AMILO Notebook Pi 3540
The perfect all-round
notebook Pages 5
The AMILO Notebook P series combines versatile performance, great technology and a fascinating design.
Processor technology
Latest Intel® Centrino® 2 processor technology (optional) and Intel® Core™ 2 Duo
processor for high-definition digital entertainment experience, blistering performance,
longer-lasting battery life and the new wireless standard for connectivity
Operating System
Windows Vista® Home Premium
Reliability
Spill-proof keyboard to protect your notebook form accidentally spilt liquids
- Enough time to shut down the notebook
- Have the liquid removed from the notebook
- Protects your investment and your data
Engineered in Germany means the test center in Germany tests conformity to
international standards and customer-specific requirements
A+ grade LCD panels for better picture quality
Mobility
Standard 15.4-inch form-factor that fits in almost every bag
Integrated draft-n Wireless LAN to go online when and wherever you want
Entertainment and multimedia
The integrated AMILOcam with low-light technology for great video-quality even in
low-light conditions and the built-in digital array microphone are perfect for Internet
telephoning (VoIP) and video chats
LCD WXGA display with BrilliantView technology for vivid colors, amazing sharpness
and impressive contrast
Enjoy your favorite Hollywood blockbuster on an external display via HDMI (with
HDCP support)
Great graphics performance with the NVIDIA® GeForce® 9300M GS graphic card
with 256 MB dedicated video memory
More convenience thanks to
The silent mode function that causes a noticable reduction in fan noise
The built-in DVD drive to store and secure data comfortably on the move
Model: Reveal white
Model: Eclipse black

Data Sheet ⏐Issue: November 2008⏐AMILO Notebook Pi 3540 Page 2 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Operating systemand Recovery
Operating system Genuine Windows Vista® Home Premium (32-bit version)
Fujitsu Siemens Computers Recovery Program Backup and restore the original status of the hard disk and create system
restore disks
or individual recovery media on CD or DVD are included
Product design
Color Reveal white or eclipse black
Architecture
System architecture Intel® Centrino® 2 processor technology (optional)
Chipset Intel® PM45 + ICH9M
Processors1
Intel® Core™2 Duo processor P7350 (2.0 GHz, 1066MHz FSB, 3 MB L2 cache)
P8400 (2.26 GHz, 1066MHz FSB, 3 MB L2 cache)
P8600 (2.4 GHz, 1066MHz FSB, 3 MB L2 cache)
T5800 (2.0 GHz, 800 MHz FSB, 2 MB L2 cache)
T6400 (2.0 GHz, 800 MHz FSB, 2 MB L2 cache)
Memory 2 SO-DIMM memory slots (no memory on board)
Memory speed 800 MHz
Memory type DDR 2 RAM
Memory modules 1024 or 2048 MB
Max. memory size1, 24096 MB
Drives
Hard disk drive
HDD type SATA
HDD size 2.5-inch
HDD speed 5400 rpm
HDD cache 8 MB
HDD capacity1160, 250 or 320 GB
Optical disc drive(built-in)
ODD type SATA
ODD technology SuperMulti-format DVD burner with double layer (DL) support
ODD read speed CD-ROM 24x, DVD-ROM 8x
ODD write speed CD-R 24x, CD-RW 16x, DVD+R 8x, DVD-R 8x, DVD+RW 8x,
DVD-RW 6x, DVD+R DL (8.5 GB) 4x, DVD-R DL (8.5 GB) 4x,
DVD-RAM 5x
Option1:
ODD technology Built-in Blu-ray Disc™ drive incl. SuperMulti-format DVD burner with
double layer (DL) support
ODD read speed BD 2x, CD-ROM 24x, DVD-ROM 8x
ODD write speed CD-R 16x, CD-RW 10x, DVD+R 8x, DVD+RW 4x, DVD-R 8x, DVD-RW
4x,
DVD+R DL (8.5 GB) 4x, DVD-R DL (8.5 GB) 4x, DVD RAM 5x
Display
Display type BrilliantView LCD
Aspect ratio 16:10
Display size 15.4-inch
Display resolution (intern) 1280 x 800 pixels
Display resolution (extern) 1920 x 1080 pixels
Resolution type WXGA
Reaction time 16 ms
Brightness (white luminance, typ.) 200 cd/m2
Contrast (typ.) 400 : 1
Compliance with standards ISO 13406-2 class II

Data Sheet ⏐Issue: November 2008⏐AMILO Notebook Pi 3540 Page 3 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Graphics
Dedicated graphics (full name) NVIDIA® GeForce® 9300M GS
Dedicated video memory 256 MB GDDR3
Shared video memory3Up to 1279 MB shared memory3
3D Benchmark 2006 Up to 1900 points4(depending on configuration)
Graphic features NVIDIA® PureVideo® technology for
- Ultra-smooth video playback
- Superb picture clarity and
- Precise, vivid colors on any display
DirectX® 10 support
Interfaces
Video 1x HDMI (1.3b, incl. HDCP), 1x VGA
Audio 1x line in, 1x microphone in, 1x line out / headphone out combined with
S/PDIF out
Network 1x LAN (RJ-45)
Wireless 1x WLAN
Data 1x eSATA combined with USB, 2x USB 2.0
1x ExpressCard slot (54 / 34 mm)
1x 15-in-1 card reader5
SD, miniSD, MicroSD, SDHC
MS, MS-Duo
MMC, RS-MMC, MMC-Micro
MSPRO, MS-PRO Duo, MS-Pro HG, MS-Pro HG Duo M2
xD picture card
Power supply 1x DC-in
Communication
LAN (Local Area Network) 10 / 100 Mbps
Built-in WLAN (Wireless Local Area Network) Yes
WLAN brand name Intel® WiFi Link 5100 AGN
WLAN type draft-n 802.11a/g/n
WLAN max. date rate Up to 300 Mbps
WLAN encryption WEP, WPA and WPA2
For use in BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI, LV, LT, LU, MT, NL, NO,
PL, AT, PT, SE, SK, ES, CZ, HU, UK, CY
Option1:
WLAN type 802.11b/g/n
WLAN max. date rate Up to 300 Mbps
WLAN encryption WEP, WPA and WPA2
For use in BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI, LV, LT, LU, MT, NL, NO,
PL, AT, PT, SE, SK, ES, CZ, HU, UK, CY
Multimedia
Audio Support of high-definition audio for S/PDIF output with up to 7.1 channels
Audio chip Realtek ALC888
Speakers 2x built-in speakers (1.5 W each)
Microphone Built-in digital array microphone
Subwoofer -
Input device Sound volume control via function key
AMILOcam
Image sensor VGA webcam
Frames per second 306
Features Auto focus
Automatic brightness adjustment with status LED (blue: on, red:
streaming / application on)
Low-light technology for great video-quality even in dark
surrounding

Data Sheet ⏐Issue: November 2008⏐AMILO Notebook Pi 3540 Page 4 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
Input devices / Control buttons
Power button Located left of the keyboard, back-lighted
Keyboard Spill-proof keyboard with 85 keys
Touchpad Hidden touchpad, with left and right mouse button,
touchpad disable function via function key combination (Fn+F6)
Multimedia keys Located on top of the keyboard to launch the following applications:
Silent mode (reduce noise level / fan speed, by reducing the CPU
performance, office applications, Internet and DVD playback are not
affected)
DVD playback
Internet browser
Hot keys The following hot keys or key combinations are available
Fn+F1 WLAN on / off
Fn+F3 Mute on / off
Fn+F4 Volume down
Fn+F5 Volume up
Fn+F6 Touchpad on / off
Fn+F7 AMILOcam on / off
Fn+F8 Brightness down
Fn+F9 Brightness up
Fn+F10 Display switch
Fn+F11 Silent mode
Fn+F12 Suspend
Status indicators The notebook has 3 status icons:
Power status (& suspend)
Blue (always on): on; Blue blinking: stand by; None: off
WLAN
Blue: on; None: off
Battery charge
Blue (always on): full; Blue blinking: charging;
Red blinking: < 10 % capacity
Security
Supervisor and user password Yes
Kensington lock Yes
Lid switch (hidden) Yes
ACPI functions ACPI 3.0 compliant for Vista requirement
Power on stand by (S1 LCD off)
Stand by / energy saving mode (S3 save to RAM)
Hibernate mode (S4 save to disk)
Off mode (S5 soft off)
Power System
Battery7
Battery type1Lithium-Ion battery
6 cells, 11.1 V / 2200 mAh (cell) / 4400 mAh (pack)
Battery runtime 8Up to 2:20 hours
Battery runtime (DVD playback)9Up to 1:20 hours
Battery charging time (idle mode)10 Up to 1:35 hours
Battery charging time (maximum active mode)11 No charging
Battery charging time (normal use)12 Up to 1:35 hours
Battery charging time (off mode) Up to 2 hours

Data Sheet ⏐Issue: November 2008⏐AMILO Notebook Pi 3540 Page 5 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
AC Adapter Dynamic charge supported, ACPI 3.0 supported
Wide Range AC adapter 110 - 240 V AC, 50 - 60 Hz
Output 90 W with 20 V DC, 4.5 A
Energy consumption
S0 (idle mode) 24 W
S0 (max. active mode)13 60 W
S3 (stand by / energy saving mode) 1.5 W
S4 (hibernate) 0.8 W
S5 (off mode) 0.8 W
Noise emission
Idle mode14 23 dBA (silent mode off)
Maximum active mode15 30 dBA (silent mode off)
Operating conditions
Operational 5 °C to 35 °C (ambient temperature)
10 % to 90 % relative humidity, non-condensing
Dimensions and weight
W x D x H 358 x 256 x 37.0 (front) / 41.0 (back) mm
Weight 3.2 kg16
Certifications GOST (WLAN)
CE Marking
R&TTE (WLAN)
Warranty Country specific terms
Application Software
Home office Microsoft® Works
Microsoft® Office Home and Student Trial
Adobe Reader
Windows Mail (within Vista operating system)
Windows Calendar (within Vista operating system)
Multimedia Nero Essentials S (CD / DVD write software)
Vista DVD Playback Pack (DVD playback software)
Windows Media Player (within Vista operating system)
Windows Media Center (within Windows Vista® Home Premium
operating system)
Optional1:
CyberLink Power DVD (playback software for Blu-ray Disc™, only with
Blu-ray Disc™ drive)
Internet Microsoft® Internet Explorer
Country specific Internet provider
Security Norman security software solution

Data Sheet ⏐Issue: November 2008⏐AMILO Notebook Pi 3540 Page 6 / 6
Fujitsu Siemens Computers recommends Windows Vista® Home Premium
All rights reserved, including intellectual property rights. Technical data subject to modifications and
delivery subject to availability. Any liability that the data and illustrations are complete, actual or
correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which
by third parties for their own purposes may infringe the rights of such owner.
For further information see http://www.fujitsu-siemens.com/terms_of_use.html
Copyright © Fujitsu Siemens Computers 11/2008
Published by
FSC CD PMKT
Christiane Geis
Fujitsu Siemens Computers
http://www.fujitsu-siemens.com/
Company stamp
Accessories
Included AC adapter 90 W
First Battery 6 cells
Optional Find out more: www.fujitsu-siemens.com
Manuals Manual (on hard disk), quick start guide, safety guide, warranty guide,
recovery guide
Drivers Updates downloadable at http://www.fujitsu-siemens.com
1Depending on exact configuration. Please check at your local retailer
2DISCLAIMER: Up to 1 GB may not be available with 32-bit operating systems due to system resource requirements if system is preinstalled
with 4096 MB RAM
3Shared video memory size may vary depending on configuration and the version of the operating system. The video memory size that is
displayed in the system information software, as well as the actually used video memory size depends on Microsoft® Windows Vista®
memory management. The following values might serve as orientation
- 1024 MB system memory enables up to 511 MB total video memory (dedicated plus shared memory)
- 2048 MB system memory enables up to 1023 MB total video memory (dedicated plus shared memory)
- 3072 MB system memory enables up to 1535 MB total video memory (dedicated plus shared memory)
- 4096 MB system memory enables up to 1535 MB total video memory (dedicated plus shared memory)
4Depending on display resolution
5An adapter is needed for the following card formats: RS-MMC, MMC-Micro, miniSD, MicroSD, SDHC, MS-Duo, MS-PRO Duo, MS-Pro HG,
MS-Pro HG Duo, M2
6AMILOcam frame rate can vary significantly depending on the used software application
7DISCLAIMER: Battery life may vary depending on product model, configuration, applications, power management settings and features
utilized. Recharge time varies depending on usage. The recharge capacity may decrease after some months so that the battery lifetime as well
as operating time can not be assured for the whole lifetime of the notebook
8Tested with Battery Mark 4.0.1
9DVD playback tested with Vista DVD playback
10 Tested with Battermon
11 Tested with 3DMark 2003
12 DVD playback tested with Vista DVD playback
13 Tested with 3DMark 2006
14 Tested with idle mode (according to ISO 7779:2001 Nr. C.15.3.1) noise emission values according to ISO 9296 at operator position
15 Tested with HDD stress test and CPU stress text at approx. 90 % CPU load, no ODD load, noise emission values according to ISO 9296 at
operator position
16 Weight may vary depending on actual configuration
The configuration described in this document is generic only and non-binding. For the exact
configuration of your AMILO, please contact your licensed dealer.
