REFRIGERATOR
F6FBM36S1
F6FBM36S2
MANUAL
Service

SERVICE MANUAL
2
Serial Number ............................................................................................................................. 3
Safety Informaon....................................................................................................................... 4
Installaon, Electrical & Plumbing Requirements ....................................................................... 6
Theory of Operation ................................................................................................................... 7
Refrigerator Components............................................................................................................ 8
Freezer Components ................................................................................................................... 9
Rear & Compressor Area Components ....................................................................................... 10
Gas Flow Diagram & Parts .......................................................................................................... 11
Electrical Components & Specicaons ...................................................................................... 12
Display & User Option Settings .................................................................................................. 13
Service Mode .............................................................................................................................. 14
Error Codes & Control Board Connections................................................................................. 15
E0 & E1 .............................................................................................................................. 16
E2 & E3 .............................................................................................................................. 17
E4........................................................................................................................................ 18
E8 & E9 ............................................................................................................................... 19
E13 & 15 ............................................................................................................................. 20
Freezing in Fresh Food Compartment ................................................................................ 21
Not Cooling in Fresh Food Compartment........................................................................... 22
High Temp Error & Temperature to Resistance Chart.................................................................. 23
Wiring Diagram ........................................................................................................................... 24
Control Board Test Points ........................................................................................................... 25
Component Access & Removal................................................................................................... 26
Control Board ..................................................................................................................... 26
Display & Reed Switches..................................................................................................... 26
Handles ............................................................................................................................... 27
Removing the Rear Wall...................................................................................................... 28
Fresh Food Fan.................................................................................................................... 29
Water Dispenser & Microswitch ......................................................................................... 30
Dispenser Water Valve & Reservoir Assembly.................................................................... 30
Fresh Food Compartment Lights......................................................................................... 31
Ionizer ................................................................................................................................. 32
Fresh Food & Freezer Air Sensors ....................................................................................... 32
Flapper Heater.................................................................................................................... 33
Freezer Drawer & Forever Rails .......................................................................................... 34
Ice Maker ............................................................................................................................ 35
Fill Tube Heater................................................................................................................... 35
Freezer Fan ......................................................................................................................... 36
Defrost Element & Thermal Fuse........................................................................................ 37
Drain Heater ....................................................................................................................... 37
Inverter ............................................................................................................................... 38
Main Water Valve ............................................................................................................... 39
Condenser Fan .................................................................................................................... 39
Troubleshoong.................................................................................................................. 40
Warranty...................................................................................................................................... 42
Refrigerator

SERVICE MANUAL
3
SERVICE DIAGNOSTICS Built-In Refrigerator
The rang label informaon is located at the upper part of the le wall of the refrigerator compartment or at the
boom of the large crisper in the same compartment.
Serial Number
Y
ear manufactured
Mo
nth manufactured
RATED VOLTAGE :
CHILL COMP. NET VOL.:
MIN INST. CLEARANCE TO BE
MAINTAINED FROM THE TOP :
LOW SIDE :
HIGH SIDE :
REFRIGERANT QUANTITY :
FREEZING CAPACITY :
FREEZER COMP. NET. VOL. :
FRESH FOOD COMP. NET. VOL. :
REFRIGERANT TYPE :
TOTAL NET VOLUME :
DEFROST POWER :
I
TYPE :
MARKETING CODE :
RATED CURRENT (TOTAL):
CLASS :
MODEL NO:
FREQUENCY :
SERIAL NUMBER :
PRODUCT NUMBER : 120 V AC~
13.33 lbs
6.56 cu-ft
88 PSIG
290 PSIG
5.12 oz
13.30 cu-ft
R134a
19.9 cu-ft
BFFD3624SS
2.7 A
T
G91629NWU
60 Hz
7293749592
240 W
20-999999-08
Made in Turkey
Serial Number
The serial tag is located on either the upper le-hand wall of the refrigerator secon, or
boom of the compartment, beneath the large crisper drawer.
YĞĂƌŵĂŶƵĨĂĐƚƵrĞĚ
DŽŶƚŚŵĂŶƵĨĂĐƚƵrĞĚ
Refrigerator

SERVICE MANUAL
4
SAVE THESE INSTRUCTIONS
REVIEW ALL SERVICE INFORMATION IN THIS SERVICE MANUAL BEFORE
BEGINNING REPAIRS.
This product should only be serviced by a qualied service technician,
who is familiar with the standard safety producers required for servicing
this product. The technician should be equipped with the proper tools,
parts, and test equipment before beginning.
We have provided many important safety messages in this manual and on the appli-
ance. ALWAYS READ AND OBEY ALL SAFETY MESSAGES.
This is the safety alert symbol
This symbol alerts you to hazards that could
cause death or injury to you or others, or cause
damage to product or property. Each occur-
rence will idenfy the hazard, describe how to
reduce the chance of injury, and describe what
can happen if the instrucons are not followed.
The symbol will be surrounded by a color which
corresponds to are parcular type of hazard.
Red for DANGER, Orange for WARNING, and
Yellow for CAUTION.
These categories are dened in the boxes to the
right
Technical Services
Please contact your authorized
Fulgor Milano dealer.
Safety Information
Fulgor Milano
Refrigerator

SERVICE MANUAL
5
Safety Instructions
The manufacturer reserves the right to make changes in the technical specicaons
in order to improve the appliance quality without any prior noce. Figures included in
this manual are for schemac purposes only and may not match the appliance exactly.
Values stated on the markings of the appliance, or in other printed documents supplied
with the appliance, are obtained under laboratory condions as per relevant standards.
These values may vary according to the usage of the appliance and ambient condions.
Proper Installation - Be sure your appliance is properly installed and grounded by a
qualied technician.
If the supplied electrical cord is damaged, it must be replaced by a power cord or as-
sembly from the manufacturer. It must also be installed by a qualied service techni-
cian.
Service repairs must always be performed by an Authorized Servicer. Instal-
lations must be performed by a Certified Installer (This can include certified
and licensed electrician or plumbers. The Manufacturer cannot be held re-
sponsible for damages caused by operations performed by unauthorized, un-
certified or unlicensed persons.
•If the refrigerator is malfunctioning, it must not be operated until it is repaired by an
Authorized Servicer. There is a risk of electrical shock!
•The unit should be plugged into a three-prong, grounded and polarized 15A, 120V,
60Hz dedicated wall outlet. Fulgor Milano will not be responsible for damages in-
curred while using the product in a way that does not comply with the electrical
code of the location where the product is installed.
•If the unit is not going to be used for an extended period of time, turn off the power
to it via the circuit breaker, shut of the water supply, and leave the doors open.
•Never wash the refrigerator by spraying or pouring water on it. There is a risk of
electric shock!
•Caution should be used when unplugging the unit for service. Make sure your hands
are not wet, and always hold the plug when disconnecting from the outlet, not the
cord. If the outlet is loose, have a licensed electrician repair or replace the outlet.
•This unit was designed to operate on a normal 60Hz, 120VAC electrical grid system.
If it is connected to any energy saving system, alternative power, or solar power sys-
tem, etc. and is experiencing any operational issues, please contact your local elec-
trical provided for further information.
•Shut off power to the refrigerator at the circuit breaker during installation, cleaning
near exposed electrical components, or service repairs.
Refrigerator

SERVICE MANUAL
6
• 
 


•C.
• 
5/8” on each side, 2” above the unit, and 1 3/4” in back of the unit.
• 
 
 (Part #: 4385910100 - Spacers & Screws, 4298950100 - Spacer only)
  


•
•
•
•
•

•



•
•
•
•

Installation, Electrical & Plumbing Requirements
Refrigerator

SERVICE MANUAL
7
Compressor & Evaporators
Fulgor Milano 
 The evaporator in the Fresh Food section is not accessible for service. 





Display
.
Inverter


Temperature Sensors




Heating Elements
There are seven heating elements on this refrigerator - a Fresh Food Heater (not accessible), a Flapper Heater between
the two Fresh Food Doors, Two Fill Tube Heaters, an Ice Maker Heater (The Flapper, Fill Tube Heaters and Ice Maker
Heater are in a parallel circuit), a Freezer Defrost Heater, and a Drain Heater (not accessible)(The Defrost and Drain
Heaters are in a parallel circuit). There are three defrost profiles: When the refrigerator is in Quick Freeze Mode, the
Defrost Element will energize every 10hrs for 60 minutes or until the Evap. thermistor reads 50OF/10OC. In Door Open
Mode the Defrost Element will energize every 38hrs or when the compressor has been running for 28hrs. Again, it will
run for 60 minutes or until the Evap thermistor reads 50OF/10OC. In Door Closed Mode the Defrost Element will energize
every 50hrs and will run for only 5 minutes, or until 50OF/10OC is reached.
Fans





Ice Makers & Water Valves






Lights




Ionizer & Air Filter



Controller


Theory of Operation
Refrigerator

SERVICE MANUAL
8
Refrigerator Components
Water Filter Cover
Normal Door Shelves
Glass Shelves
Vegetable Bin Cover
Vegetable Bin
Zero Degree Bin Cover
Zero Degree Bin
Ionizer
Side Lighng
Glass Shelves
Adjustment Panel
Air Sensor Cover
Gallon-sized
Door Shelves
Water Dispenser
Rear Panel
Air Filter
Shelf Support
Fresh Food Evaporator
(Not accessible)
Fresh Food Heater
(Not accessible)
Display
Water Reservoir & Dispenser Valve
(Located inside paron)
Flapper Heater
Fresh Food Fan
Refrigerator

SERVICE MANUAL
9
Ice Maker Bin
Freezer Basket
Freezer Bin
Freezer Storage Bin
Ice Maker
Air Sensor
LED Lighng
Upper Freezer
Rails
Lower Freezer
Rails
Freezer Rear
Panel
Evaporator Cover
Air Sensor
Thermal Fuse
Evaporator Sensor
Defrost Element
Evaporator
Freezer Components
Freezer Fan
Refrigerator

SERVICE MANUAL
10
Rear & Compressor Area Components
Inverter Condenser Condenser Fan 
 
Refrigerator

SERVICE MANUAL
11
Gas Flow Diagram & Parts
Cooling System Components
 
 
 
 
 
 
 
 
Welding Point
 
 
 
 
 
 
 
 

 
 




Refrigerator

SERVICE MANUAL
12
Electrical Components & Specifications
*Note: For the exact stock number information, look at the BOM List on the Manusoft System.
Quantity Component Stock Number Specifications
1 4151231000* 
1 5782940300* 
1 5783015200* 
2 5751240100* 
1 5799900100* 
5 4940162100* 
2 5750730100* 
1 5751370100* 
1 Freezer Defrost Heater 5749480200* 
1 Ionizer 4362700300* 
1 5724340100* 
2 4827350300* 
1 4896853600* 
1 5712631200* 
1 4919820700* 
1 Control Board 4934269501* 
1 4346600500* 
1 5733280300* 
2
 5733280100* 
Refrigerator

SERVICE MANUAL
13
Display & User Option Settings
1 2
3
4
5
6 7 8 9 10 11
12
13 14 15 16
17
18
19
20
21
1. Power key
2. Quick Cool key

3. Vacation Mode key

 
4. Fresh Food Temperature set key
tween 33F and 46C and 7
5. Temperature Scale selection

6. Power “off” Indicator
7. Quick Cool Indicator
8. Fresh Food Temperature Display
9. Vacation Mode Indicator

10. High Temperature/Error Indicator 

11. Filter Replacement Indicator


12. Ice Off Indicator 
13. Freezer Temperature Display
14. Eco-Extra Indicator
15. Quick Freeze Indicator
16. Freezer Temperature Set keyF
and 0
17. Ice Maker Off key 
18. Quick Freeze key
24 
19. Eco-Extra option key

.
20. Alarm Off key
21. Filter Reset key
Special Options
Sabbath Mode

Showroom Mode


Refrigerator

SERVICE MANUAL
14
Service Mode (Service Mode should be done before any other diagnostic or disassembly procedures.)
With the refrigerator and display on, press the “Power” & “Alarm Off” keys for 2 seconds, until PS
0 appears. Tap the Fresh Food Temp Set key once to enter the Display Test.
Display Test 

Display Software
Version & Revision



Control Board Software
Version & Revision



Sensor Readings Chart A below.

Low Voltage Test
(All lights & fans)
“SC OF
SC ON

Component Test
Chart B
                                                                 
rF, CF                                      
Ir 

Ice Maker Fill Time 

Dispenser Lighting Time 
Press and hold the “Power” & “Alarm Off” keys to exit the Service Mode
Chart A - Temperature Sensors
FH 
FE 
rH 
rE 
IS 
IS 
Chart B - Components
SC  Ir 
FF  dA 
FO  AU 
Io Ionizer dU 
bA  bU 
FL  Sb 
rF Freezer Fan CF Condenser Fan
rE Freezer Defrost Heater Co 
 
  
 
 
  
Power Quick
Cool
Fresh Food
Temp Set
Freezer
Temp Set
Quick
Freeze
Alarm
Off
Left Display Right Display
 

Refrigerator

SERVICE MANUAL
15
Error Codes
KN5
KN9
KN6
KN10 KN4
Error Codes Error Explanation
E0 
E1 
E2 
E3 
E4 
E8 
E9 
E13 
E15 
Warning Icon 


Control Board
Connection Numbers
KN5 
KN9 
KN6 Sensors
KN10 
KN4 

Refrigerator

SERVICE MANUAL
16
E1 - Freezer Compartment Evaporator Sensor Error
Yes No
1 >>2 
2
 >>3 >>4
3
 >>4 Solved
4



>>5 >>6
5Control Board. Solved
6faulty Sensor. Solved
E0 - Freezer Compartment Air Sensor Error
Yes No
1 >>2 
2
 >>3 >>
3
 >>4 Solved
4



>>5 >>6
5Control Board. Solved
6faulty Sensor.  Solved
E0 Test points E1 Test points
Refrigerator

SERVICE MANUAL
17
E2 - Fresh Food Compartment Evaporator Sensor Error
Yes No
1 >>2 
2
 >>3 >>4
3
 >>4 Solved
4



>>5 >>6
5Control Board. Solved
6 Fulgor
Milano
E3 - Fresh Food Compartment Air Sensor Error
Yes No
1 >>2 
2
 >>3 >>5
3
 >>4 Solved
4



>>5 >>6
5Control Board. Solved
6. Solved
E2 Test points E3 Test points
Refrigerator

SERVICE MANUAL
18
E4 - Freezer Defrost System Error
An E4 error does not necessarily mean you have a fault in the defrost
heating system. Follow these steps to determine the true cause. Yes No
1 >>2 
2frost
 >>4 >>3
3ice >>10 >>15
4 >>5 >>6
5 Solved
6 >>7 >>3
7
 >>8 >>9
8
 >>12 >>11
9 Solved
10  >>13 >>7
11  Solved
12  >>15 >>14
13 
 >>19 >>20
14  Solved
15  >>16 >>17
16 
 >>20 >>20
17 
 >>20 >>18
18 Control Board. Solved
19  Solved
20  Solved


Drain Heater
Refrigerator

SERVICE MANUAL
19
E8 - Ice Maker Air Sensor Error
There are two ice maker sensors. One for each tray. E8 could refer to
a fault with either one. Repeat these steps for both Ice Makers Yes No
1 >>2 
2
 >>3 >>4
3
 >>4 Solved
4



>>5 >>6
5Control Board. Solved
6faulty Sensor. Solved
E9 - Ice Maker Malfunction
There are two ice makers. This fault could refer to either one. Yes No
1 >>2 
2In 
 >>3 >>4
3 Solved
4Control Board. Solved
E8 Test points (Ice Maker 2 )
E8 Test points
(Ice Maker 1 )
E9 Test points
Ice Maker 1
E9 Test points
Ice Maker 2
Refrigerator

SERVICE MANUAL
20
E13 - Freezer Fan Error
Yes No
1 >>2 
2
 >>3 >>4
3
 >>4 Solved
4
 >>5 >>6
5
 >>6 Solved
6Freezer Fan. >>7 Solved
7 Solved
E15 - Condenser Fan Error
Yes No
1 >>2 
2
 >>3 >>4
3
 >>4 Solved
4
 >>5 >>6
5



>>6 Solved
6Condenser Fan. >>7 Solved
7 Solved
E15 Test pointsE13 Test points
Refrigerator
