Fujitsu AB*14LBAJ Original operating manual

SPLIT TYPE
ROOM AIR CONDITIONER
Models Indoor unit Outdoor unit
AO*A18LAT3
AO*A24LAT3
INVERTER MULTI
SERVICE
INSTRUCTION
R410A
Universal Floor / Ceiling
Duct / Cassette
Wall Mounted / Floor type
AB*14LBAJ
AB*18LBAJ
AB*F14LAT
AB*F18LAT
AR* 9LUAB
AR*12LUAD
AR*14LUAD
AR*18LUAD
AR*F09LALU
AR*F12LALU
AR*F14LALU
AR*F18LALU
AU*12LBAB
AU*14LBAB
AU*18LBAB
AU*F09LAL
AU*F12LAL
AU*F14LAL
AU*F18LAL
AS* 7LMACW
AS* 9LMACW
AS*12LMACW
AS*A07LACM
AS*A09LACM
AS*A12LACM
AS*A14LACM
AS*A18LACM
AG*F09LAC
AG*F12LAC
AG*F14LAC

CONTENTS
1. DESCRIPTION OF EACH CONTROL OPERATION
1. CAPACITY CONTROL................................................................................................
3. INDOOR FAN CONTROL...........................................................................................
2. AUTO CHANGEOVER OPERATION..........................................................................
5. LOUVER CONTROL...................................................................................................
4. OUTDOOR FAN CONTROL.......................................................................................
7. TIMER OPERATION CONTROL................................................................................
6. COMPRESSOR CONTROL........................................................................................
9. TEST OPERATION CONTROL..................................................................................
8. ELECTRONIC EXPANSION VALVE CONTROL........................................................
11. 4-WAY VALVE EXTENSION SELECT.......................................................................
10. PREVENT TO RESTART FOR 3 MINUTES ( 3 MINUTES ST )................................
13. MANUAL AUTO OPERATION...................................................................................
12. AUTO RESTART........................................................................................................
15. FRESH AIR CONTROL..............................................................................................
14. COMPRESSOR PREHEATING..................................................................................
18. DEFROST OPERATION CONTROL..........................................................................
16. EXTERNAL ELECTRICAL HEATER CONTROL........................................................
19. DRAIN PUMP OPERATION.......................................................................................
21. VARIOUS PROTECTIONS.........................................................................................
20. ENERGY SAVE FUNCTION.......................................................................................
01-01
01-01
01-02
01-10
01-11
01-18
01-19
01-23
01-23
01-23
01-23
01-24
01-24
01-24
01-25
01-25
17. COIL DRY OPERATION CONTROL.......................................................................... 01-25
01-27
01-27
01-28
01-24
2-1-2 OUTDOOR UNIT DISPLAY................................................................................
2-1-1 INDOOR UNIT DISPLAY....................................................................................
2-1 ERROR DISPLAY......................................................................................................
2. TROUBLE SHOOTING
2-2 TROUBLE SHOOTING WITH ERROR CODE..........................................................
2-3 TROUBLE SHOOTING WITH NO ERROR CODE....................................................
2-4 SERVICE PARTS INFORMATION............................................................................
02-01
02-01
02-06
2-1-3 WIRED REMOTE CONTROLLER DISPLAY...................................................... 02-07
02-48
02-11
02-53
3. REPLACEMENT PARTS

1 . DESCRIPTION OF EACH
CONTROL OPERATION
R410A
INVERTER (MULTI )
Universal Floor / Ceiling
Duct / Cassette
Wall Mounted / Floor type

2. AUTO CHANGEOVER OPERATION
01-01
1. CAPACITY CONTROL
1-1 COOLING, HEATING, DRY CAPACITY CONTROL
Compressor frequency decides by capacity of an indoor unit, operation number of an indoor unit,
set temperature, room temperature and outside temperature.
When the air conditioner is set to the AUTO mode by remote control, operation starts in the optimum
mode from among the HEATING, COOLING and MONITORING modes. During operation, the
optimum mode is automatically swiched in accordance with temperature changes. The temperature
can be set between 18°C and 30°C in 1 degC steps.
When operation starts, only the indoor fan is operated for 1 minute. (Air flow mode: S- Lo)
After 1 minute, depends on the room temperature and outdoor unit's operarion mode,
the operation mode is selected in accordance with the table below.
( Table 1 : Operation mode selection table )
1
Room temperature :TR Operation mode
TR > Ts +2 degC
Ts +2 degC > TR
=
=
Ts +2 degC > TR > Ts-2 degC
Cooling
Monitoring
Heating
Ts : Setting temperature
TR: Room temperature
When COOLING was selected at , the same operation as COOLING OPERATION is performed.
When HEATING was selected at , the same operation as HEATING OPERATION is performed.
When the compressor was stopped for 6 consecutive minutes by the temperature control function
after the COOLING or HEATING operation mode was selected at above, operation is switched
to MONITORING and the operation mode is selected again.
1
2
31
4
1

3. INDOOR FAN CONTROL
1. Fan speed
( Table 2 : Indoor Fan Speed )
01-02
Operation mode Air flow mode Speed (rpm)
Hi 850
760
670
Me
Lo
Cooling
S-Lo
Heating
AB*14LBAJ
Operation mode Air flow mode Speed (rpm)
Hi 1030
890
770
250 250
Me
Lo
Cooling
S-Lo
Heating
Cooling
Heating
Cooling
Heating
Cooling
Heating
Cooling
Heating
AB*18LBAJ
Operation mode Air flow mode Speed (rpm)
Hi 955
870
800
650
Me
Lo
S-Lo
Operation mode Air flow mode Speed (rpm)
Hi 750
680
610
550
Me
Lo
S-Lo
Operation mode Air flow mode Speed (rpm)
Hi 1000
860
720
570
Me
Lo
S-Lo
Operation mode Air flow mode Speed (rpm)
Hi 1040
890
750
595
Me
Lo
S-Lo
AR*9LUAB
AR*14LUAD
AR*12LUAD
AR*18LUAD
Cooling
Heating
Cooling
Heating
Operation mode Air flow mode Speed (rpm)
Hi 850
800
740
670
300
Me
Lo
Quiet
S-Lo
Operation mode Air flow mode Speed (rpm)
Hi 1040
950
800
740
300
Me
Lo
Quiet
S-Lo
AB*F14LAT AB*F18LAT
Cooling
Heating
Cooling
Heating
Cooling
Heating
Operation mode Air flow mode Speed (rpm)
Hi 1010
950
880
830
450
Me
Lo
Quiet
S-Lo
Operation mode Air flow mode Speed (rpm)
Hi 790
720
620
570
330
Me
Lo
Quiet
S-Lo
Operation mode Air flow mode Speed (rpm)
Hi 990
880
770
620
330
Me
Lo
Quiet
S-Lo
AR*F09LALU
AR*F14LALU
Cooling
Heating
Operation mode Air flow mode Speed (rpm)
Hi 1040
950
840
700
450
Me
Lo
Quiet
S-Lo
AR*F18LALU
AR*F12LALU

01-03
Cooling
Heating
Cooling
Heating
AU*12/ 14LBAB
--- ---
AU*18LBAB
AU*F09LAL AU*F12LAL
Operation mode Air flow mode Speed (rpm)
Hi 730
670
590
Me
Lo
S-Lo
Operation mode Air flow mode Speed (rpm)
Hi 800
700
600
Me
Lo
S-Lo
Operation mode Air flow mode Speed (rpm)
Hi 660
580
520
460
Me
Lo
Dry
Monitoring
Quiet
Hi
Me
Lo
Quiet
650
580
Me+ 620
520
460
460
300
Auto
S- Lo
Cooling
Fan
Heating
Operation mode Air flow mode Speed (rpm)
Hi 590
540
490
440
Me
Lo
Dry
Monitoring
Quiet
Hi
Me
Lo
Quiet
590
540
Me+ 570
490
440
460
300
Auto
S- Lo
Cooling
Fan
Heating
Operation mode Air flow mode Speed (rpm)
Hi 730
630
540
460
Me
Lo
Dry
Monitoring
Quiet
Hi
Me
Lo
Quiet
740
670
Me+ 700
600
480
460
300
Auto
S- Lo
Cooling
Fan
Heating
AU*F14LAL
Operation mode Air flow mode Speed (rpm)
Hi 790
660
570
460
Me
Lo
Dry
Monitoring
Quiet
Hi
Me
Lo
Quiet
840
750
Me+ 800
650
500
460
300
Auto
S- Lo
Cooling
Fan
Heating
AU*F18LAL

01-04
Operation mode Air flow mode
Speed (rpm)
Louver position Louver position
Hi 1100
1050
1000
950
950
500
Me
Lo
Cooling
Fan
Quiet
Quiet
Hi 1120
1070
1000
930
500
1100
1030
970
Me
Lo
Heating
AS*7LMACW
S- Lo
1
4
5
6
3
2
1456
3
2
Operation mode Air flow mode
Speed (rpm)
Louver position Louver position
Hi 1200
1100
1000
940
940
500
Me
Lo
Cooling
Fan
Quiet
Quiet
Hi 1200
1100
1000
900
500
1150
1050
960
Me
Lo
Heating
AS*9LMACW
S- Lo
1456
3
2
Operation mode Air flow mode
Speed (rpm)
Louver position Louver position
Hi 1310
1260
1190
1100
970
500
Me
Lo
Cooling
Fan
Quiet
Quiet
Hi 1310
1180
1030
970
500
1200
1100
1000
Me
Lo
Heating
AS*12LMACW
S- Lo
1456
3
2

01-05
Operation mode Air flow mode Speed (rpm)
Hi 1140
1000
880
700
Me
Lo
Dry
Monitoring
Quiet
Hi/ Me+
Me
Lo
Quiet
1140
1050
980
800
700
480
Auto
S- Lo
Cooling
Fan
Heating
AS*A07LACM
Operation mode Air flow mode Speed (rpm)
Hi 1220
1060
900
720
Me
Lo
Dry
Monitoring
Quiet
Hi/ Me+
Me
Lo
Quiet
1220
1110
1040
830
720
480
Auto
S- Lo
Cooling
Fan
Heating
AS*A09LACM
Operation mode Air flow mode Speed (rpm)
Hi 1280
1100
900
750
Me
Lo
Dry
Monitoring
Quiet
Hi/ Me+
Me
Lo
Quiet
1320
1180
1080
860
750
480
Auto
S- Lo
Cooling
Fan
Heating
AS*A12LACM
Operation mode Air flow mode Speed (rpm)
Hi 1480
1250
1050
850
Me
Lo
Dry
Monitoring
Quiet
Hi/ Me+
Me
Lo
Quiet
1480
1250
1100
950
850
480
Auto
S- Lo
Cooling
Fan
Heating
AS*A14LACM
Operation mode Air flow mode Speed (rpm)
Hi 1480
1250
1100
950
Me
Lo
Dry
Monitoring
Quiet
Hi/ Me+
Me
Lo
Quiet
1480
1250
1100
950
950
480
Auto
S- Lo
Cooling
Fan
Heating
AS*A18LACM

01-06
AG*F09LAC
Operation mode Air flow mode Speed (rpm)
Hi 1120/ 950 1230/ ---
960/ 820 1070/ ---
660/ 560 680/ ---
820/ 700 910/ ---
660/ 560 750/ ---
570/ 480 --- / ---
1120/ 950 1230/ ---
1000/ 850 1090/ ---
860/ 730 940/ ---
660/ 560 750/ ---
660/ 560 680/ ---
Me
Lo
Heating
Quiet
Hi
Me
Lo
Quiet
Cool air prevention
S-Lo
S-Lo
Cooling
Fan
Upper& Lower
air flow mode
Upper
air flow mode
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
AG*F12LAC
Operation mode Air flow mode Speed (rpm)
Hi 1240/ 1050 1300/ ---
1050/ 890 1120/ ---
660/ 560 680/ ---
860/ 730 930/ ---
660/ 560 750/ ---
570/ 480 --- / ---
1240/ 1050 1300/ ---
1080/ 920 1140/ ---
910/ 770 980/ ---
660/ 560 750/ ---
660/ 560 680/ ---
Me
Lo
Heating
Quiet
Hi
Me
Lo
Quiet
Cool air prevention
S-Lo
S-Lo
Cooling
Fan
Upper& Lower
air flow mode
Upper
air flow mode
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
AG*F14LAC
Operation mode Air flow mode Speed (rpm)
Hi 1330/ 1120 1370/ ---
1100/ 930 1160/ ---
660/ 560 680/ ---
890/ 750 960/ ---
660/ 560 750/ ---
570/ 480 --- / ---
1330/ 1120 1370/ ---
1140/ 970 1180/ ---
940/ 800 1020/ ---
660/ 560 750/ ---
660/ 560 680/ ---
Me
Lo
Heating
Quiet
Hi
Me
Lo
Quiet
Cool air prevention
S-Lo
S-Lo
Cooling
Fan
Upper& Lower
air flow mode
Upper
air flow mode
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
(Upper/ Lower)
2. FAN OPERATION
The airflow can be switched in 5 steps such as AUTO, QUIET, LOW, MED, HIGH,
while the indoor fan only runs.
2-2. For AB*F14L/ 18L
AR*F09L/ 12L/ 14L/ 18L
AU*F09L/ 12L/ 14L/ 18L
AS*7L/ 9L/ 12L
AS*A07L/ 09L/ 12L/ 14L/ 18L
AG*F09L/ 12L/ 14L
The airflow can be switched in 4 steps such as AUTO, LOW, MED, HIGH,
while the indoor fan only runs.
2-1. For AB*14L/ 18L
AR* 9L/ 12L/ 14L/ 18L
AU*12L/ 14L/ 18L

3. COOLING OPERATION
(Fig.1)
airflow change - over ( Cooling: AUTO ) When the room
temperature rises
Lo mode
When the room
temperature lowers
01-07
Hi mode
Me mode
TR : Room temperature
Ts : Setting temperature
TR-Ts > 2 degC
=
1 degC > TR-Ts
2 degC > TR-Ts > 1 degC
=
TR-Ts > 3 degC
*(TR-Ts > 2.5 degC)
=
=
2 degC > TR-Ts
*(2 degC > TR-Ts)
3 degC > TR-Ts > 2 degC
*(2.5 degC > TR-Ts > 1.5 degC)
=
=
*1
*1 : Contains a condition to the following
When the operation mode is set to AUTO mode
at the start of operation.
When the setting temperature was changed.
When the operation mode was changed to COOLING mode.
When the airflow mode was changed to AUTO mode.
4. HEATING OPERATION
When the airflow is set to [AUTO], the indoor fan
motor operates [MED] mode.
Then the indoor fan motor will run according
to a room temperature, as shown in Figure 2.
On the other hand, if switched in [HIGH] [QUIET],
the indoor motor will run at a constant airflow
of [HEAT] operation modes QUIET, LOW, MED, HIGH,
as shown in Table 2.
47°C
41°C
*(42°C)
Indoor heat exchanger
temperature
( Fig.2 : Airflow change - over ( Heating : AUTO ) )
Hold
Go down one-step
Go up one-step
Switch the airflow [AUTO], and the indoor fan motor will run according to a room temperature,
as shown in Figure 1.
On the other hand, if switched in [HIGH] [QUIET], the indoor motor will run at a constant airflow of [COOL]
operation modes QUIET, LOW, MED, HIGH,as shown in Table 2.
*For AS*7/ 9/ 12LMACW
*For AS*A07/ 09/ 12/ 14/ 18LACM
*For AB*F/ AR*F/ AS*A/ AU*F/ AG*F Type
4-1. For AB/ AR/ AU/ AS Type
4-2. For AB*F/ AR*F/ AU*F/ AS*A/ AG*F Type
Switch the airflow [AUTO], and the indoor fan motor will run according to a room temperature,
as shown in Figure 3.
On the other hand, if switched in [HIGH] [QUIET], the indoor motor will run at a constant airflow
of [HEAT] operation modes QUIET, LOW, MED, HIGH, as shown in Table 2.
( Fig.3 : Airflow change - over ( Heating : AUTO ) )
TR-Ts > - 1.5 degC
=
- 2.5 degC > TR-Ts
- 1.5 degC > TR-Ts > - 2.5 degC
=
TR-Ts > - 1 degC
=
- 2 degC > TR-Ts
- 1 degC > TR-Ts > - 2 degC
=
When the room
temperature rises When the room
temperature drops
TR : Room temperature
Ts : Setting temperature
Lo mode
Me mode
Hi mode
*(Me+ mode)

01-08
5. COOL AIR PREVENTION CONTROL (Heating mode)
SETTING
FAN MODE
LO mode
S-LOW mode
33°C
30°C
30°C
Indoor heat exchanger
temperature
Indoor heat exchanger
temperature
The maximum value of the indoor fan speed is set as shown in Figure 4, based on the detected
temperature by the indoor heat exchanger sensor on heating mode.
( Fig.4 : Cool Air Prevention Control )
5-1. For AB/ AR/ AU Type
42°C
35°C
30°C
18°C
39°C
32°C
26°C
15°C
Indoor heat exchanger
temperature
Indoor heat exchanger
temperature
The maximum value of the indoor fan speed is set as shown in Figure 6, based on the fan speed mode
and the detected temperature by the indoor heat exchanger sensor on heating mode.
( Fig.6 : Cool Air Prevention Control for AS*7/ 9/ 12LMACW )
5-3. For AS Type
5-2. For AB*F/ AU*F Type
E zone
D zone
C zone
B zone
A zone
AUTO HIGH MED LOW QUIET
E zone
D zone
C zone
B zone
A zone
Fan speed
mode
ZONE
AUTO
AUTO
S-Lo
OFF OFF OFF OFF OFF
S-Lo S-Lo S-Lo S-Lo
Me
Lo Lo Lo
Setting Fan Speed
42°C
30°C
34°C
Indoor heat exchanger
temperature Indoor heat exchanger
temperature
When the compressor operates, the maximum value of the indoor fan speed is set as shown in Figure 5,
based on the detected temperature by the indoor heat exchanger sensor on heating mode.
When the compressor does not operate, the indoor fan motor operates [S-Lo] mode.
( Fig.5 : Cool Air Prevention Control )
< [Hi] setting >
Hi
Me+
Lo
Cool air
prevention
39°C
37°C
37°C
32°C
24°C
39°C
32°C
Indoor heat exchanger
temperature Indoor heat exchanger
temperature
< The other of [Hi] setting >
S-Lo
Lo (Qu)
Cool air
prevention
37°C
30°C
34°C
24°C
Setting
FAN mode
S-Lo
[ Cool air prevention 400rpm, S-Lo 300rpm ]

01-09
5-4. For AS*A Type
47°C
30°C
34°C
Indoor heat exchanger
temperature Indoor heat exchanger
temperature
When the compressor operates, the maximum value of the indoor fan speed is set as shown in Figure 7,
based on the detected temperature by the indoor heat exchanger sensor on heating mode.
When the compressor does not operate, the indoor fan motor operates [S-Lo] mode.
( Fig.7 : Cool Air Prevention Control )
< [Hi] setting >
Hi
Me+
Lo
Cool air
prevention
40°C
37°C
40°C
32°C
28°C
40°C
32°C
Indoor heat exchanger
temperature Indoor heat exchanger
temperature
< The other of [Hi] setting >
S-Lo
Lo (Qu)
Cool air
prevention
37°C
30°C
34°C
28°C
Setting
FAN mode
S-Lo
[ AS*A07L: Cool air prevention 800rpm, S-Lo 480rpm ]
[ AS*A09L: Cool air prevention 830rpm, S-Lo 480rpm ]
[ AS*A12L: Cool air prevention 860rpm, S-Lo 480rpm ]
[ AS*A14L/ 18L: Cool air prevention 850rpm, S-Lo 480rpm ]
5-5. For AG*F Type
42°C
30°C
31°C
Indoor heat exchanger
temperature Indoor heat exchanger
temperature
When the compressor operates, the maximum value of the indoor fan speed is set as shown in Figure 8,
based on the detected temperature by the indoor heat exchanger sensor on heating mode.
When the compressor does not operate, the indoor fan motor operates [S-Lo] mode.
( Fig.8 : Cool Air Prevention Control )
< [Hi] setting >
Hi
Me
Lo
Cool air
prevention
39°C
37°C
34°C
29°C
24°C
39°C
29°C
Indoor heat exchanger
temperature Indoor heat exchanger
temperature
< The other of [Hi] setting >
S-Lo
Lo (Qu)
Cool air
prevention
37°C
30°C
31°C
24°C
Setting
FAN mode
S-Lo
During the dry mode operation, the fan speed setting can not be changed. ( S-Lo )
6. DRY OPERATION
5-6. For AR*F Type
< [Hi] setting > < The other of [Hi] setting >
When the compressor operates, the maximum value of the indoor fan speed is set as shown in Figure 9,
based on the detected temperature by the indoor heat exchanger sensor on heating mode.
When the compressor does not operate, the indoor fan motor operates [S-Lo] mode.
( Fig.9 : Cool Air Prevention Control )
Setting
Fan mode
Lo (Qu) mode
S-Lo mode
37°C
30°C
32°C
24°C
Indoor heat exchanger
temperature
Indoor heat exchanger
temperature
Hi mode
Lo mode
S-Lo mode
37°C
30°C
32°C
24°C
Indoor heat exchanger
temperature
Indoor heat exchanger
temperature

4. OUTDOOR FAN CONTROL
Following table shows the fan speed of the outdoor unit.
01-10
1. Outdoor Fan Motor
*It runs at 500rpm for 20 seconds after starting up the outdoor fan.
When the outdoor heat exchanger tenperature is lower than 1°C,
the fan speed switches to 780rpm on heating mode.
( Table 3 : Fan speed of the outdoor unit )
780/ 730/ 400/ 300/ 250/ 200 rpm 780/ 730/ 660/ 400/ 300/ 250 rpm
Cooling Heating
AO*A18LAT3
AO*A24LAT3

5. LOUVER CONTROL
1. VERTICAL LOUVER CONTROL
Each time the button is pressed, the air direction range will change as follows:
Cooling / Dry mode
Heating mode
Fan mode
Use the air direction adjustments within the ranges shown above.
The vertical airflow direction is set automatically as shown, in accordance with the type of operation
selected.
Cooling / Dry / Fan mode Horizontal flow
Heating mode Downward flow
(Function Range)
(Air Direction Range)
(Operation Range)
1-2. SWING OPERATION
When the swing signal is received from the remote controller, the vertical louver starts to swing.
The range of swing depends on the set airflow direction.
(Swinging Range)
When the indoor fan is either at S-Lo or Stop mode, the swinging operation is interrupted
and the louver stops at the memorized position.
01-11
1
2
3
4
The indoor fan motor starts after the louver reaches to the setting position.
At the start of operation if the setting louver position is ,the setting position is set to
after the louver moves from totally-enclosed position to . (Positioning Control)
( Stop mode means Operation stop.)
Airflow direction set Range of swing
to
to
to
to
5-1 Compact Cassette (AU) type

1. VERTICAL LOUVER CONTROL
Each time the button is pressed, the air direction range will
change as follows:
Cooling / Dry mode
Heating mode
Fan mode
Use the air direction adjustments within the ranges shown above.
The vertical airflow direction is set automatically as shown, in accordance with the type of operation selected.
Cooling / Dry / Fan mode Horizontal flow
Heating mode Downward flow
(Function Range)
(Air Direction Range)
(Operation Range)
1-2. SWING OPERATION
When the swing signal is received from the remote controller, the vertical louver starts to swing.
The range of swing depends on the set airflow direction.
When the indoor fan is either at S-Lo or Stop mode, the swinging operation is interrupted
and the louver stops at the memorized position.
01-12
The indoor fan motor starts after the louver reaches to the setting position.
At the start of operation if the setting louver position is or ,the setting position is set to or
after the louver moves from totally-enclosed position to . (Positioning Control)
( Stop mode means Operation stop.)
1
4
5
6
7
3
2
1 2 3 4 5 6 7
1 2 3 4 5 6 7
1
2
1
3
1
2
3
6
4
5
3
4
5
6
7
1
7
1
12
2
3
(Swinging Range)
Airflow direction set Range of swing
to
to
to
to
1
4
5
7
7
7
to
to
to
5-2 Universal (AB) type

2. HORIZONTAL LOUVER CONTROL
Each time the button is pressed, the air direction range will
change as follows:
Cooling / Dry mode
Heating mode
Fan mode
Use the air direction adjustments within the ranges shown above.
The horizontal airflow direction is set automatically on after initialization.
(Function Range)
(Air Direction Range)
(Operation Range)
2-1. SWING OPERATION
When the swing signal is received from the remote controller, the horizontal louver starts to swing.
The range of swing depends on the set airflow direction.
When the indoor fan is either at S-Lo or Stop mode, the swinging operation is interrupted
and the louver stops at the memorized position.
01-13
( Stop mode means Operation stop.)
1 2 3 4 5
1 2 3
3
4 5
1345
2
1
2
1
3
1
2
5
5
3
4
3
4
5
(Swinging Range)
Airflow direction set Range of swing
to
to
to
to
1 5
to

1. VERTICAL LOUVER CONTROL
Each time the button is pressed, the air direction range will change as follow:
Cooling / Dry mode
Heating mode
Use the air direction adjustments within the ranges shown above.
The remote control unit's display does not change.
The vertical airflow direction is set automatically as shown,
in accordance with the type of operation selected.
Cooling / Dry mode Horizontal flow
Heating mode Downward flow
During AUTO mode operation, for the first minute after beginning operation,
airflow will be horizontal ; the air direction cannot be adjusted during this period.
Cooling mode / Dry mode / Fan mode ( )
)
Heating mode / Fan mode (
(Function Range)
(Air Direction Range)
(Operation Range)
1-2. SWING OPERATION
When the swing signal is received from the remote controller,
the vertical louver starts to swing.
(Swinging Range)
When the indoor fan is either at S-lo or Stop mode, the swinging operation is interrupted
and the louver stops at the memorized position.
01-14
5-3 Wall Mounted (AS) type

1. VERTICAL LOUVER CONTROL
Each time the button is pressed, the air direction range will change as follow:
Cooling / Dry mode
Heating mode
Fan mode
Use the air direction adjustments within the ranges shown above.
The vertical airflow direction is set automatically as shown, in accordance with the type of operation
selected.
Cooling / Dry mode Horizontal flow
Heating mode Downward flow
When the temperature of the air being blown out is low at the start of heating operation or during
defrosting, the airflow direction temporarily becomes to prevent cold air being blown onto the body.
During use of the Cooling and Dry modes, do not set the Air Flow Direction Louver in the Heating
range ( ) for long period of time, since water vapor many condense near the outlet louvers and
drop of water may drip from the air conditioner. During the Cooling and Dry modes, if the Air Flow
Direction Louvers are left in the hating range for more than 30 minutes, they will automatically
return to position .
During Monitor operation in AUTO CHANGEOVER mode, the airflow direction automatically
becomes , and it cannot be adjusted.
Cooling mode / Dry mode / Fan mode ( )
Heating mode / Fan mode ( )
(Function Range)
(Air Direction Range)
(Operation Range)
1-2. SWING OPERATION
When the swing signal is received from the remote controller,
the vertical louver starts to swing.
(Swinging Range)
When the indoor fan is either at S-lo or Stop mode, the swinging operation is interrupted
and the louver stops at the memorized position.
01-15
5-4 Wall Mounted (AS*A) type

01-16
5-5 Compact Cassette (AU*F) type
1. VERTICAL LOUVER CONTROL
Each time the button is pressed, the air direction range will change as follows:
Use the air direction adjustments within the ranges shown above.
The vertical airflow direction is set automatically as shown, in accordance with the type of operation
selected.
Cooling / Dry / Fan mode Horizontal flow
Heating mode Downward flow
(Function Range)
(Air Direction Range)
(Operation Range)
1-2. SWING OPERATION
When the swing signal is received from the remote controller, the vertical louver starts to swing.
The range of swing depends on the set airflow direction.
When the indoor fan is either at S-Lo or Stop mode, the swinging operation is interrupted
and the louver stops at the memorized position.
1
2
3
4
( Stop mode means Operation stop.)
During Cooling/Dry mode/Fan mode :
During Heating mode :
During AUTO mode operation, for the first minute after beginning operation, air-flow will be horizontal
; the air direction cannot be adjusted during this period.
(Swinging Range)
The type of operation
Cooling/Dry/Fan
Range of swing
to
Heating to

01-17
5-6 Floor (AG*F) type
1. VERTICAL LOUVER CONTROL
1-2. SWING OPERATION
Each time the button is pressed,
the air direction range will change as follows:
Use the air direction adjustments within the ranges shown above.
The vertical airflow direction is set automatically as shown, in accordance with the type of operation
selected.
Cooling / Dry mode Horizontal flow
Heating mode Downward flow
When the temperature of the air being blown out is low at the start of heating operation or during
defrosting, the airflow direction temporarily becomes to prevent cold air being blown onto the body.
During Monitor operation in AUTO CHANGEOVER mode, the airflow direction automatically
becomes , and it cannot be adjusted.
(Function and Operation Range)
(Air Direction Range)
When the swing signal is received from the remote controller, the vertical louver starts to swing.
(Swinging Range)
When the indoor fan is either at S-lo or Stop mode, the swinging operation is interrrupted
and the louver stops at the memorized position.
