Fujitsu AO G09LUCB Series Service manual

AIR CONDITIONER
Wall Mounted type
INDOOR
OUTDOOR
ASG07LUCA
ASG09LUCA
ASG12LUCA
ASG14LUCA
AOG07LUCA
AOG09LUCB
AOG12LUC
AOG14LUC
DESIGN & TECHNICAL MANUAL

1. INDOOR UNIT
WALL MOUNTED TYPE :
ASG07LUCA
ASG09LUCA
ASG12LUCA
ASG14LUCA
DTR_AS073E_01
2012.11.26

WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
CONTENTS
1. INDOOR UNIT
1. FEATURES.............................................................................................................. 01 - 01
2. WIRELESS REMOTE CONTROLLER............................................... 01 - 03
3. SPECIFICATIONS.............................................................................................. 01 - 05
4. DIMENSIONS ........................................................................................................ 01 - 07
5. WIRING DIAGRAMS........................................................................................ 01 - 09
6. CAPACITY TABLE ............................................................................................ 01 - 10
6-1. COOLING CAPACITY...................................................................................... 01 - 10
6-2. HEATING CAPACITY........................................................................................01 - 11
7. FAN PERFORMANCE.................................................................................... 01 - 12
7-1. AIR VELOCITY DISTRIBUTION..................................................................... 01 - 12
7-2. AIR FLOW.......................................................................................................... 01 - 15
8. OPERATION NOISE (SOUND PRESSURE)................................. 01 - 19
8-1. NOISE LEVEL CURVE .................................................................................... 01 - 19
8-2. SOUND LEVEL CHECK POINT..................................................................... 01 - 21
9. ELECTRIC CHARACTERISTICS........................................................... 01 - 22
10. SAFETY DEVICES ............................................................................................ 01 - 23
11. EXTERNAL INPUT & OUTPUT............................................................... 01 - 24
11-1. EXTERNAL INPUT ........................................................................................... 01 - 24
11-2. EXTERNAL OUTPUT....................................................................................... 01 - 26
12. FUNCTION SETTINGS .................................................................................. 01 - 28
13. OPTIONAL PARTS ........................................................................................... 01 - 32
13-1. CONTROLLER.................................................................................................. 01 - 32
13-2. OTHERS............................................................................................................. 01 - 32

- (01 - 01) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
FEATURES1.
MODEL

ASG07LUCA / AOG07LUCA
ASG09LUCA / AOG09LUCB
ASG12LUCA / AOG12LUC
ASG14LUCA / AOG14LUC
FEATURES

Energy efciency class
z
MODEL
ASG07LUCA ASG09LUCA ASG12LUCA ASG14LUCA
Cooling A++ A++ A++ A++
Heating
(Average) A+ A+ A+ A+
Thin & Slim design
z
Ø5mm
20mm
Large fan
Open
panel
Distributor
4-path
Refrigerant
Large intake
Big open panel and High density multi path heat
exchanger
Thin and slim design is realized by Ø5mm heat
exchanger and high efciency wind blower.
H282 X W870 X D185
185mm
Powerful operation
z *Only available with Wireless RC.
20 minutes continuous operation by maximum airow and maximum compressor speed is
possible. Rapid cooling and heating makes the room comfortable quickly.
Powerful
Setting temp.
Normal mode
Time
Temperature
10°C HEAT Operation
z *Only available with Wireless RC.
The room temperature can be set to go no lower than 10°C,
thus ensuring that the room does not get too cold when not occupied
Caution)
When the room temperature is higher than 10°C, “•10°C HEAT” operation does not start. Operation starts and maintains the room
temperature at 10°C when the temperature drops below 10°C.
When “•10°C HEAT” operation stops, the room set temperature quickly returns to the preset temperature.
10°C
20°C
“10°C HEAT”
Button ON
Indoor unit
operation START
AOG07LUCA
AOG09LUCB
AOG12LUC
AOG14LUC

- (01 - 02) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
Outdoor unit low noise
z *Only available with Wireless RC.
When air-conditioner operates in large capacity, operation noise of outdoor unit will be
suppressed. In case of room temperature being close to setting temperature, operation noise
might not decrease.
Rated
noise level
Noise level
Down
Low noise
mode
Economy operation
z
Example : Cooling operation
• Economy operation is energy saving, as the set temperature of indoor unit is shifted by 1°C and
the maximum electric value of the outdoor unit is suppressed.
Temp.
Economy operation
Shift
setting
temp
Control maximum current
Normal operation Time
Set temperature
3 Mode timer (Weekly/Program/Sleep)
z *Only available with Wireless RC.
Weekly timer can be easily set by wireless
remote controller.
ON, OFF can be set up to 4 times in 1 day and
up to 28 times in 1 week.
For other modes, program timer and sleep
timer can be also selected by one push.
Filter sign display
z
Indicates the lter cleaning period by lamp.
Indication lamp
Low outdoor air temperature correspondence
z
50
40
30
20
10
0
-10
-15°C
Cooling
24°C
Heating
46°C
-10°C
*1
*1: 12LUC and 14LUC are up to 43°C.

- (01 - 03) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
WIRELESS REMOTE CONTROLLER2.
FEATURES

3 Mode timer setup

(Weekly / Program / Sleep) are possible.
Easy operation.

Easy to change signal code (4 patterns) by button operation.

Simple function setting
z
Setting of the air conditioner selection function is performed by remote controller.
Built-in timers
z
Select from three different timer programs (Weekly / Program / Sleep).
Weekly timer
z
Weekly timer can be easily set by wireless remote controller. ON, OFF can be set up to 4 times in
1 day and up to 28 times in 1 week.
Program timer
z
The program timer operates the on and off timer once within a 24 hour period.
Sleep timer
z
The sleep timer function automatically corrects the temperature thermostat setting according to
the timer setting to prevent excessive cooling and heating while sleeping.
60min.
1 °C 2 °C
Timer setting
1 °C
30min.
60min.
90min.
2 °C 3 °C 4 °C
Timer setting
Cooling operation/dry operation
When the sleep timer is set, the set temperature
automatically rises 1 °C every hour. The set
temperature can rise up to a maximum of 2 °C.
Heating operation
When the sleep timer is set, the set temperature
automatically drops 1 °C every 30 minutes. The set
temperature can drop to a maximum of 4 °C.
Switching remote controller signal code
z
A B C D
A B CD
Mixed-up
I.U. I.U. I.U. I.U. I.U. I.U. I.U. I.U.
After code change
Code selector switch eliminates unit

•
being wrongly switched.
(Up to 4 codes can be set.)
*I.U.=Indoor unit

- (01 - 04) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
FUNCTIONS

Signal
Transmitter
10 °C HEAT
button
TEMP.
button
POWERFUL
button
START/STOP
button
MODE button
ECONOMY button
OUTDOOR UNIT LOW
NOISE button
SWING button
TIMER SETTING button
SEND button
SELECT button
NEXT button
BACK button
SET button
WEEKLY button
ON/OFF button
SLEEP button
FAN button
RESET button
CLOCK ADJUST button
Display panel
To facilitate explanation, the accompanying illustration has been drawn to show all possible indicators; in actual op-
eration, however, the display will only show those indicators appropriate to the current operation.
MODE Display
LOW NOISE MODE
Display
CLOCK & TIMER
Display
SEND Display
TEMPERATURE Display Transmit Indicator
Display
FAN Speed Display
SWING Display
Functions will be different due to type of indoor unit. For details, please see operation manual.
SPECIFICATION

SIZE (H x W x D mm) 205 x 61 x 17
WEIGHT ( g ) 122
ACCESSORY Holder

- (01 - 05) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
SPECIFICATIONS3.
Note:
Specications are based on the following conditions
Cooling:Indoor temperature of 27°CDB/19°CWB.and outdoor temperature of 35°CDB/24°CWB.
Heating:Indoor temperature of 20°CDB/15°CWB.and outdoor temperature of 7°CDB/6°CWB.
Pipe length:5m,Height difference:0m(Outdoor unit-Indoor unit)
The protective function might work when using it out the operation range.
*1: The maximum current is the maximum value when operated within the operation range.
Type WALL MOUNTED
INVERTER HEAT PUMP
Model name ASG07LUCA ASG09LUCA ASG12LUCA ASG014LUCA
Power source 230V~ 50Hz
Available voltage range 198-264V~ 50Hz
Capacity
Cooling
Rated kW 2.00 2.50 3.50 4.20
Btu/h 6,800 8,500 11,900 14,300
Min-Max kW 0.5-3.0 0.5-3.2 0.9-4.0 0.9-5.0
Btu/h 1,700-10,200 1,700-10,900 3,100-13,600 3,10 0 -17,10 0
Heating
Rated kW 3.00 3.20 4.00 5.40
Btu/h 10,200 10,900 13,600 18,400
Min-Max kW 0.5-4.0 0.5-4.2 0.9-5.6 0.9-6.0
Btu/h 1,700-13,600 1,700-14,300 3,10 0 -19 ,10 0 3,100-20,500
Input power
Cooling Rated
kW
0.46 0.555 0.905 1.235
Min-Max 0 .2 5 -1.19 0.25-1.27 0.25 -1.40 0.25-2.03
Heating Rated 0.660 0.680 0.930 1.380
Min-Max 0.25-1.60 0.25 -1.60 0.25 -1.99 0.25-2.40
Current Cooling Rated A2.6 3.1 4.6 5.8
Heating 3.4 3.4 4.7 6.3
EER Cooling kW/kW 4.35 4.50 3.87 3.40
COP Heating 4.55 4.71 4.30 3.91
Sensible capacity Cooling kW 1.32 1.62 2.28 2.78
Power factor Cooling %77 78 86 93
Heating 84 87 86 95
Moisture removal l/h (pints/h) 1.0(1.8) 1.3(2.3) 1.8(3.2) 2.1(3.7)
Maximum operating current *1 Cooling A6.0 6.0 6.5 9.0
Heating 7.5 7.5 9.0 10.5
Fan
Airow rate
Cooling
High
m3/h
680 800 850 900
Med 620 640 670 740
Low 530 550 550 570
Quiet 330 330 330 390
Heating
High 710 800 850 950
Med 620 670 710 740
Low 530 550 550 600
Quiet 330 330 330 430
Type × Q’ty Cross ow fanx1
Motor output W 29
Sound pressure level
Cooling
High
dB (A)
38 42 43 45
Med 35 36 37 40
Low 31 32 32 33
Quiet 21 21 21 25
Heating
High 38 42 43 45
Med 35 37 38 40
Low 31 32 32 34
Quiet 21 21 21 27
Heat exchanger type
Dimensions
(H × W × D) mm
320 × 690 × 20
Sub 84 × 690 × 13.3
Fin pitch 1.1
Sub 1.4
Rows Stages 2 × 20
Sub 1 × 4
Pipe type Copper
Fin type Aluminium
Enclosure
Material Polystyrene
Colour White
Approximate colour of MUNSELL N9.3/
Dimensions
(H × W × D)
Net mm 282 × 870 × 185
Gross 247 × 920 × 373
Weight Net kg 9.5
Gross 12
Connection pipe Size Liquid mm Ø6.35 (Ø1/4in.)
Gas Ø9.52 (Ø3/8in.) Ø12.70 (Ø1/2in.)
Method Flare
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless
Drain hose Material PP+LLDPE
Size mm Ø13.8 (I.D.), Ø15.8 to Ø16.7 (O.D.)

- (01 - 06) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
Model name ASG07LUCA ASG09LUCA ASG12LUCA ASG014LUCA
Energy efciency class Cooling A++ A++ A++ A++
Heating (Average) A+ A+ A+ A+
Pdesign Cooling kW 2.0 (35°C) 2.5 (35°C) 3.5 (35°C) 4.2 (35°C)
Heating (Average) 2.6 (-10°C) 2.8 (-10°C) 3.9 (-10°C) 4.8 (-10°C)
SEER Cooling kWh/kWh 7. 20 7.10 7.05 6.78
SCOP Heating (Average) 4.10 4.10 4.00 4.00
Annual energy consumption QCE kWh/a 97 123 174 217
QHE (Average) 887 956 1363 1677
Sound power level Cooling High dB (A) 57 59 60 60
Heating 59 61 62 64

- (01 - 07) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
DIMENSIONS4.
MODEL
 : A S G07LUCA, ASG09LUCA, ASG12LUCA,
ASG14LUCA
(Unit : mm)
ASG07LUCA,
ASG09LUCA,
ASG12LUCA
ASG14LUCA
Refrigerant pipe are
connection
Liquid ø 6.35 mm (ø 1/4 in.) ø 6.35 mm (ø 1/4 in.)
Gas ø 9.52 mm(ø 3/8 in.) ø 12.70 mm(ø 1/2 in.)
Drain hose connection Drain hose I.D. ø 13.8 mm , O.D. ø 15.8 to ø 16.7 mm
Drain hose : L=520mm
282
870 185
187:Installed state

- (01 - 08) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
INSTALLATION PLACE

(Unit : mm)

- (01 - 09) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
WIRING DIAGRAMS5.
MODEL
 : A S G07LUCA, ASG09LUCA, ASG12LUCA,
ASG14LUCA

- (01 - 10) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL
 : ASG07LUCA
MODEL
 : ASG09LUCA
MODEL
 : ASG12LUCA
MODEL
 : ASG14LUCA
AFR : Air Flow Rate (m3/min)
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP :Input Power (kW)
AFR 11.3
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 1.87 1.32 0.32 2.09 1.33 0.33 2.16 1.45 0.33 2.30 1.45 0.33 2.37 1.57 0.33 2.51 1.56 0.34 2.65 1.66 0.34
25 1.78 1.26 0.36 1.98 1.26 0.37 2.05 1.37 0.37 2.18 1.38 0.37 2.25 1.49 0.38 2.39 1.48 0.38 2.52 1.58 0.38
30 1.68 1.19 0.40 1.87 1.19 0.41 1.94 1.30 0.41 2.06 1.30 0.42 2.13 1.41 0.42 2.25 1.40 0.42 2.38 1.49 0.43
35 1.58 1.12 0.44 1.76 1.12 0.45 1.82 1.22 0.45 1.94 1.23 0.46 2.00 1.32 0.46 2.12 1.32 0.46 2.24 1.40 0.47
40 1.41 1.00 0.44 1.57 1.00 0.45 1.62 1.09 0.45 1.73 1.09 0.46 1.78 1.18 0.46 1.89 1.17 0.46 2.00 1.25 0.47
46 1.24 0.88 0.45 1.38 0.88 0.46 1.43 0.96 0.46 1.52 0.96 0.47 1.57 1.04 0.47 1.66 1.04 0.47 1.76 1.10 0.48
AFR 13.3
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 2.34 1.62 0.39 2.61 1.63 0.39 2.70 1.77 0.39 2.87 1.78 0.40 2.96 1.92 0.40 3.14 1.91 0.40 3.32 2.04 0.41
25 2.22 1.54 0.43 2.48 1.55 0.44 2.56 1.68 0.44 2.73 1.69 0.45 2.81 1.82 0.45 2.98 1.82 0.45 3.15 1.93 0.46
30 2.10 1.45 0.48 2.34 1.46 0.49 2.42 1.59 0.49 2.58 1.60 0.50 2.66 1.72 0.50 2.82 1.72 0.50 2.98 1.83 0.51
35 1.98 1.37 0.53 2.20 1.38 0.54 2.28 1.50 0.54 2.43 1.50 0.55 2.50 1.62 0.55 2.65 1.61 0.56 2.80 1.72 0.56
40 1.76 1.22 0.53 1.96 1.23 0.54 2.03 1.33 0.54 2.16 1.34 0.55 2.23 1.44 0.55 2.36 1.44 0.56 2.50 1.53 0.56
46 1.55 1.07 0.55 1.73 1.08 0.56 1.79 1.17 0.56 1.90 1.18 0.57 1.96 1.27 0.57 2.08 1.27 0.57 2.20 1.35 0.58
AFR 14.2
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 3.28 2.28 0.62 3.65 2.30 0.63 3.77 2.50 0.63 4.02 2.50 0.64 4.15 2.70 0.64 4.40 2.69 0.65 4.64 2.87 0.66
25 3.12 2.17 0.70 3.47 2.18 0.71 3.59 2.37 0.72 3.83 2.38 0.73 3.95 2.57 0.73 4.18 2.56 0.74 4.42 2.72 0.74
30 2.95 2.05 0.79 3.28 2.06 0.80 3.40 2.24 0.80 3.62 2.25 0.81 3.73 2.43 0.82 3.96 2.42 0.82 4.18 2.57 0.83
35 2.77 1.93 0.87 3.08 1.94 0.89 3.19 2.11 0.89 3.40 2.11 0.90 3.50 2.28 0.91 3.71 2.27 0.91 3.92 2.42 0.92
40 2.34 1.72 0.81 2.60 1.73 0.82 2.69 1.88 0.83 2.87 1.88 0.84 2.96 2.03 0.84 3.14 2.02 0.85 3.31 2.16 0.86
43 2.15 1.59 0.81 2.40 1.60 0.83 2.48 1.74 0.83 2.64 1.75 0.84 2.72 1.89 0.84 2.89 1.88 0.85 3.05 2.00 0.86
AFR 15.0
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 3.91 2.76 0.86 4.35 2.78 0.87 4.50 3.02 0.88 4.80 3.03 0.89 4.95 3.27 0.89 5.24 3.26 0.90 5.54 3.47 0.91
25 3.72 2.63 0.97 4.15 2.65 0.98 4.29 2.88 0.99 4.57 2.89 1.00 4.71 3.12 1.00 5.00 3.11 1.01 5.28 3.31 1.03
30 3.53 2.50 1.08 3.93 2.51 1.10 4.07 2.73 1.10 4.34 2.74 1.11 4.47 2.96 1.12 4.74 2.95 1.13 5.01 3.14 1.14
35 3.32 2.35 1.19 3.70 2.36 1.21 3.82 2.56 1.22 4.07 2.57 1.23 4.20 2.78 1.24 4.45 2.77 1.25 4.70 2.95 1.26
40 2.92 2.06 1.17 3.25 2.07 1.19 3.36 2.25 1.20 3.58 2.26 1.21 3.69 2.44 1.22 3.91 2.43 1.23 4.13 2.59 1.24
43 2.66 1.88 1.16 2.96 1.89 1.17 3.06 2.05 1.18 3.26 2.06 1.19 3.36 2.22 1.20 3.56 2.22 1.21 3.77 2.36 1.22

- (01 - 11) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
HEATING CAPACITY6-2.
MODEL
 : ASG07LU
CA
MODEL
 : ASG09LUCA
MODEL
 : ASG12LUCA
MODEL
 : ASG14LUCA
AFR : Air Flow Rate (m3/min)
TC : Total Capacity (kW)
IP :Input Power (kW)
AFR 12.2
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 2.15 0.83 2.10 0.85 2.05 0.87 2.00 0.88 1.95 0.90
-10 -11 2.52 0.88 2.46 0.90 2.40 0.92 2.34 0.94 2.28 0.96
-5 -7 2.77 0.91 2.70 0.93 2.63 0.95 2.57 0.97 2.50 0.98
0-2 2.83 0.89 2.76 0.91 2.70 0.93 2.63 0.95 2.56 0.97
5 3 3.66 0.99 3.58 1.01 3.49 1.03 3.40 1.05 3.31 1.07
7 6 4.20 1.06 4.10 1.08 4.00 1.10 3.90 1.12 3.80 1.14
10 8 4.64 1.19 4.53 1.21 4.42 1.24 4.31 1.26 4.20 1.29
15 10 4.81 1.18 4.70 1.20 4.58 1.23 4.47 1.25 4.35 1.27
AFR 13.3
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 2.31 0.86 2.26 0.88 2.20 0.89 2.15 0.91 2.09 0.93
-10 -11 2.61 0.91 2.55 0.93 2.49 0.95 2.43 0.97 2.36 0.99
-5 -7 2.84 0.93 2.77 0.95 2.70 0.96 2.63 0.98 2.57 1.00
0-2 2.95 0.89 2.88 0.91 2.81 0.93 2.74 0.95 2.67 0.97
5 3 3.84 1.00 3.75 1.02 3.66 1.04 3.57 1.06 3.48 1.08
7 6 4.41 1.07 4.31 1.10 4.20 1.12 4.10 1.14 3.99 1.16
10 8 4.87 1.19 4.76 1.21 4.64 1.24 4.53 1.26 4.41 1.29
15 10 5.05 1.18 4.93 1.20 4.81 1.23 4.69 1.25 4.57 1.27
AFR 14.2
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 3.36 1.31 3.28 1.34 3.20 1.37 3.12 1.39 3.04 1.42
-10 -11 3.89 1.40 3.79 1.43 3.70 1.46 3.61 1.49 3.52 1.51
-5 -7 4.25 1.45 4.15 1.48 4.04 1.51 3.94 1.54 3.84 1.57
0-2 4.36 1.44 4.26 1.47 4.16 1.50 4.05 1.53 3.95 1.56
5 3 5.29 1.50 5.17 1.53 5.04 1.56 4.91 1.59 4.79 1.62
7 6 5.88 1.54 5.74 1.57 5.60 1.61 5.46 1.64 5.32 1.67
10 8 6.50 1.51 6.34 1.54 6.19 1.57 6.03 1.60 5.88 1.63
15 10 6.73 1.41 6.57 1.44 6.41 1.47 6.25 1.50 6.09 1.53
AFR 15.8
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 3.47 1.31 3.38 1.34 3.30 1.37 3.22 1.39 3 .14 1.42
-10 -11 4.06 1.40 3.96 1.43 3.86 1.46 3.77 1.49 3.67 1.51
-5 -7 4.43 1.45 4.33 1.48 4.22 1.51 4.12 1.54 4.01 1.57
0-2 4.49 1.44 4.38 1.47 4.28 1.50 4.17 1.53 4.06 1.56
5 3 5.59 1.65 5.45 1.68 5.32 1.71 5.19 1.75 5.05 1.78
7 6 6.30 1.79 6.15 1.82 6.00 1.86 5.85 1.90 5.70 1.93
10 8 6.96 1.80 6.80 1.84 6.63 1.88 6.47 1.92 6.30 1.96
15 10 7.22 1.81 7.04 1.85 6.87 1.89 6.70 1.93 6.53 1.97

- (01 - 12) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
FAN PERFORMANCE7.
AIR VELOCITY DISTRIBUTION7-1.
MODEL
 :
ASG07LUCA
Note:
Fan speed : High
Operation mode : FAN
1.0
0.75 0.5
2
1
0
1
2
Unit : m/s(m)
(m)
TOP VIEW
Vertical ap : Up
Horizontal ap : Center
012345678
0.5
0.5
0.75
0.75
1.0
1.0
3
2
1
0
1
2
3
Unit : m/s(m)
TOP VIEW
Vertical ap : Up
Horizontal ap : Right & Left
(m)
012345678
1.0
0.75 0.5
3
2
1
0
Unit : m/s(m)
SIDE VIEW
Vertical ap : Up
Horizontal ap : Center
(m)
012345678
1.0 0.75
0.5
3
2
1
0
Unit : m/s(m)
SIDE VIEW
Vertical ap : Down
Horizontal ap : Center
(m)
012345678

- (01 - 13) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
MODEL
 :
ASG09LUCA
Note:
Fan speed : High
Operation mode : FAN
1.5 1.0 0.5
2
1
0
1
2
Unit : m/s(m)
(m)
TOP VIEW
Vertical ap : Up
Horizontal ap : Center
012345678
0.5
0.5
1.0
1.0
1.5
1.5
3
2
1
0
1
2
3
Unit : m/s(m)
TOP VIEW
Vertical ap : Up
Horizontal ap : Right & Left
(m)
012345678
1.5
1.0
0.5
3
2
1
0
Unit : m/s(m)
SIDE VIEW
Vertical ap : Up
Horizontal ap : Center
(m)
012345678
1.5 1.0 0.5
3
2
1
0
Unit : m/s(m)
SIDE VIEW
Vertical ap : Down
Horizontal ap : Center
(m)
012345678

- (01 - 14) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
MODEL
 :
ASG12LUCA, ASG14LUCA
Note:
Fan speed : High
Operation mode : FAN
1.5
1.0 0.5
2
1
0
1
2
Unit : m/s(m)
(m)
TOP VIEW
Vertical ap : Up
Horizontal ap : Center
012345678
0.5
0.5
1.0
1.0
1.5
1.5
3
2
1
0
1
2
3
Unit : m/s(m)
TOP VIEW
Vertical ap : Up
Horizontal ap : Right & Left
(m)
012345678
1.5
1.0
0.5
3
2
1
0
Unit : m/s(m)
SIDE VIEW
Vertical ap : Up
Horizontal ap : Center
(m)
012345678
1.5
1.0 0.5
3
2
1
0
Unit : m/s(m)
SIDE VIEW
Vertical ap : Down
Horizontal ap : Center
(m)
012345678

- (01 - 15) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
AIR FLOW7-2.
MODEL
 : ASG07LU
CA
Cooling
z
Heating
z
Fan speed
Number of
rotations
(r.p.m.)
Air ow
HIGH 1140
680 m3/h
189 l/s
400 CFM
MED 1050
620 m3/h
172 l/s
365 CFM
LOW 930
530 m3/h
147 l/s
312 CFM
QUIET 650
330 m3/h
92 l/s
194 CFM
Fan speed
Number of
rotations
(r.p.m.)
Air ow
HIGH 118 0
710 m3/h
197 l/s
418 CFM
MED 1050
620 m3/h
172 l/s
365 CFM
LOW 930
530 m3/h
147 l/s
312 CFM
QUIET 650
330 m3/h
92 l/s
194 CFM

- (01 - 16) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
MODEL
 : ASG09LU
CA
Cooling
z
Heating
z
Fan speed
Number of
rotations
(r.p.m.)
Air ow
HIGH 1300
800 m3/h
222 l/s
471 CFM
MED 1080
640 m3/h
178 l/s
376 CFM
LOW 960
550 m3/h
153 l/s
324 CFM
QUIET 650
330 m3/h
92 l/s
194 CFM
Fan speed
Number of
rotations
(r.p.m.)
Air ow
HIGH 1300
800 m3/h
222 l/s
471 CFM
MED 1120
670 m3/h
186 l/s
394 CFM
LOW 960
550 m3/h
153 l/s
324 CFM
QUIET 650
330 m3/h
92 l/s
194 CFM

- (01 - 17) -
WALL MOUNTED TYPE ASG07-14LUCA WALL MOUNTED TYPE ASG07-14LUCA
MODEL
 : ASG12LU
CA
Cooling
z
Heating
z
Fan speed
Number of
rotations
(r.p.m.)
Air ow
HIGH 1370
850 m3/h
236 l/s
500 CFM
MED 1120
670 m3/h
186 l/s
394 CFM
LOW 960
550 m3/h
153 l/s
324 CFM
QUIET 650
330 m3/h
92 l/s
194 CFM
Fan speed
Number of
rotations
(r.p.m.)
Air ow
HIGH 1370
850 m3/h
236 l/s
500 CFM
MED 118 0
710 m3/h
197 l/s
418 CFM
LOW 960
550 m3/h
153 l/s
324 CFM
QUIET 650
330 m3/h
92 l/s
194 CFM
