Fujitsu D1692 User manual

Technical Manual
Mainboard D1692
English
answers2

Are there ...
... any technical problems or other questions you need clarified?
Please contact:
• your sales partner
• your sales outlet
The latest information and updates (e. g. BIOS update) on our mainboards can be found on the
Internet under: http://www.fujitsu-siemens.com

Dieses Handbuch wurde auf Recycling-Papier gedruckt.
This manual has been printed on recycled paper.
Ce manuel est imprimé sur du papier recyclé.
Este manual ha sido impreso sobre papel reciclado.
Questo manuale è stato stampato su carta da riciclaggio.
Denna handbok är tryckt på recyclingpapper.
Dit handboek werd op recycling-papier gedrukt.
Herausgegeben von/Published by
Fujitsu Siemens Computers GmbH
Bestell-Nr./Order No.: A26361-D1692-Z120-1-7619
Printed in the Federal Republic of Germany
AG 1103 11/03
A26361-D1692-Z120-1-7619

Mainboard D1692
Technical Manual
English
November 2003 edition

AMD, Opteron, and combinations thereof are trademarks of AMD Corporation.
Broadcom® is a trademark of Broadcom Corporation and/or its subsidiaries
IBM, PC, AT, and PS/2 are trademarks of IBM Corporation
Linux is a trademark of Linus Torvalds
Microsoft, Windows are trademarks of Microsoft Corporation
Phoenix, PhoenixBIOS are trademarks of Phoenix Technologies Ltd.
Silicon Image, SATALink are trademarks of Silicon Image
SuSE is a trademark of SuSE AG
Winbond is a trademark of Winbond Electronics Corporation
All other trademarks referenced are trademarks or registered trademarks of their respective owners,
whose protected rights are acknowledged.
Copyright Fujitsu Siemens Computers GmbH 2003
All rights, including rights of translation, reproduction by printing, copying or similar methods, even of
parts are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design, are
reserved. Delivery subject to availability.
Right of technical modification reserved.
This manual was produced by
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de

A26361-D1692-Z120-1-7619 1
Contents
Mainboard D1692.............................................................................................................................1
Notational conventions...............................................................................................................1
Important notes .................................................................................................................................2
Information about boards ...........................................................................................................2
List of features...................................................................................................................................3
Board Installation ............................................................................................................................5
D1692 Block Diagram........................................................................................................................5
Board Parts, Jumpers and Connectors..........................................................................................6
J4, J14, J34, J39, J42 and J43 ..........................................................................................................7
SMBus 1.1 Connector (J4).........................................................................................................7
Onboard Buzzer/Speaker header (J14)......................................................................................8
Clear CMOS Jumper (J34) ........................................................................................................8
PCI-X Slots 3 & 4 Force PCI Mode Jumper (J39) ......................................................................8
COM2 Header (J42)...................................................................................................................8
Front Panel Audio Header (J43) ................................................................................................9
J46, J53, J69, J77, J86, J87, J92, J112, J7, J8, J11, J45 and J117 ................................................10
USB E/F (Front Panel Header) (J46) .......................................................................................11
PCI-X Slots 1 & 2 Bus Speed Override (J53) ...........................................................................11
Firewire Disable Jumper (J69) .................................................................................................11
INTR – Chassis Intrusion Header (J77) ...................................................................................11
Front Panel Header (J86) ........................................................................................................12
Gigabit Ethernet Disable (J87).................................................................................................12
PCI-X Slots 3 & 4 Bus Speed Override (J92) ...........................................................................12
SATA (Serial ATA) Controller Disable (J112)...........................................................................12
RCV (BIOS Recovery) (J7) ......................................................................................................12
BIOS Write Protect (J8) ...........................................................................................................13
USB D (with Chipcardreader support) (J11).............................................................................13
LCD header (J45) ....................................................................................................................13
Remote Temp (J117)...............................................................................................................13
CPU and Chassis Fan Connectors ..................................................................................................14
CPU and System Fan Specifications .......................................................................................14
Add-on modules / Upgrading........................................................................................................15
Installing the Processor(s) ...............................................................................................................15
Heat sink Installation................................................................................................................16
Installing the Memory.......................................................................................................................16
Attaching Drive Cables ....................................................................................................................18
Connecting AUX/CD Sound Cables & Speakers..............................................................................19
Installing Add-In Cards ....................................................................................................................20
Connecting External Devices...........................................................................................................21
Installing the Power Supply..............................................................................................................22
Replacing lithium battery .................................................................................................................23
BIOS update....................................................................................................................................24
When should a BIOS update be carried out?...........................................................................24
How does a BIOS update work? ..............................................................................................24
BIOS Recovery................................................................................................................................24
Glossary .........................................................................................................................................25

A26361-D1692-Z120-1-7619 1
Mainboard D1692
Your mainboard is available in different configuration levels. Depending on the configuration chosen,
some of the hardware components described may not be available on your mainboard.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
!
indicates information which is important for your health or for preventing physical
damage.
i
indicates additional information which is required to use the system properly.
Ê Text which follows this symbol describes activities that must be performed in the order shown.
↵This symbol indicates that you must press the Enter key.
Text in this typeface indicates screen outputs.
Text in this bold typeface indicates the entries you make via the keyboard.
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters or terms.

Mainboard D1692
2 A26361-D1692-Z120-1-7619
Important notes
With the mainboard installed you must open the system to access the mainboard. How to dismantle
and reassemble the system is described in the operating manual accompanying the system.
Connecting cables for peripherals must be adequately shielded to avoid interference.
!
Observe the safety notes in the operating manual of your system.
Incorrect replacement of the lithium battery may lead to a risk of explosion. It is therefore
essential to observe the instructions in the "Replacing lithium battery" section.
Components can become very hot during operation. Ensure you do not touch
components when making extensions to the mainboard. There is a danger of burns!
The shipped version of this board complies with the requirements of the EEC directive
89/336/EEC "Electromagnetic compatibility".
Compliance was tested in a typical PC configuration.
When installing the board, refer to the specific installation information in the manual for
the receiving device.
i
The warranty is invalidated if the system is damaged during the installation or
replacement of expansions. Information on which expansions you can use is available
from your sales outlet or the customer service centre.
Information about boards
To prevent damage to the mainboard, the components and conductors on it, please take great care
when you insert or remove boards. Take great care to ensure that extension boards are slotted in
straight, without damaging components or conductors on the mainboard, or any other components,
for example EMI spring contacts.
Remove the plug from the mains outlet so that system and mainboard are totally disconnected from
the mains voltage.
Be careful with the locking mechanisms (catches, centring pins etc.) when you replace the
mainboard or components on it, for example memory modules or processors.
Never use sharp objects (screwdrivers) for leverage.
Boards with electrostatic sensitive devices (ESD) are identifiable by the label shown.
When you handle boards fitted with ESDs, you must, under all circumstances,
observe the following:
• You must always discharge static build up (e.g. by touching a grounded object)
before working.
• The equipment and tools you use must be free of static charges.
• Remove the power plug from the mains supply before inserting or removing
boards containing ESDs.
• Always hold boards with ESDs by their edges.
• Never touch pins or conductors on boards fitted with ESDs.

Mainboard D1692
A26361-D1692-Z120-1-7619 3
List of features
Processor
• Dual µPGA 940-pin ZIF sockets
• Supports up to two AMD Opteron™processors
• Two onboard 3-phase VRMs
• 128-bit DDR dual-channel memory controller integrated in CPU
Chipset
• AMD-8131™ PCI-X Tunnel
• AMD-8151™ AGP Tunnel
• AMD-8111™I/O Hub
• Winbond W83627HF Super I/O
Memory
• 128-bit DDR dual-channel memory bus
• Eight DIMM sockets (four per CPU)
• Supports a total of 16GB of DDR RAM
• Requires registered RAM
• Supports ECC or non-ECC
• Supports PC2700, PC2100, PC1600
Integrated I/O
• One floppy, Two serial (one header and one connector), and one parallel port connector
• PS/2 KB/mouse connectors
• Total six USB connections (three rear connectors, two front USB headers and one internal
USB header with Chipcardreader support)
• One LCD connector
Expansion Slots
• One 8x AGP/AGP-PRO 110W slot (110W only with 550W power supply, else AGP-Pro 50W)
• Four PCI-X slots
• Two 64-bit (3.3v) PCI-X slots support up to 133 MHz on Bus B
• Two 64-bit (3.3v) PCI-X slots support up to 100 MHz on Bus A
• One legacy 32-bit 33MHz PCI slot (5v)
• Total of six usable slots
System Management
• Four 3-pin fan headers with tachometer monitoring and speed control
• 3-pin Chassis Intrusion header
Integrated Enhanced IDE Controller
• Two ports for up to four EIDE devices
• Supports up to ATA-133 IDE devices

Mainboard D1692
4 A26361-D1692-Z120-1-7619
Integrated Audio
• AMD-8111 AC97 Audio Controller
• Analog Devices AD1981b Audio Codec
• One RCA SPDIF digital connector
• Line-in, line-out (headphone capable), mic-in, rear connectors
• Line out (headphone capable) & MIC front panel headers
• Two 4-pin ATAPI Audio headers
Integrated SATA Controller
• Silicon Image SIL3114 SATA
• Four SATA 1.0 channels
• IDE RAID 0, 1, 0+1 (option)
• 48-bit LBA support
Integrated PCI Firewire
• TI TSB43AB22A IEEE1394A controller
• One external and one internal connector
Integrated Gigabit Ethernet
• Broadcom®BCM5703C Gigabit Ethernet
• RJ-45 LAN connector with LEDs
• Connected to PCI-X Bridge A
• (64-bit 100MHz)
Regulatory
• FCC Class B (Declaration of Conformity)
• European Community CE (Declaration of Conformity)
BIOS
• Phoenix BIOS V4.06 on 4Mbit LPC Flash ROM
• ACPI - 2.0
• PXE via Ethernet
• USB device boot
• 48-bit LBA Support
Form Factor
• SSI EEB v3.0 footprint (13" x 12" 330.2x304.8 mm)
• EPS12V SSI Workstation Spec 2.0 (24pin + 8pin + 6pin) power connector
• Serial (one) connector
• Stacked USB 1.1 (three) connectors
• Stacked PS/2 KB/Mouse connectors
• One RJ-45 LAN connectors with LED
• Line-in/Out, Mic, & SPDIF Audio Connectors
Software Specifications
• OS (Operating System) Support
• Microsoft Windows XP Professional
• Microsoft Windows XP x86/64 Professional
• SuSE Linux
• Red Hat

Board Installation
A26361-D1692-Z120-1-7619 5
Board Installation
!
The mainboard D1692 supports EPS12V/SSI type power supplies (24pin + 8pin + 6pin)
and will not operate with any other types. For proper power supply installation procedures
see "Installing the Power Supply" section
DO NOT USE ATX 2.x, ATX12V or ATXGES power supplies as they will damage the
board and void your warranty.
D1692 Block Diagram

Board Parts, Jumpers and Connectors
6 A26361-D1692-Z120-1-7619
Board Parts, Jumpers and Connectors
This diagram is representative of the latest board revision available at the time of publishing. The
board you receive may not look exactly like the above diagram.
Jumper Legend
OPEN - Jumper OFF without jumper cover
CLOSED - Jumper ON with jumper cover
!Key Pin Missing pin to indicate proper orientation

Board Parts, Jumpers and Connectors
A26361-D1692-Z120-1-7619 7
J4, J14, J34, J39, J42 and J43
SMBus 1.1 Connector (J4)
J4 SMBus 1.1 Connector
Use this connector to connect external SMBUS devices
Pin 1: SMBUS_DATA Pin 2: GND
""""
Pin 3: SMBUS_CLK Pin 4: NC

Board Parts, Jumpers and Connectors
8 A26361-D1692-Z120-1-7619
Onboard Buzzer/Speaker header (J14)
J14 Onboard Buzzer/Speaker header
"""" Close Pin-3 and 4 (Default) - Onboard Buzzer Enabled
"""" Open Pin- 3 and 4 - Disable onboard buzzer or connect to chassis speaker
Clear CMOS Jumper (J34)
J34 Clear CMOS Jumper
"""
(Clear)
"""
(Default)
You can reset CMOS settings by using this jumper if you have lost your
system/setup password or need to clear system BIOS setting.
There are three easy steps:
Power off system and disconnect all three power connectors from the
motherboard
Use jumper cap to close Pin2 and Pin3 for several seconds to Clear CMOS Put
jumper cap back to Pin1 and Pin2 (default setting)
Reconnect power & power on system
NOTE: If you do not disconnect the power connectors from the motherboard the
CMOS may not clear completely.
PCI-X Slots 3 & 4 Force PCI Mode Jumper (J39)
J39 PCI-X Slots 3 & 4 Force PCI Mode Jumper
"" Open - (Default) Allows PCI 3 & 4 to operate in PCI-X mode
"" Closed - Force PCI slots 3 & 4 to operate in PCI compatibility mode
Close this jumper if the card you are using does not support PCI-X
COM2 Header (J42)
J42 COM2 Header
""
""
""
""
"!
Use these pin definitions to connect a port to COM2
Signal Pin Pin Signal
Data Carrier Detect 1 2 Data-Set-Ready
Receive-Data 3 4 Request-to-Send
Transfer-Data 5 6 Clear-to-Send
Data Terminal Ready 7 8 Ring-Indicator
Ground 9 10 NC/KEY

Board Parts, Jumpers and Connectors
A26361-D1692-Z120-1-7619 9
Front Panel Audio Header (J43)
J43 Front Panel Audio Header
""
""
""
"!
""
If you remove the front panel audio cable you have to put jumpers on Pin 5&6 and
Pin 9&10 to get audio or microphone signals on your front or rear audio
connections.
Signal Pin Pin Signal
MIC In FP 12 Audio GND
MIC BIAS 34Audio Analog
Right Front out 5 6 Right Rear In
No Connect 78 Key
Left Front Out 910 Left Rear In
WARNING: Do not place jumpers on this header in any other configuration. Doing
so could result in damage to the motherboard!

Board Parts, Jumpers and Connectors
10 A26361-D1692-Z120-1-7619
J46, J53, J69, J77, J86, J87, J92, J112, J7, J8, J11,
J45 and J117
