Fujitsu Lifebook C1320D Quick start guide

1
C Series BIOS
BIOS SETUP UTILITY
The BIOS Setup Utility is a program that sets up the
operating environment for your notebook. Your BIOS
is set at the factory for normal operating conditions,
therefore there is no need to set or change the BIOS’
environment to operate your notebook.
The BIOS Setup Utility configures:
■Device control feature parameters, such as changing
I/O addresses and boot devices.
■System Data Security feature parameters, such
as passwords.
Entering the BIOS Setup Utility
To enter the BIOS Setup Utility do the following:
1. Turn on or restart your notebook.
2. Press the [F2] key once the Fujitsu logo appears
on the screen. This will open the main menu
of the BIOS Setup Utility with the current
settings displayed.
3. Press the [RIGHT ARROW] or [LEFT ARROW] key
to scroll through the other setup menus to review or
alter the current settings.
Navigating Through The Setup Utility
The BIOS setup utility consists of seven menus; Main,
Advanced, Security, Power, Boot, Info and Exit. This
document explains each menu in turn including all
submenus and setup items.
The following procedures allow you to navigate the
setup utility menus:
1. To select a menu, use the cursor keys: .
2. To select a field within a menu or a submenu, use the
cursor keys: , .
3. To select the different values for each field, press the
[Spacebar] or [+] to change to the next higher selec-
tion and [F5] or [-] to go to the next lower selection.
4. To activate a submenu press the [Enter] key.
5. To return to a menu from a submenu, press
the [Esc] key.
6. To go to the Exit menu from any other menu,
press the [Esc] key.
7. Pressing the [F9] key resets all items in the BIOS to
the default values.
8. Pressing the [F10] key saves the current configura-
tion and exits the BIOS Setup Utility. You will be
asked to verify this selection before it is executed.
9. Pressing the [F1] key gives you a general help screen.
Entering the Setup Utility After a Configuration
Change or System Failure
If there has been a change in the system configuration
that does not agree with the parameter settings stored
in your BIOS memory, or there is a failure in the system,
the system beeps and/or displays an error message after
the Power On Self Test (POST). If the failure is not
too severe, it will give you the opportunity to modify
the settings of the setup utility, as described in the
following steps:
1. When you turn on or restart the computer there is
a beep and/or the following message appears on
the screen:
Error message - please run SETUP
program Press <F1> key to continue,
<F2> to run SETUP
POINT
Selecting a field causes a help message about that field
to be displayed on the right-hand side of the screen.
POINT
Pressing the Enter key with the highlight on a selection
that is not a submenu or auto selection will cause a list
of all options for that item to be displayed. Pressing the
Enter key again will select the highlighted choice.
C Series BIOS
,

2
LifeBook C Series BIOS
2. If an error message is displayed on the screen, and
you want to continue with the boot process and start
the operating system anyway, press the [F1] key.
3. If an error message is displayed on the screen, and
you want to enter the setup utility, press the [F2] key.
4. When the setup utility starts with a fault present, the
system displays the following message:
Warning!
Error message
[Continue]
5. Press any key to enter the setup utility. The system
will then display the Main Menu with current
parameters values.
CAUTION
If your notebook beeps a series of beeps that sounds
like a code and the display is blank, please refer to the
Troubleshooting Section. The Troubleshooting Section
includes a list of error messages and their meanings.
POINT
If your data security settings require it, you may be
asked for a password before the operating system will
be opened.

3
MAIN MENU – SETTING STANDARD SYSTEM PARAMETERS
The Main Menu allows you to set or view the current
system parameters. Follow the instructions for Navi-
gating Through The Setup Utility to make any changes.
(See Navigating Through The Setup Utility on page 1 for
more information)
The following tables show the names of the menu fields
for the Main menu and its submenus, all of the options
for each field, the default settings and a description of
the field’s function and any special information needed
to help understand the field’s use.
*Actual drive labels shown may vary.
Figure 1 Main Menu
POINT
System Time and System Date can also be set from your
operating system without using the setup utility. Use
the calendar and time icon on your Windows Control
panel or type time or date from the MS-DOS prompt.
Table 1: Fields, Options and Defaults for the Main Menu
Menu Field Options Default Description
System Time: –— –— Sets and displays the current time. Time is in a 24 hour format
of hours:minutes:seconds with 2 digits for each. (HH:MM:SS).
Example: 16:45:57. You may change each segment of the time
separately. Move between the segments with the [Tab] key and/or
[Shift] + [Tab] keys.
System Time: [02:34:56]
System Date: [11/18/1999]
Floppy Disk A: [1.44/1.2 MB, 3.5"]
Primary Master [TOSHIBA MK6014MAP-(PM)]*
Secondary Master [TOSHIBA CD-ROM XM-7002B-(SM)]*
Language: [English (US)]
PhoenixBIOS Setup Utility
F1 Help
ESC Exit Select Item Select Menu -/Space Change Values Enter Select Sub-Menu F9 Setup Defaults F10 Save and Exit
▲
Main Advanced Security Power Boot Info Exit
Item Specific Help
Adjust calendar clock.
<Tab>, <Shift-Tab>, or
<Enter> selects field.
▲ ▲
Main Menu

4
LifeBook C Series BIOS
System Date: –— –— Sets and displays the current date. Date is in a month/day/year
numeric format with 2 digits each for month and day and 4 digits
for year. (MM/DD/YYYY) for example: 03/20/1998. You may
change each segment of the date separately. Move between the
segments with the [Tab] key and/or [Shift] + [Tab] keys.
Floppy Disk A: ■[1.44/1.25 MB
3.5"]
■Disabled
[1.44/1.25 MB
3.5"]
Enables or disables a floppy disk drive.
Primary Master: ■Selects Primary
Master submenu
The product # of
the Hard Drive
Display the type of device on this ATA/ATAPI interface, if there is
one. Pressing the Enter key selects the Primary Master submenu
allowing additional device configuration options for this interface.
Secondary Master ■Selects
Secondary
Master submenu
The product # of
the CD-ROM
Display the type of device on this ATA/ATAPI interface, if there is
one. Pressing the Enter key selects the Secondary Master submenu
allowing additional device configuration options for this interface
Language: ■English (US)
■Japanese (JP)
[English (US)] The default setting differs between the US/European and the
Japanese model. Selects the display language for the BIOS.
Table 1: Fields, Options and Defaults for the Main Menu
Menu Field Options Default Description

5
Primary Master Submenu of the Main Menu
The Primary Master submenu identifies what ATA
devices are installed.
* Actual hard drive label shown may vary. Depending on
the drive type, information such as cylinders, heads and
sectors may also be displayed.
Figure 2 Primary Master Submenu
Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu
Menu Field Options Default Description
Type: ■Auto
■None
■CD-ROM
■Hard Disk
[Auto] Selects the ATA/ATAPI device type. Select Auto to have the type
automatically identified by the BIOS at POST. If None is selected, all
of the following Set-up items do not appear. Select CD-ROM if a
CD-ROM drive is installed at this connection. If Hard Disk is
selected, you must specify the number of Cylinders, Heads, and
Sectors for the drive.
Cylinders: ■A number
between 0
and 65,535
–— This item appears only when Hard Disk is selected. When Hard Disk
is selected, you can change the value. This field is changed by
incrementing (pressing the [Spacebar]) or by typing in the number.
Heads: ■A number
between 1
and 16
–— This item appears only when Hard Disk is selected. When Hard Disk
is selected, you can change the value. This field is changed by
incrementing (pressing the [Spacebar]) or by typing in the number.
Sectors: ■A number
between 0
and 63
–— This item appears only when Hard Disk is selected. When Hard Disk
is selected, you can change the value. This field is changed by
incrementing (pressing the [Spacebar]) or by typing in the number.
PhoenixBIOS Setup Utility
F1 Help
ESC Exit Select Item Select Menu -/Space Enter F9 Setup Defaults F10 Save and Exit
Change Values
Select Sub-Menu
Main
Item Specific Help
Select ATA/ATAPI drive
installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
Except [Auto]
You enter parameters of
the drive.
[None]
The drive is disabled.
Primary Master [TOSHIBA MK6014MAP-(PM)]*
Type: [Auto]
Maximum Capacity: 12073MB
Multi-Sector Transfers: [16 Sectors]
LBA Mode Control: [Enabled]
PIO Transfer Mode: [Fast PIO 4]
DMA Transfer Mode: [Ultra DMA 2]
▲
Main Menu

6
LifeBook C Series BIOS
Maximum
Capacity:
■Display only –— Displays the maximum capacity of the drive calculated from the
parameters of the hard disk when Hard Disk is selected.
Multi-Sector
Transfers:
■Disabled
■2 Sectors
■4 Sectors
■8 Sectors
■16 Sectors
■32 Sectors
■64 Sectors
■128 Sectors
[16 Sectors] This option cannot be changed when Auto is selected. Specify the
number of sectors per block for multiple sector transfer. MAX refers
to the size the disk returns when required.
LBA Mode
Control:
■Enabled
■Disabled
[Enabled] Enables or disables logical Block Addressing in place of Cylinder,
Head, Sector addressing. This option cannot be changed when
Auto is selected.
PIO Transfer
Mode:
■Standard
■Fast PIO 1
■Fast PIO 2
■Fast PIO 3
■Fast PIO 4
[Fast PI0 4] Selects the method for moving data to/from the drive. Autotype
the drive to select the optimum transfer mode. This option cannot
be changed when Auto is selected. Multi-word DMA is
automatically set to mode 1 for Fast PIO 1, Fast PIO 2, Fast PIO 3,
and set to mode 2 for Fast PIO 4 / DMA.
DMA Transfer
Mode:
■Disabled
■Multiword
DMA 1
■Multiword
DMA 2
■Ultra DMA 0
■Ultra DMA 1
■Ultra DMA 2
[Ultra DMA 2] Selects the method for moving data to/from the drive. Autotype
the drive to select the optimum transfer mode. This option cannot
be changed when Auto is selected.
Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu
Menu Field Options Default Description
CAUTION
A bootable CD-ROM may have either a floppy disk for-
mat or a hard drive format. When the bootable CD-
ROM is used the drive allocations change automatically
without changing the BIOS setup. If a floppy disk for-
mat CD-ROM is used the CD-ROM becomes Drive A.
The CD-ROM will only take drive C: (hard drive format)
if the internal hard drive is not present or is disabled.
The bootable CD-ROM can never use a C: designation
if a formatted internal hard drive is present since the C:
designator is always reserved for the internal hard
drive.The boot sequence ignores the new drive designa-
tions, however, your application software will use the
new designations.
CAUTION
Be careful of the operating environment when booting
from a CD-ROM or you may overwrite files by mistake.

7
Secondary Master Submenu of the Main Menu
The Secondary Master submenu is for the internal CD-
ROM drive. The drive type is displayed on this menu as
well as the Main menu. Your notebook auto-senses the
characteristics of the internal CD-ROM Drive installed.
You will not need to modify these settings, they are
displayed for your reference.
*Actual drive labels shown may vary.
Figure 3 Secondary Master Submenu
Table 3: Fields, Options and Defaults for the Secondary Master Submenu of the Main Menu
Menu Field Options Default Description
Type: ■Auto
■None
■CD-ROM
■Hard Disk
[Auto] Selects the ATA/ATAPI device type. Select Auto to have the type
automatically identified by the BIOS at POST. If None is selected, all
of the following Set-up items do not appear. Select CD-ROM or
Hard Disk for appropriate drive type installed at this connection.
Multi-Sector
Transfers:
■Disabled
■2 Sectors
■4 Sectors
■8 Sectors
■16 Sectors
■32 Sectors
■64 Sectors
■128 Sectors
[Disabled] This option cannot be changed when Auto is selected. Specify the
number of sectors per block for multiple sector transfer.
LBA Mode
Control:
■Enabled
■Disabled
[Disabled] Enables or disables Logical Block Addressing in place of Cylinder,
Head, Sector addressing. This option cannot be changed when
Auto is selected.
PhoenixBIOS Setup Utility
F1 Help
ESC Exit Select Item Select Menu -/Space Enter F9 Setup Defaults F10 Save and Exit
Change Values
Select Sub-Menu
Main
Item Specific Help
Select ATA/ATAPI drive
installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
Except [Auto]
You enter parameters of
the drive.
[None]
The drive is disabled.
Secondary Master [TOSHIBA CD-ROM XM-7002B-(SM)]*
Type: [Auto]
Multi-Sector Transfers: [Disabled]
LBA Mode Control: [Disabled]
PIO Transfer Mode: [Fast PIO 4]
DMA Transfer Mode: [Ultra DMA 2]
▲
Main Menu

8
LifeBook C Series BIOS
Exiting from Main Menu
When you have finished setting the parameters on this
menu, you can either exit from the setup utility, or move
to another menu. If you wish to exit from the setup
utility, press the [Esc] key or use the cursor keys to go to
the Exit menu. If you wish to move to another menu, use
the cursor keys.
PIO Transfer
Mode:
■Standard
■Fast PIO 1
■Fast PIO 2
■Fast PIO 3
■Fast PIO 4
[Standard] Selects the method for moving data to/from the drive. Autotype
the drive to select the optimum transfer mode. This option cannot
be changed when Auto is selected. Multi-word DMA is
automatically set to mode 1 for Fast PIO 1, Fast PIO 2, Fast PIO 3,
and set to mode 2 for Fast PIO 4 / DMA.
DMA Transfer
Mode:
■Disabled
■Multiword
DMA 1
■Multiword
DMA 2
■Ultra DMA 0
■Ultra DMA 1
■Ultra DMA 2
[Disabled] Selects the method for moving data to/from the drive. Autotype
the drive to select the optimum transfer mode. This option cannot
be changed when Auto is selected.
Table 3: Fields, Options and Defaults for the Secondary Master Submenu of the Main Menu
Menu Field Options Default Description

9
ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS
The Advanced Menu allows you to:
■Enable or disable support for Plug & Play
operating systems.
■Set the I/O addresses for the serial and parallel ports.
■Set the communication mode for the parallel and
infrared ports.
■Set the features of the keyboard/mouse.
■Select between the display panel and an external
CRT display.
■Enable or disable compensation for your display.
■Configure PCI devices in your system.
■Configures CPU features.
■Configures ACPI features.
■Configures DMI Event Logging.
Follow the instructions for Navigating Through the
Setup Utility to make any changes.
(See Navigating Through The Setup Utility on page 1 for
more information)
The following tables show the names of the menu fields
for the Advanced Menu and its submenus, all of the
options for each field, the default settings and a descrip-
tion of the field’s function and any special information
needed to help understand the field’s use.
* Note that not all fields appear in all configurations; the
fields that appear are dependent upon the system CPU.
Figure 4 Advanced Menu
PhoenixBIOS Setup Utility
F1 Help
ESC Exit Select Item Select Menu -/Space Enter F9 Setup Defaults F10 Save and Exit
Change Values
Select Sub-Menu
▲
Main Advanced Security Power Boot Info Exit
Item Specific Help
▲ ▲ ▲ ▲ ▲ ▲ ▲
Plug & Play O/S: [Yes]
Protected Device Configurations:[No]
Serial/Parallel Port Configurations
Keyboard/Mouse Features
Video Features
Internal Device Configurations
PCI Configuration:
CPU Features
ACPI Features
Event Logging
[No]
The BIOS configures
also non-boot devices.
Select if you are using
a non-Plug & Play OS or
a non-ACPI OS.
[Yes]
The BIOS configures
only boot devices.
▲
Advanced Menu

10
LifeBook C Series BIOS
Table 4: Fields, Options and Defaults for the Advanced Menu
Menu Field Options Default Description
Plug & Play O/S: ■Ye s
■No
[Yes] Select Yes if you are using a Plug & Play capable operating system.
Select No if you need the BIOS to configure non-boot devices.
Protected Device
Configuration:
■Yes
■No
[No] No: allows Plug & Play operating system to change device
system settings.
Yes: prevents a Plug & Play operating system from changing
system settings.
*ACPI operating system ignores this setting.
Serial/Parallel Port
Configurations
–— –— When selected, opens the Serial/Parallel Port Configurations
submenu which allows the user to modify settings for serial,
infrared and parallel ports.
Keyboard/Mouse
Features
–— –— When selected, opens the Keyboard/Mouse Features submenu,
which allows setting external and internal keyboard and
mouse parameters.
Video Features –— –— When selected, opens the Video Features submenu, which allows
setting of the display parameters, including routing of video signals
to different displays.
Internal Device
Configurations
–— –— When selected, opens the Internal Device Configuration submenu,
which allows enabling or disabling the Floppy Disk and IDE
Controllers.
PCI Configurations –— –— When selected, opens additional menus to configure PCI devices.
CPU Features Page –— –— Configure CPU features
ACPI Features Page –— –— Configure ACPI features
Event Logging –— –— When selected, opens the event logging submenu.

11
Serial/Parallel Port Configuration Submenu of the Advanced Menu
The Serial/Parallel Port Configuration submenu
provides the ability to set the I/O addresses and
interrupt levels for the serial, infrared and parallel
ports of your notebook.
Figure 5 Serial/Parallel Port Configuration Submenu
CAUTION
I/O addresses, DMA channels and Interrupt levels
can be entered in various ways, including via the BIOS
setup utility, the control software for the I/O device,
or the hardware. If any two ports or devices, serial or
parallel, have the same I/O address assigned your
notebook will not function normally. Please keep a
record of original settings before making any changes
in the event that a restoration is required. See your
hardware and software documentation as well as the
setup utility to determine settings, limitations, etc.
POINT
To prevent IRQ and address conflicts, avoid changing
the default settings. If you must change the settings,
you can call 1-800-8FUJITSU for technical assistance.
CAUTION
The BIOS will warn you of a resource conflict by placing
a yellow asterisk next to each device that is in conflict.
POINT
All I/O addresses in Table 5 are in hexadecimal.
PhoenixBIOS Setup Utility
F1 Help
ESC Exit Select Item Select Menu -/Space Enter F9 Setup Defaults F10 Save and Exit
Change Values
Select Sub-Menu
▲
Advanced
Item Specific Help
Serial Port: [Enabled]
I/O Address: [3F8-3FF]
Interrupt: [IRQ 4]
Infrared Port: [Enabled]
Mode: [FIR]
I/O Address: [2E8 - 2EF]
Interrupt: [IRQ 3]
I/O Address: [118-11F]
DMA Channel: [DMA 3]
Parallel Port: [Enabled]
Mode: [Bi-directional]
I/O Address: [378-37F]
Interrupt: [IRQ 7]
[Disabled]
The port is disabled.
[Enabled]
the port is enabled
with user configuration.
[Auto]
the port is configured
depending on 'Plug &
Play OS' setting.
Serial/Parallel Port Configurations
Advanced Menu

12
LifeBook C Series BIOS
Table 5: Fields, Options and Defaults for the Serial/Parallel
Port Configuration Submenu of the Advanced Menu
Menu Field Options Default Description
Serial Port: ■Disabled
■Enabled
■Auto
[Enabled] Configures the serial port using either no configuration
(Disabled), a user defined configuration (Enabled), or by
allowing the BIOS or OS to choose the configuration (Auto).
I/O Address: ■3F8 - 3FF
■2F8 - 2FF
■3E8 - 3EF
■2E8 - 2EF
[3F8 - 3FF] Allows user to set the serial port base I/O address when serial port
is Enabled.
Interrupt: ■IRQ 3
■IRQ 4
■IRQ 10
■IRQ 11
[IRQ 4] Allows user to set the serial port interrupt when serial port
is Enabled.
Infrared Port: ■Disabled
■Enabled
■Auto
[Enabled] Configures the infrared port using either no configuration
(Disabled), a user defined configuration (Enabled), or by
allowing the BIOS or OS to choose the configuration (Auto).
Mode: ■IrDA
■FIR
[FIR] When the infrared port is enabled this option is available allowing
the user to set the mode for the infrared port.
I/O Address: ■2E8 - 2EF
■3F8 - 3FF
■2F8 - 2FF
■3E8 - 3EF
[2E8 - 2EF] Allows user to set the infrared port I/O address when the
infrared port is Enabled.
Interrupt: ■IRQ 3
■IRQ 4
■IRQ 10
■IRQ 11
[IRQ 3] Allows user to set the infrared port interrupt when the infrared
port is Enabled.
I/O address: ■100 - 107
■108 - 10F
■110 - 117
■118 - 11F
[118 - 11F] Allows user to set the infrared port I/O address when the
infrared port is Enabled.

13
DMA Channel: ■DMA 1
■DMA 3
[DMA 3] Allows user to set the infrared port DMA Channel when the
infrared port is Enabled.
Parallel Port: ■Disabled
■Enabled
■Auto
[Enabled] Configures the parallel port using either no configuration
(Disabled), a user defined configuration (Enabled), or by
allowing the BIOS or OS to choose the configuration (Auto).
Mode: ■Output Only
■Bi-directional
■ECP
[Bi-directional] When the parallel port is enabled this option is available allowing
the user to set the mode for the parallel port. Bi-directional allows
two-way transfer of information between your notebook and a
connected parallel device. Output Only (Half Duplex) allows
information to be transferred in only one direction, from your
notebook to the printer or similar device. ECP Mode allows
communication with the ECP class of parallel I/O devices.
I/O address: ■378 - 37F
■278 - 27F
■3BC - 3BF
[378 - 37F] Allows user to set the parallel port base I/O address when the
parallel port is Enabled.
Interrupt: ■IRQ 5
■IRQ 7
[IRQ 7] Allows user to set the parallel port interrupt when the parallel
port is Enabled.
Table 5: Fields, Options and Defaults for the Serial/Parallel
Port Configuration Submenu of the Advanced Menu
Menu Field Options Default Description
Advanced Menu

14
LifeBook C Series BIOS
Keyboard/Mouse Features Submenu of the Advanced Menu
The Keyboard/Mouse Features submenu is for setting
the parameters of the integrated and external mouse
and keyboard.
Figure 6 Keyboard/Mouse Features Submenu
Table 6: Fields, Options and Defaults for the Keyboard/Mouse Submenu of the Advanced Menu
Menu Field Options Default Description
Numlock: ■Auto
■Off
■On
[Auto] Sets the NumLock function state when the computer
completes booting.
Hot Plug: ■Enabled
■Disabled
[Enabled] Enables and disables the ability to plug a mouse or keyboard into
the PS/2 port and have it immediately recognized and active.
Internal Pointing
Device:
■Auto Disabled
■Always Enabled
[Auto Disabled] Sets the device controlling the mouse cursor on the screen.
Always Enabled makes the pointing device always enabled
whether there is an external mouse or not. Auto Disabled disables
the internal pointing device when an external pointing device is
connected to the PS/2 port.
Infrared Mouse: ■Disabled
■Enabled
[Disabled] If IR Mouse is enabled, the PS/2 mouse is disabled. If you want to
use the internal pointing device with the IR Mouse, you must select
Always Enabled in the Internal Pointing Device.
F1 Help
ESC Exit Select Item Select Menu -/Space Enter F9 Setup Defaults F10 Save and Exit
Change Values
Select Sub-Menu
▲
Advanced Security Power Savings Exit
Item Specific Help
PhoenixBIOS Setup Utility
Selects power-on state
for Numlock.
Keyboard/Mouse Features
Numlock:
Hot Plug:
Internal Pointing Device:
Infared Mouse:
[Auto]
[Enabled]
[Auto Disabled]
[Disabled]

15
Video Features Submenu of the Advanced Menu
The Video Features Submenu is for setting the
display parameters.
Figure 7 Video Features Submenu
Table 7: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu
Menu Field Options Default Description
Display: ■Internal
Flat Panel
■External
■Simultaneous
[Internal
Flat Panel]
Selects where the video signal will be routed.
Compensation: ■Enabled
■Disabled
[Disabled] Enables or disables compensation which controls spacing on the
display. When enabled, displays with less than pixel resolution
1024 x 768 or 800 x 600 will still cover the entire screen.
Display [Internal Flat Panel]
Compensation: [Disabled]
F1 Help
ESC Exit Select Item Select Menu -/Space Enter F9 Setup Defaults F10 Save and Exit
Change Values
Select Sub-Menu
▲
Main Advanced Security Power Savings Exit
Item Specific Help
Select display terminal.
Video Features
PhoenixBIOS Setup Utility
Advanced Menu

16
LifeBook C Series BIOS
Internal Device Configuration Submenu of the Advanced Menu
The Internal Device Configuration submenu allows the
user to configure other internal devices.
Figure 8 Internal Device Configuration Submenu
Table 8: Fields, Options and Defaults for the Internal Device Configuration Submenu of the Advanced Menu
Menu Field Options Default Description
Floppy Disk
Controller:
■Disabled
■Enabled
[Enabled] Enables or disables the Floppy Disk Drive.
IDE Controller: ■Both
■Disabled
■Primary
■Secondary
[Both] Enables or disables selected IDE devices.
F1 Help
ESC Exit Select Item Select Menu -/Space Enter F9 Setup Defaults F10 Save and Exit
Change Values
Select Sub-Menu
▲
Main Advanced Security Power Savings Exit
Item Specific Help
[Disabled]
Floppy disk drive is
disabled.
[Enabled]
Floppy disk drive is
enabled.
Internal Device Configurations
PhoenixBIOS Setup Utility
Floppy Disk Controller: [Enabled]
IDE Controller: [Both]

17
PCI Configuration Submenu of the Advanced Menu
The PCI Configuration submenu allows the user to
reserve specific interrupts (IRQs) for legacy ISA devices,
and to enable or disable built in PCI device modules.
Figure 9 PCI Configuration Submenu
POINT
The BIOS setting for your communication device
is variable depending on your LifeBook C Series
Built-to-order configuration.
Table 9: Fields, Options and Defaults for the PCI Configuration Submenu of the Advanced Menu
Menu Field Options Default Description
IRQ Reservation –— –— Reserve specific IRQs for use by legacy ISA devices.
F1 Help
ESC Exit Select Item Select Menu -/Space Enter F9 Setup Defaults F10 Save and Exit
Change Values
Select Sub-Menu
▲
Main Advanced Security Power Savings Exit
Item Specific Help
Reserve specific IRQs
for use by legacy ISA
devices.
PCI Configuration
IRQ Reservation
PhoenixBIOS Setup Utility
▲
Advanced Menu

18
LifeBook C Series BIOS
IRQ Reservation Submenu of the PCI Configuration Submenu
The IRQ Reservation submenu of the PCI Configuration
submenu allows the user to mark various IRQs as
reserved for use by legacy ISA devices. When an IRQ
is reserved, the BIOS does not use it for embedded PCI
or ISA devices.
Figure 10 IRQ Reservation Submenu
CAUTION
Only IRQ's 9, 10, & 11 can be reserved without conflict.
Table 10: Fields, Options and Defaults for the IRQ Reservation Submenu of the
PCI Configuration Submenu of the Advanced Menu
Menu Field Options Default Description
IRQ 3: ■Available
■Reserved
[Available] Reserves IRQ 3. If Reserved is selected, the BIOS reserves IRQ 3 for
use by legacy ISA devices and does not use it for embedded PCI or
ISA devices. IRQ 3 is removed from the IRQ bitmap in the PCI IRQ
routing table.
IRQ 4: ■Available
■Reserved
[Available] Reserves IRQ 4.
IRQ 5: ■Available
■Reserved
[Available] Reserves IRQ 5.
IRQ 7: ■Available
■Reserved
[Available] Reserves IRQ 7.
F1 Help
ESC Exit Select Item Select Menu -/Space Enter F9 Setup Defaults F10 Save and Exit
Change Values
Select Sub-Menu
▲
Main Advanced Security Power Savings Exit
Item Specific Help
Reserve the specified
IRQ for use by legacy
ISA devices.
IRQ Reservation
PhoenixBIOS Setup Utility
IRQ 3: [Available]
IRQ 4: [Available]
IRQ 5: [Available]
IRQ 7: [Available]
IRQ 9: [Available]
IRQ 10: [Available]
IRQ 11: [Available]

19
IRQ 9: ■Available
■Reserved
[Available] Reserves IRQ 9.
IRQ 10: ■Available
■Reserved
[Available] Reserves IRQ 10.
IRQ 11: ■Available
■Reserved
[Available] Reserves IRQ 11.
Table 10: Fields, Options and Defaults for the IRQ Reservation Submenu of the
PCI Configuration Submenu of the Advanced Menu
Menu Field Options Default Description
Advanced Menu

20
LifeBook C Series BIOS
CPU Features Submenu of the Advanced Menu
The CPU Features Submenu configures the system
processor.
*Note that this submenu only appears in certain
configurations, based upon the system CPU.
Figure 11 CPU Features Submenu
Menu Field Options Default Description
Processor Serial
Number
■Disabled
■Enabled
[Disabled] Configures Processor Serial Number feature of Pentium(R) III
processor.
Intel(R)
SpeedStep(TM)
Tech n ology
■Auto
■Max. Pref.
■Batt. Opt.
■Disabled
[Auto] When Auto is selected, the CPU speed is changed based upon a
power source change. If Max. Pref. is selected, the CPU speed is
maximized. If Batt. Opt. is selected, the CPU speed is optimized for
battery operation. If Disabled is selected, the CPU speed is fixed to
the Battery Optimized speed.
F1 Help
ESC Exit Select Item Select Menu -/Space Enter F9 Setup Defaults F10 Save and Exit
Change Values
Select Sub-Menu
▲
Main Advanced Security Power Savings Exit
Item Specific Help
PhoenixBIOS Setup Utility
Configures Processor
Serial Number feature
of Pentium(R) III
processor.
[Disabled]
Processor Serial Number
feature is disabled.
[Enabled]
Processor Serial Number
feature is enabled.
CPU Features
Processor Serial Number:[Disabled]
Intel(R) SpeedStep(R) Technology: [Auto]
