Fujitsu PA03586-B205 Manual

Operator's Guide
P3PC-2432-02ENZ0

2
Introduction
Thank you for purchasing our Color Image Scanner, ScanSnap S1500/S1500M (hereinafter
referred to as "the ScanSnap").
This Operator's Guide describes how to handle and operate the ScanSnap.
Before using the ScanSnap, be sure to read this manual, "Safety Precautions" and "Getting
Started" thoroughly for proper operation.
If you are using a Microsoft®Windows®operating system, either Adobe®Acrobat®(7.0 or
later) or Adobe®Reader®(7.0 or later) is required to display or print this manual.
Microsoft, Windows, Windows Vista, PowerPoint, SharePoint, and Entourage are either
registered trademarks or trademarks of Microsoft Corporation in the United States and/or
other countries.
Word and Excel are the products of Microsoft Corporation in the United States.
Apple, the Apple logo, Mac, Mac OS, iPhoto and Rosetta are trademarks of Apple Inc.
Adobe, the Adobe logo, Acrobat, Adobe Reader, and Acrobat Reader are either registered
trademarks or tradenames of Adobe Systems Incorporated in the United States and/or other
countries.
Intel, Pentium, and Intel Core are trademarks or registered trademarks of Intel Corporation in
the United States and other countries.
PowerPC is a trademark of International Business Machines Corporation in the United
States, other countries, or both.
Cardiris is a trademark of I.R.I.S.
ABBYY, FineReader are trademarks of ABBYY.
ScanSnap, the ScanSnap logo, CardMinder, and Rack2-Filer are registered trademarks or
trademarks of PFU LIMITED in Japan.
Other company names and product names are the trademarks or registered trademarks of
the respective companies.
Manufacturer
PFU LIMITED
International Sales Dept., Imaging Business Division, Products Group
Solid Square East Tower
580 Horikawa-cho, Saiwai-ku, Kawasaki-shi, Kanagawa 212-8563, Japan
Phone:[phone]
All Rights Reserved, Copyright © PFU LIMITED 2008-2009

Introduction
3
Disclaimer
•Reproducibility of the scanned image data
Confirm that the image data scanned with the ScanSnap meets your requirements (e.g.
image reproducibility in size accuracy, information amount, fidelity, content and color).
•Disposing of the original document
Check the image data using the application where you transferred the image data to
make sure that there are no missing parts before disposing of the original document
scanned with the ScanSnap.
It is the responsibility of the customer to store and manage the scanned image data,
and dispose of the original document scanned with the ScanSnap.
Description of Each Manual
When using the ScanSnap, read the following manuals as required.
Manual Description Reference Method
Safety Precautions This manual contains important
information about the safe use
of the ScanSnap.
Make sure to read this manual
before using the ScanSnap.
Included in the package.
ScanSnap S1500/S1500M
Getting Started
This manual describes how to
install and connect the Scan-
Snap.
Included in the package.
ScanSnap S1500/S1500M
Operator's Guide
(this manual)
This manual describes basic
operations of ScanSnap, the
scanning methods, various set-
tings, troubleshooting, and han-
dling of the ScanSnap.
Select [Operator's Guide] from the [Start]
menu →[All Programs] →[ScanSnap
Manager].
With Finder, select [Operator's Guide.pdf]
from [Applications] →[ScanSnap] →
[Manual].
ScanSnap Organizer
User's Guide (*1)
Read this manual when using
this product for the first time, or
when details about the product
features, windows, operating
environment and functions are
required.
Select [User's Guide] from the [Start]
menu →[All Programs] →[ScanSnap
Organizer].
CardMinder User's Guide
(*1)
Select [User's Guide] from the [Start]
menu →[All Programs] →[CardMinder].
Cardiris
GETTING STARTED (*2)
With Finder, select [User's Manual.pdf]
from [Applications] →[Cardiris 3.6 for
ScanSnap].

Introduction
4
*1: Supplied with S1500.
*2: Supplied with S1500M.
ABBYY FineReader for
ScanSnap User's Guide
(*1)
Read this manual when using
this product for the first time,
or when details about the
product features, windows,
operating environment and
functions are required.
Select [User's Guide] from the [Start]
menu, select [All Programs] →[ABBYY
FineReader for ScanSnap(TM) 4.1]→
[User’s Guide].
Scan to Microsoft
SharePoint User Guide (*1)
Select [Scan to Microsoft SharePoint User
Guide] from the [Start] menu →
[All Programs] →[KnowledgeLake].
ScanSnap Manager
Help
Use this Help when questions
or problems regarding opera-
tions (e.g. when setting items)
arise.
This provides an explanation of
every operation, dialog box/win-
dow, and message.
Refer to this by either of the following
methods:
•Right-click the [ScanSnap Manager]
taskbar icon , and then select [Help]
→[Help].
In Windows 7, the ScanSnap Manager
icon is displayed in the menu that
appears when you click in the
taskbar.
•Click the Help button ( ) for
ScanSnap Manager.
•Press the [F1] key on the keyboard
while a dialog box is displayed.
•Click the [Help] button on each dialog
box.
•Click the ScanSnap Manager icon
in the Dock while pressing the [control]
key on the keyboard, and then select
[Help] J[Help].
•Click the Help button ( ) for
ScanSnap Manager.
•From the menu bar, select [Help] →
[ScanSnap Manager Help].
ScanSnap Organizer
Help (*1)
For details about how to start up help,
refer to the User's Guide for each product.
CardMinder Help (*1)
Cardiris Help (*2) From the menu bar, select [Help] →
[Cardiris Help].
ABBYY FineReader for
ScanSnap Help (*2)
From the menu bar, select [Help] →
[FineReader for ScanSnap Help].
Adobe Acrobat Help From the menu bar, select [Help] →
[Acrobat Help].
Manual Description Reference Method

Introduction
5
■ About This Manual
Structure of This Manual
This manual consists of the following:
ScanSnap Overview
This chapter describes the features, the names of parts and their functions, the
system requirements, and basic operation of the ScanSnap.
Installing the Software
This chapter gives an overview and describes the installation procedure of the
software supplied with the ScanSnap.
Using the ScanSnap (for Windows Users)/ Using the ScanSnap (for Mac OS
Users)
This chapter describes how to perform a scan with the ScanSnap, change or
save scanning settings, and other various functions of the ScanSnap.
Troubleshooting
This chapter describes how to remove jammed documents and resolve other
problems.
Daily Care
This chapter describes how to clean the ScanSnap.
Consumables
This chapter describes how to replace consumables such as pad assy and
pick roller.
Appendix
This appendix describes how to update ScanSnap Manager, how to uninstall
software, scan settings, and ScanSnap installation conditions.
For details about ScanSnap operations, read this manual in order from "ScanSnap
Overview" through "Using the ScanSnap".
