AMILO Notebook Li 3710
Your entry into mobile computing
DATA SHEET
Issue: October 2009
Enter the world of mobile home computing, surf the Internet, write e-mails or watch
DVDs - the AMILO Notebook L Series offers you reliable devices for your everyday
tasks and more.
Processor technology
Intel®mobile processor technology with Intel®Celeron®(singel or dual-core) or
Intel®Pentium®(dual-core) processors for great performance – wherever you are
Operating System
Windows®7 Home Basic, Home Premium or Professional
Entertainment and Multimedia
Enjoy your favorite Hollywood blockbuster on the 16:9 HD LCD display with
BrilliantView technology for vivid colors, amazing sharpness and impressive
contrast
The integrated AMILOcam with low-light technology for great video-quality even
in low-light conditions and a built-in microphone are perfect for Internet telephony
(VoIP) and video chats
Mobile technology
Integrated Wireless LAN to go online when and wherever you are
More convenience thanks to
The spill-proof keyboard that protects your notebook against accidentially spilt
liquids
The silent mode function that causes a noticeable reduction in fan noise
The built-in DVD drive to store and secure data comfortably on the move

Hard disk drives (internal) 500 GB, 5400 rpm, SATA, 2.5-inch, HDD cache: 8 MB, S.M.A.R.T.
320 GB, 5400 rpm, SATA, 2.5-inch, HDD cache: 8 MB, S.M.A.R.T.
250 GB , 5400 rpm, SATA, 2.5-inch, HDD cache: 8 MB, S.M.A.R.T.
160 GB, 5400 rpm, SATA, 2.5-inch, HDD cache: 8 MB, S.M.A.R.T.
Hard disk notes Hard disk capacity depends on exact conguration. Please check at your local retailer.
One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.
Optical drives
Optical drive technology SuperMulti-format DVD burner with double layer (DL) suport)
Interface type SATA
Optical drive read speed CD-ROM 24x, DVD-ROM 8x
Optical drive write speed CD-R 24x, CD-RW 16x, DVD+R 8x, DVD-R 8x, DVD+RW 8x, DVD-RW 6x, DVD+R DL
(8.5 GB) 6x, DVD-R DL (8.5 GB) 6x, DVD-RAM 5x
Display
Base unit name AMILO Li 3710 (40.6 cm / 16”) AMILO Li 3710 (39.6 cm / 15.6”)
Display Technology BrilliantView LCD BrilliantView LCD
Diagonal Size 40.6 cm (16-inch) 39.6 cm (15.6-inch)
Aspect ratio 16:9 16:9
Display Resolution type HD HD
Resolution (native) 1366 x 768 pixel 1366 x 768 pixel
Response time typical 16 ms 16 ms
Brightness - typical 200 NIT 220 NIT
Contrast - typical 600 : 1 400 : 1
Battery
Battery type Li-Ion battery 6-cell
Battery voltage 10.8 V
Battery capacity 2200 mAh
Battery runtime (idle mode) Up to 3:10 hours
Battery runtime (DVD playback) Up to 1:50 hours (depending on usage)
Battery charging time (idle mode) Up to 1:40 hours
Battery charging time (maximum
active mode)
Up to 1:50 hours (depending on usage)
Battery charging time (normal use) Up to 2:20 hours (depending on usage)
Battery charging time (off mode) Up to 1:40 hours
Components
Processor Intel®Pentium®processor T4300 (2.1 GHz, 1 MB, 800 MHz)
Intel®Pentium®processor T4200 (2.00 GHz, 1 MB, 800 MHz)
Intel®Celeron®processor T3000 (1.80 GHz, 1 MB, 800 MHz)
Intel®Celeron®processor 900 (2.20 GHz, 1 MB, 800 MHz)
Processor notes Processor depends on exact conguration. Please check at your local retailer.
Memory modules
4 GB (2 module(s) with 2 GB, DDR2), 667 MHz
3 GB (2 module(s) with 1 GB and 2 GB, DDR2), 667 MHz
2 GB (2 module(s) with 1 GB, DDR2), 667 MHz
2 GB (1 module(s) with 2 GB, DDR2), 667 MHz
1 GB (1 module(s) with 1 GB, DDR2), 667 MHz
Supported capacity RAM (min.) 1 GB
Supported capacity RAM (max.) 4 GB
Memory slots total 2
Memory slot type SO DIMM (DDR2, 667 MHz)
Memory notes Memory size depends on exact conguration. Please check at your local retailer.
Disclaimer: Up to 1 GB may not be available with 32-bit operating systems due to system
resource requirements if system is preinstalled with 4 GB RAM

Battery notes Battery life may vary depending on product model, conguration, applications, power
management settings and features utilized. Battery recharge time varies depending
on usage. The recharge capacity may decrease after some months so that the battery
lifetime as well as operating time can not be assured for the whole lifetime of the
notebook.
Battery runtime (idle mode) tested with Battery Mark 4.0.1 (“power saver mode”).
Battery runtime (DVD playback) tested with Vista DVD playback.
Battery charging time (DVD playback) tested with Vista DVD playback (0% to 90%).
Battery charging time (normal use) tested with 3DMark 2003.
AMILO Notebook Li 3710
Operating system
Operating system compatible Genuine Microsoft®Windows®7 Professional 32-bit
Genuine Microsoft®Windows®7 Home Premium 32-bit
Genuine Microsoft®Windows®7 Home Basic (EM) 32-bit
Genuine Microsoft®Windows Vista®Business 32-bit
Genuine Microsoft®Windows Vista®Home Premium 32-bit
Genuine Microsoft®Windows Vista®Home Basic 32-bit
no operating system
Recovery application Backup and restore the original status of the hard disk and create system restore disks or
individual recovery media on CD or DVD are included
Drivers Updates downloadable at http://ts.fujitsu.com/support
Operating system notes If system is shipped without operating system, there is no additional application software
preinstalled.
Product design
Color Eclipse black
General system information
System architecture Intel®mobile processor technology
Chipset Intel®GL40, ICH 9-M
Graphics
Onboard graphics processor Mobile Intel®Graphics Media Accelerator 4500M
Shared video memory up to 1759 MB
3D Benchmark points Approx. 600 (3DMark 2006, depending on conguration)
Max. resolution external display 1920 x 1200 pixel (WUXGA) for a 16:10 display; 2048 x 1536 pixels (QXGA) for a 4:3
display.
Graphics features DirectX®10 support
Graphics notes Shared video memory size may vary depending on conguration and the version of the
operating system. The video memory size that is displayed in the system information
software, as well as the actually used video memory size depends on Microsoft®Windows
Vista®memory management. The following values might serve as orientation.
- 1024 MB system memory enables up to 253 MB total video memory (dedicated pluas
shared memory).
- 2048 MB system memory enables up to 765 MB total video memory (dedicated pluas
shared memory).
- 3072 MB system memory enables up to 1277 MB total video memory (dedicated pluas
shared memory).
- 4096 MB system memory enables up to 1759 MB total video memory (dedicated pluas
shared memory).
Interfaces
DC-in 1
Audio: line-in 1
Audio: line-out / headphones /
SPDIF
1
Audio: microphone in 1
Internal microphones 1
USB 2.0 total 3
VGA 1
Ethernet (RJ-45) 1
Memory card slots 1x 13-in-1 card reader (supported formats: MS, SD, miniSD, MicroSD, MMC, RS-MMC,
MMC-Micro, Mobile MMC, MSPRO, MS-Duo, MS-PRO Duo, MS-Pro HG Duo, M2)
Express card slots 1 (34/54 mm)
Kensington Lock support 1

Interfaces
Interface Module notes Card reader: An adapter is needed for the following card formats: RS-MMC, MMC-Micro,
Mobile MMC, miniSD, MicroSD, MS-Duo, MS-PRO Duo, MS-Pro HG Duo, M2
Communication
LAN type Ethernet (10/100 Mbit/s)
WLAN Built-in WLAN (Wireless Local Area Network)
WLAN (optional)
WLAN name WLAN (IEEE 802.11b/g)
WLAN max. data rate up to 54 Mbit/s
WLAN encryption WEP, WPA, WPA2
WLAN notes For use in: BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI, LV, LT, LU, MT, NL, NO, PL, AT,
PT, SE, SK, ES, CZ, HU, UK, CY
Audio
Audio type On board
Audio codec Realtek ALC662-GR
Audio features Support of high-denition audio for S/PDIF output with up to 7.1 channels
2x built-in speakers (1 W each)
Internal microphone
Sound volume control via function key
Camera
Camera VGA webcam
Frame rate 30 per second
Camera features Automatic brightness adjustment with status LED (blue: on, red: streaming / application
on)
Low-light technology for great video-quality even in dark surrounding
Camera notes AMILOcam frame rate can vary signicantly depending on the used software application.
Input devices / Control buttons
Power Button Located left of the keyboard, back-lighted
Keyboard Spillproof keyboard
Number of keyboard keys 85
Keyboard notes The keyboard is spill-proof up to 50ml. This is enough to protect your notebook from an
accidental spill. However, we recommend a backup as well as a system shut-down should
liquids come into contact with the keyboard. The spill-proof protection does not prevent
data loss caused by water damage. If this should happen, please contact your local
customer service desk.
Input device(s) Hidden touchpad, with left and right mouse button, touchpad disable function via function
key combination (Fn+F6)
Hot keys
Hot key Fn+F1 WLAN on / off
Hot key Fn+F3 Mute on / off
Hot key Fn+F4 Volume down
Hot key Fn+F5 Volume up
Hot key Fn+F6 Touchpad on / off
Hot key Fn+F7 AMILOcam on / off
Hot key Fn+F8 Brightness down
Hot key Fn+F9 Brightness up
Hot key Fn+F10 Display switch
Hot key Fn+F11 Silent mode
Hot key Fn+F12 Suspend

Status indicators
Status indicators The notebook has 3 status LEDs
Power status (& suspend)
Blue (always on): on
Blue blinking: stand by
None: off
Battery charge
Blue (always on): full
Blue blinking: charging
Red blinking: < 10 % capacity
WLAN
Blue: on
None: off
Power supply
AC adapter 20 V / 65 W (3.25 A)
Rated voltage range 110 - 240 V (AC Input)
Rated frequency range 50 - 60 Hz
Battery features ACPI 3.0 supported;
Dynamic charge supported (rapid charge)
Energy consumption
S0 (idle mode) 22.4 W
S0 (max. active mode) 56.4 W (depending on usage)
S3 (stand by / energy saving
mode)
0.36 W
S4 (hibernate) 0.2 W
S5 (off mode) 0.08 W
ACPI functions ACPI 3.0 compliant for Vista requirement
Power on stand by (S1 LCD off)
Stand by / energy saving mode (S3 save to RAM)
Hibernate mode (S4 save to disk)
Off mode (S5 soft off)
Energy consumption notes Maximum active mode tested with 3DMark 2003
Noise emission
Idle mode 28 dB(A) (silent mode off)
Maximum active mode 35 dB(A) (silent mode off, no ODD activity)
Noise notes / description Noise emission tested according to ISO 7779 and ISO 9296.
Dimensions / Weight / Environmental
Dimension (W x D x H) 380 x 245 x 24.8 (front) / 37.4 (back) mm
Weight Approx. 2.67 kg
Weight notes Weight may vary depending on actual conguration
Operating ambient temperature 5 - 35°C
Operating relative humidity 10 - 90 % (relative humidity, non-condensing)
Compliance
Europe CE Marking
R&TTE (WLAN)
Global RoHS (Restriction of hazardous substances)
Russia GOST (WLAN)
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
Application software
Home ofce software Microsoft® Ofce Ready (60-day trial version for Microsoft® Ofce Professional software
package, only with Windows®7 operating system)
Microsoft®Works (only with Windows Vista®operating system)
Microsoft® Ofce Home and Student Trial (60-day trial version, only with Windows Vista®
operating system)
Adobe Acrobat Reader
Windows Mail (only within Windows Vista®operating system)
Windows Calendar (only within Windows Vista®operating system)

Application software
Multimedia software Nero Essentials S (burning software)
Vista DVD Playback Pack (DVD playback software, only within Windows Vista®operating
system)
Windows Media Player (playback of music CDs and Video DVDs)
Internet software Microsoft®Internet Explorer
Country specic Internet provider
Security software Norman security software solution
Additional software (optional) Windows Media Center edition (optional)
- Share and stream media easily in your home network
- Organize media (videos, music, pictures)
- Watch and record TV shows
(For certain aspects of Windows Media Center functionality, a TV tuner and
additional hardware may be required. To watch Internet TV, Internet access is
required. Free Internet TV content varies by geography.
Some content may require additional fees.)
Security
Physical security Kensington Lock support
Lid switch (hidden)
User security User and supervisor password
Warranty
Standard Warranty 1 year / 2 years (depending on country)
Service level Collect & Return Service / Bring in (depending on county specic requirements)
Maintenance and Support Services - the perfect extension
Recommended Service 3 years, Collect & Return Service
Spare Parts availability 3 years
Service Weblink http://ts.fujitsu.com/Supportservice
Accessories
Accessories included AC adapter 65 W
First Battery 6 cells
Manuals (manual on hard disk, quick start guide, safety guide, warranty guide, recovery
guide)
Accessories link http://ts.fujitsu.com/accessories
Information about environmental care, policies, programs and our Environmental Guideline FSC 03230:
http://ts.fujitsu.com/aboutus
Take back and Recycling information:
http://ts.fujitsu.com/recycling
All rights reserved, including intellectual property rights. Changes to technical data reserved.
Delivery subject to availability. Any liability that the data and illustrations are complete, actual or
correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of
which by third parties for their own purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.com/terms_of_use.html
Copyright © Fujitsu Technology Solutions October 2009
Published by
Fujitsu Technology Solutions
http://ts.fujitsu.com
