Furinno 11069WH-PI-GR-LBL User manual

Assembly Instruction
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
Recommended Maximum Weight
*Unit in Pound(lbs)
STEP 4
Attach Top Panel (D) to assembled unit using
Screw (1) as shown.
Attach Right Side Panel (B) to assembled unit
using Screw (1) as shown.
STEP 5
STEP 6
6.1 Attach Back Panel (F) to the back of
assembled unit using Power Pin (2).
6.2 Cover screw head with Sticker (3).
B
E
D
D
(1)x 6pcs
F
A
D
(2)x 18pcs
A
D
E
E
D
(1)x 4pcs
10
10
10
Recomm. 2 Person
Approx. 30 minutes
Furinno 5-Cube Reversible Open Shelf
MODEL : 11069WH-PI-GR-LBL
11069WH-PI-GR-LBL20180329
Tool RequiredTool Required
Customer Support
www.furinno.com
NEED HELP? For replacement requests or product inquiries,
please contact our Customer Service Team by emailing us at
[email protected]. Thank you for selecting Furinno!

STEP 2
Attach another Shelf Panel (E) to the other side
of Center Panel (C) using Screw (1) as shown.
3.1 Attach Bottom Panel (D) to Center Panel (C) using Screw (1).
3.2 Attach Left Side Panel (A) to the assembled unit
using Screw (1).
STEP 3
STEP 1
Attach two Shelf Panel (E) to Center Panel (C)
using Screw (1) as shown.
USEFUL HINTS BEFORE YOU START:
1. Read each step carefully before starting.
2. It is important that each step is performed in correct order to avoid difficulties.
3. Identify, sort and count the parts before assembly.
4. Assemble your furniture on packaging cardboard to prevent scratch or damage.
5. Clean the product with mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser.
6. Using uncompatible hardware might cause damage to product.
1
2
3
Screw
Sticker
A
B
C
D
E
F
1pc
1pc
1pc
2pcs
3pcs
1pc
Left Side Panel
Right Side Panel
Center Panel
Top/ Bottom Panel
Shelf Panel
Back Panel
Power Pin
No Hardware List Qty No QtyParts List
F
A
B
C
D
D
E
E
E
(1)x 4pcs
E
E
C
D
A
E
E
(1)x 8pcs
E
E
E
C
(1)x 2pcs
C
14x2pcs
18pcs
24pcs
