its
performance and ensure its long-termservice.
Since the CP-31useschemicalsolutions,dailymaintenance is essential for proper
operation.
"Cautionneverturn onthe unitwithout full solutiontrays"
Turning the unit on when dry will causeseriousdamage.
Contents
CP-31FEATURES
CP-31 SPECIFICATIONS
PARTS DESCRIPTION
INSTALLATION
THE CONTROLPANEL
THE CONTROL BOX
INITIALSET-UP AND OPERATION
PREOPERATION CHECK AND CLEANING OF BATH
SETTING THE SOLUTIONTEMPERATURE
SETTING THE TRANSPORTSPEED
TEST RUN
I of 2
15/06/2007 12:28 PM

:P31MANUAL CONTENTS
http://www.fiijimoto-photo.co.jp/fpi_e/31e_manu/contents.htm
FILLING THE MACHINE
DEVELOPING
DRAINING
CLEANING
2 of 2
15/06/2007 12:28 PM

:P3 1MANUAL_FETURES & SPEC
http://www.fujimoto-photo.co jp/fpi_e/3 lejnianu/futures.htm
$ The CP-31 isa 3-bath, 3-heaterprocessor.Eachbathcontains a heater and agitator,
automatic processing of positive/positivecolor Cibachrome P-30),
negative/positivecolor(EP2 and similar) and conventionalB&W.
^ Developing canbe performed in ordinaryroom light by simply closing the shield
cover.
^ Paper sizesfrom 12x 16 inch to83x 108mm canbe processed.
^ Automatictemperaturecontrol and variabletransportspeedinsuresextremely
repeatable results.
^ Requires only 2 liters of processing solution.
® Solutiontemperature and papertransportspeed are fully adjustablematchingeach
type of paperused.
^ The ventilation fan,standby function, and magneticagitationpumpsprevent
problemscommon to other roller transportprocessors.
^ Paper sensordetectspaperfeed.
^ Small profile allows easy convenientplacementbeside an enlarger.
CP-31SPECIFICATIONS
Transport System
Transport Speed
ProcessingTime
Processing Baths
Capacity
Temperature
Control
Opposed roller transport system, processing Size - RC type
paper 305x 406mm (12x 16inch) 483x 108mm. (31/2x41/2
inch)
42~420mm per minute. Digital display of transportspeed.
30 seconds,45 minutes per bath(eachbath isthe same).
Temperature controlled with overflowdevice on each bath.
Each bathcontains 2 liters.
Fjrst Bath Djgjta| micro-computer controlled. Setting range
upto50degC. Accuracy+0.1 degC. Digital
display ofset temperature and actual
temperature.Up-down key allowssetting in0.1
deg C units.
Second Dial set analogtemperature control. Setting
and Third range upto50degC. Accuracy+0.2 degC.Can
Bath beset independently for each bath.
1of2
15/06/200712:28 PM

CP31MANUAL FETURES & SPEC
http://www.fujimoto-photo.co.jp/fpi_e/31e_manu/futures.htm
Agitation
Paper Sensor
Standby
Ventilation Fan
Chemical Drain
Power Source
General Dimension
Dry weight
Accessories
Options
"All three baths provided with an overheating shut down
circuit.
Each bath is agitated bya magneticpump.
IR sensor in first bathdetectspaperfeed.
Feed rollers and agitation will automatically stop when the
processor isnot used for morethan 45 minutes, thenruns
intermittently for3 seconds atan interval of15 seconds. The
standby function will release and return to normaloperation
whenpaper is inserted.
Equipped with a ventilation fanfor discharging humidity.
Drainedindependentlyfromeachbath bya drainpipe.
230/115 volt 50/60 cycles
23.50 x 24.00 x 9.75inches
1600 x 610X 250mm(Depth X Width X Height)
29kg/64 pounds
One 5A Fuse, 2 Funnels
Auto replenishment and wash/drymodule.
2 of 2
15/06/2007 12:28 PM

CP31MANUAL PARTSDISCRIPTION
http://www.fiijimoto-photo.co.jp/^pi_e/31e_manu/descript.htm
PARTS DESCRIPTION
lofl
15/06/200712:28 PM

CP31MANUAL INSTALLATION & CONTROL
http://www.fiijimoto-photo.co.jp/J^pi_e/31e_manu/install.htm
INSTALLATION
Install the CP-31 ona table or desktop.Allow adequate height for gravity drains to operate
properly.Avoid placing itonthe floor.
Level the CP-31 on yourworksurface.
Do not move the CP-31once itis filled with solution.Place the CP-31 ontheright side of
the enlarger to facilitate opening ofthe cover shield.
Set 1/2 gallon containers onthe floor andputthe respective overflow hoseeachintoeach
containers.
THE CONTROLPANEL
1 Temperaturedisplay ofthe No.1
bathsolution.Indicates the actual
temperature andset temperature of
the solution.
2Set button for temperature ofthe
No.1 bathsolution.Used tosetthe
temperature ofthe No.1bath. The
set temperature will rise with UP
and temperature will dropwith
DOWN,
3Set buttonThis is used for setting
the upper and lower limit ofthe
temperature ofthe No.1bath
solution.
4 Papersensorlamp A lampwhich
shows the condition of paperfeed.
The lamp will light whenpaper
passes through the inletrack.
5 WarninglampThislamp will light iftheset temperature ofthe No.1bathsolutionexceeds
the upper limit and gives outa warning thattemperature istoo high. Turnpower switch OFF
ifthe lamplights,remove the uppercover and wait until the temperaturedrops. A
nickel-cadmiumbattery is used to power theLCD display. The memory will notbe losteven
if power is switched off.(Pleaserefer tothe paragraph onthe solutiontemperature setting.)
LCD
The memory will notfee lost ever* $ power &
, fFfease- r®fe? to the peraqrapft on $h& solution
setting,:*
THE CONTROL BOX
Iof2
15/06/2007 12:29 PM

CP31MANUAL INSTALLATION & CONTROL
http://www.fujimoto-photo.co.jp/ipi_e/31e_inanu/install.htm
1 Dial for setting temperature of
solutionThis isfor setting the
temperature ofthe No.2 andNo.3
baths.
2 Solutiontemperaturepilotlamp The
lamp will light whenheater is
actuated and goes off when the
heater is off.
3 Dial for settingtransportspeed.
This dial isfor setting the transport
speed (processingtime) of paper.
4 Transportspeeddisplay.Displays
the transportspeed of paper in units
of mm/min. Refer to table on page
18 for the relationshipbetween
transportspeed and processing
time.
2 of 2
15/06/2007 12:29 PM

CP31MANUALJNITIAL SET-UP AND OPERATION http://www.fiijimoto-photo.co.jp/fpi_e/3 le_manu/ini_set.htm
INITIAL SET-UP AND OPERATION
Preparationwork
Operation check
and
cleaning of bath?
*
Pour in water for
leveladjustment. &
Cleaningbath **'
Powerswitch ON.
4? Checkoperation of drive moter and agitation.
PowerswitchOFF.
water Settingtenperature
of solution. ^
Powerswitch ON.
Set temperature of solution.
Setting of
transport speed. ^
Test run. &
Insertpaper and check deveroping operation with
4Jr water.
Power switch OFF.
Drain water. &
Pour in processingsolution.
*
Carefully mix eachsolution.
Processing Powerswitch ON.
solution. 5 minutestandby.
Stabilization of solution
temperature.
Preparationcompleted.
Iof2 15/06/200712:29 PM

CP31MANUAL_INITIAL SET-UP AND OPERATIONhttp://www.fujimoto-photo.co.jp/foi_e/3 le_manu/ini_set.htm
^Developing Operation
Opencover shield in darkroom.
Check lighting of sensor lamp.
room-
Close covershield. &"
I Automaticdeveloping in
Daylight.daylight.
Sensor lampgoes off.
I
Opencovershield in dark room, f
Dark
room.
t | Continuousdeveloping.
W * »*
Sensorlampgoes on.
I
I
Closecovershield.
4
Daylight.
Washing and drying.
Cleaning,
Draining of solution. ^
*Powerswitch
OFF.
:
Drain solution.
Cleaning. *
Pour water in.
Power switch ON.
Cleanbath by agitation.
Power switchOFF.
Power switchOFF.
Drain water. &
2of2 15/06/200712:29 PM

CP31MANUAL PREOPERATION CHECK AND CLEANING O...
http://www.fujimoto-photo.co.jp/^)i_e/31e_manii/check.htm
PREOPERATION CHECK AND CLEANING OF BATH
Before operation,check the unit's
operation by using hot water.This
work includes the cleaning ofthe
bath.
1
Unpacking:
Take outthe mainbody and
accessories from the case, install
as described in page 4 and check
to seeifall parts are complete.
•
2
(Fig.1,2,3)
Remove partsfrommainbody.
Remove the parts inthe order of
the uppercover,inletrack, No. 1,2
cross-over guide andtheNo. 1,2,3
racks. Remove the cross-over
guide by pulling upthe leftside as
shown bythe arrowmark in Fig. 2.
3
(Fig-4)
Put hot water inand performlevel
adjustment. Puthot water in which
is 1C deg- 2 C deg higherthan the
processing temperature uptothe
levelline of eachbath and adjust
the mainbody with the level
adjustingscrewuntil itis level. Do
not usehot water of morethan 50
Cdeg.
(Fig. 5)
Put the overflowhoseinto the
container. Place the 1/2gallon
containers onthe floorwith the
overflowhose ofthe mainbody in
it. (This isto receivesolution in
l of 2
15/06/200712:29 PM

CP31MANUAL PREOPERATION CHECK AND CLEANING O... http://www.fiijimoto-photo.co.jp/j|)i_e/31e_manu/check.htm
case it overflows). The gear box
drain isfor drainingwater which
has entered the gear box during
cleaning.
Actuate the mainbody.
Connect powercord tothe power
source, turnpowerswitch ONand
check ifthe drivemotor and
agitationpump are operating
properly. "Donot heatwithout
solution!". Neverturn the power
switch ON without water or solution
in eachbath. The unit is working
properly ifthe driveshaftstarts to
turnslowly and waterspoutsfrom
the agitation nozzle.
® StandbyMechanism.
The drivemotor andthe
agitationpump will operate
continuously for about 45
minutesafter turning power
switch ONand thenoperate
intermittently for3 seconds at
an interval of15 seconds.(This
will stop automatically and
return to continuousoperation
when developing). To cancel
standby, turn powerswitch
OFF and then ON again.
Next, setthe temperature forthe
solution.Proceed tothe page
below for settingsolution
temperature with hot water
contained inthe bath.
Put 4 Besses into one
2 of 2
15/06/2007 12:29 PM

CP31MANUAL SETTING THE SOLUTION TEMPERATURE
http://wvvw.iujimoto-photo.co.jp/fpi_e/31e_manu/set_temp.htm
SETTING THE SOLUTIONTEMPERATURE
CAUTIONS:
BEFORE SETTING THE TEMPERATURE, BE SURE TO POWER ONTHE UNITFOR10
MINUTES FOR BATTERY CHARGING. THE UNITSHOULD BE FILLEDWITH HOT WATER
WHEN THE POWER ISON.
CP-31 Digital TemperatureRead Out Error:
You may have the problemthat the digital temperaturedisplaymalfunctions.This isduetothe
discharging of Nicd batterylocated atthe temperaturePCB.Thisbattery is automatically
chargingwhile the unit isinuse (powerswitch ison) however ifthe unit is longunattended, the
battery is discharged.
To restorethissituation,switch onthe unit for about 10 minutes to make the batterystart to
charge and follow the steps onhowto reset.
WARNING: Be sure to pourwater to eachbathbeforeswitching onthe unit.
How to ResetTemperature:
1 .Switch onthe unit for about 1Q
minutes.
2.Pull outthe frontdrawer and push
the resetbuttonwith a finestick Isee
figurel. Now resetting is completed
and actualtemperaturedisplays on
the panel.
3.Push inthe frontdrawer.
4.Do the temperaturesettingagain
from the first stage as instructed in
the manual.
5.Make sure the small letters onthe bottom ofthe displaypanelare:
THERMOMETER TEMP. CONTROLLER,!} POINT
Ifyou find the letteM_at H location, you have to "Reset" again and repeat the sametemperature
setting from the firststage as instructed inthe manual.
Iof5
15/06/2007 12:29 PM

CP31MANUAL SETTING THE SOLUTION TEMPERATURE http://www.fiijinioto-photo.co.jp/i]pi_e/31e_manii/set_temp.htm
Use hot waterinstead of processing solution when setting the temperature of solution.
Temperaturesetting is performed bythe controlpanel forthe firstbath andthe control boxfor
the second and thirdbath.
Oncetemperature is set, itisnot necessary to makefurthersettings.
1
ContinuedfromSection 6 ofthe
pageabove. The upper cover, inlet
rack, No.1 and2 cross-overguide
and theNo. 1,2,3 racks are already
removed andhot water isinthe
bath. The power switch is turned
ON.
(Fig. 1) Setting the temperature of
the No.1 bathsolution.
(A) Continuously press theset
button for morethan 2 seconds, the
set temperature will be displayed
with a maximumvalue of 50cC
indicatingHIGH SET (warning
Temperature) ontheLCD display.
Next, press V (DOWN) ofthe
solution temperature set button and
set the upper limit value oftheset
temperature. The value will change
0.1 QC everytime theset button is
pressed and continuouspressing will
keep changing the value.
rnwk ot
when
actual temperafefe exceeds the
set temperature and «.
tempwi
TNs w^t
aetes temperature reaches the
sc*t s
This vs$l display in afecR
go on.
Clipper and lower limit ofset temperature.With the processingtemperature ofthe
solution asthe lowerlimit(example - 30C cleg.), setthe upper limit 1C deg.higher
(example - 31C deg.)than the lower limit.
(B) Next,press theset buttononcemorewhich will setthe indicatedtemperature asthe upper
limit oftheset temperature andtheLCDatthe same time will display -20C deg. asLOW
SET. (Solutiontemperaturerecommended by chemistrymanufacturer)
(C)In thiscondition and with A (up) ofthe temperature set button, setthe lower limit value.
(D) When theset button is pressedagain, the temperaturewhich was displayed will beset
(memorized) asthe lower limit and will display ontheLCDas shown bythe arrowmark inthe
drawing at right. To change theset temperature,repeat the procedures of(A)~ (D).
2 of 5
15/06/2007 12:29 PM

CP31MANUALJSETTING THE SOLUTION TEMPERATURE
http://w\vw.fijjimoto-photo.co.jp/^)i_e/31e_manu/set_temp.htm
Setting the temperature ofthe No.2,3bathsolution. The temperature oftheNo.2 and3 bath
solution are shippedwith the temperature setat about33oC,With the exception of high
temperature processing,most ofthe bleaching and fixing canbe used in thiscondition.Minute
adjustment ofthe solutiontemperature canbe performed by turning the temperaturesetting
dial ina clockwise direction to raise the temperature and counterclockwise to lower the
temperature.Followprocedures as describedbelowwhenfirstsetting thenew temperature of
the solutionotherthanfactory setone
3 of 5 15/06/2007 12:29 PM

CP31MANUAL_SETTING THE SOLUTION TEMPERATURE
http://www.fujimoto-photo.co.jp/Ipi_e/3 le_rQanu7set_temp.htm
(A) Pull outthe control boxand with
a screw-driver,turn the temperature
setting dial ofthe No.2 and3 bath in
a counter-clockwise direction until it
stops. (Fig.2)
(B) Check the temperature ofthe
No.2 and3 bath with a thermometer.
The solutiontemperaturepilotlamp
isoffat thistime.
(C)The temperature ofhot water
which wasputinthe bath as
described in Section 1of page 8has
dropped slightly. Ifthe temperature
is lowerthan the temperature ofthe
thermometerwhich istobe set,then
turn the temperature setting dial of
that, bath fully ina clockwise
direction. The solution temperature
pilotlamp will light.Wait until the
solutionreaches theset
temperature.(Fig.3)
(D) When the temperature ofthe
solution reaches theset
temperature,turn the temperature
settingdial of thatbathslowlyback
ina counter-clockwisedirection and
stop where the solutiontemperature
pilotlampgoesoff.(Fig.4)
"Check temperature for5
minutes!"
After the temperature ofthe solution
is set,continue to checktemperature
for about 5 minutes tosee whether
the solution has stabilized.Setting is
completed ifthe pilotlamp
repeatedlyblinkswithin the range of
+/-0.2 C deg. oftheset temperature.
"Caution! Temperatureexceeding 50
C deg. is strictly prohibited!".
Avoid setting of temperature to
exceed 50C deg.
tssfb tsmoemtum setting dial
4 of 5
15/06/200712:29 PM

CP31MANUAL_SETTING THE SOLUTIONTEMPERATURE
http://www.fujimoto-photo.co.jp/^pi_e/31e_manu/set_temp.htm
Turn power switch OFF.
Next, setthe transport speed.
5 of 5
15/06/2007 12:29 PM

CP31MANUAL SETTING THE TRANSPORT SPEED http://www.fujimoto-photo.co.jp/^pi_e/31e_mamj/set_spd.htm
SETTING THE TRANSPORTSPEED
Set transportspeed ofthe paper.
Turn powerswitch ON aftermaking
sure water isin eachbath.
(Fig.1) Setthe speed with the
transportspeed dial. Pull outthe
controlbox,turn the transportspeed
dial and display the speed.
The speed is displayed in mm/min.
Though the speed is displayed in
mm/min,refer to table in page 18 for
the relationbetweentransportspeed
and processingtime.Eachbath has
the sameprocessingtime.
o* ths speed dispsiy may ehsnp« after
, hut: this usffetiOft w$ not affect
4
After setting the speed, turn power
switch OFF.
lof 1
15/06/200712:30 PM

CP31MANUAL TEST RUN
http://www.fujimoto-photo.co.jp/ii)i_e/31e_manu/testnui.htm
TEST RUN (Mounting of each rack, cross-overguide and uppercover)
Operations which are described in PREOPERATIONCHECK AND CLEANING OF BATH to SETTING THE
TRANSPORT SPEED completes the settings, but beforepouring inthe processingsolution, pre-check
developingoperationwithwater.
•
A
(Fig.1,2,3)
Mount each part tothe mainbody. After makingsure
that water isinthe bath, mount theNo. 1,2,3 racks,
No.1,2 cross-over guides and then the inlet rack tothe
main body. Plug inthe connector ofthe inlet rack tothe
connector ofthe mainbody.Water will overflow slightly
when the rack is mounted.Turnpowerswitch ON.
Iof3
15/06/2007 12:30 PM

CP31MANUAL TEST RUN
http://www.fujimoto-photo.cojp/^pi_e/31e_manu/testrun.htm
2
(Fig.4)
Check the feeding of paper. Insert theRC paperwith
the emulsionsurfacefacing up. Position the paper
along the guide ofthe inlet rack into the center ofthe
roller. The paper will advanceslowlyinto the bath and
thencome out from the outlet ofthe mainbody.
Runningpaperclean up sheetsthrough the machine
cleans the transportrollers.Clean up sheetsshould be
run beforeeach developing session.
3
(Fig.5,6)
Mounting of uppercover.Mount the uppercover tothe
mainbody by matching the holes (2 holes) atthe left
side ofthe uppercover tothe positioningpins (2 pcs) at
the leftside ofthe main body.Open the cover shield
and insert the paperwith thefilm surfacefacing up
from the paper guide and makesure the papersensor
lamp lights onthe controlpanel. The paper will come
out slowlyfrom the paperoutlet ofthe mainbody.
"Notice!" The actualdevelopingwork is performed ina
darkroom.Thissectiondescribes a test runin ordinary
room light forthe purpose of checking machine
operation.
4
(Fig.7)
Drainwater. After checking the above,turnpower
switchOFF,remove thecap from the drainhose and
drain waterfromeach bath. The number onthe drain
hose shows the number of eachbath. "Caution!"
Alwaysturnpowerswitch OFF when draining water.
Drainingwaterwith the powerswitch ON will not only
overheat the heater, butcan causeseizure ofthe
agitationpumpbearings.
2 of 3
15/06/200712:30 PM

CP31MANUAL TEST RUN
http://www.fhjimoto-photo.co.jp/^)i_e/31e_manu/testrun.htm
3 of 3
15/06/2007 12:30 PM
