Fujitsu P1630 - LifeBook Tablet PC User manual

With its feather-light weight, innovative bi-directional hinge, and versatile touch screen
display, the LifeBook ®P1630 notebook is one of the most compelling mobile computing
products on the market today. This ultra-portable tablet computer offers dual-core
power and the convenience of a notebook with the unique versatility to handle
special-purpose applications that are best suited for a slate tablet.
LifeBook®P1630 Notebook
BENEFITS
Versatile Design
The LifeBook P1630 notebook is one of the
most versatile mobile computing products ever
designed for the highly mobile professional.
Its compact size, extreme light weight (just
over two pounds), innovative touch screen
technology, and ability to easily convert from
a standard notebook to a slate tablet makes it
a “must-have” for on-the-go computing. You
can effortlessly transform a standard notebook
into a slate tablet conguration by rotating and
folding down the screen. Navigate through
forms-based or menu-driven applications with
the included stylus. For entering data using the
keyboard, simply rotate the screen and tilt it
up into a notebook conguration.
Boundless Connectivity
Being able to conduct business in real time is
crucial for maximum productivity. You need
to have access to business-critical resources
at all times regardless of your geographical
location. The LifeBook P1630 notebook lets
you access your ofce network or the Internet
with ease. The optional Intel®Wireless Wi-Fi
Link 5300 with Intel®Next-Gen Wireless-N is
the ideal solution, delivering high throughput,
enhanced wireless connectivity, and expanded
enterprise security. Using the optional Atheros
XSPAN®Wireless LAN (802.11a/b/g/draft-n),
users get great throughput, a steady signal, and
few drop-outs. The LifeBook P1630 notebook
gives you all the options you need to stay con-
nected. With excellent connectivity and data
transfer rates, the built-in diversity antenna
lets you take full advantage of being wireless.
Mobile Performance
With its high-performance, yet energy-
efcient dual-core Intel®Core™ 2 Ultra-Low
Voltage SU9300 Processor, and the full
power and full functionality of Windows®,
the LifeBook P1630 notebook delivers big
when it comes to mobile productivity in a
small package.
No Compromises
Just because it’s light and compact doesn’t
mean that it’s saddled with compromises. In
fact, the LifeBook P1630 notebook has more
features and functionality than any full-sized
Netbook or Ultra-Mobile PC on the market
today. Larger devices are generally too heavy
and bulky for practical, on-your-feet computing.
Most small Netbooks and UMPCs devices
also come with performance compromises;
not so with the LifeBook P1630 notebook.
You get the best of both worlds–extraordinary
portability, a touch screen display, keyboard/
pen driven input, full Genuine Windows®
operating system, ample processing power,
long battery life6, integrated ngerprint
biometrics, and industry standard ports/card
slots like PCMCIA and Secure Digital. For a
complete desktop work space, the Fujitsu Port
Replicator allows for quick and easy docking
and undocking to all your desktop peripherals
with the push of a single lever. Ideal for
the ofce and the home, it allows for true
drop-and-dock desktop convenience.
Quality and Reliability
The close integration of Fujitsu design,
manufacturing, and service creates some
of the highest quality products offered in the
PC market. In a time when most PCs are
assembled by third-party vendors, Fujitsu
takes pride in its own world-class design
and manufacturing capabilities.
OVERVIEW
Available with Genuine Windows Vista• ®
Business, and can also be downgraded to
Microsoft®Windows®XP Professional,
or Microsoft®Windows®XP Tablet PC
operating systems
Intel• ®Core™ 2 Duo Processor Ultra-Low
Voltage SU9300
Intel• ®GS45 chipset
8.9" WXGA display with touch screen•
Bi-directional hinge•
Biometric fingerprint swipe sensor with•
pre-boot authentication
Webcam and Digital microphone•
Optional Bluetooth•
Choice of Intel• ®Wireless Wi-Fi Link
5300AGN (802.11a/b/g/draft-n) or Atheros
XSPAN®WLAN (802.11a/b/g/draft-n)
Choice of 3 or 6-cell batteries for•
long battery life
Bundled with EverNote• ®Plus or OneNote®
2007

LifeBook®S2000 Notebook
Software
Operating Systems Genuine Windows Vista®Business, Downgrade Service
(Note: Downgrade service to either Genuine Windows®XP Tablet PC Edition 2005 or
Genuine Windows®XP Professional. Systems include both Genuine Windows Vista®
Business and Genuine Windows®XP recovery disc and utility. Requires intent to
purchase an annual volume of 25 units).
Genuine Windows Vista®Business, Bonus Media
(Note: Systems with Genuine Windows Vista®Business preinstalled will include
Genuine Windows Vista®Business and Genuine Windows®XP recovery disc and utility).
Software Adobe Acrobat®Reader, Norton Internet Security™ 20081, OmniPass Fingerprint
application, Fujitsu Driver Update utility, Evernote®Plus, Portshutter™ Data Leak
Prevention Software, Arcsoft Webcam Companion
Optional Software
Genuine Windows Vista
®
Genuine Windows
®
XP Genuine Windows
®
XP
Depending on your Business: Tablet PC Edition 2005: Professional:
operating system and
OneNote
®
2007, Bluetooth OneNote
®
2007, Bluetooth ritePen
®
, Bluetooth Utility
configuration, you may Utility Utility
also receive: Note: Optional software may require an external optical drive.
Key Specications
Listed specications are for the current model only and NOT for earlier models or revisions to this product.
Processor Intel®Core™ 2 Duo Processor Ultra-Low Voltage SU9300 (1.20 GHz, 3 MB L2 cache,
800 MHz FSB)
Chipset Intel®GS45 Express chipset
System Memory DDR2-667 MHz SDRAM dual-channel memory module.
One DIMM slot; upgradeable to 2 GB of total memory.
Digitizer Resistive (Passive)
Display LCD 8.9" Wide XGA touch screen display
Video
Intel
®
Graphics Media Accelerator 4500HD video graphics. Up to 384 MB
Controller shared video memory using Dynamic Video Memory Technology (DVMT)
Resolution Internal display (max.): 1,280 x 768 pixel resolution, 16M colors
External monitor display: 1,280 x 1,024 pixel resolution, 16M colors
Simultaneous display resolution: 1,280 x 800 pixel resolution, 16M colors
Hard Drive2 80 or 120 GB (5,400 rpm), S-ATA 150; Shock-mounted; further protected by Fujitsu Shock
Sensor Utility hard drive protection system; or 64 GB Flash-Based Solid State Drive
Webcam Integrated Webcam (1.3 Mega-Pixels)
Audio Realtek ALC269 with high Definition (HD) audio
Stereo and headphone/line-out jacks
Stereo Microphone/line-in jack
Internal digital microphone
Communication Multinational356K4V.92 modem; 10/100/1000 Gigabit Ethernet LAN
Wireless Communication Choice of Intel®Wireless Wi-Fi Link 5300AGN (802.11a/b/g/draft-n), or, Atheros
XSPAN®, Optional Bluetooth 2.1 for wireless personal area network communication
User Interface StickPoint by Alps, 82-key keyboard with 16 mm key pitch; 2 mm key stroke
Ports One 15-pin D-SUB connector for VGA external monitor (see Display specifications)
Two USB 2.0 (Universal Serial Bus) connectors for input/output devices
One DC In connector
One LAN (RJ-45) connector
One modem (RJ-11) connector
Docking port (80-pin, to dock with port replicator)
One stereo headphone jack
One stereo microphone/line-in jack
Card Slots One Type I/II PCMCIA slot
One Secure Digital (SD) Card slot
Security Platform Integrated Fingerprint Sensor with pre-boot authentication
Smart Card ready (via PCMCIA card slot; third-party software and Smart Card holder required)
Embedded Trusted Platform Module (TPM) 1.2
Two-level hard drive and BIOS password protection
Computrace BIOS Persistence Module5
Security lock slot
Battery6Standard Lithium ion (3-cell, 10.8V, 2600 mAh, 28 WHr); up to 3 hours
High-Capacity Lithium ion (6-cell, 10.8V, 5200 mAh, 56 WHr);
up to 6 hours and 15 minutes
AC Adapter Autosensing dual voltage support, 100-240V AC supplying 16V DC 3.75A
Dimensions/Weight 9.13" x 6.57" x 1.36" Approximately 2.2 lbs. with a 3-cell battery
9.13" x 7.32" x 1.36" Approximately 2.5 lbs. with a 6-cell battery
Operating Temperature 41°F to 95°F / 5°C to 35°C (ambient temperature); 20% to 85% relative humidity,
non-condensing
Non-operating Temperature 5°F to 140°F / -15°C to 60°C, 8% to 85% relative humidity; non-condensing
Key Accessories Port replicator with two USB 2.0, external monitor, Ethernet (RJ-45), and DC-in,
External USB Dual-Layer DVD Writer,
External USB DVD/CD-RW combo drive
For a full list of accessories, visit www.shopfujitsu.com or call 1-800-FUJITSU
Service & Regulatory Information
Compliance FCC Part 15B Class B and FCC Part 15C, FCC Part 15E;
IC ICES-003 Class B and RSS-210
UL-cUL Listed
FCC Part 68; IC CS-03
Warranty7One- or three-year International Limited Warranty on select corporate configurations;
24/7 technical support; Fujitsu extended service plans available.
Fujitsu Computer Systems Corporation
Enterprise Sales:
1.800.831.3183
us.fujitsu.com/computers
Consumer Sales (24/7):
1.800.FUJITSU
www.shopfujitsu.com
1) Preinstalled with a 90-day trial version of Symantec
Norton Internet Security 2007. The 90-day trial version
is activated upon user's acceptance of software license
agreement. After 90 days, the user must purchase a
subscription from Symantec to download latest
virus definitions
2) one gigabyte (GB) = one billion bytes; accessible
capacity will be less and actual capacity depends on
the operating environment and formatting.
3) The internal modems on all Fujitsu notebooks
from Fujitsu Computer Systems Corporation are only
qualified for use with telephone systems in selected
countries, including the United States and Canada.
For a list of certified countries, please check
http://www.computers.us.fujitsu.com/modems.
4) Actual speeds over U.S. telephone lines vary, and are
less than 56Kbps due to the current FCC regulations
and line conditions.
5) Requires Computrace or LoJack for Laptops service.
6) Battery life estimates reflect the results of BAPCo
MobileMark2007 Productivity Workloads performed
upon systems with battery life setting enabled.
Actual battery life will vary based on screen
brightness, applications used, features selected,
power management settings, battery conditioning,
and other customer preferences. DVD/CD-RW, DVD
Writer, LAN, wireless LAN or hard drive usage may also
have a significant impact on battery life.
7) Service and warranty turnaround time may vary by
country and product. The International warranty is only
valid for products purchased in North, Central, and
South America.
Fujitsu, the Fujitsu logo, and LifeBook are registered
t r a d e m a r k s o f F u j i t s u L i m i t e d . P o r t s h u t t e r i s a t r a d e m a r k
or registered trademark of Fujitsu Software
Technologies Limited in the United States and other
countries. Centrino, Intel, Intel Core, the Centrino
logo and the Intel logo are trademarks or registered
trademarks of Intel Corporation or its subsidiaries in
the United States and other countries. Microsoft,
Windows, Windows Vista, and OneNote are either
registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other
countries. Atheros and XSPAN are trademarks or
registered trademarks of Atheros Communications.
Inc. Evernote and ritePen are trademarks or registered
trademarks of EverNote Corporation in the United
States and other countries. Adobe Reader is a
registered trademark of Adobe Systems, Inc. All
other trademarks mentioned herein are the property
of their respective owners. Product description data
represents Fujitsu design objectives and is provided for
comparative purposes; actual results may vary based
on a variety of factors. Specifications are subject to
change without notice.
© 2008 Fujitsu Computer Systems Corporation.
All rights reserved. FPC65-4374-01 10/08.
08.1047
LifeBook P1630 Notebook
