FUJITSU SEMICONDUCTOR
SUPPORT SYSTEM SS01-26029-1E
F
2
MC-8FX Family
STARTER KIT (ver. 3V)
MB2146-401-01A
SETUP GUIDE

i
PREFACE
Thank you for purchasing the F2MC*1-8FX Family Starter Kit (ver. 3V) (Model: MB2146-401-
01A)*2.
This product is a starter kit for F2MC-8FX MB95FV100D-101 (ver. 3V), which comes with
MB2146-09A-E (F2MC Family BGM Adapter)*3, MB2146-301A-E (F2MC-8FX Family MCU
Board for MB95FV100D-101)*4, MB2146-401 (F2MC-8FX Family Evaluation Board)*5, and
F2MC-8L/8FX Family SOFTUNE Professional Pack Evaluation Version*6.
This manual explains how to use the Starter Kit. Be sure to read this manual before using the product.
For mass production/evaluation MCUs for this product, consult with sales representatives or support
representatives.
*1 : F2MC is the abbreviation of FUJITSU Flexible Microcontroller.
*2 : Referred below as the “Starter Kit”.
*3 : Referred below as the “BGM Adapter”.
*4 : Referred below as the “MCU Board”.
*5 : Referred below as the “Evaluation Board”.
*6 : Referred below as the “SOFTUNE”.
■Handling and use
Handling and use of this product and notes regarding its safe use are described in the manuals for
products bundled with the Starter Kit.
Follow the instructions in the manuals to use this product.
Keep this manual at hand so that you can refer to it anytime during use of this product.
■Notice on this document
All information included in this document is current as of the date it is issued. Such information is
subject to change without any prior notice.
Please confirm the latest relevant information with the sales representatives.

ii
■Caution of the products described in this document
The following precautions apply to the product described in this manual.
WARNING Indicates a potentially hazardous situation which, if not avoided appropriately,
could result in death or serious injury and/or a fault in the user’s system.
Electric shock,
Damage
Before performing any operation described in this manual, turn off all the power
supplies to the system. Performing such an operation with the power on may
cause an electric shock or device fault.
Electric shock,
Damage
Once the product has been turned on, do not touch any metal part of it.
Doing so may cause an electric shock or device fault.
CAUTION
Indicates the presence of a hazard that may cause a minor or moderate injury, dam-
ages to this product or devices connected to it, or may cause to loose software re-
sources and other properties such as data, if the device is not used appropriately.
Cuts, Damage
Before moving the product, be sure to turn off all the power supplies and unplug the
cables. Watch your step when carrying the product. Do not use the product in an
unstable location such as a place exposed to strong vibration or a sloping surface.
Doing so may cause the product to fall, resulting in an injury or fault.
Cuts The product contains sharp edges that are left unavoidably exposed, such as jump-
er plugs. Handle the product with due care not to get injured with such pointed parts.
Damage Do not place anything on the product or expose the product to physical shocks. Do
not carry the product after the power has been turned on. Doing so may cause a
malfunction due to overloading or shock.
Damage
Since the product contains many electronic components, keep it away from direct
sunlight, high temperature, and high humidity to prevent condensation. Do not use
or store the product where it is exposed to much dust or a strong magnetic or elec-
tric field for an extended period of time. Inappropriate operating or storage environ-
ments may cause a fault.
Damage Use the product within the ranges given in the specifications.
Operation over the specified ranges may cause a fault.
Damage
To prevent electrostatic breakdown, do not let your finger or other object come into
contact with the metal parts of any of the connectors. Before handling the product,
touch a metal object (such as a door knob) to discharge and any static electricity
from your body.
Damage
Before turning the power on, in particular, be sure to finish making all the required
connections. Furthermore, be sure to configure and use the product by following the
instructions given in this document. Using the product incorrectly or inappropriately
may cause a fault.
Damage
Always turn the power off before connecting or disconnecting any cables from the
product. When unplugging a cable, unplug the cable by holding the connector part
without pulling on the cable itself. Pulling the cable itself or bending it may expose
or disconnect the cable core, resulting in a fault.
Damage
Because the structure of the MCU socket does not allow an evaluation MCU to be
mounted in the incorrect orientation, be very careful of the orientation of the evalu-
ation MCU when mounting it. Inserting the evaluation MCU in the wrong orientation
may damage the MCU, causing the MCU to become faulty.
Damage
Because the product has no casing, it is recommended that it be stored in the orig-
inal packaging. Transporting the product may cause a damage or fault. Therefore,
keep the packaging materials and use them in case of for the re-shipment of the
product.

iii
Copyright ©2008 FUJITSU LIMITED All rights reserved
•The contents of this document are subject to change without notice.
Customers are advised to consult with sales representatives before ordering.
•The information, such as descriptions of function and application circuit examples, in this document are presented sole-
ly for the purpose of reference to show examples of operations and uses of FUJITSU semiconductor device; FUJITSU
does not warrant proper operation of the device with respect to use based on such information. When you develop
equipment incorporating the device based on such information, you must assume any responsibility arising out of such
use of the information. FUJITSU assumes no liability for any damages whatsoever arising out of the use of the infor-
mation.
•Any information in this document, including descriptions of function and schematic diagrams, shall not be construed
as license of the use or exercise of any intellectual property right, such as patent right or copyright, or any other right
of FUJITSU or any third party or does FUJITSU warrant non-infringement of any third-party's intellectual property
right or other right by using such information. FUJITSU assumes no liability for any infringement of the intellectual
property rights or other rights of third parties which would result from the use of information contained herein.
•The products described in this document are designed, developed and manufactured as contemplated for general use,
including without limitation, ordinary industrial use, general office use, personal use, and household use, but are not
designed, developed and manufactured as contemplated (1) for use accompanying fatal risks or dangers that, unless
extremely high safety is secured, could have a serious effect to the public, and could lead directly to death, personal
injury, severe physical damage or other loss (i.e., nuclear reaction control in nuclear facility, aircraft flight control, air
traffic control, mass transport control, medical life support system, missile launch control in weapon system), or (2)
for use requiring extremely high reliability (i.e., submersible repeater and artificial satellite).
Please note that FUJITSU will not be liable against you and/or any third party for any claims or damages arising in
connection with above-mentioned uses of the products.
•Any semiconductor devices have an inherent chance of failure. You must protect against injury, damage or loss from
such failures by incorporating safety design measures into your facility and equipment such as redundancy, fire pro-
tection, and prevention of over-current levels and other abnormal operating conditions.
•Exportation/release of any products described in this document may require necessary procedures in accordance with
the regulations of the Foreign Exchange and Foreign Trade Control Law of Japan and/or US export control laws.
•The company names and brand names herein are the trademarks or registered trademarks of their respective owners.

1
1. Checking the Delivered Product
Before using the product, make sure that the following components are included:
•MB2146-09A-E*1: 1
•MB2146-301A-E*2: 1
•MB2146-401*3: 1
•F2MC-8L/8FX Family
SOFTUNE Professional Pack Evaluation Version*4: 1
•Setup Guide(Japanese version) : 1
•Setup Guide(English version, this manual) : 1
*1 : To use the BGM Adapter, connect it to the host computer and USB cable. The USB cable is
enclosed by the BGM Adapter.
*2 : MB95FV100D-101 is implemented in the MCU Board.
To use the MCU Board, connect it to the BGM Adapter and the Evaluation Board.
*3 : To use the Evaluation Board, connect it to the MCU Board. AC Adapter is enclosed by the
evaluation board.
*4 : To use the SOFTUNE, install it in your host computer.
MB2146-401-01A is used as a starter kit for F2MC-8FX MB95FV100D-101 (ver. 3V) by combining
with the bundled products.
For details about this product, consult with sales representatives or support representatives.
2. Handling Precautions
The Starter Kit can be used in connection with its bundled products. To ensure correct use of this
product in a proper environment, observe the following guideline:
•Follow the instructions described in each manual for the bundled product to use this product.
MB2146-09
Host computer
MB2146-09A-E
(BGM Adapter)
USB Cable Connector
(BGM Adapter enclosure)
MB2146-401
(Evaluation Board)
MB2146-301A-E
(MCU Board)
F2MC-8L/8FX Family
SOFTUNE Professional Pack
Evaluation Version
(SOFTUNE)
MB95FV100D-101
(mounting at the
MCU Board back )
The inside of a dashed line is the package
of this product.

2
3. Feature
The F2MC-8FX starter kit is the best for a performance and functional evaluation, and a check of
operation before including F2MC-8FX in a user's system.By carrying out additional purchase of the
header board, continuation use also of the evaluation with a user's system can be carried out.
Below, the feature of the BGM debugger for F2MC-8FX is shown.
•Microcomputer operation voltage It corresponds to +2.6V to +3.6V.
(The maximum and minimum of microcomputer operation voltage and frequency of operation
differs with each MCU. refer to the documents (a data sheet, hardware manual, etc.) of each
device relation for operation voltage and frequency of MCU of operation).
•Compact development environment, a light and small BGM Adapter.
•Since a monitor program is performed in exclusive memory space, it does not consume user
memory space.
•Continuation execution, step execution, a command break, a data break, sequential break cor-
respondence
•Command trace is possible (a maximum of 16 branches).
•It connects with a host computer by the USB interface.
4. Hardware Setup
In the hardware setup procedure, you configure and connect the hardware products. This chapter in-
cludes the configuring and connecting procedure for each product in order. Check the contents and
complete the hardware setup.
•Configuration of each product
- Configuring MCU Board
- Configuring Evaluation Board
•Connection of each product
- Connecting MCU Board and Evaluation Board
- Connecting BGM Adapter
- Connecting oscillators
- Connecting AC Adapter

3
4.1 Configuration of Each Product
This section describes how to configure the MCU Board and the Evaluation Board.
■Configuring MCU Board
Set the following switches on the MCU Board, referring to "Figure 1 MCU Board Configuration".
Figure 1 MCU board configuration
BGM
ADAPTER
SUB CLOCK
C B A
1
2
CLK CLK S.V. APB8 C X0 X1 X0A X1A
7
6
5
4
3
2
1
0
F
E
D
C
B
A
9
8
PRODUCT SELECT
LVD4 LVD3 LVD2
LVD1
LVD0
GNDVCC
3V5V
LVD2OFFLVD1
MAIN CLOCK
1 2 34 1 2 34
ON ON
(1)
(2)
(3)(4)
(5) (6)(7)
(1) LVD2 detection voltage selection jumper plug
Set the value to "LVD0".
(2) Voltage selector switch
Set the value to "3V".
(3) Product selector switch
Rotate the center tab to position the pointer for the corresponding number:
For 100-pin package, set the value to "0".
For 80-pin package, set the value to "1".
For 64-pin package, set the value to "2".
For 48-pin package, set the value to "3".
For none of the above, check on the settings in the MCU Board manual.
(4) LVD selector switch
Set the value to "OFF".
(5) Miscellaneous switches
Set "CLK" to "OFF" if you use subclock, or "ON" if you don’t.
Set the other switches to "OFF" (to the side of numeral letters).
(6) Clock input selector switch
Set all to "OFF" (to the side of numeral letters)".
(7) Subclock selector jumper plug
Set all the values to the side of "B-C".

4
■Configuring Evaluation Board
Set the following switches on the Evaluation Board, referring to "Figure 2 Evaluation Board Con-
figurarion".
Figure 2 Evaluation board configuration
SW1
JP6 JP5 JP3JP4
1 2
119
120
1 2
119
120
CN3
JP1
JP2
CN4 PJ1
SW2
JP7
CN2 CN1
JP8
+3.3V
+5V
(1)
(2)
(3)
(1) 5V/3.3V Power supply selector jumper plug
Set the value to the side of "+3.3V".
(2) Analog power supply jumper plug
Insert jumper plug for all the switches.
(3) MOD selector jumper plug
Insert jumper plug.

5
4.2 Connection of Each Product
This section describes how to connect the MCU Board, the Evaluation Board, and the BGM Adapter.
This section also describes how to mount the crystal oscillator on the MCU Board, and how to plug
the AC adapter into the Evaluation Board.
■Connecting MCU Board and Evaluation Board
Connect the MCU Board and the Evaluation Board, referring to "Figure 3 Connection of MCU
Board and Evaluation Board". Each board has an index to avoid the reverse mounting. Look at the
index position to connect the boards.
Figure 3 Connection of MCU board and evaluation board
SW1
JP6 JP5
1
2
119
120
1
2
119
120
CN3
JP1
JP2
CN4 PJ1
SW2
JP7
CN2 CN1
JP3JP4
+3.3V
+5V
Evaluation Board
Index
(Backside mounting)
MCU Board
Index
(Surface mounting)

6
■Connecting BGM Adapter
Connect the BGM Adapter and the MCU Board, referring to "Figure 4 Connection of BGM Adapt-
er". The BGM Adapter and the MCU Board have an index mark (for pin 1) on its connectors. Align
the index mark on both sides.
Plug a USB cable into the BGM Adapter (the cable is bundled with the BGM Adapter).
Make sure that POWER-SW on the Evaluation Board is set to OFF (to the side of " ") before plug-
ging the cable.
Figure 4 Connection of BGM adapter
SW1
JP6 JP5
CN3
JP1
JP2
CN4 PJ1
SW2
JP7
MB2146-09
JP3JP4
+3.3V
+5V
Plug into BGM Adapter
USB cable
(Bundled with BGM Adapter)
BGM Adapter
MCU Board
Evaluation Board
Power-SW
Index mark

7
■Connecting Oscillators
Plug crystal/ceramic oscillators into the crystal oscillator mounting sockets (one for the main clock
and the other for the subclock) on the MCU Board (See "Figure 5 Connection of oscillators") .
You can see one crystal oscillator mounting socket for main clock and the other for subclock on the
MCU Board. Mount a crystal or ceramic oscillator and a capacitor on the MCU Board.
Figure 5 Connection of oscillators
BGM
ADAPTER
SUB CLOCK
C B A
1
2
CLK CLK S.V. APB8 C X0 X1 X0A X1A
7
6
5
4
3
2
1
0
F
E
D
C
B
A
9
8
PRODUCT SELECT
LVD4 LVD 3
LVD2
LVD1 LVD0
GNDVCC
3V5V
LVD2OFFLVD1
MAIN CLOCK
1 2 34 1 2 34
ON ON
(1)
(2)
(1) Crystal oscillator mounting socket for main clock
Mount a crystal oscillator used as "main clock".
(2) Crystal oscillator mounting socket for subclock
Mount a crystal oscillator used as "subclock".
If you disable the subclock, set the "CLK" switch to "ON".
GND
Capacitor mounting socketCapacitor mounting socket
Crystal oscillator mounting socket
Ceramic
oscillator
Crystal
oscillator

8
■Connecting AC Adapter
Connect the AC Adapter and the Evaluation Board, referring to "Figure 6 Connection of AC Adapt-
er". The AC Adapter (bundled with the Evaluation Board) is plugged into the PJ1 on Evaluation
Board and the AC 100V Power Supply.
Figure 6 Connection of AC adapter
SW1
JP6 JP5
CN3
JP1
JP2
CN4 PJ1
SW2
JP7
MB2146-09
JP3JP4
+3.3V
+5V
BGM Adapter
Plug into Evaluation Board
AC Adapter
Evaluation Board

9
5. Software Setup
In the software setup procedure, you install and operate the software applications.
This chapter includes the installing and operating procedure for each software in order. Check the
contents and complete the software setup.
•Installation of software
- Installing SOFTUNE
- Installing USB driver
- Installing sample program
•Operation of SOFTUNE
- Starting SOFTUNE Workbench
- Starting Debugging
- Initializing MCU
- Running the program
- Aborting the program
- Ending Debugging
- Exiting SOFTUNE Workbench
5.1 Installation of Software
This section describes how to install SOFTUNE and the USB driver in your host computer, as well as
how to install the sample program.
■Installing SOFTUNE
Follow the instruction described in "F2MC-8L/8FX Family 8-bit Microcontroller SOFTUNE Work-
bench Installation Guide" to install SOFTUNE in your host computer.
■Installing USB Driver
Plug a USB cable connected to BGM Adapter into your host computer. After you connect the host
computer and the BGM Adapter, the [Found New Hardware Wizard] window appears. Follow the
instruction below to install the USB driver.
In a few seconds after the above dialog is displayed, the [Welcome to the Found New Hardware Wiz-
ard] screen appears. Click [Next] to install the device driver.

10
The [Install New Hardware Device Drivers] screen appears.
Click [Search for a suitable driver for my device (recommended)], and then click [Next] to search
for a suitable driver for your device.
The [Locate Driver Files] screen appears.
Check [Specify a location], and then click [Next] to specify the location for the driver.
A file location dialog appears.
Select "SiUSBdB.INF" in the "\Drivers" folder (under a directory where SOFTUNE is installed), and
click [Open] to specify the driver.

11
In the [Copy manufacturer’s files from] box, make sure that the "\Drivers" folder (under a directory
where SOFTUNE is installed) is selected, and click [OK].
The [Driver Files Search Results] screen appears.
Click [Next] to start installing the driver.
The [Completing the Found New Hardware Wizard] screen appears.
Now that the USB driver installation has completed, click [Finish] to exit the Wizard.

12
■Installing Sample Program
Copy only a folder named "\fsg" under "\MANUAL\FirstStepGuide" in SOFTUNE CD into the "\sam-
ple" folder under a directory where SOFTUNE is installed.
All the data in the "\fsg" folder is set to "read-only". Open the folder’s properties, and deselect the
[Read Only] checkbox, and click [OK].
In the [Confirm Attribute Change] dialog, check [Apply Changes to this folder, sub-folders, and
files], and click [OK] to confirm the attribute change.

13
5.2 Operation of SOFTUNE
This section describes how to start SOFTUNE Workbench and operate it using the sample program.
■Starting SOFTUNE Workbench
Start SOFTUNE and configure the SOFTUNE development environment. From the [File] menu, click
[Open Workspace].
In a file location dialog, select the "\sample\fsg\8fx_sample" folder under a directory where SOFTUNE
is installed, and specify "fsg_sample.wsp", then click [Open].

14
Select and right-click "emu_dbg.sup" under the "Debug" folder, then click [Change Settings] to start
the setup wizard.

15
The setup wizard is started. Click [Next].
In [Debug Type], specify [Emulator Debugger], and click [Next].
In [ICE Type], specify [MB2146-09], and click [Next].
