Fujitsu D3162-B User manual

TechNotes V1.0
Extended Lifecycle Mainboard
D3162-B

a
g
e
2
Page
TechNotes D3162-B V1.0 Page 2 of 45 www.ts.fujitsu.com/mainboards
Content
1Safety Instructions 4
2Feature Overview D3162-B 5
2.1 Basic Layout 8
2.2 Block Diagram 9
2.3 External Connectors D3162-B 10
2.4 Onboard components D3162-B 11
2.5 I/O-Shield 12
3Interfaces & Connectors 14
3.1 Frontpanel Connector 14
3.2 Internal Parallel Port Connector 15
3.3 Internal USB2.0 Connector (2 x 2 Ports) 15
3.4 Internal USB3.0 Connector (1 x 2 Ports) 16
3.5 External USB3.0 Connector 16
3.6 Fan Connector 17
3.7 Power Supply Fan Connector 17
3.8 High Definition Frontpanel Audio Connector (HD Audio) 18
3.9 AC97 Frontpanel Audio Connector (Legacy Audio) 18
3.10 Power Supply Connector 19
3.11 Additional Power Supply Connector 19
3.12 Chassis Intrusion 20
4System Monitoring 21
4.1 D3162-B: Temperature Sensors and Fan Connectors 22
4.2 D3162-B: SystemGuard 23
4.3 D3162-B: SystemGuard - Details 24
4.4 SilentFanConfigManager –Customize System Monitoring Settings 25
4.5 Components for continous 24/7 operation @ +45°C 26
4.6 Capacitor Endurance Time Comparison 27
4.7 Temperature Reference Points D3162-B 28

a
g
e
3
Page
TechNotes D3162-B V1.0 Page 3 of 45 www.ts.fujitsu.com/mainboards
5Power Supply 29
5.1 ATX Power Supply 29
6Display Options 30
6.1 VGA Output 30
6.2 DVI Output 31
6.3 HDMI Output 32
6.4 DisplayPort Output 33
6.5 Dual DVI Output 34
6.6 Multi Monitor Output 35
7Operating System Support 36
7.1 Support for Windows XP / Windows 7 37
8Mainboard Tools 38
Common Mainboard Tools 38
8.1 BIOS Boot Logo Tool 38
8.2 EditCMOS 38
8.3 OEMIDENT 38
8.4 SystemGuard 39
9Known Issues & Important Notes 40
9.1 Windows XP Installation in AHCI mode –necessary adjustments 40
9.2 RAID / AHCI driver disk installation (Windows XP) from floppy disk 41
10 Miscellaneous 42
10.1 System Watchdog (WD) 42
10.2 BIOS Update / BIOS Recovery 43

a
g
e
4
Page
TechNotes D3162-B V1.0 Page 4 of 45 www.ts.fujitsu.com/mainboards
1 Safety Instructions
3 Copyright2011FUJITSU
TechNotesD307x-S V1.1
Safety Instructions
Do not connect or disconnect any cables or modules to or from any onboard connectors (except
for the rear I/O connectors) until the mainboard is completely powered down.
Any damage caused to the mainboard by misuse of the onboard connectors is excludedfrom the
standard warranty. Fujitsu Technology Solutions cannot be held liable for any damage that results
from incorrect use of any onboard connectors.
The system integrator is fully responsible for the usage of appropriate connectors and cables in
order to fulfill the technical requirements (electrical contact, durability, power/current levels,
signal integrity etc.)

a
g
e
5
Page
TechNotes D3162-B V1.0 Page 5 of 45 www.ts.fujitsu.com/mainboards
2 Feature Overview D3162-B
•Based on latest Intel Pantherpoint single-chip technology (iQ77)
•Support for full range of latest LGA1155 processors (gen2 / gen3; up to 95W)
•Intel® Core™ i7 – 2xxx / i7-37xx processor series
•Intel® Core™ i5 – 2xxx / i5-3xxx processor series
•Intel® Core™ i3 – 2xxx / i3-32xx processor series
•Intel® Pentium® –G6xx / G8xx processor series
•Intel® Celeron® –G4xx / G5xx processor series
•iAMT 8.0 / VPro 2012 Manageabilty Support
Note: Available feature set depends on installed processor
•Four memory sockets DDR3/1066/1333/1600 supporting up to 32GB
•Intel Gbit LAN 82579LM onboard
•iAMT support

a
g
e
6
Page
TechNotes D3162-B V1.0 Page 6 of 45 www.ts.fujitsu.com/mainboards
Feature Overview D3162-B
•Trusted Platform Module TPM V1.2 (Infineon) onboard
•Latest Intel®HD Graphics (integrated in processor)
•Simultaneous use of integrated graphics and PCIe graphics possible
•PCI Express Gen3
•5.1 multichannel audio onboard
•4-Layer PCB

a
g
e
7
Page
TechNotes D3162-B V1.0 Page 7 of 45 www.ts.fujitsu.com/mainboards
Feature Overview D3162-B
Designed & approved for 24/7 continuous operation
High Efficiency core voltage regulator design (80-85%)
Extended lifecycle up to 3 years
Hardware Watchdog
Easy SW integration via Windows API & Linux Driver

a
g
e
8
Page
TechNotes D3162-B V1.0 Page 8 of 45 www.ts.fujitsu.com/mainboards
Feature Overview D3162-B
2.1 Basic Layout

Feature Overview D307x-S
2.2 Block Diagram

Feature Overview D3162-B
2.3 External Connectors D3162-B
PS/2 Kbd / Mouse
4 x USB 2.0
DisplayPort
COM; DVI-I
2 x USB 3.0
LAN1; 2 x USB 2.0
Audio

a
g
e
1
Page
TechNotes D3162-B V1.0 Page 11 of 45 www.ts.fujitsu.com/mainboards
Feature Overview D3162-B
2.4 Onboard components D3162-B
Parallel Port
Frontpanel
PSU Fan Control
Processor Fan (4 pin
PWM)
Intrusion
12V Supply (Processor)
PCIe x16 (4 Lanes, Gen2)
PCIe x16 (16 Lanes, Gen3)
24 pin ATX PS
Fan 2 (4 pin PWM)
2 x SATA III
4 x SATA II
2x USB 3.0 (Frontpanel)
2 x USB 2.0 (Frontpanel)
2 x USB 2.0 (Internal)
Fan3 (4 pin PWM)
Frontpanel Audio
4 Layer PCB
1 x PCI
1 x PCIe x1
Processor LGA1155
Memory Sockets 4x

a
g
e
1
Page
TechNotes D3162-B V1.0 Page 12 of 45 www.ts.fujitsu.com/mainboards
Feature Overview
2.5 I/O-Shield
Spring Steel Sheet
Enforcement Sheet
(front view)
Rear Side: EMI Gasket
(Foam with Aluminium)

a
g
e
1
Page
TechNotes D3162-B V1.0 Page 13 of 45 www.ts.fujitsu.com/mainboards
Feature Overview
I/O-Shield
Apparatus to evaluate and specify
insertion force of FTS IO shield.
Nominal force: ~ 150 –200 N (tbd)
for specified ATX IO “letterbox”
Note: ATX Chassis “letterbox” for I/O shield:
Nom. size = 158.75 x 44.45mm
Tolerance = +/- 0.2mm

a
g
e
1
Page
TechNotes D3162-B V1.0 Page 14 of 45 www.ts.fujitsu.com/mainboards
3 Interfaces & Connectors
3.1 Frontpanel Connector
Power LED:
Anode: Pin 2 –80R Pullup to 5V_AUX
Cathode: Pin 4 –output (12mA)
HDD LED:
Anode: Pin 1 –365R Pullup to 5V
Cathode: Pin 3 –output (6mA ; ~ 0.7V low level)
Speaker Output:
Differential audio signal; max. 0.5W / 8Ohm

a
g
e
1
Page
TechNotes D3162-B V1.0 Page 15 of 45 www.ts.fujitsu.com/mainboards
Interfaces & Connectors
3.2 Internal Parallel Port Connector
3.3 Internal USB2.0 Connector (2 x 2 Ports)
optional Parallelport cable
with ATX bracket

a
g
e
1
Page
TechNotes D3162-B V1.0 Page 16 of 45 www.ts.fujitsu.com/mainboards
Interfaces & Connectors
3.4 Internal USB3.0 Connector (1 x 2 Ports)
3.5 External USB3.0 Connector

a
g
e
1
Page
TechNotes D3162-B V1.0 Page 17 of 45 www.ts.fujitsu.com/mainboards
Interfaces & Connectors
3.6 Fan Connector
Fan speed control is only supported for 4 pin (PWM) fans.
3-pin fans (voltage controlled) can be connected, but they will always operate
at full speed resp. 12V supply voltage!
Fan current: Max. 1A continuous
3.7 Power Supply Fan Connector
Note: This feature is not supported by standard ATX power supplies!
Note:
Fans must never be attached or
removed while the system is
powered. Mainboard may be
damaged!

a
g
e
1
Page
TechNotes D3162-B V1.0 Page 18 of 45 www.ts.fujitsu.com/mainboards
Interfaces & Connectors
3.8 High Definition Frontpanel Audio Connector (HD Audio)
3.9 AC97 Frontpanel Audio Connector (Legacy Audio)
Note: In case of using this connector in AC97 = Legacy mode (BIOS Setting) take care for pin 7.
This pin is tied to GND. HP_ON# signaling on this pin is not supported.

a
g
e
1
Page
TechNotes D3162-B V1.0 Page 19 of 45 www.ts.fujitsu.com/mainboards
Interfaces & Connectors
3.10 Power Supply Connector
3.11 Additional Power Supply Connector

a
g
e
2
Page
TechNotes D3162-B V1.0 Page 20 of 45 www.ts.fujitsu.com/mainboards
Interfaces & Connectors
3.12 Chassis Intrusion
Note:
The intrusion supervision feature needs to be enabled in BIOS Setup first (Menu „Security“ „Cabinet
Monitoring“).
This BIOS option is only available if pin 3 („Intrusion Switch Present“) is connected to GND!
Note:
Chassis intrusion is active even if the system is switched off (S5 state) or
disconnected from mains power.
The intrusion event is monitored by the chipset (PCH) and stored in the BIOS
Eventlog during the next Boot.
A timestamp (Boot date/time) will be added then.
Note: This timestamp does not represent date/time of the intrusion event!
If a Supervisor Password is enabled in BIOS Setup, the system will stop
during BIOS POST if an intrusion event has been detected. In order to
continue, the Supervisor Password must be entered to confirm the intrusion
event.
The intrusion status can be easily monitored by using the BMCAPI (Windows):
ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D3162-B/IndustrialTools_D3162-B/
