Fujitsu LOOX 610 Product information sheet

EasyGuide
Pocket LOOX 610
English
answers2

Are there ...
... any technical problems or other questions which you would like to be clarified?
Please contact:
•your sales partner
•your sales outlet
Further information can be found in the "Safety and Ergonomics" and "Warranty" manuals.
The latest information on our products, tips, updates, etc., can be found on the internet under:
http://www.fujitsu-siemens.com

Published by
Fujitsu Siemens Computers GmbH
Order No.: A26391-K139-Z120-2-7619
AG 0903 09/03

Pocket LOOX 610
May I introduce myself?
Technical data
Information before you
start
Index
Software overview
Operating pocket LOOX
610
Pocket LOOX 610 in
mobile use
FSC SpeedMenu
Confi
g
urin
g
Pocket LOOX
610
Connecting and
networking Pocket LOOX
610 with other devices
Accessories and
additional components
Troubleshooting and tips
September 2003 edition

Adobe and Acrobat are trademarks of Adobe systems Incorporated and may be protected in
certain countries.
Intel is a registered trademark, XScale is trademark of Intel Corporation, USA.
Microsoft, MS, Microsoft Pocket PC 2003 and Microsoft Windows for Pocket PC are
registered trademarks of Microsoft Corporation.
The BLUETOOTH trademarks are the property of BLUETOOTH SIG, Inc., U.S.A. licensed
for Fujitsu Siemens Computers GmbH.
All other trademarks referenced are trademarks or registered trademarks of their respective
owners, whose protected rights are acknowledged.
Copyright Fujitsu Siemens Computers GmbH 2003
All rights, including rights of translation, reproduction by printing, copying or similar methods,
in part or in whole, are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved.
Delivery subject to availability. Right of technical modification reserved.

A26391-K139-Z120-2-7619
Contents
May I introduce myself?..................................................................................................................1
Information before you start...........................................................................................................3
To make things clear.........................................................................................................................3
Important notes..................................................................................................................................4
Safety notes ..............................................................................................................................4
Energy saving............................................................................................................................5
Disposal and recycling...............................................................................................................5
CE markings..............................................................................................................................5
Battery storage..........................................................................................................................6
Cleaning Pocket LOOX 610.......................................................................................................6
Software overview...........................................................................................................................7
Operating pocket LOOX 610 ...........................................................................................................9
Overview of operating elements and connections............................................................................10
Initial start-up...................................................................................................................................11
Removing stylus from Pocket PC ............................................................................................12
Actuate full reset switch...........................................................................................................12
Installing the battery.................................................................................................................13
Connecting the power adapter AD 3110 ..................................................................................14
Starting Pocket LOOX 610 the first time..................................................................................15
Switching Pocket PC off and on.......................................................................................................16
Switch on and off in Suspend mode.........................................................................................16
Switching on and off with soft reset (warm boot)......................................................................17
Switching on and off with Full Reset switch .............................................................................17
Using standard operating elements .................................................................................................21
Using stylus.............................................................................................................................21
Using navigation key................................................................................................................21
Using the arrow keys...............................................................................................................22
Using the application buttons...................................................................................................23
Adjusting display lighting .................................................................................................................23
Making sound recordings.................................................................................................................24
Using the cradle...............................................................................................................................25
Selecting location for cradle.....................................................................................................25
Adjusting the locking catch......................................................................................................26
Charging battery in cradle........................................................................................................27
Using cradle for data synchronisation......................................................................................27
Synchronising data with ActiveSync................................................................................................28
Installing ActiveSync................................................................................................................28
Connecting Pocket PC directly to ActiveSync cable ................................................................28
Establishing an ActiveSync partnership...................................................................................28
Backing up data with FSC Backup...................................................................................................29
Backup ....................................................................................................................................29
Restoring.................................................................................................................................30
Panning instead of scrolling with FSC Panning................................................................................30
Inserting and removing expansion cards..........................................................................................31
Inserting CompactFlash expansion card..................................................................................31
Inserting SD/MMC expansion card ..........................................................................................33
Removing CompactFlash expansion card................................................................................34
Removing SD/MMC expansion card........................................................................................35

Contents
A26391-K139-Z120-2-7619
Pocket LOOX 610 in mobile use...................................................................................................37
Using battery................................................................................................................................... 37
Charging the battery................................................................................................................ 37
Optimising battery performance .............................................................................................. 38
Checking battery charge level................................................................................................. 38
Information on transport and travelling............................................................................................ 39
Transporting Pocket LOOX 610 .............................................................................................. 39
Information on travelling.......................................................................................................... 39
FSC SpeedMenu - Operating pocket LOOX 610 quickly with one hand................................... 41
Operating FSC SpeedMenu............................................................................................................ 41
Programme structure ...................................................................................................................... 42
Main and quick menu.............................................................................................................. 42
Editing FSC SpeedMenu................................................................................................................. 44
Tips and tricks................................................................................................................................. 45
Configuring Pocket LOOX 610.....................................................................................................47
Optimising energy management...................................................................................................... 47
General information on energy management........................................................................... 47
Displaying battery status......................................................................................................... 47
Using energy-saving functions ................................................................................................ 48
Configuring hardware buttons ......................................................................................................... 50
FSC KeyLock: preventing switch-on via application buttons.................................................... 50
Assigning chosen functions to the hardware buttons............................................................... 50
Adjusting menus ............................................................................................................................. 51
Using security functions.................................................................................................................. 51
Password protection under Pocket PC 2003........................................................................... 51
Changing time................................................................................................................................. 52
Using alarm functions...................................................................................................................... 53
Connecting and networking Pocket LOOX 610 with other devices........................................... 55
Safety precautions when using radio components .......................................................................... 55
Wireless data transfer with infrared interface................................................................................... 56
Wireless communication with BLUETOOTH (optional).................................................................... 56
Selecting location for BLUETOOTH operation......................................................................... 57
Activating and deactivating BLUETOOTH............................................................................... 57
Wireless connection via Wireless LAN (optional) ............................................................................ 57
Accessories and additional components.................................................................................... 59
Troubleshooting and tips............................................................................................................. 61
Installing new software............................................................................................................ 61
Date or time of the Pocket PC is incorrect............................................................................... 61
The display of the Pocket PC remains dark............................................................................. 61
The information on the display of the Pocket PC is difficult to read......................................... 61
The Pocket PC switches off .................................................................................................... 62
The Pocket PC does not start after switch on.......................................................................... 62
The Pocket PC stops working................................................................................................. 63
The battery discharges too quickly.......................................................................................... 66
The Suspend button does not respond properly...................................................................... 67
No sound or minimal volume................................................................................................... 67
Contact with hotline/help desk................................................................................................. 67
Technical data............................................................................................................................... 69
Pocket LOOX 610........................................................................................................................... 69
Battery ............................................................................................................................................ 70
Power adapter AD 3110.................................................................................................................. 70

Contents
A26391-K139-Z120-2-7619
Index...............................................................................................................................................71

A26391-K139-Z120-2-7619 1
May I introduce myself?
My name is Pocket LOOX 610. I am part of the Pocket PC family, also called handhelds.
I'm sure you've already noticed that I'm flat, handy and light-weight. Now I'd like to draw your
attention to my extensive, diverse capabilities.
I am equipped with the Office applications MS-Word, Excel and Outlook - naturally all in the Pocket
version. In Outlook you can not only receive and send e-mails, you can also manage your
appointments and let me remind your of the things you have to do. Of course, you can also enter
your address list in me so that you can access names (e-mail) addresses and telephone numbers
when you're on the go. You can enter notes in me in writing or verbally as with a dictaphone.
Memory cards, which you can buy in various sizes, ensure that I can also reliably hold and retain
large amounts of data.
In the office you can then effortlessly transfer all your data and newly created documents to your
notebook or PC. To do this, just insert me in my cradle, install ActiveSync on your PC and you're
ready to synchronise your data. In addition, a short stay in the cradle also gives me new power, as
my battery will be charged while I'm there. If you don't have your cradle at hand, for example in a
hotel room, it doesn't matter. You can synchronise your data using the ActiveSync cable via the
infrared interface or with BLUETOOTH, and you can charge my battery with the power adapter.
And since life isn't all work and no play, I offer you additional functions as well. You can read your
favourite book quite comfortably on my display or use me as an MP3 player. Insert the memory card
of your digital camera in the suitable card slot and you can view the photos you just took on my
display.
Have you already noticed that I provide you with two slots? You can use different cards at the same
time. And how about the combination memory card and GSM/GPRS CompactFlash card? Or you
can combine two memory cards for maximum memory capacity.
With BLUETOOTH, the infrared interface and the integrated Wireless LAN (depending on the
model), you can also connect to other devices in your office and on the go without bothersome
cables. For example, thanks to BLUETOOTH you can take me into the Internet without cables with
your BLUETOOTH-capable cell phone. Naturally, I also have the Pocket Internet Explorer ready for
you. With it you can visit both websites and WAP sites.
Incidentally, if you install a GSM/GPRS CompactFlash card in me I am completely autonomous
when it comes to Internet and data connections: send your emails, carry out research in the net or
synchronise your data (e.g. via XTND Connect), regardless of where you are at the moment.
For long hours far from a power connection and cradle, I can warmly recommend the Main Battery
XL (also available as an accessory). In conjunction with the Main Battery XL, I can offer you up to
24 hours of battery runtime, depending on your preferred applications.

May I introduce myself?
2A26391-K139-Z120-2-7619
But whether with or without accessories, you'll notice I'm fully willing and able to help you in a wide
variety of situations. Thanks to the FSC SpeedMenu and the corresponding keys you can also operate
me with one hand. Test my diversity! - This manual will help you do that!
The following documentation contains additional information on your Pocket PC and the Pocket PC
2003 operating system:
•in the manuals "Safety and Ergonomics" and “Warranty"
•in the "Getting Started" manual
•in the help on your Pocket LOOX.

A26391-K139-Z120-2-7619 3
Information before you start
To make things clear
The following symbols are used in this manual:
!Pay particular attention to texts marked with this symbol. Failure to observe
this warning may endanger your life, destroy the system, or lead to loss of
data. Failure to follow the instructions may lead to loss of data, invalidate
your warranty, destroy the Pocket PC, or endanger your life.
i
Indicates important information which is required to use the system
properly.
ÊText which follows this symbol describes activities that must be performed
in the order shown.
This font indicates screen outputs.
This font indicates programme names, commands, or menu items.
"Quotation marks" indicate names of chapters, data carriers, and terms that are being
emphasised.

Information before you start
4A26391-K139-Z120-2-7619
Important notes
This chapter contains information on the proper, safe use of your Pocket PC. Please be sure to
observe the following safety precautions to prevent damage to your device, data loss or damage to
your health. The information on saving energy, charging the battery and cleaning your Pocket PC
are very important for proper operation of the Pocket LOOX 610. To protect the environment, we
urgently ask that you observe the disposal and recycling information.
Keep this operating manual together with the device. If you pass on the device to a third party,
please also pass on the operating manual.
Safety notes
!Pay attention to the information provided in the "Safety and Ergonomics" and "Warranty"
manuals and in the following security notes.
Observe the sections in the manual marked with the symbol on the left.
•The Pocket LOOX 610 is a technical device that contains small parts. Therefore, please keep
your Pocket PC out of reach of children under 36 months of age.
•When setting up and before operating the device, observe the information on the environmental
conditions in the "Operating pocket LOOX 610“ and "Technical data“ chapters, as well as the
safety precautions in the "Safety and Ergonomics“ and "Warranty"manuals.
•You may only operate the Pocket LOOX 610 with the power adapter AD 3110 if the nominal
voltage of the power adapter AD 3110 (100 V to 240 V) matches the local mains voltage.
•When transporting and during trips, observe the safety precautions in the "Pocket LOOX 610 in
mobile use“chapter.
This Pocket PC complies with the relevant safety regulations for data processing equipment. If you
have questions as to whether you can set up the cradle and the Pocket PC in the intended
environment, please contact your sales point or our hotline/help desk.

Information before you start
A26391-K139-Z120-2-7619 5
Energy saving
Switch off your Pocket PC with the Suspend key when you don't need it. In the System settings you
can specify after how many minutes the Pocket PC switches off when it is not used (see the
"Configuring Pocket LOOX 610" chapter).
While you are working, and if the ambient light conditions permit, you can reduce the display
brightness or even switch off the display lighting completely. The Pocket LOOX 610 is equipped with
a transflective display that reflects incident light and enables you to work even under unfavourable
lighting conditions.
You can also specify the switching off and on again of the display lighting in the system settings of
your Pocket PC (see the "Configuring Pocket LOOX 610" chapter).
If you use the energy saving functions, you can work with the Pocket PC longer before having to
recharge the battery. We particularly recommend that you reduce the display brightness to
effectively save energy and therefore appreciably increase the time you can work with the battery.
Disposal and recycling
The following applies for the Pocket PC itself and the Main Battery XL: batteries and accumulators
do not belong in the household rubbish bin.
Our devices are mostly produced of materials that can be turned over for proper recycling. The
device may be taken back after use to be recycled, provided that it is returned in a condition that is
the result of normal use. Any components not reclaimed will be disposed of in an environmentally
acceptable manner. To give back a device please take advantage of your country's disposal and
recycling possibilities.
Further information about country-specific disposal and recycling possibilities can be found on the
following website www.fujitsu-siemens.com/recycling.
If you have any questions on disposal, please contact your local office or our Help Desk.
CE markings
The shipped version of this device complies with the requirements of the EC Guidelines
73/23/EEC.
This equipment complies with the requirements of Directive 1999/5/EC of the European Parliament
and Commission from 9 March, 1999 governing Radio and Telecommunications Equipment and
mutual recognition of conformity.
BLUETOOTH is approved for use in Austria, Belgium, Denmark, Germany, Finland, France,
Greece, Great Britain, Ireland, Iceland, Italy, Liechtenstein, Luxembourg, the Netherlands, Norway,
Portugal, Sweden, Switzerland and Spain.
To all customers:
If you are not sure whether the use of BLUETOOTH is permitted in your country, please contact the
corresponding supervisory authorities.
!The user is responsible for radio interference that may occur when operating the device.

Information before you start
6A26391-K139-Z120-2-7619
Battery storage
Store the Pocket PC in a fully charged state. The Pocket PC should be stored in a dry area at a
temperature between -20°C and +60°C. The lower the temperature at which the batteries are stored,
the lower is the rate of self-discharge. Avoid leaving your Pocket PC lying in direct sunlight in a car.
If you want to store your Pocket PC unused for a longer time (longer than two months), charge the
battery 100% beforehand. Please note that batteries discharge themselves over time. Therefore,
recharge the battery of your Pocket PC at regular intervals during the storage period.
Cleaning Pocket LOOX 610
ÊSwitch the Pocket PC off.
ÊPull the power plug of the network adapter out of the mains outlet.
!Do not clean any interior parts yourself; leave this job to a service technician.
Do not use any cleaning agents that contain abrasives or may corrode plastic.
Please ensure that no liquid enters the Pocket PC.
Wipe the casing with a dry cloth.
If it is very dirty, you can clean the casing and the display with a damp cloth.

A26391-K139-Z120-2-7619 7
Software overview
In the following table you see which programs are already installed on your Pocket PC and where
you can find information on the use and operation of these programs.
Software Used for Operating information
PocketWord For word processing Help file on Pocket PC
PocketExel For spread-sheet functions Help file on Pocket PC
PocketOutlook Contacts/calendar//things to do Help file on Pocket PC
ActiveSync 3,7 For data synchronisation Help file on the notebook or
PC on which you installed
ActiveSync.
Pocket Internet Explorer Browser for websites and WAP sites Help file on Pocket PC
Micrsoft Reader 2.0 for
Pocket PC For reading eBooks Help file on Pocket PC
Microsoft Windows
Media Player 9 for Pocket
PC
For playing audio and video files Help file on Pocket PC
MSN Messenger For online communication Help file on Pocket PC
FSC SpeedMenu For fast file and program
management; supports one-hand
operation
EasyGuide on the "Pocket
LOOX AddOn &
Documentation" CD and help
file on Pocket PC
BLUETOOTH connection
software For BLUETOOTH configuration and operation Help file on Pocket PC
FSC Panning For simple navigation in windows with
extensive contents (panning instead
of scrolling!)
Help file on Pocket PC
CONNECT2AIR For quickly finding the Wireless LAN
and BLUETOOTH functions Help file on Pocket PC
Backup program FSC
Backup Partial and full data backup on external storage modules or in
LOOXstore (if available)
Help file on Pocket PC
Registry backup For backing up configuration settings Help file on Pocket PC

A26391-K139-Z120-2-7619 9
Operating pocket LOOX 610
This chapter describes the operating elements of your Pocket PC and how you
•put the Pocket LOOX 610 into operation the first time
•switch the Pocket LOOX 610 on and off
•operate the Pocket LOOX 610 with the stylus
•operate the Pocket LOOX 610 with the navigation key
•operate the Pocket LOOX 610 with the scroll button
•switching the display lighting on and off
•Making sound recordings
•connecting the docking station
•synchronising data
•handling expansion cards
!Please take note of the information in the "Important notes" chapter.

Operating pocket LOOX 610
10 A26391-K139-Z120-2-7619
Overview of operating elements and connections
18
17
6
5
4
12
3
10
11
12
13
14
987
15
16
1 = Connection for ActiveSync cable and for
cradle
2 = Microphone
3 = DC jack (DC IN)
4 = CONNECT2AIR application button
5 = Navigation key
6 = Today application button
7 = Contacts application button
8 = Calendar application button
9 = Loudspeakers
10 = Infrared interface
11 = Soft reset
12 = Lower arrow key
13 = Upper arrow key
14 = FSC Speed button
15 = LED (radio indicator)
16 = LED (power-on indicator)
17 = Antenna
18 = Suspend button
