ScanSnap N1800 Network Scanner
P3PC-3772-02ENZ0
Google Docs Add-in User’s Guide

2
Contents
Introduction .................................................................................. 4
■ About This Manual ............................................................... 4
■ Opening Help ........................................................................ 5
Chapter 1 Overview ................................................................. 6
1.1 Features of the Google Docs Add-in ............................. 7
1.2 System Requirements ..................................................... 8
Chapter 2 Installation/Uninstallation ................................... 10
2.1 Installing the Google Docs Add-in ............................... 11
2.2 Uninstalling the Google Docs Add-in .......................... 13
Chapter 3 Regular User Operations ..................................... 14
3.1 Saving the Scanned Data to Google Docs .................. 15

3

4
Introduction
Thank you for using the Google Docs Add-in.
This manual aims to provide administrators and regular users with an overview of the Google Docs
Add-in, and instructions on its installation, uninstallation, and operations.
We hope that this manual will provide you with useful information in order to utilize the Google
Docs Add-in.
Trademarks
Google and Google Docs are registered trademarks or trademarks of Google Inc.
ScanSnap and the ScanSnap logo are registered trademarks or trademarks of PFU LIMITED
in Japan.
Manufacturer
PFU LIMITED
International Sales Dept., Imaging Business Division, Products Group Solid Square East
Tower, 580 Horikawa-cho, Saiwai-ku, Kawasaki-shi Kanagawa 212-8563, Japan
Phone: [phone]
© PFU LIMITED 2011
■About This Manual
Symbols Used in This Manual
The following symbols are used in this manual:
This symbol alerts operators to particularly important information. Be sure to
read this information.
This symbol alerts operators to helpful advice regarding operations.

5
Screen Examples in This Manual
The screen examples in this manual are subject to change without notice in the interest of
product improvement.
The actual windows and operations may differ depending on the operation method.
If the actual screen differs from the screen examples in this manual, operate by following the
actual displayed screen.
Abbreviations Used in This Manual
The following abbreviations are used in this manual:
■Opening Help
When the [Help] button is available on the window or dialog box that is displayed during the
operation, you can open Help by pressing it.
Help provides information about items on the screens and actions to take for the messages.
On the touch panel, the Help button is displayed as .
This symbol is used to indicate information about administrator operations.
Each operation method is indicated by the following symbols:
z
Administrator operating via the LCD touch panel.
z
Administrator operating via the network interface using the Network Scanner
Admin Tool.
z
Administrator operating via the network interface using the Scanner Central
Admin Console.
This symbol is used to indicate information about regular user operations.
Abbreviation Name
Google Docs Google Docs™
Admin Tool Network Scanner Admin Tool
Central Admin
Console
Scanner Central Admin Console
Scanner ScanSnap N1800
Central Admin
Console

6
Chapter 1
Overview
This chapter provides an overview of the Google Docs Add-in.
1.1 Features of the Google Docs Add-in..................................................................... 7
1.2 System Requirements ............................................................................................ 8

7
1.1 Features of the Google Docs Add-in
The Google Docs Add-in is an application used for linking with Google Docs so that
scanned data can be saved to it.
Saving scanned data to Google Docs enables scanned data to be viewed from anywhere
at anytime by logging into Google Docs via a Web browser.
For details about how to install and uninstall the Google Docs Add-in, refer to "Chapter 2
Installation/Uninstallation" (page 10).
For the Google Docs Add-in, the following is regarded as user information.
ze-Mail address and password used for Google Docs authentication on the [Google
Docs™ Authentication] window
zList of accounts (up to five e-mail addresses)
zCollection as a destination for saving scanned data
zScan settings
zSetting for whether to remember the password
When scanner user information is backed up and restored, this information is also backed
up and restored.
For details about how to back up or restore user information, refer to the Operator’s Guide
of the ScanSnap N1800.

1.2 System Requirements
8
1.2 System Requirements
The Google Docs Add-in runs under the following conditions:
Access to the Internet must be possible for saving to Google Docs.
A Google account must be created in Google in advance.
Scanner System Version
ScanSnap N1800 ss001 01.01.01.0046 or later

9

10
Chapter 2
Installation/Uninstallation
This chapter explains how to install and uninstall the Google Docs Add-in.
For details about operations of the ScanSnap N1800, refer to the Operator’s Guide of the
scanner model.
2.1 Installing the Google Docs Add-in ...................................................................... 11
2.2 Uninstalling the Google Docs Add-in.................................................................. 13

11
2.1 Installing the Google Docs Add-in
The Google Docs Add-in can be installed by selecting
"NetScanner_ScanToGoogleDocs_1.1.1" on the [Add-in Software] window, and pressing
the [Install] button.
When the Google Docs Add-in is installed, "ScanToGoogleDocs" is shown in the list.
Central Admin
Console
"1.1.1" in the name of the file to be installed indicates the version.
The version may change when a new file is provided for the Google Docs Add-in.

2.1 Installing the Google Docs Add-in
12
On the regular user’s [Main Menu] and [Job Menu] window, the [Scan to Google Docs™]
button is shown.
Example: On the [Main Menu] window, the button is shown as below.
There is no need to configure an Add-in settings file or set whether to show the
keyboard.
The keyboard can be shown regardless of the [Show On-Screen Keyboard] setting.

13
2.2 Uninstalling the Google Docs Add-in
The Google Docs Add-in can be uninstalled by selecting "ScanToGoogleDocs" on the
[Add-in Software] window, and pressing the [Uninstall] button.
When the Google Docs Add-in is uninstalled, "ScanToGoogleDocs" is deleted from the
list.
User information for the Google Docs Add-in is not deleted.
Central Admin
Console

14
Chapter 3
Regular User Operations
This chapter explains regular user operations after the Google Docs Add-in is installed.
For details about operations of the ScanSnap N1800, refer to the Operator’s Guide of the
scanner model.
3.1 Saving the Scanned Data to Google Docs.......................................................... 15

15
3.1 Saving the Scanned Data to Google Docs
Save the scanned data to Google Docs.
1. On the [Main Menu] or [Job Menu] window, press the [Scan to Google
Docs™] button.
DThe [Google Docs™ Authentication] window appears.
When the following conditions are satisfied, Google authentication is performed
for the previously used Google account and the [Scan to Google Docs™] window
appears.
zIf you logged in with an account other than a guest account
zIf the password was set to be remembered

3.1 Saving the Scanned Data to Google Docs
16
2. Enter an e-mail address (user name) and password for logging into
Google Docs, and select whether to remember the password.
If you have logged into Google Docs before, you can select the previously
used e-mail address (user name) from the [Account List] window, which is
shown by pressing .

17
3. Press the [OK] button.
DThe [Scan to Google Docs™] window appears.
4. Press for [Save to].
DThe [Save to] window appears.
To change the scan settings, press for [Scan Settings]. For details, refer to
the Operator’s Guide of the ScanSnap N1800.
Note that the output file format used for a scan setting is fixed to PDF.

3.1 Saving the Scanned Data to Google Docs
18
5. Select a destination for saving scanned data. To save scanned data to a
collection, select a collection from the tree.
6. Press the [OK] button.
DThe [Scan to Google Docs™] window appears again.
7. For [File Name], enter a file name for the scanned data to be saved to
Google Docs.
8. Press the [Scan] button.
When [Scan Viewer] is [Off], press the [Scan&Save] button.
DThe scanning starts.
DThe procedures after scanning or for viewing the scanned data are the same as
when scanned data is sent via e-mail or saved to a folder. For details, refer to the
Operator’s Guide of the ScanSnap N1800.
9. When the saving process is completed, the [Main Menu] or [Job Menu]
window is shown again.
zThe following file names cannot be used:
zCON
zPRN
zAUX
zCLOCK$
zNUL
zCOM0 - COM9
zLPT0 - LPT9
zThe following symbols cannot be used:
\ / * " : < > ? |
On the [File Name] window which is shown by pressing for [File Name], a
default file name format can be selected.

19

zThe contents of this manual are subject to change without notice.
zPFU LIMITED assumes no liability for incidental or consequential
damages arising from the use of this Product, and any claims by a
third party.
zCopying of the contents of this manual, in whole or in part, as well
as the scanner applications is prohibited under the copyright law.
ScanSnap N1800 Network Scanner
Google Docs Add-in User’s Guide
P3PC-3772-02ENZ0
Issue date June 2011
Issued by PFU LIMITED
