Fujitsu LAN Console Quick guide

LAN Console
Installation, Configuration and Operation
E. Hübner-Hatzel
Fujitsu Siemens Computers GmbH UNIX
33094 Paderborn
e-mail: Internet:[email protected]
Tel.: (05251) 814895
Fax: (0 52 51) 8-1 52 48
U41224-J-Z916-1-76
Sprachen: De
Edition October 2001

This manual is printed on
paper treated with
chlorine-free bleach.
Comments…Suggestions…Corrections
…
The User Documentation Department would like to know
your opinion on this manual. Your feedback helps us to
optimize our documentation to suit your individual needs.
Fax forms for sending us your comments are included at
the back of the manual.
There you will also find the addresses of the relevant
User Documentation Department
Copyright and Trademarks
Copyright © 2000, 2001 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.
This manual was produced by
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de

U41224-J-Z916-1-76
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Target group . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Summary of contents . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . . 4
2 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 Functions supported . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 LAN Console . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1 Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.1 Power ratings . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.2 Environmental conditions . . . . . . . . . . . . . . . . . . . . 13
4.1.3 Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2 Startup and operation . . . . . . . . . . . . . . . . . . . . . . 14
4.2.1 Scope of Delivery . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2.2 Unpacking and checking the delivery unit . . . . . . . . . . . . 14
4.2.3 Installing the LAN Console . . . . . . . . . . . . . . . . . . . 15
4.3 Overview of connections . . . . . . . . . . . . . . . . . . . . . 16
4.3.1 Connecting the keyboard . . . . . . . . . . . . . . . . . . . . 17
4.3.2 Connecting the mouse . . . . . . . . . . . . . . . . . . . . . . 17
4.3.3 Connecting devices with a serial or parallel interface . . . . . . 18
4.3.4 Connecting the monitor . . . . . . . . . . . . . . . . . . . . . 18
4.3.5 Connecting the LAN Console to the power supply . . . . . . . 19
4.4 Operating the LAN Console . . . . . . . . . . . . . . . . . . . 21
4.4.1 Switching on/off the LAN Console . . . . . . . . . . . . . . . 21
4.4.1.1 System unit is switched off . . . . . . . . . . . . . . . . . . . . 21
4.4.1.2 System unit is ready to operate . . . . . . . . . . . . . . . . . 21
4.4.1.3 System unit is switched on . . . . . . . . . . . . . . . . . . . 22
4.4.2 Indicators on the system unit . . . . . . . . . . . . . . . . . . 22
4.4.3 Pre-installation . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.4.4 Hard disk partitioning . . . . . . . . . . . . . . . . . . . . . . 23
4.4.5 First Booting . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.5 Installing the software packages . . . . . . . . . . . . . . . . . 25
4.6 Starting WSA . . . . . . . . . . . . . . . . . . . . . . . . . . 28

U41224-J-Z916-1-76
Contents
5 Installing the RCA . . . . . . . . . . . . . . . . . . . . . . . . 29
5.1 Connecting the cables . . . . . . . . . . . . . . . . . . . . . . 29
5.1.1 LAN connection . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.1.2 Serial interface for connecting the console . . . . . . . . . . . . 30
5.1.3 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.1.4 Connections at the rear of the RCA . . . . . . . . . . . . . . . . 31
5.1.4.1 Connecting to the RM server . . . . . . . . . . . . . . . . . . . 32
5.1.4.2 Connecting to the PRIMEPOWER (MR) server . . . . . . . . . 33
5.2 Cable types . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.2.1 PRIMEPOWER 100N . . . . . . . . . . . . . . . . . . . . . . . 34
5.2.2 RM and PRIMEPOWER 200-600 . . . . . . . . . . . . . . . . . 34
5.3 Technical specifications . . . . . . . . . . . . . . . . . . . . . . 35
5.3.1 Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.3.2 Power ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.3.3 Environmental conditions . . . . . . . . . . . . . . . . . . . . . 36
5.3.4 Dimensions and weights . . . . . . . . . . . . . . . . . . . . . 36
5.3.5 Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.4 Switching on the RCA . . . . . . . . . . . . . . . . . . . . . . . 38
6 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.1 Configuring the PRIMEPOWER (MR) . . . . . . . . . . . . . . 39
6.2 Configuring the LAN Console and RCA . . . . . . . . . . . . . 40
6.2.1 Initial configuration of the LAN Console and RCA . . . . . . . . 42
6.2.1.1 Configuring the LAN Console . . . . . . . . . . . . . . . . . . . 43
6.2.1.2 Configuring the RCA . . . . . . . . . . . . . . . . . . . . . . . 45
6.2.2 New ports for the RCA . . . . . . . . . . . . . . . . . . . . . . 51
6.2.3 Another RCA connected to the LAN Console . . . . . . . . . . . 52
6.2.4 Another LAN Console connected to the RCA . . . . . . . . . . . 52
6.2.5 Modifying the LAN Console and RCA . . . . . . . . . . . . . . 52
6.2.5.1 Modifying the configuration entry for an RCA port . . . . . . . . 53
6.2.5.2 Modifying the RCA setup parameters . . . . . . . . . . . . . . . 53
6.2.5.3 Removing a LAN Console . . . . . . . . . . . . . . . . . . . . 53
6.2.5.4 Removing an RCA . . . . . . . . . . . . . . . . . . . . . . . . 54
6.3 Teleservice . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.3.1 Installation and generation . . . . . . . . . . . . . . . . . . . . 56
6.3.1.1 Hardware installation . . . . . . . . . . . . . . . . . . . . . . . 56
6.3.1.2 Software installation . . . . . . . . . . . . . . . . . . . . . . . 57
6.3.2 Generating the software . . . . . . . . . . . . . . . . . . . . . 57
6.3.2.1 Logging in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
6.3.2.2 Selecting validated Teleservice modems . . . . . . . . . . . . . 59
6.4 TeleCall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
6.4.1 Installing Telecall . . . . . . . . . . . . . . . . . . . . . . . . . 66
6.4.1.1 Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
6.4.1.2 Software installation on the LAN Console . . . . . . . . . . . . 66

U41224-J-Z916-1-76
Contents
6.4.1.3 Software installation on the RM . . . . . . . . . . . . . . . . . 67
6.4.1.4 Software installation on the PRIMEPOWER (MR) . . . . . . . . 67
6.4.2 Generating the Telecall cluster . . . . . . . . . . . . . . . . . 67
6.5 Remote boot und installation . . . . . . . . . . . . . . . . . . 71
6.5.1 setup_RM_server . . . . . . . . . . . . . . . . . . . . . . . . 72
6.5.2 bootpconf . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
6.5.3 add_RM_client . . . . . . . . . . . . . . . . . . . . . . . . . . 76
7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
7.1 xscon call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
7.2 Switching LAN Consoles . . . . . . . . . . . . . . . . . . . . 82
7.2.1 Planned switches . . . . . . . . . . . . . . . . . . . . . . . . 82
7.2.2 Switching because of problems . . . . . . . . . . . . . . . . . 83
7.3 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
7.3.1 Log files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
7.3.2 Status informations for the rtty monitor . . . . . . . . . . . . . 84
7.3.3 Configuration entries for the LAN Console . . . . . . . . . . . 84
7.3.4 System information for the RCA . . . . . . . . . . . . . . . . . 85
7.4 Error situations . . . . . . . . . . . . . . . . . . . . . . . . . . 86
7.4.1 No response from the RCA . . . . . . . . . . . . . . . . . . . 86
7.4.2 Failure to establish a connection . . . . . . . . . . . . . . . . 86
7.4.3 Disrupted RCA - LAN Console connection . . . . . . . . . . . 87
7.4.3.1 LAN connection disrupted . . . . . . . . . . . . . . . . . . . . 87
7.4.3.2 No output in console window . . . . . . . . . . . . . . . . . . 88
7.4.4 Invalid password for RCA setup . . . . . . . . . . . . . . . . . 88
7.4.5 Incorrect remote call of RCA setup . . . . . . . . . . . . . . . 88
8 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
8.1 Access control . . . . . . . . . . . . . . . . . . . . . . . . . . 90
8.2 Language/Keyboard . . . . . . . . . . . . . . . . . . . . . . . 91
8.3 Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
8.4 Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
8.5 Mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
8.6 Graphics/Screen . . . . . . . . . . . . . . . . . . . . . . . . . 97
8.7 DPMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
8.8 Hosts/DNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
8.9 Sessions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
8.10 Firmware update . . . . . . . . . . . . . . . . . . . . . . . . . 103
8.11 System information . . . . . . . . . . . . . . . . . . . . . . . 105
8.12 Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
8.13 Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

U41224-J-Z916-1-76
Contents
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

U41224-J-Z916-1-76 1
1 Preface
The LAN Console acts as a system console for one or more RM or PRIME-
POWER midrange servers. The server systems are connected to the LAN Con-
sole via the RCA (Remote Communication Adapter), a V.24/Ethernet converter
located close to the system (max. 15m away) or in the system cabinets. The
LAN Console can be connected at any point in the LAN, thusat a distance away
from the systems being administered.
The LAN Console is based on a high-performance SPARC processor in a desk-
top model, which can also be installed and operated in a 19-inch rack using a
rack mounting kit. It is released for the following products:
– RM300/400/600 with Reliant UNIX
– PRIMEPOWER 100N/200/400/600 (Midrange Server, MR) with Solaris
– PRIMEPOWER 800/1000/2000 (Enterprise Server, EP) with Solaris
This SPARC-based LAN Console canbe usedboth as acentral systemconsole
for midrange servers and asa system management console for enterpriseserv-
ers.
Midrange Server
This includes the RM 300/400/600, ServerNode models and the
PRIMEPOWER midrange server models 100N/200/400/600. Genuine
LAN console software is used on the LAN Console for managing the
server systems. The Remote Communication Adapter (RCA) can be
used as a V.24/Ethernet converter.
Enterprise Server
This includes the PRIMEPOWER server models 800/1000/2000. The
LAN Console is used as a system management console (SMC), which
manages systems and system partitions with upgrade components. The
SPARC-based LAN Console is a cost-effective alternative to an SMC on
the basis of a PRIMEPOWER 200 system console. When used as an
SMC, the LAN Console should be equipped with additional hardware.
The SCS (System Console Software) software is used as well as the
Console Connection Units (CCU) as V.24/Ethernet converters in the sys-
tem cabinets. Use of the console as an SMC is not described in this man-
ual, rather in the manual
“PRIMEPOWER (Solaris): System Management Console”.

2 U41224-J-Z916-1-76
Preface
Throughoutthismanual,thename PRIMEPOWER(MR)alwaysrefers to
the models 100N, 200, 400 and 600. If you have a GP7000 F midrange
(M200/M400/M600)machine,allofthePRIMEPOWER(MR)information
applies to your machine also, because the name GP7000F has been
changed to PRIMEPOWER.
Mixed operation RM/PRIMEPOWER (MR and EP)
The midrange models referred to from both system families can be man-
aged in mixed mode from a LAN Console with the xscon user interface.
xscon and SCS (System Console Software) can be operated in parallel
on a LAN console with the relevant hardware/software configuration.
It is not only possible to use the LAN Console in its console function but also for
(network-based)systemadministration,configuration,diagnosticsandsoftware
installationanddistributionforoneormoreRM orPRIMEPOWER(MR)servers.
Furthermore, multiple clustered RM or PRIMEPOWER (MR) servers can be
configured, administered and monitored from one console.
The Teleservice connection for all networked RM or PRIMEPOWER (MR) serv-
ers is also handled via the LAN Console (Teleservice gateway) so only one line
to the Service organization is needed for all networked RM or PRIMEPOWER
(MR) servers.
When connected to a LAN (local area network), the console can be located at
any point in the LAN, for example in another room or building. The distance is
no longer restricted to 15 m max. The existing V.24 console interfacing has not
been changed so that the console can be used both for existing and new RM or
PRIMEPOWER (MR) servers.
The LAN Console product consists of a SPARC-based machine with the Solaris
Version 8 operating system, the Solaris Desktop Media Kit, and the LAN con-
sole software (see “Installing the software packages” on page 25).
A Remote Communication Adapter (RCA) is needed to establish a connection
from the LAN Console to the RM or PRIMEPOWER (MR) server’s console port.
Up to six RM or PRIMEPOWER (MR) servers can be connected to this RCA.
Multiple RCAs can be installed. Up to 64 RM or PRIMEPOWER (MR) systems
can be managed from the LAN Console.
RM and PRIMEPOWER (MR) servers can be operated in combination on an
RCA.
IThe RCA and LAN Console must be ordered separately.

U41224-J-Z916-1-76 3
Preface Target group
1.1 Target group
This manual is targeted at system administrators. Knowledge of Reliant UNIX
and Solaris systems is required. If any problems occur with the RCA (Remote
Communication Adapter) or the SPARC-based LAN Console during operation,
please contact your local Service organization.
VLAN Console and RCA are not SIDATA-compatible
The LAN Console and RCA do not support SIDATA, i.e. they must be
installed andstarted up by a technician. Systemadministrators are given
instructions on setting them up and configuring them.
1.2 Summary of contents
VSafety notes
It is essential to read the chapter “Safety notes” on page 5 before start-
ing to work with the LAN Console. This chapter contains essential infor-
mation for proper installation and handling of this device.
This manualdescribes how toinstall theLAN Console and theRCA, how to con-
figure the system and how to operate the LAN Console.
The chapter “LAN Console” on page 9 tells you everything about installing the
LAN Console and setting up the software from the CD-ROM.
The chapter “Installingthe RCA” on page 29 presents the hardware of the RCA.
It tells you how to install the device, cable it and start it up.
The chapter “Configuration” on page 39 explains the (initial) configuration of the
RCA and LAN Console, how to set up Teleservice and TeleCall and remote
boot/installation.
The chapter “Operation” on page 79 describes how to select RM systems with
xscon and how to change a LAN Console.
The section “Diagnostics” on page 83 provides support for troubleshooting and
diagnostics.
The “Appendix” on page 89 contains screen masks for setting up the RCA.
You will find other helpful information in the reference chapters “Glossary” on
page 109, “Related publications” on page 115 and “Index” at the end of the
manual.

4 U41224-J-Z916-1-76
Notational conventions Preface
IPlease follow all instructions in the order they appear in thismanual. You
willavoidproblemsbydoingsoandgetalongfaster.Alwayspayattention
to the device-specific information that is supplied with the various
devices.
1.3 Notational conventions
The following notational conventions are used in this manual:
Monospace This indicates system output, e.g. text on a CRT or
LCD screen (cathode ray tube / liquid crystal dis-
play).
Bold
monospace font This indicates user inputs in examples.
Italics This indicates commands, file names, menu names
and inputs in continuous text.
Bold This indicates emphasis in the text.
[Taste] This indicates keys or key combinations in continu-
ous text.
IThis indicates additional information and tips.
VTitle This indicates information, which if not heeded may
jeopardize your health, the functioning of your sys-
tem or the security of your data.
ÊThis indicates a step that you have to do.
--> Thisindicatesthe lastpossiblesolutionto aproblem
or the last step in a flow chart.
●This character and the one below
– Symbolizes itemized lists.

U41224-J-Z916-1-76 5
2 Safety notes
This section gives advice on safety that you have to heed when usingyour LAN
Console or RCA.
Thisdevicecomplieswith therelevantsafety regulationsfor informationtechnol-
ogy equipment including electrical machines for use in office environments.
Please contact your local sales office or our Service organization if you are in
doubt about whether the device can be installed in the environment you envis-
age. Also note the safety notes for RM and PRIMEPOWER (MR) and rack sys-
tems.
VRadio Frequency Interference Statement
(see also the statements given in section “Standards” on page 14 and
page 37).
●The following notice is for EU users only:
This is a product which meets class B of EN55022.
●The following notice is for USA users only:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference.
VSafety notes
●Only transport the device in its original packaging or in other suitable
packaging, which will protect it against impact and jolts.
●Condensation may occur when the device is brought in from the cold
to its site of installation. Wait until the device has reached a stable
temperature and is absolutely dry before putting it into operation.
●Heed the ambient conditions given in the “Technical specifications”
on page 35 before installing the device and putting it into operation.
●This device features a safety-tested power cable and may only be
connected to a grounded socket.
●Make sure that the socket on the device or the mains socket on the
housing installation are readily accessible.

6 U41224-J-Z916-1-76
Safety notes
●The ON/OFF button does not isolate the device from the mains volt-
age completely. To do this, you have to remove the plug from the
mains socket.
●In the case of system units that do not have a main switch, the
ON/OFF button does not disconnect the monitor socket from the
mains supply. A monitor connected to this socket must always be
switched off using its own ON/OFF button.
●Lay cables in such a way that there is no danger of people tripping
overthemanddamagingthem. Whenconnectingthedevice,notethe
information given in the section “Connecting the cables” on page 29.
●Do not connect or disconnect communication cables during a thun-
derstorm.
●Make sure that no liquids penetrate the interior of the device (risk of
electric shock, short-circuit).
●In cases of emergency (e.g. damage to the housing, controls or
power cable, or penetration of liquid) turn the device off immediately,
remove the mains plug and notify your sales office or our Service
organization.
●This device may only be repaired by authorized personnel. Unautho-
rized opening of the housing and inadequate repairs may pose a con-
siderable danger for users (electric shock, risk of ignition).

U41224-J-Z916-1-76 7
3 Functionality
This chapter describes the functionality of the LAN Console for RM and PRIME-
POWER (MR) servers.
3.1 Functions supported
The LAN Console supports the following functions:
1. It can be used for installation, configuration, administration, and cluster and
diagnostics management of one or more connected RM or PRIMEPOWER
(MR) servers.
2. It can be used as System Management Console (SMC) of PRIMEPOWER
Enterprise Servers. This requires an upgrade of 128 MByte main memory,
DAT drive, Combo controller and System Console Software (SCS), which
are not part of the standard LAN Console.
3. Input and output take placeon the keyboard and displayof the LAN Console.
4. All functions of a character-oriented display, including IKDB (Internal Kernel
Debugger) and BDM (Board Debug Monitor) or OBP (Open Boot Prom)
Monitor and rebooting of a system can be carried out with the LAN Console.
5. The xscon tool is used to select and represent one or more consoles of RM
and PRIMEPOWER (MR) servers.
6. RM and PRIMEPOWER (MR) servers can also be booted and installed
remotely (via LAN).
7. Connection to Teleservice.
8. The LAN Console can be used simultaneously as a console on RM and
PRIMEPOWER (MR) servers and with hardware/software upgrades as an
SMC for the PRIMEPOWER Enterprise Server.
9. The LAN Console can be used as cluster console in high availability appli-
cations with RM an PRIMEPOWER (MR) Servers. This requires additional
components such as a further ethernet controller and software, which are
not part of the standard LAN Console. By default the LAN Console has two
Fast Ethernet controllers (onboard). The console takes over the function of
monitoring the system cluster as a whole and the function of system console
for all connected RM and PRIMEPOWER systems.

8 U41224-J-Z916-1-76
Architecture Functionality
10. The console can also be used as a computer system in its own right.
3.2 Architecture
Figure 1: Architecture of the LAN Console
RM systems and/or
PRIMEPOWER (MR)
systems
2 x V.24 4 x V.24
Remote Communication Adapter
RCA
Ethernet TCP/IP
LAN Console

U41224-J-Z916-1-76 9
4 LAN Console
The LAN Console is based on a high-performance SPARC-based computer
system running the Solaris 8 operating system. It is connected with the RCA
(Remote Communication Adapter) via the LAN (TCP/IP).
The LAN Console can be used as a standalone system indesktop housing with
a desktop monitor, standard PC keyboard (German/International) and 3-button
mouse.
Figure 2: LAN Console as a standalone system
A mounting frame is provided for installing the LAN Console in a 19-inch rack
(3.5 height units), as well as a pull-out rack console with fold-away TFT monitor
(15”/35cm) and keyboard with trackball.

10 U41224-J-Z916-1-76
LAN Console
Figure 3: LAN Console rack module
Figure 4: Fold-away monitor of LAN Console in the rack
The power supply is enabled when the monitor is tilted open. At the same time,
a safety mechanism on the right hand side of the rack module prevents the rack
being pushed back in while the monitor is tilted open.

U41224-J-Z916-1-76 11
LAN Console Hardware
4.1 Hardware
The LAN Console is provided with the following hardware:
Hardware elements Configuration/Performance
Processor 500MHz UltraSparc IIe
Main memory 128 MByte (max. 2 GByte possible)
Graphics controller Resolution of 1280x1024 pixels, 24-bit
color, VGA port, VGA controller integrated
on motherboard
DVD drive 12x DVD/40x CD-ROM or better
Diskette drive 1.44 MByte
2 x Fast-Ethernet onboard 2 x 10/100 Mbits/s
Hard disk 2 x 20 GByte
V.24 interface COM1 and COM2, DB9 Connector
COM2 for Teleservice
PS/2 interface 3-button mouse for X-Windows interface
PS/2 interface Keyboard German/international
Audio on board
Table 1: LAN Console hardware components
Upgrade to SMC
DAT drive DDS-4
Main memory extension 128 MByte (1x128 MByte module)
SCSI / Fast Ethernet Combo controller
System Console Software SCS (CD-ROM, license, documentation)
Table 2: Upgrade to SMC

12 U41224-J-Z916-1-76
Hardware LAN Console
4.1.1 Power ratings
VDifferent mains voltages
Note the different mains voltages in Anglo-American countries. You will
find details of this in the English language Operating Manual for the
RM600 and PRIMEPOWER (MR) as well as in the general safety notes
for RM/SR-2000 and GP7000F/PRIMEPOWER (MR) servers.
Mains voltage range
(switchable) 100V-125V/ 200V-240V
Rated frequency 50-60 Hz
Power consumption approx. 60 W
Power factor cosϕ120V: >0.90
230V: >0.75
Table 3: Power ratings

U41224-J-Z916-1-76 13
LAN Console Hardware
4.1.2 Environmental conditions
Environmental conditions for the LAN Console
Climatic class Operation:
(acc. to EN 60721-3-x) 3K3
– Temperature (°C):
– Relative humidity (%):
– Height above sea-level (m):
5 – 40
5 – 85
3000
Climatic class Transport:
(acc. to EN 60721-3-2) 2K2
– Temperature (°C):
– Relative humidity (%) at 30°C:
– Height above sea-level (m):
-25 – +60
15 – 98
3000
Physically active substances (operation): 3M2
Physical environmental conditions:
Operation
Transport 3M2
2M2
Required space for service activities
– Minimum distance (mm)
front:
rear: 1000
1000
Table 4: Environmental conditions
Dimensions and weight Desktop housing Rack module
Breadth (mm):
Depth (mm):
Height (mm):
Weight basic configuration (kg)1
Weight SMC (kg)1
1without documentation and media kit
454
456
138
11
12
449 (with panel 482.6)
456
138 (with panel 152)
11,2
12,2
Table 5: Dimensions and weight

14 U41224-J-Z916-1-76
Startup and operation LAN Console
4.1.3 Standards
4.2 Startup and operation
The LAN Console can be used as a central console for one or more RM or
PRIMEPOWER- (MR) servers. Up to 64 RM or PRIMEPOWER (MR) servers
can be administrated from one LAN Console.
VWarning
Please refer to the chapter “Safety notes” on page 5.
4.2.1 Scope of Delivery
The product LAN Console only consists of the system unit. RCA, monitor, key-
board and mouse, the modem for teleservice and the requested cables are not
part of the scope of delivery and have to be ordered separately.
4.2.2 Unpacking and checking the delivery unit
You should keep the original device packaging in case the device has to be
transported.
ÊUnpack all the parts.
ÊCheck the package contents for visible transport damage.
ÊCheck that the delivery matches the details on the delivery note.
Ifyoudiscovertransportdamage orinconsistenciesbetweenthepackagingunit
and the delivery note, inform your local sales office immediately.
Product safety IEC60950; EN60950
UL60950;CSA60950-00
GS symbol
Immunity to radiation EN55024
Radiated interfer-
ence EN 55022-B; EN 61000-3-2; EN 61000-3-3
FCC Class B
Approvals GS symbol;cCSAUS; CE; CB certificate
Table 6: Standards
