Fujitsu AOYG12KATA Service manual

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ
Fujitsu AUXG12KVLA/AOYG12KATA

AIR CONDITIONER
Cassette type
DESIGN & TECHNICAL MANUAL
INDOOR AUXG09KVLA
AUXG12KVLA
AUXG14KVLA
AUXG18KVLA
AUXG22KVLA
OUTDOOR
AOYG09KBTB
AOYG12KBTB
AOYG14KBTB
AOYG18KBTB
AOYG22KBTB
DR_AU020EF_03
2019.07.11

Notices:
• Product specifications and design are subject to change without notice for future improvement.
• For further details, please check with our authorized dealer.
Trademarks
FGLair™ is trademark of Fujitsu General Limited in the United States, other countries or both.
Google Play™ is trademark of Google Inc.
App Store® is a service mark of Apple Inc., registered in the U.S. and other countries.
Copyright © 2019 Fujitsu General Limited. All rights reserved.

CONTENTS
Part 1. INDOOR UNIT...........................................................................1
1. Specifications................................................................................................2
2. Dimensions....................................................................................................6
2-1. Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA, AUXG18KVLA, and
AUXG22KVLA ....................................................................................................................6
2-2. Installation space requirement .........................................................................................7
3. Wiring diagram ..............................................................................................8
3-1. Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA, AUXG18KVLA, and
AUXG22KVLA ....................................................................................................................8
4. Capacity table................................................................................................9
4-1. Cooling capacity...............................................................................................................9
4-2. Heating capacity ............................................................................................................11
5. Fan performance .........................................................................................13
5-1. Air velocity distributions..................................................................................................13
5-2. Airflow ............................................................................................................................23
6. Operation noise (sound pressure).............................................................28
6-1. Noise level curve............................................................................................................28
6-2. Sound level check point .................................................................................................31
7. Safety devices .............................................................................................32
8. External input and output...........................................................................33
8-1. External input.................................................................................................................33
8-2. External output...............................................................................................................34
8-3. Combination of external input and output.......................................................................35
8-4. Details of function ..........................................................................................................36
9. Function settings ........................................................................................39
9-1. Function settings on indoor unit .....................................................................................39
9-2. Function settings by using remote controller..................................................................41
10. Accessories.................................................................................................46
10-1.Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA, AUXG18KVLA, and
AUXG22KVLA ..................................................................................................................46
11. Optional parts .............................................................................................47
11-1.Controllers ....................................................................................................................47
11-2.Cassette grille ...............................................................................................................48
11-3.Others ...........................................................................................................................49

Part 2. OUTDOOR UNIT.....................................................................51
1. Specifications..............................................................................................52
2. Dimensions..................................................................................................54
2-1. Models: AOYG09KBTB, AOYG12KBTB, and AOYG14KBTB .......................................54
2-2. Models: AOYG18KBTB and AOYG22KBTB ..................................................................55
3. Installation space ........................................................................................56
3-1. Models: AOYG09KBTB, AOYG12KBTB, AOYG14KBTB, AOYG18KBTB, and
AOYG22KBTB..................................................................................................................56
4. Refrigerant circuit .......................................................................................59
4-1. Models: AOYG09KBTB, AOYG12KBTB, and AOYG14KBTB .......................................59
4-2. Model: AOYG18KBTB ...................................................................................................60
4-3. Model: AOYG22KBTB ...................................................................................................61
5. Wiring diagrams ..........................................................................................62
5-1. Model: AOYG09KBTB ...................................................................................................62
5-2. Models: AOYG12KBTB, AOYG14KBTB, and AOYG18KBTB .......................................63
5-3. Model: AOYG22KBTB ...................................................................................................64
6. Capacity compensation rate for pipe length and height difference........65
6-1. Model: AOYG09KBTB ...................................................................................................65
6-2. Model: AOYG12KBTB ...................................................................................................66
6-3. Model: AOYG14KBTB ...................................................................................................67
6-4. Model: AOYG18KBTB ...................................................................................................68
6-5. Model: AOYG22KBTB ...................................................................................................69
7. Additional charge calculation ....................................................................70
7-1. Model: AOYG09KBTB ...................................................................................................70
7-2. Models: AOYG12KBTB and AOYG14KBTB ..................................................................70
7-3. Model: AOYG18KBTB ...................................................................................................70
7-4. Model: AOYG22KBTB ...................................................................................................70
8. Airflow..........................................................................................................71
8-1. Model: AOYG09KBTB ...................................................................................................71
8-2. Model: AOYG12KBTB ...................................................................................................71
8-3. Model: AOYG14KBTB ...................................................................................................71
8-4. Model: AOYG18KBTB ...................................................................................................72
8-5. Model: AOYG22KBTB ...................................................................................................72
9. Operation noise (sound pressure).............................................................73
9-1. Noise level curve............................................................................................................73
9-2. Sound level check point .................................................................................................75
10. Electrical characteristics............................................................................76
11. Safety devices .............................................................................................77
12. Accessories.................................................................................................78
CONTENTS (continued)

12-1.Models: AOYG09KBTB, AOYG12KBTB, AOYG14KBTB, AOYG18KBTB, and
AOYG22KBTB..................................................................................................................78
CONTENTS (continued)

Part 1. INDOOR UNIT
CASSETTE TYPE:
AUXG09KVLA
AUXG12KVLA
AUXG14KVLA
AUXG18KVLA
AUXG22KVLA

1. Specifications
Type
Cassette
Inverter heat pump
Model name AUXG09KVLA AUXG12KVLA AUXG14KVLA
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Capacity
Cooling
Rated kW 2.50 3.50 4.30
Btu/h 8,500 11,900 14,700
Min.—Max. kW 0.90—3.20 0.90—4.40 0.90—5.40
Btu/h 3,100—10,900 3,100—15,000 3,100—18,400
Heating
Rated kW 3.20 4.10 5.00
Btu/h 10,900 13,400 17,000
Min.—Max. kW 0.90—4.70 0.90—5.70 0.90—6.50
Btu/h 3,100—16,000 3,100—19,400 3,100—22,200
Input power
Cooling Rated
kW
0.55 0.93 1.28
Max. 1.82 2.24 2.35
Heating Rated 0.79 1.08 1.32
Max. 1.82 2.24 2.35
Current Cooling Rated A 2.9 4.1 5.6
Heating 4.0 4.8 5.8
Power factor Cooling %82.5 98.6 99.4
Heating 85.9 97.8 99.0
EER Cooling kW/kW 4.57 3.76 3.36
COP Heating 4.05 3.80 3.79
Moisture removal L/h (pints/h) 0.6 (1.1) 1.2 (2.1) 1.5 (2.6)
Maximum operating current *1 Cooling A7.9 9.7 10.2
Heating 7.9 9.7 10.2
Fan
Airflow rate
Cooling
HIGH
m3/h
540 600 680
MED 490 530 580
LOW 440 470 490
QUIET 390 410 410
Heating
HIGH 540 600 800
MED 490 530 680
LOW 440 470 580
QUIET 390 410 450
Type × Q'ty Turbo × 1
Motor output W 54
Sound pressure level *2
Cooling
HIGH
dB (A)
33 37 38
MED 31 34 34
LOW 29 30 30
QUIET 27 27 27
Heating
HIGH 34 37 43
MED 32 34 38
LOW 29 31 34
QUIET 27 29 30
Heat exchanger type
Dimensions
(H × W × D) mm
210 × 1,310 × 13.3
210 × 1,250 × 13.3
Fin pitch 1.2
Rows × Stages 2 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net mm 245 × 570 × 570
Gross 265 × 730 × 625
Weight Net kg 15
Gross 19
Connection pipe Size Liquid mm (in) Ø 6.35 (Ø1/4) Gas Ø9.52 (Ø3/8)
Method Flare
Operation range Cooling °C 18 to 32 %RH 80 or less
Heating °C 16 to 30
Cassette grille
(Grid type: Option)
Material Polystyrene
Color White
Approximate color of Munsell 9PB 9.1/0.2
Dimensions
(H × W × D)
Net mm 49 × 620 × 620
Gross 120 × 765 × 755
Weight Net kg 2.3
Gross 4.5
Remote control (Option) Wired remote controller, Wireless remote controller, Mobile app*3 (FGLair™)
Drain hose Material PVC
Size mm VP25 [Ø25(I.D.),Ø32(O.D.)]
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Available on Google Play™ store or on App Store®. Optional WLAN adapter is also required. For details, refer to the setting manual.
- 2 - 1. Specifications
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA

Specifications for ErP Lot10
Model name AUXG09KVLA AUXG12KVLA AUXG14KVLA
Energy efficiency class Cooling A++
Heating (Average) A+
Pdesign Cooling kW 2.5 (35°C) 3.5 (35°C) 4.3 (35°C)
Heating (Average) 2.6 (-10°C) 3.4 (-10°C) 3.8 (-10°C)
SEER Cooling kWh/kWh 6.70 6.60 6.50
SCOP Heating (Average) 4.40 4.30 4.40
Annual energy consumption QCE kWh/a 131 186 231
QHE (Average) 826 1,106 1,208
Sound power level Cooling HIGH dB (A) 46 49 50
Heating 47 49 55
- 3 - 1. Specifications
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA

Type
Cassette
Inverter heat pump
Model name AUXG18KVLA AUXG22KVLA
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Capacity
Cooling
Rated kW 5.20 6.00
Btu/h 17,700 20,500
Min.—Max. kW 0.90—5.90 0.90—6.70
Btu/h 3,100—20,100 3,100—22,900
Heating
Rated kW 6.00 7.00
Btu/h 20,500 23,900
Min.—Max. kW 0.90—7.50 0.90—8.00
Btu/h 3,100—25,600 3,100—27,300
Input power
Cooling Rated
kW
1.60 1.82
Max. 2.79 2.90
Heating Rated 1.66 1.87
Max. 2.79 2.90
Current Cooling Rated A 7.0 8.0
Heating 7.3 8.2
Power factor Cooling %99.4 98.9
Heating 98.9 99.2
EER Cooling kW/kW 3.25 3.30
COP Heating 3.61 3.74
Moisture removal L/h (pints/h) 2.2 (3.9) 2.6 (4.6)
Maximum operating current *1 Cooling A12.1 12.6
Heating 12.1 12.6
Fan
Airflow rate
Cooling
HIGH
m3/h
680 830
MED 580 740
LOW 490 600
QUIET 410 450
Heating
HIGH 800 860
MED 680 760
LOW 580 700
QUIET 450 530
Type × Q'ty Turbo × 1
Motor output W 54
Sound pressure level *2
Cooling
HIGH
dB (A)
38 44
MED 34 42
LOW 30 36
QUIET 26 30
Heating
HIGH 43 45
MED 38 43
LOW 34 40
QUIET 30 33
Heat exchanger type
Dimensions
(H × W × D) mm
210 × 1,310 × 13.3
210 × 1,250 × 13.3
210 × 1,360 × 13.3
210 × 1,295 × 13.3
210 × 1,235 × 13.3
Fin pitch 1.2 1.45
Rows × Stages 2 × 10 3 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net mm 245 × 570 × 570
Gross 265 × 730 × 625
Weight Net kg 15 16
Gross 19 20
Connection pipe Size Liquid mm (in) Ø 6.35 (Ø1/4) Gas Ø12.70 (Ø1/2)
Method Flare
Operation range Cooling °C 18 to 32 %RH 80 or less
Heating °C 16 to 30
Cassette grille
(Grid type: Option)
Material Polystyrene
Color White
Approximate color of Munsell 9PB 9.1/0.2
Dimensions
(H × W × D)
Net mm 49 × 620 × 620
Gross 120 × 765 × 755
Weight Net kg 2.3
Gross 4.5
Remote control (Option) Wired remote controller, Wireless remote controller, Mobile app*3 (FGLair™)
Drain hose Material PVC
Size mm VP25 [Ø25(I.D.),Ø32(O.D.)]
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Available on Google Play™ store or on App Store®. Optional WLAN adapter is also required. For details, refer to the setting manual.
- 4 - 1. Specifications
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA

Specifications for ErP Lot10
Model name AUXG18KVLA AUXG22KVLA
Energy efficiency
class
Cooling A++
Heating (Average) A+
Pdesign Cooling kW 5.2 (35°C) 6.0 (35°C)
Heating (Average) 4.4 (-10°C) 4.8 (-10°C)
SEER Cooling kWh/kWh 6.60 6.60
SCOP Heating (Average) 4.20 4.30
Annual energy con-
sumption
QCE kWh/a 275 318
QHE (Average) 1,466 1,562
Sound power level Cooling HIGH dB (A) 50 56
Heating 55 57
- 5 - 1. Specifications
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA

2. Dimensions
2-1. Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA,
AUXG18KVLA, and AUXG22KVLA
Unit: mm
285 285
Ceiling
114
B
View A
570: Indoor unit
370
540
Hanging bolt position
a: Ceiling openings
530
530
Hanging bolt position
Drain hose
A
215
19
30
123
30
262
183
Control Box
146
40
C
620
620
IR receiver
Grid type grille
View B View C
114
a: Ceiling openings
Cassette grille (Option [Grid type]) mm 580 to 610
- 6 -
2-1. Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA, AUXG18KVLA, and
AUXG22KVLA
2. Dimensions
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA

2-2. Installation space requirement
1,000
or more
1,000
or more
1,800
or more
262
or more
Strong and durable ceiling
Obstruction
Floor
Unit: mm
Maximum height from floor to ceiling (Unit: mm)
Standard 2,700
High ceiling 3,000
3-way direction setting:
100 or more*
Unit: mm
NOTES:
• To set “3-direction”, optional Air outlet shutter plate (UTR-YDZB) must be installed, and the “out-
let-direction” need to be switched to “3-way” by remote controller.
*When installing the indoor unit, be careful about the maintenance space.
• The ceiling height cannot be set in the 3-way outlet mode. Therefore, ceiling height setting
change by function setting 20 is prohibited. For details, refer to "Contents of function setting" on
page 41.
- 7 -
2-2. Installation space requirement 2. Dimensions
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA

3. Wiring diagram
3-1. Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA,
AUXG18KVLA, and AUXG22KVLA
- 8 -
3-1. Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA, AUXG18KVLA, and
AUXG22KVLA
3. Wiring diagram
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA

4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢Model: AUXG09KVLA
AFR m3/h 540
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 2.03 1.62 0.49 2.26 1.63 0.50 2.34 1.77 0.50 2.49 1.78 0.51 2.57 1.92 0.51 2.72 1.91 0.52 2.88 2.04 0.52
-10 1.89 1.57 0.56 2.10 1.58 0.57 2.17 1.72 0.57 2.32 1.72 0.58 2.39 1.86 0.58 2.53 1.85 0.59 2.68 1.97 0.59
0 2.09 1.66 0.34 2.33 1.67 0.34 2.41 1.82 0.34 2.57 1.82 0.35 2.65 1.97 0.35 2.81 1.96 0.35 2.97 2.09 0.36
5 2.04 1.65 0.39 2.27 1.66 0.39 2.35 1.80 0.39 2.50 1.81 0.40 2.58 1.95 0.40 2.73 1.94 0.40 2.89 2.07 0.41
10 2.14 1.69 0.33 2.38 1.70 0.33 2.47 1.85 0.33 2.63 1.85 0.34 2.71 2.00 0.34 2.87 1.99 0.34 3.04 2.12 0.35
15 2.08 1.66 0.38 2.31 1.67 0.38 2.39 1.82 0.38 2.55 1.82 0.39 2.63 1.97 0.39 2.79 1.96 0.39 2.95 2.09 0.40
20 2.22 1.74 0.40 2.47 1.75 0.40 2.56 1.90 0.40 2.73 1.91 0.41 2.81 2.06 0.41 2.98 2.05 0.41 3.15 2.19 0.42
25 2.13 1.75 0.44 2.38 1.76 0.45 2.46 1.91 0.45 2.62 1.92 0.46 2.70 2.07 0.46 2.86 2.06 0.46 3.02 2.20 0.47
30 2.05 1.76 0.48 2.29 1.77 0.49 2.37 1.92 0.49 2.52 1.93 0.50 2.60 2.08 0.50 2.76 2.07 0.51 2.91 2.21 0.51
35 1.98 1.76 0.53 2.20 1.77 0.54 2.28 1.93 0.54 2.43 1.94 0.55 2.50 2.09 0.55 2.65 2.08 0.56 2.80 2.22 0.56
40 1.90 1.76 0.61 2.11 1.77 0.62 2.18 1.93 0.62 2.33 1.94 0.63 2.40 2.09 0.63 2.54 2.08 0.64 2.69 2.22 0.64
46 1.81 1.76 0.69 2.02 1.77 0.71 2.08 1.92 0.71 2.22 1.93 0.72 2.29 2.08 0.72 2.43 2.07 0.73 2.56 2.21 0.73
¢Model: AUXG12KVLA
AFR m3/h 600
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 2.92 2.46 0.70 3.25 2.48 0.72 3.36 2.70 0.72 3.58 2.70 0.73 3.69 2.92 0.73 3.91 2.91 0.74 4.13 3.10 0.74
-10 3.11 2.55 0.59 3.47 2.56 0.60 3.59 2.79 0.60 3.82 2.80 0.61 3.94 3.02 0.61 4.18 3.01 0.62 4.41 3.20 0.62
0 3.45 2.70 0.40 3.85 2.72 0.40 3.98 2.95 0.40 4.24 2.96 0.41 4.37 3.20 0.41 4.63 3.19 0.41 4.89 3.40 0.42
5 3.31 2.63 0.46 3.69 2.65 0.47 3.81 2.88 0.47 4.06 2.89 0.48 4.19 3.12 0.48 4.44 3.11 0.48 4.69 3.31 0.49
10 3.39 2.65 0.47 3.78 2.67 0.48 3.90 2.90 0.48 4.16 2.91 0.49 4.29 3.14 0.49 4.55 3.13 0.49 4.80 3.33 0.50
15 3.29 2.61 0.56 3.67 2.62 0.57 3.79 2.85 0.57 4.04 2.86 0.58 4.17 3.09 0.58 4.42 3.08 0.59 4.67 3.28 0.59
20 3.29 2.62 0.62 3.67 2.64 0.63 3.79 2.87 0.63 4.04 2.88 0.64 4.17 3.11 0.64 4.42 3.10 0.65 4.67 3.30 0.65
25 3.11 2.51 0.71 3.47 2.52 0.73 3.59 2.74 0.73 3.82 2.75 0.74 3.94 2.97 0.74 4.18 2.96 0.75 4.41 3.15 0.75
30 2.94 2.38 0.81 3.27 2.39 0.82 3.39 2.60 0.83 3.61 2.61 0.84 3.72 2.82 0.84 3.94 2.81 0.85 4.17 2.99 0.86
35 2.77 2.26 0.90 3.08 2.28 0.91 3.19 2.47 0.92 3.40 2.48 0.93 3.50 2.68 0.93 3.71 2.67 0.94 3.92 2.84 0.95
40 2.68 2.23 0.99 2.98 2.24 1.01 3.08 2.44 1.01 3.29 2.44 1.02 3.39 2.64 1.03 3.59 2.63 1.04 3.80 2.80 1.05
46 2.36 2.19 0.98 2.63 2.21 1.00 2.72 2.40 1.00 2.90 2.41 1.01 2.99 2.60 1.02 3.17 2.59 1.03 3.35 2.76 1.04
¢Model: AUXG14KVLA
AFR m3/h 680
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 3.32 2.78 0.98 3.70 2.79 1.00 3.82 3.04 1.00 4.07 3.05 1.01 4.20 3.29 1.02 4.45 3.28 1.03 4.70 3.49 1.04
-10 3.60 2.89 0.64 4.01 2.91 0.65 4.15 3.17 0.65 4.42 3.18 0.66 4.56 3.43 0.66 4.83 3.42 0.67 5.11 3.64 0.67
0 3.74 2.96 0.45 4.17 2.98 0.46 4.31 3.24 0.46 4.60 3.25 0.47 4.74 3.51 0.47 5.02 3.50 0.47 5.31 3.72 0.48
5 3.56 2.87 0.55 3.97 2.89 0.56 4.10 3.14 0.56 4.37 3.15 0.57 4.51 3.40 0.57 4.78 3.39 0.58 5.05 3.61 0.58
10 3.61 2.84 0.55 4.02 2.85 0.56 4.16 3.10 0.56 4.43 3.11 0.57 4.57 3.36 0.57 4.84 3.35 0.58 5.12 3.56 0.58
15 3.55 2.84 0.66 3.95 2.86 0.67 4.09 3.11 0.67 4.36 3.12 0.68 4.49 3.37 0.68 4.76 3.36 0.69 5.03 3.58 0.69
20 3.94 3.06 0.88 4.39 3.07 0.89 4.54 3.34 0.90 4.84 3.35 0.91 4.99 3.62 0.91 5.29 3.61 0.92 5.59 3.84 0.93
25 3.76 2.96 1.00 4.19 2.98 1.02 4.33 3.24 1.02 4.62 3.25 1.03 4.76 3.51 1.04 5.05 3.50 1.05 5.33 3.72 1.06
30 3.58 2.86 1.12 3.99 2.88 1.14 4.12 3.13 1.14 4.39 3.14 1.15 4.53 3.39 1.16 4.80 3.38 1.17 5.07 3.60 1.18
35 3.40 2.77 1.24 3.78 2.78 1.25 3.91 3.03 1.26 4.17 3.04 1.27 4.30 3.28 1.28 4.56 3.27 1.29 4.82 3.48 1.31
40 3.25 2.70 1.33 3.63 2.72 1.35 3.75 2.95 1.36 4.00 2.96 1.37 4.12 3.20 1.38 4.37 3.19 1.39 4.61 3.40 1.41
46 2.45 2.39 1.02 2.73 2.40 1.04 2.82 2.61 1.04 3.01 2.62 1.05 3.10 2.83 1.06 3.29 2.82 1.07 3.47 3.00 1.08
- 9 -
4-1. Cooling capacity 4. Capacity table
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA

¢Model: AUXG18KVLA
AFR m3/h 680
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 4.17 3.26 0.49 4.65 3.28 0.50 4.80 3.56 0.50 5.12 3.57 0.51 5.28 3.86 0.51 5.60 3.84 0.52 5.91 4.10 0.52
-10 4.20 3.28 0.41 4.68 3.30 0.42 4.84 3.59 0.42 5.16 3.60 0.43 5.32 3.89 0.43 5.64 3.87 0.43 5.96 4.13 0.44
0 3.99 3.21 0.65 4.44 3.23 0.66 4.60 3.51 0.66 4.90 3.52 0.67 5.05 3.80 0.67 5.35 3.78 0.68 5.66 4.03 0.68
5 3.91 3.18 0.69 4.36 3.20 0.70 4.50 3.48 0.70 4.80 3.49 0.71 4.95 3.77 0.71 5.25 3.75 0.72 5.54 4.00 0.72
10 4.05 3.24 0.47 4.51 3.26 0.48 4.67 3.54 0.48 4.98 3.56 0.49 5.13 3.84 0.49 5.44 3.82 0.49 5.75 4.07 0.50
15 3.92 3.20 0.58 4.36 3.22 0.59 4.51 3.50 0.59 4.81 3.51 0.60 4.96 3.79 0.60 5.26 3.77 0.61 5.56 4.02 0.61
20 4.83 3.53 1.11 5.39 3.55 1.13 5.57 3.86 1.13 5.94 3.87 1.14 6.12 4.18 1.15 6.49 4.16 1.16 6.85 4.43 1.17
25 4.59 3.39 1.25 5.11 3.41 1.27 5.29 3.71 1.28 5.64 3.72 1.29 5.81 4.02 1.30 6.16 4.00 1.31 6.51 4.27 1.33
30 4.35 3.26 1.41 4.84 3.28 1.43 5.01 3.56 1.44 5.34 3.57 1.45 5.50 3.86 1.46 5.83 3.84 1.47 6.16 4.10 1.49
35 4.11 3.12 1.54 4.58 3.14 1.57 4.73 3.42 1.58 5.04 3.43 1.59 5.20 3.70 1.60 5.51 3.69 1.62 5.82 3.93 1.63
40 3.68 3.05 1.41 4.10 3.06 1.43 4.24 3.33 1.44 4.52 3.34 1.45 4.66 3.61 1.46 4.94 3.60 1.47 5.22 3.83 1.49
46 2.58 2.58 1.05 2.87 2.63 1.07 2.97 2.86 1.07 3.16 2.87 1.08 3.26 3.10 1.09 3.46 3.09 1.10 3.65 3.29 1.11
¢Model: AUXG22KVLA
AFR m3/h 830
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 4.99 3.61 0.58 5.56 3.63 0.59 5.75 3.95 0.59 6.13 3.96 0.60 6.32 4.28 0.60 6.70 4.26 0.61 7.08 4.54 0.61
-10 5.03 3.62 0.49 5.61 3.64 0.50 5.80 3.96 0.50 6.18 3.97 0.51 6.37 4.29 0.51 6.75 4.27 0.52 7.13 4.55 0.52
0 4.91 3.57 0.50 5.46 3.59 0.51 5.65 3.90 0.51 6.02 3.92 0.52 6.21 4.23 0.52 6.58 4.21 0.53 6.96 4.49 0.53
5 4.77 3.52 0.64 5.32 3.54 0.65 5.50 3.85 0.65 5.86 3.86 0.66 6.04 4.17 0.66 6.40 4.15 0.67 6.76 4.42 0.67
10 4.74 3.51 0.62 5.28 3.53 0.63 5.46 3.84 0.63 5.82 3.85 0.64 6.00 4.16 0.64 6.36 4.14 0.65 6.72 4.41 0.65
15 4.59 3.45 0.75 5.11 3.47 0.76 5.29 3.78 0.77 5.64 3.79 0.78 5.81 4.09 0.78 6.16 4.07 0.79 6.51 4.34 0.80
20 5.77 3.94 1.33 6.43 3.96 1.35 6.65 4.31 1.36 7.09 4.32 1.37 7.31 4.67 1.38 7.75 4.65 1.39 8.19 4.95 1.41
25 5.43 3.81 1.48 6.05 3.84 1.50 6.25 4.17 1.51 6.66 4.19 1.52 6.87 4.52 1.53 7.28 4.50 1.55 7.69 4.80 1.56
30 5.08 3.69 1.62 5.66 3.71 1.65 5.85 4.03 1.65 6.24 4.05 1.67 6.43 4.37 1.68 6.82 4.35 1.70 7.20 4.64 1.71
35 4.74 3.56 1.76 5.28 3.58 1.78 5.46 3.90 1.79 5.82 3.91 1.81 6.00 4.22 1.82 6.36 4.20 1.84 6.72 4.48 1.86
40 4.50 3.45 1.90 5.01 3.47 1.93 5.18 3.78 1.94 5.52 3.79 1.96 5.69 4.09 1.97 6.03 4.07 1.99 6.37 4.34 2.01
46 3.69 3.06 1.64 4.11 3.07 1.67 4.25 3.34 1.67 4.53 3.35 1.69 4.67 3.62 1.70 4.95 3.61 1.72 5.23 3.84 1.73
- 10 -
4-1. Cooling capacity 4. Capacity table
CASSETTE TYPE AUXG09-22KVLA CASSETTE TYPE AUXG09-22KVLA
