Fujitsu LIFEBOOK U7511 User manual

System
Operating Manual
FUJITSU LIFEBOOK U7411
FUJITSU LIFEBOOK U7511

Congratulations on your purchase of an innovative
product from Fujitsu.
The latest information about our products, tips, updates etc. can be found
on the Internet at: "http://www.fujitsu.com/fts/"
You can find driver updates at: "http://support.ts.fujitsu.com/download"
Should you have any technical questions, please contact:
• our Hotline/Service Desk ("http://support.ts.fujitsu.com/contact/servicedesk")
• Your sales partner
• Your sales office
We hope you enjoy working with your new Fujitsu system!

Issued by / EU importer
Fujitsu Technology Solutions GmbH
Mies-van-der-Rohe-Straße 8
80807 Munich, Germany
"http://www.fujitsu.com/fts/"
Copyright
© Fujitsu Client Computing Limited 2021. All rights reserved.
Publication Date
03/2021
Edition 1

FUJITSU LIFEBOOK U7411
FUJITSU LIFEBOOK U7511
Operating Manual
Innovative technology 7
Ports and controls 9
Important notes 15
First-time setup of your device 19
Working with the notebook 22
Security functions 49
Connecting external devices 56
Removing and installing components
during servicing 62
Settings in BIOS Setup Utility 63
Troubleshooting and tips 68
Technical data 77
Manufacturer’s notes 79
Index 80

Remarks
Information on the product description meets the design specifications of Fujitsu and
is provided for comparison purposes. Several factors may cause the actual results to
differ. Technical data is subject to change without prior notification. Fujitsu rejects any
responsibility with regard to technical or editorial mistakes or omissions.
Trademarks
Fujitsu, the Fujitsu logo and LIFEBOOK are registered trademarks of Fujitsu Limited
or its subsidiaries in the USA and other countries.
Microsoft and Windows are trademarks or registered trademarks of Microsoft
Corporation in the USA and/or other countries.
TM
The terms HDMI and HDMI High-Definition Multimedia Interface and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
Adobe Reader is a trademark of Adobe Systems Incorporated.
USB Type-C™ and USB-C™ are trademarks of the USB Implementers Forum
in the USA and other countries.
All other trademarks specified here are the property of their respective owners.
Copyright
No part of this publication may be copied, reproduced or translated without
the prior written consent of Fujitsu.
No part of this publication may be saved or transferred by any electronic means
without the written approval of Fujitsu.

Contents
Contents
Innovativetechnology ................................................................. 7
Furtherinformation ...................................................................... 7
Notational conventions .................................................................. 8
Portsandcontrols ..................................................................... 9
FUJITSU LIFEBOOKU7411 ............................................................. 9
FUJITSU LIFEBOOKU7511 ............................................................. 12
Importantnotes ........................................................................ 15
Safety notes ............................................................................ 15
Additional safety notes for devices with wireless components . . ............................. 16
Energy saving .......................................................................... 16
Energy saving under Windows ....................................................... 16
Travellingwith yournotebook ............................................................ 17
Beforeyoutravel ................................................................... 17
Notebook: transporting ............................................................... 17
Cleaningthe notebook .................................................................. 18
First-time setup ofyourdevice ......................................................... 19
Unpacking and checkingthedevice ...................................................... 19
Selectingaloca
tion ..................................................................... 20
Mains adapter connecting . . . . ........................................................... 20
Switchingonth
e device for the firsttime .................................................. 21
Workingwiththenotebook ............................................................ 22
Status indicators ........................................................................ 22
Switching on the notebook . . . . ........................................................... 24
Notebook: switching off .................................................................. 24
Keyboard ............................................................................... 25
Virtualnumerickeypad .............................................................. 27
Separate number block . . . ........................................................... 28
Function keysandkey combinations .................................................. 28
F-Locksetting ....................................................................... 31
Keyboard with background lighting (optional) . . ........................................ 31
Country and keyboard settings ....................................................... 31
Touchpadandtouchpadbuttons .......................................................... 32
Movingthepointer .................................................................. 32
Selectingan item .................................................................... 32
Executing commands . . . . . ........................................................... 32
Dragging items ...................................................................... 33
Touchscreen/LCD screen without touch function (device-dependent) . . . ..................... 33
Using fingers ....................................................................... 34
WebCam andInfrared Camera ........................................................... 35
ePrivacyFilter (optional) ................................................................. 35
Rechargeable battery ................................................................... 36
Charging, caringforand maintaining the battery ....................................... 36
Switchthebattery off and on ......................................................... 36
Usingthe power-management features ................................................... 37
Adjusting system performance in Microsoft Windows . . . . . . ............................. 37
Adjustingfancontrol ................................................................. 38
Memory cards .......................................................................... 39
Supported format . . .................................................................. 39
Fujitsu 3

Contents
Inserting thememorycard ........................................................... 39
Removingthememorycard .......................................................... 39
Loudspeakers and microphones . . ........................................................ 40
SIM card (configuration dependent) . . . . . . ................................................. 41
Inserting theSIMcard ............................................................... 41
RemovingtheSIM card .............................................................. 42
Wireless components: wireless LAN / Bluetooth / LTE / 5G (optional) . . . . . ................... 43
Switching the wireless components on and off ......................................... 43
SettingupWLANaccess ............................................................ 43
Access via LTE / 5G (optional) . . . . . . ................................................. 43
Ethernetand LAN ....................................................................... 44
Your PortReplicator ..................................................................... 45
Ports onthe PortReplicator .......................................................... 45
Connecting the notebook to the Port Replicator . . . . . .................................. 46
Connecting the mains adapter to the Port Replicator . .................................. 47
Switching on the notebook via the port replicator . . . . . .................................. 47
Disconnecting the notebook from the Port Replicator .................................. 48
Securityfunctions ..................................................................... 49
Configuring the fingerprint sensor ........................................................ 49
Configuring thepalm veinsensor ......................................................... 50
Usingthe Security Lock ................................................................. 50
Configuring passwordprotection in BIOS SetupUtility ...................................... 51
Protecting BIOS Setup Utility (supervisor and user password) . .......................... 51
Password protection for booting of the operating system . .............................. 53
Passwordprotection forthehard disk ................................................. 53
Trusted Platform Module (TPM) (device-dependent) . . . . . .................................. 54
EnablingTPM ....................................................................... 54
Disabling TPM ...................................................................... 54
SmartCard reader ....................................................................... 55
Inserting theSmartCard ............................................................. 55
Connectingexternaldevices ........................................................... 56
Connecting an external monitor . . ........................................................ 57
Connecting USB devices ................................................................ 58
USB port Intel® ThunderboltTM 4withchargingfunctionanddisplayport(USBType-C) .... 59
USB portwithcharging function (Anytime USB charge) ................................. 60
How to remove USBdevicescorrectly ................................................ 60
Headsetport ........................................................................... 61
Removing and installing components during servicing . . . .............................. 62
Settings in BIOS Setup Utility . . ........................................................ 63
Starting the BIOSSetupUtility ........................................................... 63
Operating theBIOSSetupUtility ......................................................... 64
ExitingBIOS Setup Utility ................................................................ 65
Exit Saving Changes - save changes and exit BIOS Setup Utility . . . . ................... 65
Exit Discarding Changes – Discard changes and exit BIOS Setup Utility . . ............... 65
Load Setup Defaults – Copy Standard Entries ......................................... 65
Discard Changes – Discard changes without exiting the BIOS Setup Utility ............... 65
Save Changes - save changes without exiting the BIOS Setup Utility . ................... 65
Save Changes and Power Off . . . . . . ................................................. 65
Erase Disk ............................................................................. 66
4Fujitsu

Contents
Troubleshootingandtips .............................................................. 68
Helpifproblems occur ................................................................... 68
Restorecontents ofthehard diskfrom RecoveryCD/DVD .................................. 69
Restoring the system under Windows 10 . . . . . . ............................................ 69
The notebook’s date or time is incorrect ................................................... 70
Whencertaincharactersareentered on the keyboard,only numeralsare written ............. 70
The notebook’s LCD screen remains blank . . . . ............................................ 70
The LCD screen is difficulttoread ........................................................ 70
The external monitorremains blank ...................................................... 71
The external monitorisblankortheimageisunstable ..................................... 71
The notebook cannot be started . . . ....................................................... 72
The notebook stops working . . ........................................................... 72
The printer does not print . . . . . ........................................................... 73
The wireless connection to a network does not work . . . .................................... 73
SmartCard reader is not recognised. . . . ................................................... 73
SmartCard PIN forgotten ................................................................ 73
SmartCard lost ......................................................................... 74
Error messagesonthescreen ........................................................... 75
Technicaldata ......................................................................... 77
LIFEBOOK ............................................................................. 77
Rechargeable battery ................................................................... 77
Mains adapter (notebook computer) . . . ................................................... 78
Mains adapter (port replicator) ........................................................... 78
Manufacturer’snotes .................................................................. 79
Disposaland recycling .................................................................. 79
TCO Certified ........................................................................... 79
SAR limit value (SpecificAbsorptionRate) ................................................ 79
Other certificationmarkings .............................................................. 79
Index .................................................................................. 80
Fujitsu 5

Contents
6Fujitsu

Innovative technology
Innovative technology
... and ergonomic design make your device a reliable and convenient companion.
The device boots very quickly, is ready for immediate use and offers a particularly
long operating time because of its high capacity battery.
With the user-friendly "BIOS Setup Utility" you can control your notebook’s hardware and better
protect your system against unauthorised access by using the powerful password properties.
Information on the connections and user components of your notebook
canbefoundin"Ports and controls", Page 9.
Further information
The Windows drivers for your device can be found on our Internet site.
The factory installation of your device does not support any other operating
system. Fujitsu Technology Solutions accepts no liability whatsoever
if any other operating system is used.
Software oriented components of these instructions refer to Microsoft products,
if they come within the scope of the delivery.
If you install other software products, pay attention to the operating
instructions of the manufacturer.
Fujitsu 7

Innovative technology
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to health, damage the device or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.
Indicates important information for the proper use of the device.
►Indicates an activity that must be performed
Indicates a result
This font indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123) or a command used to
start a program (start.exe)
This font indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This font Indicates
• terms and texts used in a software interface, e.g.: Click on Save
• names of programs or files, e.g. Windows or setup.exe.
"This font" Indicates
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://www.fujitsu.com/fts/"
• Names of CDs, DVDs and titles or designations for other materials,
e.g.: "CD/DVD Drivers & Utilities" or "Safety/Regulations" manual
Key indicates a key on the keyboard, e.g: F10
This font indicates terms and texts that are emphasised or highlighted, e.g.: Do
not switch off the device
8Fujitsu

Ports and controls
Ports and controls
This chapter presents the individual hardware components of your device. It gives
an overview of the indicators and ports of the device. Please familiarise yourself with
these components before you start to work with the device.
FUJITSU LIFEBOOK U7411
Front
10
9
56
1
3
4
1
2
2
7
8
1 = Infra-red camera sensors (optional)
2 = Microphone (optional)
3 = WebCam (optional) with webcam shutter
4 = WebCam LED (optional)
5 = Status indicators
6 = ON/OFF button
7 = Fingerprint sensor (optional) or palm
sensor (optional)
8 = Status indicators
9 = Touchpad buttons
10 = Touchpad
Fujitsu 9

Ports and controls
Left side
1 3 42
25
1 = LAN port
2 = USB ports Intel® ThunderboltTM 4
with charging function and display
port (USB Type-C)
3 = HDMI port
4 = USB 3.2 Gen1 port with charging function
(USB Type-A, Anytime USB charge)
5 = SmartCard reader (optional)
Right side
1 3 4
2
1 = Headset port
2 = USB port 3.2 Gen1 (USB Type-A)
3 = Memory card slot
4 = Security lock device
Rear
1
1 = SIM card slot (configuration-dependent,
protected by cover)
10 Fujitsu

Ports and controls
Bottom
2
1
3 3
1 = Port replicator port
2 = Off button for the battery (recessed)
3 = Loudspeakers
Fujitsu 11

Ports and controls
FUJITSU LIFEBOOK U7511
Front
10
9
56
1
3
4
1
2
2
7
8
1 = Infra-red camera sensors (optional)
2 = Microphone (optional)
3 = WebCam (optional) with webcam shutter
4 = WebCam LED (optional)
5 = Status indicators
6 = ON/OFF button
7 = Fingerprint sensor (optional) or palm
sensor (optional)
8 = Status indicators
9 = Touchpad buttons
10 = Touchpad
12 Fujitsu

Ports and controls
Left side
1 3 42
25
1 = LAN port
2 = USB ports Intel® ThunderboltTM 4
with charging function and display
port (USB Type-C)
3 = HDMI port
4 = USB 3.2 Gen1 port with charging function
(USB Type-A, Anytime USB charge)
5 = SmartCard reader (optional)
Right side
1 4 53
2
1 = Headset port
2 = Memory card slot
3 = USB port 3.2 Gen1 (USB Type-A)
4 = USB port 3.2 Gen1 (USB Type-A)
5 = Security Lock device
Rear
1
1=SIMcardslot(configuration-dependent,
protected by cover)
Fujitsu 13

Ports and controls
Bottom
2
1
3 3
1 = Port Replicator port
2 = Off button for the battery (recessed)
3 = Loudspeakers
14 Fujitsu

Important notes
Important notes
ImportantnotesNotes
This chapter contains essential safety information which must be followed
when working with your notebook. Other notes also provide useful information
which will help you with your notebook.
Safety notes
SafetynotesNotes
Please follow the safety notes provided in the "Safety/Regulations" manual
as well as the safety notes given below.
Please pay special attention to the sections in the manual marked
with the symbol on the left.
When connecting and disconnecting cables, observe the relevant
notes in this operating manual.
In order to prevent burn injury or the device from overheating, do not lay the device
directly on your lap and make sure that the ventilation openings are not obstructed.
Read the information on the ambient conditions in the "Technical data",
Page 77 and "First-time setup of your device", Page 19 before preparing your
notebook for use and switching it on for the first time.
When cleaning the device, please observe the relevant notes in the
section "Cleaning the notebook", Page 18.
Pay attention to the additional safety notes for devices with wireless components
provided in the "Safety/Regulations" manual.
Please refer to the notes in the chapter "Removing and installing
components during servicing", Page 62.
This notebook complies with the relevant safety regulations for data processing
equipment. If you have questions about using your notebook in a particular area,
please contact your sales outlet or our Hotline/Service Desk.
Opening angle of the LCD screen
Please open the LCD screen carefully until you feel resistance. Do not try to open it further with force!
Fujitsu 15

Important notes
Additional safety notes for devices with
wireless components
Wirelesscom ponent :WirelessLAN:Bluetooth,safetynotes
If a wireless component (Wireless LAN, Bluetooth, UMTS, LTE. 5G) is incorporated in your
notebook, you must be sure to observe the following safety notes when using your notebook:
• Switch off the wireless components when you are in an aircraft or driving in a car.
• Switch off the wireless components when you are in a hospital, an operating
room or near a medical electronics system. The transmitted radio waves
can impair the operation of medical devices.
• Switch off the wireless components when you let the device get near flammable
gases or into hazardous environments (e.g. petrol station, paintshops), as the
transmitted radio waves can cause an explosion or a fire.
For information on how to switch wireless components on and off, see chapter
"Switching the wireless components on and off", Page 43.
Energy saving
NotesEnergyEnergysaving
Switch the notebook off when it is not in use. Switch off external, connected devices if you
are not using them. If you use the energy saving functions, the notebook uses less energy.
You will then be able to work for longer before having to recharge the battery.
Energy efficiency is increased and the environmental impact is reduced.
You save money while protecting the environment.
Energy saving under Windows
►Make use of the power management features (see ""Using the power-management features",
Page 37").
16 Fujitsu
