Fujitsu Lifebook A1110 Guide User manual

The A1110 is designed to deliver excellent performance and best-in-class reliability
at a very affordable price.
LifeBook®A1110 Notebook
BENEFITS
Easy to Own
There are two ways of approaching your note-
book investment. One is to purchase a low cost
unit, but the savings are generally eaten up by the
maintenance costs and the hassle of dealing with
a poorly constructed substandard notebook. On
the other hand, high-quality units may cost a little
more, but the maintenance costs are lower be-
cause the reliability is signicantly higher. What
if you could purchase a high-quality notebook at
a reasonable price? The best of both worlds just
became a reality with the affordable LifeBook®
A1110 notebook.
The old adage, “you get what you pay for”
certainly applies in the highly competitive world
of notebook computers. Now the upfront costs of
top quality notebooks just became less. Designed,
engineered, and manufactured in Japan (leader
in quality and reliability) the Fujitsu A1110 Life-
Book notebook provides you an easy way to cut
costs without cutting performance or reliability.
Performance
With its high-speed Intel®Core™ 2 Duo Pro-
cessor, the Fujitsu A1110 LifeBook notebook
provides all the computing power you will ever
need, even for the most demanding applications.
The Fujitsu A1110 LifeBook comes standard
with a Dual-Layer, Multi-format DVD writer.
The Dual-layer DVD-R or RW technology lets
you record up to 8.5 GB of data on a single disc.
This nearly doubles the standard DVD capacity
of 4.7 GB. In other words, a Dual-layer DVD-R/
RW disc will hold up to 4 hours of DVD quality
video or 16 hours of VHS quality video. Dual-
layer discs can also be read on DVD players that
were originally designed for single-layer discs.
Of course you can listen to your CDs and write to
CD-Rs as well.
Personalize your notebook
A variety of Color Lids are available for your
A1110 LifeBook notebook. They can protect your
computer from scratches while giving your note-
book a personalized look. A unique cover will
also make your notebook less of a target for theft.
Who would want to take a personal computer that
would be so easy to spot?
Flexible Connectivity
With both 56K modem and Ethernet LAN
built-in, you can easily connect to your ofce
network and the Internet at home or at work. For
wireless connectivity, the built-in Intel WiFi Link
5100 (802.11AGN) or Atheros XSPAN®BGN
(802.11BGN) wireless offers you a seamless and
exible way to stay in touch using transfer rates
as high as 108 Mbps. The webcam adds a fun
(and very useful) dimension to staying in touch
with family and friends. Bluetooth is also avail-
able on select congurations providing a way to
transmit stereo CD quality sound to Bluetooth
headphones or Bluetooth speakers.
Stable and Reliable
The LifeBook A1110 delivers all the key features
that have contributed to Fujitsu LifeBook note-
books being named some of the most reliable in
the industry. The new LifeBook A1110 notebook
also features a strong exterior, highly durable
hinges, and a spill-resistant keyboard. It also
comes with an easily accessible embedded dust
lter. This allows maximum airow to keep your
notebook running as cool as it looks.
In a time when most PCs are assembled by
third-party vendors, Fujitsu takes pride in its own
world-class design, rigorous testing, and manu-
facturing capabilities. Fujitsu provides extremely
high quality mobile computers with one of the
lowest failure rates in the industry.
OVERVIEW
Designed, engineered, and manufactured•
in Japan (Industry leader in performance
and reliability)
High speed and energy efficient Intel Core 2•
Duo Processor
Standard spill resistant keyboard offers•
protection against damage caused by
accidental spills.
Accessible embedded dust filter allows periodic•
cleaning to keep dust and lint from blocking the
vents, prolonging operational life
Fast and long range 802.11N wireless•
Dual Layer DVD-RW for playing DVDs or 8.5 GB•
of storage for your movies or data
ExpressCard• ®slot for durable expansion
flexibility
SD card slot and USB ports to easily transfer•
pictures and files
Removable color lid lets you make a•
personal statement

LifeBook®S2000 Notebook
Spill
Resistant
Keyboard
Software
Operating Systems Genuine Windows Vista®Home Premium, 32bit or 64bit) with Microsoft®Works 9.0 and
Microsoft®Office 2007 60-Day Trial (Home & Student)
(Service Pack 1)
Software Adobe Acrobat Reader®, ArcSoft Webcam Companion, Norton Internet Security™1
Roxio Easy Media Creator, CyberLink MakeDisc, CyberLink PowerDirectorDE,
CyberLink PowerDVD, LifeBook Application Panel, Fujitsu Driver Update utility (32 bit OS),
Microsoft Works 9.0 with Microsoft Office, Home and Student Trial Edition 2007
Key Specications
Listed specications are for the current model only and NOT for earlier models or revisions to this product.
Processor Intel®Core™ 2 Duo Processor P7350 (2GHz, 3MB L2 cache,1066 MHz FSB)
Intel®Core™ 2 Duo Processor T5800 (2GHz, 2MB L2 cache, 800 MHz FSB)
Chipset Intel®GM45 Express Chipset
Memory 4 GB Max (2 GB x 2): DDR2 800 SDRAM dual-channel memory
Webcam One 1.3 megapixel with digital microphone
Display LCD 15.4" Active Matrix Crystal View WXGA
Video Intel®Graphics Media System Memory Max Graphics Memory
Controller Accelerator 4500MHD 32 -bit 64-bit
video graphics, with the 1 GB 271 MB 271 MB
following amounts of 2 GB 783 MB 783 MB
shared video memory 3 GB 1,295 MB 1,295 MB
using Dynamic Video 4 GB 1,295 MB 1,759 MB
Memory Technology
(DVMT), as determined
by the amount of
system memory:
Resolution Internal Display: Max. 1280 x 800, 16M colors
External Only: 1600 x 1200, 16M colors
Simultaneous: Max. 1280 x 768, 16M Colors
Hard Drive2320 GB or 250 GB Serial ATA 5400 rpm hard drive
Optical Drive Dual-Layer Multi-Format DVD Writer: 24x CD-ROM, 24x CD-R, 10x CD-RW, 8x DVD-ROM, 5x
DVD-RAM, 8x DVD-R, 4x DVD-R (DL), 6x DVD-RW, 8x DVD-R, 4x DVD-R (DL), 8x DVD-RW
Audio Realtek®codec ALC269 with 2-channel High Definition (HD) audio.
Communication Multinational356K4V.92 modem, Ethernet
Wireless Communication Intel®WiFi Link 5100 (802.11AGN) or Atheros XSPAN®BGN (802.11BGN) wireless;
Bluetooth wireless v2.1 on select configuration
User Interfaces 86-key full-size, Spill-resistant keyboard with 19 mm key pitch and 2.7 mm key stroke,
Integrated gesture enabled touchpad pointing device
Ports One 15-pin D-SUB connector for VGA external monitor
Three USB 2.0 (Universal Serial Bus) connectors for input/output devices
One DC In connector
One modular modem (RJ-11) connector
One LAN (RJ-45) connector
One stereo headphone/line-out jack
One stereo microphone/line-in jack
Card Slots ExpressCard®slot for one ExpressCard®
SD Card slot for one SD Card
Battery5Lithium ion battery, rechargeable, 6-cell, 10.8V, 4000 mAh, 41.0 Wh; up to 2 hours
and 30 minutes
AC Adapter Auto-sensing AC100-240V, Output: 19V, 4.22A, 80W
Dimensions/Weight 14.56"(w) x 10.43"(d) x 1.65"/1.85"(h) approx. weight 6.28 lbs. with battery and optical drive.
Operating Temperature 41°F to 95°F / 5°C to 35°C (ambient temperature); 20% to 85% relative humidity,
non-condensing
Non-Operating Temperature 5°F to 140°F / -15°C to 60°C, 8% to 85% relative humidity; non-condensing
Key Accessories For a full list of accessories, visit www.shopfujitsu.com or call 1-800-FUJITSU
Compliance and Service Information
Compliance FCC Part 15B Class B and FCC Part 15C; FCC Part 15E; IC ICES-003 Class B and RSS-210
UL-cUL Listed
FCC Part 68; IC CS-03
CE Marking (Not supported when configured with the WLAN module)
ExpressCard™ Compliance ID EC100297
CB Generic Report
Warranty6One- or three-year International Limited Warranty on select corporate configurations;
24/7 technical support; Fujitsu extended service plans available.
Fujitsu Computer Systems Corporation
Enterprise Sales:
1.800.831.3183
us.fujitsu.com/computers
Consumer Sales (24/7):
1.800.FUJITSU
www.shopfujitsu.com
1) Preinstalled with a free 90-day trial version of
Symantec Norton Internet Security 2008. The 90-day
trial version is activated upon user’s acceptance of
software license agreement. After 90 days, the
user must purchase a subscription from Symantec to
download latest virus definitions.
2) One gigabyte (GB) = one billion bytes; accessible
capacity will be less and actual capacity depends on
the operating environment and formatting.
3) The internal modems on all Fujitsu notebooks
from Fujitsu Computer Systems Corporation are only
qualified for use with telephone systems in selected
countries, including the United States and Canada.
For a list of certified countries, please check
http://www.computers.us.fujitsu.com/modems.
4) Actual speeds over U.S. telephone lines vary, and are
less than 56 Kbps due to the current FCC regulations
and line conditions.
5) Battery life estimates reflect the results of BAPCo
MobileMark2007 Productivity Workloads performed
upon systems with battery life setting enabled. Actual
battery life will vary based on screen brightness,
applications used, features selected, power
management settings, battery conditioning, and other
customer preferences. LAN, wireless LAN or hard
drive usage may also have a significant impact on
battery life.
6) Service and warranty turnaround time may vary
by country and product. International warranty valid
only for products purchased in North, Central, and
South America.
Fujitsu, the Fujitsu logo, and LifeBook are registered
trademarks of Fujitsu Limited. Centrino, Intel, Pentium,
Intel Core Duo, the Centrino logo and the Intel logo are
trademarks or registered trademarks of Intel
Corporation or its subsidiaries in the United States
and other countries. Atheros Super AG is a registered
trademark of Atheros Communications, Inc. Microsoft,
Genuine Windows Vista, and Windows are either
registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other
countries. Adobe Acrobat Reader is a registered
trademark of Adobe Systems, Inc. The ExpressCard
wordmark and logo are owned by PCMCIA and any
use of such marks by Fujitsu Computers Corporation
is under license. All other trademarks mentioned
herein are the property of their respective owners.
Product description data represents Fujitsu design
objectives and is provided for comparative purposes;
actual results may vary based on a variety of factors.
Specifications are subject to change without notice.
©2009 Fujitsu Computer Systems Corporation.
All rights reserved. FPC58-4366-04 1/09.
09.0006
LifeBook A1110 Notebook
