Fujitsu ASUH30LPAS Service manual

AIR CONDITIONER
Wall mounted type
DESIGN & TECHNICAL MANUAL
INDOOR
ASUH30LPAS
ASUH36LPAS
OUTDOOR
AOUH30LPAS1
AOUH36LPAS1
DR_AS144EF_01
2021.11.26

Notices:
• Product specifications and design are subject to change without notice for future improvement.
• For further details, please check with our authorized dealer.
Trademarks
FGLair™ is trademark of Fujitsu General Limited in the United States, other countries or both.
Google Play™ is trademark of Google Inc.
App Store® is a service mark of Apple Inc., registered in the U.S. and other countries.
Copyright © 2021 Fujitsu General Limited. All rights reserved.

CONTENTS
Part 1. INDOOR UNIT...........................................................................1
1. Specifications................................................................................................2
2. Dimensions....................................................................................................4
2-1. Models: ASUH30LPAS and ASUH36LPAS .....................................................................4
3. Wiring diagrams ............................................................................................6
3-1. Models: ASUH30LPAS and ASUH36LPAS .....................................................................6
4. Capacity table................................................................................................7
4-1. Cooling capacity...............................................................................................................7
4-2. Heating capacity ..............................................................................................................9
5. Fan performance .........................................................................................10
5-1. Air velocity distributions..................................................................................................10
5-2. Airflow ............................................................................................................................11
6. Operation noise (sound pressure).............................................................12
6-1. Noise level curve............................................................................................................12
6-2. Sound level check point .................................................................................................12
7. Safety devices .............................................................................................13
8. External input and output...........................................................................14
8-1. External input.................................................................................................................15
8-2. External output...............................................................................................................17
8-3. Combination of external input and output.......................................................................19
8-4. Details of function ..........................................................................................................21
9. Group connection .......................................................................................44
10. Remote controller .......................................................................................45
10-1.Wireless remote controller ............................................................................................45
11. Function settings .......................................................................................47
11-1.Function settings by using remote controller.................................................................47
11-2.Custom code setting for wireless remote controller.......................................................56
12. Accessories.................................................................................................57
12-1.Models: ASUH30LPAS and ASUH36LPAS ..................................................................57
13. Optional parts .............................................................................................58
13-1.Controllers ....................................................................................................................58
13-2.Others ...........................................................................................................................59

Part 2. OUTDOOR UNIT.....................................................................61
1. Specifications..............................................................................................62
2. Dimensions..................................................................................................63
2-1. Models: AOUH30LPAS1 and AOUH36LPAS1 ..............................................................63
3. Installation space ........................................................................................64
3-1. Models: AOUH30LPAS1 and AOUH36LPAS1 ..............................................................64
4. Refrigerant circuit .......................................................................................68
4-1. Models: AOUH30LPAS1 and AOUH36LPAS1 ..............................................................68
5. Wiring diagrams ..........................................................................................69
5-1. Models: AOUH30LPAS1 and AOUH36LPAS1 ..............................................................69
6. Capacity compensation rate for pipe length and height difference........70
6-1. Models: AOUH30LPAS1 and AOUH36LPAS1 ..............................................................70
7. Additional charge calculation ....................................................................71
7-1. Models: AOUH30LPAS1 and AOUH36LPAS1 ..............................................................71
8. Airflow..........................................................................................................72
8-1. Models: AOUH30LPAS1 and AOUH36LPAS1 ..............................................................72
9. Operation noise (sound pressure).............................................................73
9-1. Noise level curve............................................................................................................73
9-2. Sound level check point .................................................................................................74
10. Electrical characteristics............................................................................75
11. Safety devices .............................................................................................76
12. External input and output ..........................................................................77
12-1.External input................................................................................................................77
12-2.External output..............................................................................................................79
13. Function settings .......................................................................................81
13-1.Control PCB and switch buttons location ......................................................................81
13-2.Local setting procedure.................................................................................................83
14. Accessories.................................................................................................85
14-1.Models: AOUH30LPAS1 and AOUH36LPAS1 .............................................................85
15. Optional parts..............................................................................................86
CONTENTS (continued)

Part 1. INDOOR UNIT
WALL MOUNTED TYPE:
ASUH30LPAS
ASUH36LPAS

1. Specifications
Type
Wall mounted
Inverter heat pump
Model name ASUH30LPAS ASUH36LPAS
Power supply 208/230 V ~ 60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Capacity
Cooling
Rated kW 8.79 9.67
Btu/h 30,000 33,000
Min.—Max. kW 2.90—9.50 2.90—10.00
Btu/h 9,900—32,400 9,900—34,100
Heating
Rated kW 8.79 9.96
Btu/h 30,000 34,000
Min.—Max. kW 2.55—9.67 2.55—10.26
Btu/h 8,700—33,000 8,700—35,000
Heating
(17 °F)*1
Rated kW 5.69 6.57
Btu/h 19,400 22,400
Max. kW 8.44 8.97
Btu/h 28,800 30,600
Input power
Cooling Rated
kW
3.07 4.08
Min.—Max. 0.45—4.03 0.45—4.29
Heating Rated 2.46 3.1
Min.—Max. 0.53—3.15 0.53—3.32
Heating
(17 °F)*1
Rated 1.98 2.43
Max. 4.26 4.49
Current Cooling Rated A 13.4 17.8
Heating 10.9 13.5
EER Cooling kW/kW 2.86 2.37
Btu/hW 9.8 8.1
COP Heating kW/kW 3.57 3.21
Btu/hW 12.2 11.0
SEER Cooling Btu/hW 18.0 18.0
HSPF Heating Btu/hW 11.0 11.0
Power factor Cooling %99.6 99.7
Heating 98.1 99.8
Moisture removal pints/h (L/h) 9.7 (4.6) 10.1 (4.8)
Maximum operating current*2Cooling A18.9 18.9
Heating 18.9 18.9
Fan
Airflow rate
Cooling
HIGH
CFM (m3/h)
812 (1,380) 812 (1,380)
MED 665 (1,130) 665 (1,130)
LOW 536 (910) 536 (910)
QUIET 418 (710) 418 (710)
Heating
HIGH 812 (1,380) 812 (1,380)
MED 665 (1,130) 665 (1,130)
LOW 536 (910) 536 (910)
QUIET 418 (710) 418 (710)
Type × Q'ty Crossflow fan × 1
Motor output W 78
Sound pressure level*3
Cooling
HIGH
dB (A)
50 50
MED 45 45
LOW 38 38
QUIET 32 32
Heating
HIGH 49 49
MED 44 44
LOW 38 38
QUIET 32 32
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main 1: 18-3/16 × 35-3/8 × 1-1/16 (462 × 898 × 26.6)
Sub 1: 4-15/16 × 35-3/8 × 1/2 (126 × 898 × 13.3)
Sub 2: 3-5/16 × 35-3/8 × 1/2 (84 × 898 × 13.3)
Fin pitch FPI (mm)
Main 1: 21 (1.2)
Sub 1: 18 (1.4)
Sub 2: 18 (1.4)
Rows × Stages
Main 1: 2 × 22
Sub 1: 1 × 6
Sub 2: 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net in (mm) 13-3/8 × 45-1/4 × 11 (340 × 1,150 × 280)
Gross 15-15/16 × 50 × 17-11/16 (405 × 1,270 × 450)
Weight Net lb (kg) 39 (17.5)
Gross 51 (23.0)
Connection pipe Size Liquid in (mm) Ø3/8 (Ø9.52) Gas Ø5/8 (Ø15.88)
Method Flare
Drain hose
Material PP+HDPE
Tip diameter in (mm) Ø17/32 (Ø13.8) (I.D.),
Ø19/32 to 21/32 (Ø15.0 to 16.8) (O.D.)
Operation range Cooling °F (°C) 64 to 90 (18 to 32) %RH 80 or less
Heating °F (°C) 86 (30) or less
Remote controller type Wireless (Option: Wired, Mobile app*4 [FGLair™])
- 2 - 1. Specifications
WALL MOUNTED ASUH30-36LPAS WALL MOUNTED ASUH30-36LPAS

Type
Wall mounted
Inverter heat pump
Model name ASUH30LPAS ASUH36LPAS
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 80°FDB (26.67°CDB) /67°FWB (19.44°CWB), and outdoor temperature of 95°FDB (35°CDB) / 75°FWB (23.9°CWB).
– Heating: Indoor temperature of 70°FDB (21.11°CDB) /59°FWB (15.56°CWB), and outdoor temperature of 47°FDB (8.33°CDB) /43°FWB (6.11°CWB).
– *1: Heating (17°F): Indoor temperature of 70°FDB (21.11°CDB) /60°FWB (15.56°CWB), and outdoor temperature of 17°FDB (-8.33°CDB) /15°FWB (-9.44°CWB).
– Pipe length: 25 ft (7.5 m), Height difference: 0 ft (0 m). (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *2: Maximum current is maximum value when operated within the operation range.
• *3: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *4: Available on Google Play™ store or on App Store®. Optional WLAN adapter is also required. For details, refer to the setting manual.
- 3 - 1. Specifications
WALL MOUNTED ASUH30-36LPAS WALL MOUNTED ASUH30-36LPAS

2. Dimensions
2-1. Models: ASUH30LPAS and ASUH36LPAS
Unit: in (mm)
Outline of unit
20-1/2 (520) 3-9/16 (90)
13/16 (20)
2-1/2 (64)
18-7/8 (479)2-6/16 (61)
4-1/4
(108)19-6/8 (502)
20-1/2 (520)
1-15/16 (50)
1-15/16
(50)
7/16 (11)
13-6/16 (340)
ø80
ø80
13-6/16
(340)
11 (280)
10/16
(16)
45-1/4 (1,150)
19 (483)
21-7/16 (544)
22-1/16 (560)
45-1/4 (1,150)
- 4 -
2-1. Models: ASUH30LPAS and ASUH36LPAS 2. Dimensions
WALL MOUNTED ASUH30-36LPAS WALL MOUNTED ASUH30-36LPAS

¢Installation space requirement
Provide sufficient installation space for product safety.
CAUTION
Do not place any other electrical products or household belongings under the product. Conden-
sation dripping from the product might get them wet, and may cause damage or malfunction to
the property.
2-1/2 (63)
or more
3-8/1 (80)
or more
1-15/16 (50)
or more
1-15/16 (50)
or more
2-3/4 (70)
or more
Outline of unit
5-1/2 (140)
or more
59-1/16 (1,500) or more
70-7/8 (1,800) or more
Unit: in (mm)
- 5 -
2-1. Models: ASUH30LPAS and ASUH36LPAS 2. Dimensions
WALL MOUNTED ASUH30-36LPAS WALL MOUNTED ASUH30-36LPAS

3. Wiring diagrams
3-1. Models: ASUH30LPAS and ASUH36LPAS
- 6 -
3-1. Models: ASUH30LPAS and ASUH36LPAS 3. Wiring diagrams
WALL MOUNTED ASUH30-36LPAS WALL MOUNTED ASUH30-36LPAS
