Full Gauge Controls EVOLUTION Multi-FG User manual

EM DESENVOLVIMENTO
AA
B B
A B
Multi-FG
REMOTE INTERFACE FOR
DIGITAL CONTROLLERS
1. DESCRIPTION
2. APPLICATIONS
Multi-FG is an interface intended for controllers with RS485 connection and compatible protocol,
and it can be used with up to 32 instruments.
It enables viewing temperatures and controller status, changing the value of function parameters, and
sending commands. The instruments to be viewed may be changed automatically or manually.
Multi-FG protocol.Interface for controllers compatible with
evolution
Multi-FG
Ver.01
Multi-FG
Multi-FG
Functions
lockdown
Protection
level
Defrost
manual
IP 65
FRONT
6. FIRST STEPS
6.1 Electric connection and RS485 Network
After all connections are ready (sensors, relays, valve, and RS-485 networks) the configuration must be carried out with one controller at a time. To do this, power up only the first controller to be configured. When
has no instruments registered in the scan list the message [None] blinks on the main screen. Follow the next steps in this chapter to add the address of the controller in .Multi-FG Multi-FG
B A
6.2 Entering the access code
Access the main menu by pressing the keys >and<, simultaneously. Menu [Code]will be displayed upon releasing the keys. Enter the code 123 to gain full access to the other menus.
6.3 Adding a new controller
Follow the steps below to add new network controllers:
1) With the access code previously entered (according to item 6.2), use the keys >or< to access the menu [ADD,] and then press /.
The value to be sent to the controller in its new address is shown in the display. Adjust the value using the keys>and< and press / to confirm.
- The message [done] is displayed if the address is successfully configured.
- The message [used] is displayed if the address is already on the list.
- The message [Ecnn] is displayed if there is an error in the connection.
NOTE: In case of connection error, check the terminals for correct connection and tightening and the wires for ruptures. Try the same command again after checking.
4. INDICATIONS AND KEYS
Increase key
Decrease key
Set key
Quick Access
Menu Key (Flatec)
Address switching indicator led
Compressor output indicator led
Defrost indicator led
Fan indicator led
Economy mode indicator led
3. TECHNICAL SPECIFICATIONS
Power supply
Dimensions 76 x 34 x 77 mm (WxHxD)
Dimensions of the clipping for
fixing of the instrument 71 ± 0,5 x 29 ± 0,5 mm (see item 5)
Multi-FG: 115 or 230 Vac ±10%(50/60 Hz)
5. INSTALLATION - ELECTRICAL CONNECTIONS AND PANEL
Panel (Front View)
Panel
(Side View)
Dimension of the clipping
for setting of the
instrument in panel
71 mm± 0,5
29 mm± 0,5
1
5678
2349
POWER
SUPPLY
10 11 12 13 14 15 16 17
115 Vac
Connection 115 Vac
A
B
Connection 230 Vac
1
5678
2349
POWER
SUPPLY
10 11 12 13 14 15
230 Vac
16 17
A
B
FOR INSTALLATIONS WHERE A SEALING IS REQUIRED TO
AVOID LIQUID CONTACT, THE CUT FOR THE CONTROLLER
MUST BE OF 70,5X29mm MAXIMUM. THE SIDE LOCKS MUST BE
FIXED SO IT PRESSES THE RUBBER SEALING AVOIDING
INFILTRATION BETWEEN THE CUT AND THE CONTROLLER.
ATTENTION IMPORTANT
THE USE OF APPROPRIATE TOOLS IS ESSENTIAL TO AVOID
DAMAGE IN THE CONNECTION AT INSTRUMENT TERMINALS:
SCREWDRIVER SLOT 3/32''(2.4mm) FOR ADJUSTMENTS IN
THE SIGNAL TERMINALS;
SCREWDRIVER PHILLIPS #1 FOR ADJUSTMENTS IN THE
POWER TERMINALS;
Multi-FG
Sitrad
VEE
Power
MULTI-FG
2 | multi-FG (B)
1 | multi-FG (A)
SITRAD
11 | SITRAD (A)
12 | SITRAD (B)
RELAYS
13-14 | fans
15-16 | compressor
17-18 | defrost
Line
SENS. PRESS.
3 |
4~20mA (green)
4 |
12Vdc (brown)
|
Power Supply
12Vdc - 1.3A
vx-950 plus
SENS. TEMP. / DIG. IN
9-10 | sens. ambient temp.
8-9 | sens. evap. temp.
6-7 | sens. suction temp.
5-6 | digital input (door)
A B
AA
B B
A B
A B
Multi-FG
Sitrad
VEE
Power
MULTI-FG
2 | multi-FG (B)
1 | multi-FG (A)
SITRAD
11 | SITRAD (A)
12 | SITRAD (B)
RELAYS
13-14 | fans
15-16 | compressor
17-18 | defrost
Line
SENS. PRESS.
3 |
4~20mA (green)
4 |
12Vdc (brown)
|
Power Supply
12Vdc - 1.3A
vx-950 plus
SENS. TEMP. / DIG. IN
9-10 | sens. ambient temp.
8-9 | sens. evap. temp.
6-7 | sens. suction temp.
5-6 | digital input (door)
Multi-FG
Sitrad
VEE
Power
MULTI-FG
2 | multi-FG (B)
1 | multi-FG (A)
SITRAD
11 | SITRAD (A)
12 | SITRAD (B)
RELAYS
13-14 | fans
15-16 | compressor
17-18 | defrost
Line
SENS. PRESS.
3 |
4~20mA (green)
4 |
12Vdc (brown)
|
Power Supply
12Vdc - 1.3A
vx-950 plus
SENS. TEMP. / DIG. IN
9-10 | sens. ambient temp.
8-9 | sens. evap. temp.
6-7 | sens. suction temp.
5-6 | digital input (door)
AA
B B
A B
A B
12Vdc
1.3A
Powered down controller
LEGEND
12Vdc
1.3A
12Vdc
1.3A
Multi-FG
115/230 Vac MAINS
Control temperature 0 to 50°C / 32 to 122°F
- Use a 120 Ω termination resistor in
terminals A and B of the last network
connection block.
- Maximum cable length is 100 meters.
Full Gauge Controls recommends:
120Ω
WARNING
ACCESSORIES:
Only use original Full Gauge Controls accessories.
If you have any questions, please contact technical support.
AUTHORIZED SERVICE:
The installation or maintenance of the product must be performed by qualified professionals only;
BEFORE INSTALLING THE CONTROLLER, WE RECOMMEND READING THROUGH THE
ENTIRE INSTRUCTION MANUAL IN ORDER TO AVOID POSSIBLE DAMAGE TO THE
PRODUCT.
PRECAUTIONS WHEN INSTALLING THE PRODUCT:
Before performing any procedure on this instrument, disconnect it from the mains;
Ensure that the instrument has adequate ventilation and avoid installation in panels containing
devices that may cause it to operate outside the specified temperature limits;
Install the product away from sources that may generate electromagnetic disturbances such as:
motors, contactors, relays, solenoid valves, etc;
DUE TO YOUR CONSTANT EVOLUTION, THE FULL GAUGE CONTROLS RESERVES THE RIGHT TO
CHANGE THE INFORMATION CONTAINED IN THIS MANUAL AT ANY TIME WITHOUT NOTICE.
Temperature unit indicator led
MULTIFG-01T-14850

2)In the same menu, power up the second controller, select a new address, and then press/. Repeat this operation until all controllers in the network have addresses configured.
NOTE: The menu [Add,] has a 15-second time limit if no key is pressed. The message [----]is displayed after this time and returns to the temperature display.
3) After all addresses are configured, update the readings by pressing ; ,select the menu [Chng] and press /.
NOTE 1: If more than one address is added at each change, either manual or automatic (see item 11.1), the message [Addr] + number of the address to be viewed will be displayed.
NOTE 2: If you want to erase all records in the scan list, enter the code 717 in the menu [Code](see item 6.2).
7. ADVANCED CONFIGURATION
7.1 Searching instruments in the network
If a controller has an address other than 247, i.e. previously changed by itself or by Sitrad,
use this procedure to add to the list. This way the address will not be changed in the controller. Follow the
steps below:
Step 1: With the security code previously entered (according to item 6.2), hold down keys>and<
until the menu [sCan]is displayed.
Step 2: Power up the controller to be inserted on the list.
Step 3: Press/ and then will automatically search the network for addresses displaying
the numbers from [,001] to [,246].
Signaling:
NOTE: To clear the whole scan list, go to the main menu (according to item 6.2), select the menu
[code]and enter the code 717. will reboot with the scan list without registered
addresses.
7.2 Removing an instrument from the scan list
With the security code previously entered (according to item 6.2), hold down the keys >and< until
the menu [Del,]is displayed. Select the value of the address to be removed from the list and then
press /. The message [Done]will be displayed if the operation is successful.
The message [no,,]will be displayed if the address is not on the list.
Multi-FG
Multi-FG
Multi-FG
8.2 Quick Access Keys Map
When controller is on temperature display mode, the following keys can be used as shortcuts for the
following functions:
9. ACCESS MENU
10. ADJUSTING THE DESIRED TEMPERATURE
Access the main menu by pressing the keys >and<, simultaneously. The menus will be
displayed upon releasing the keys. It is also possible to access the main menu through the quick access
menu (see item 8.1).
[Code] Enter the access code
[func] Functions of the controller's parameter table (related to the current instrument)
[Cnfg]
[Add,] Program the instrument in the controller and add it to the list (sending a new address)
[sCan] Search an instrument
[Del,] Remove an instrument from the list
Hold down the key / for 2 seconds to enter the setpoint adjustment menu. The message [SP,,]
will be shown in the display and then the value to adjust the normal setpoint. Use the keys >or< to
change the value and press/to confirm. Then the message [SP-e] will be displayed to indicate the
economy setpoint adjustment. Use the keys >or<again to change the value and press/. to
confirm. Finally the indication [----] is signaled concluding the configuration. The setpoints may also
be adjusted individually in the quick access menu.
Multi-FG configurations
11. SETTINGS TABLE OF MULTI-FG
Instrument scan mode
Maximum update time
Time for functions lockdown
[,C01]
[,C02]
[,C03]
DescriptionFun Min Max Unit
Auto
20
60
-
sec.
sec.
Manual
5
No = 14
11.1 Description of the functions
C01- Instrument scan mode:
If more than one instrument is registered on the scan list, allows changing the instrument
view automatically at each interval defined in C02.
The views are displayed according to the instrument's address in ascending order.
NOTE: Even in the automatic mode the instrument may be changed manually by pressing ;to access
the menu [Chng], and then pressing/.
C02 - Maximum update time:
This function defined the reading update time according to the following configurations:
Only one instrument registered: The elapsed time updates the data reading.
More than one instrument registered and C01 in manual mode: The elapsed time updates only the
data reading of the instrument being viewed.
More than one instrument registered and C01 in automatic mode: The elapsed time changes the
instrument to the next on the list in ascending order with the data reading updated.
C03 - Time for functions lockdown:
For safety reasons the controller has a feature to allow locking functions. When this configuration is
active, the setpoint and other parameters are protected from undue changes. However, these can be
viewed. In this condition the message[LOC,]no display. will be displayed when trying to change those
values.
To lock functions you need first to adjust the parameter
Multi-FG
“[,C03]- Time for functions lockdown” with a
value greater than 14 (below 15, [no,,]is displayed and it means that function lockdown is not
allowed). Using the key ;(quick touch) select the function lock function and then press/(quick
touch). After that, hold down the key>until [LOC,][On,,]is displayed.
EM DESENVOLVIMENTO
To unlock, turn the controller off and then turn it on again with the key >pressed. Hold down the key
until the message [LOC,][OFF,] indicates the unlocking (10 seconds).
Multi-FG
ADDRESS 1 ADDRESS 2 CONFIGURING
AA
B B
A B
B A
Multi-FG
Sitrad
VEE
Power
MULTI-FG
2 | multi-FG (B)
1 | multi-FG (A)
SITRAD
11 | SITRAD (A)
12 | SITRAD (B)
RELAYS
13-14 | fans
15-16 | compressor
17-18 | defrost
Line
SENS. PRESS.
3 |
4~20mA (green)
4 |
12Vdc (brown)
|
Power Supply
12Vdc - 1.3A
vx-950 plus
SENS. TEMP. / DIG. IN
9-10 | sens. ambient temp.
8-9 | sens. evap. temp.
6-7 | sens. suction temp.
5-6 | digital input (door)
A B
AA
B B
A B
A B
Multi-FG
Sitrad
VEE
Power
MULTI-FG
2 | multi-FG (B)
1 | multi-FG (A)
SITRAD
11 | SITRAD (A)
12 | SITRAD (B)
RELAYS
13-14 | fans
15-16 | compressor
17-18 | defrost
Line
SENS. PRESS.
3 |
4~20mA (green)
4 |
12Vdc (brown)
|
Power Supply
12Vdc - 1.3A
vx-950 plus
SENS. TEMP. / DIG. IN
9-10 | sens. ambient temp.
8-9 | sens. evap. temp.
6-7 | sens. suction temp.
5-6 | digital input (door)
Multi-FG
Sitrad
VEE
Power
MULTI-FG
2 | multi-FG (B)
1 | multi-FG (A)
SITRAD
11 | SITRAD (A)
12 | SITRAD (B)
RELAYS
13-14 | fans
15-16 | compressor
17-18 | defrost
Line
SENS. PRESS.
3 |
4~20mA (green)
4 |
12Vdc (brown)
|
Power Supply
12Vdc - 1.3A
vx-950 plus
SENS. TEMP. / DIG. IN
9-10 | sens. ambient temp.
8-9 | sens. evap. temp.
6-7 | sens. suction temp.
5-6 | digital input (door)
AA
B B
A B
A B
12Vdc
1.3A
12Vdc
1.3A
12Vdc
1.3A
Multi-FG
115/230 Vac MAINS
8. OPERATIONS
8.1 Quick Access Menu Map
To access or browse in the quick access menu use the key ;(quick touch) while the temperature is
being displayed by the controller. Each touch displays the next function of the list; for confirming, use the
key/(quick touch).
FUNCTIONS LOCKDOWN
CONTROL FUNCTIONS
(ON/OFF)
;
SWITCH THE VIEW TO THE NEXT
REGISTERED INSTRUMENT
;
;
MULTI-FG
CONFIGURATION
EXIT FUNCTION
;
FUNCTION SELECTION
;
CURRENT PROCESS
VIEWER
;
ERASE MIN. AND MAX.
RECORD VALUES
;
MIN. AND MAX. TEMPERATURE
RECORD
;
Multi-FG Multi-FG
Multi-FG
Multi-FG
Multi-FG
Multi-FG
Multi-FG
Multi-FG
;
Multi-FG
DEFROST (ON/OFF)
ECONOMY SETPOINT (ON/OFF)
;
Multi-FG
;
Multi-FG
/
<
<
Hold down for 2 seconds: Setpoint adjustment.
Quick touch: Displays the current process, process time, and sensor data.
Quick touch: Maximum and minimum records display.
<Hold down for 2 seconds: Erases the maximum and minimum records.
<
Hold down for 2 seconds: When the buzzer is active, disables the audible
alarm.
<Hold down for 4 seconds: Carries out manual defrost.
<
<Quick touch: Enters function selection.
and
Default
Auto
8
No
The address is already being used by another instrument.
The address searched found a new instrument in the network.
[uSed]
[done]

14. SIGNALING
Connection error.
No instruments registered in the scan list.
[Ecnn]
[none]
15.1 Ecase
It is recommended for the Evolution line, keeps water from entering the back part of the instrument. It also
protects the product when the installation site is washed.
15.2 Extended frame
It allows the installation of Evolution line controllers with sizes 76 x 34 x 77 mm in various situations,since it
does not require precision in the notch of the instrument fitting panel. The frame integrates two switches of
10 Amperes that may be used to actuate interior light, air curtain, fan, and others.
15. OPTIONAL ITEMS - Sold Separately
WARRANTY - FULL GAUGE CONTROLS
Products manufactured by Full Gauge Controls, as of May 2005, have a two (02) year
warranty, as of the date of the consigned sale, as stated on the invoice. They are guaranteed
against manufacturing defects that make them unsuitable or inadequate for their intended
use.
EXCEPTIONS TO WARRANTY
The Warranty does not cover expenses incurred for freight and/or insurance when sending
products with signs of defect or faulty functioning to an authorized provider of technical
support services. The following events are not covered either: natural wear and tear of parts;
external damage caused by falls or inadequate packaging of products.
LOSS OF WARRANTY
Products will automatically lose its warranty in the following cases:
- The instructions for assembly and use found in the technical description and installation
procedures in Standard IEC60364 are not obeyed;
- The product is submitted to conditions beyond the limits specified in its technical
description;
- The product is violated or repaired by any person not a member of the technical team of
Full Gauge Controls;
- Damage has been caused by a fall, blow and/or impact, infiltration of water, overload
and/or atmospheric discharge.
USE OF WARRANTY
To make use of the warranty, customers must send the properly packaged product to Full
Gauge Controls together with the invoice or receipt for the corresponding purchase. As much
information as possible in relation to the issue detected must be sent to facilitate analysis,
testing and execution of the service.
These procedures and any maintenance of the product may only be provided by Full
Gauge Controls Technical Support services in the company's headquarters at Rua Júlio de
Castilhos, 250 - CEP 92120-030 - Canoas - Rio Grande do Sul – Brasil
ENVIRONMENTAL INFORMATION
Packaging:
The materials used in Full Gauge products' packaging are 100% recyclable. Dispose of
your waste preferably using specialized recycling agents.
Product:
The components used in Full Gauge controllers can be recycled and reused if
disassembled by a specialized company.
Disposal:
Do not burn or throw controllers in domestic garbage. Obey the laws in effect for your
area regarding the disposal of electronic waste. If in doubt, please contact Full Gauge
Controls.
EM DESENVOLVIMENTO
Inhibits the audible alarm.
Multi-FG not programmed.
[inib]
[pppC]
[ECal] Please contact Full Gauge Controls.
13. ACCESS CODES
[,123] Allows changing the advanced parameters in the menus [Func] and [Cnfg].
[,231] Allows choosing the units of pressure and temperature:
[=C-b]Temperature in degrees Celsius and pressure in bar
[=C-p] Temperature in degrees Celsius and pressure in psig
[=F-b]Temperature in degrees Fahrenheit and pressure in bar
[=F-p] Temperature in degrees Fahrenheit and pressure in psig
Rev. 03
Copyright 2015
