Furman PRESTIGE P-6900 AR E User manual

P-6900 AR E POWER CONDITIONER
CONDITIONNEUR D’ALIMENTATION P-6900 AR E / P-6900 AR E ACONDICIONADOR DE ENERGíA
P-6900 AR E NETZSCHUTZGERÄ / ПРОВОДНИК СИЛЫ P-6900 AR E
230
PRESTIGE SERIES OWNER’S MANUAL
SÉRIE PRESTIGE GUIDE DE L’UTILISATEUR / SERIE PRESTIGE MANUAL DEL PROPIETARIO
PRESTIGE REIHE HANDBUCHTEXT / КПРЕДПРИНИМАТЕЛИ СЕРИИ ПРЕСТИЖНОСТИ РУЧНЫЕ

ALL CONTENT ©2009 FURMAN. ALL RIGHTS RESERVED. PRINTED IN CHINA.
ENGLISH
Page 4
FRANÇAIS
Page 12
ESPAÑOL
Page 20
P-6900 AR E OWNER’S MANUAL
P-6900 AR E GUIDE DE L’UTILISATEUR
P-6900 AR E
MANUAL DEL PROPIETARIO
P-6900 AR E POWER CONDITIONER
CONDITIONNEUR D’ALIMENTATION P-6900 AR E / P-6900 AR E ACONDICIONADOR DE ENERGíA
P-6900 AR E NETZSCHUTZGERÄ / ПРОВОДНИК СИЛЫ P-6900 AR E
230
PRESTIGE SERIES OWNER’S MANUAL
SÉRIE PRESTIGE GUIDE DE L’UTILISATEUR / SERIE PRESTIGE MANUAL DEL PROPIETARIO
PRESTIGE REIHE HANDBUCHTEXT / КПРЕДПРИНИМАТЕЛИ СЕРИИ ПРЕСТИЖНОС ТИ РУЧНЫЕ
DEUTSCH
Page 28
РУССКИЙ
Page 36
P-6900 AR E HANDBUCHTEXT
P-6900 AR E ТЕКСТ ИНСТРУКЦИИ ПО ЭКСПЛУАТАЦИИ

4
P-6900 AR E OWNER’S MANUAL
FURMAN P-6900 AR E FEATURES
True RMS Voltage Regulaon• - A 30 amp ultra-low noise toroidal autoformer with microprocessor control
SMP• (Series Mul-Stage Protecon) with EVS (Extreme Voltage Shutdown)
LiFT• (Linear Filtering Technology) with zero ground contaminaon
Nine total regulated, ltered and protected rear panel AC outlets and two front panel convenience outlets•
230V or 240V output (switchable)•
Dimmable/Switchable true RMS digital ammeter and laboratory precise voltmeter•
Tri-color voltage range indicator (complements numerical voltage reading - even when viewed at a distance from the display)•
Front panel USB connector charges most portable media devices and cell phones•
30 amp (6900 wa) maximum current capacity•
C-form male inlet and 30A outlet (C-form female cord-end connector included) •
Five year limited warranty•
INTRODUCTION
Thank you for purchasing a Furman Presge Series Voltage Regulator/Power Condioner, and congratulaons on your choice. The
Presge Series P-6900 AR E features Furman’s True RMS Voltage Regulaon, Series Mul-Stage Protecon (SMP) circuit, and our exclu-
sive Linear Filtering Technology (LiFT). Together, these technologies comprise precisely what our customers have grown to expect from
Furman: uncompromised protecon and puricaon. The P-6900 AR E has been precisely engineered to more than meet the crical
demands of sound reinforcement, recording studios, broadcast facilies, remote A/V work, and discerning musicians alike.
The Furman P-6900 AR E is intended to protect sensive electronic equipment from problems caused by AC line voltage irregulari-
es—brownouts or over-voltages that can cause audio tonal changes, digital equipment malfuncon (such as loss of MIDI programs
or other data), or, in extreme cases, permanent damage. It accepts input voltages over a wide AC voltage range and converts them to
a steady, stable output of either 230V or 240V (switchable), plus or minus 10 volts. Voltages approximately ±10% beyond the capture
range may be converted to usable levels, depending on the requirements of the equipment. This stable voltage protects equipment
and allows opmal performance. If you frequently move your rack to dierent locaons, derive power from generators, use excessive-
ly long extension cords, travel internaonally, or are in an area prone to brownouts, you will benet greatly from the use of a Furman
P-6900 AR E.
DESCRIPTION
True RMS Voltage Regulaon Technology
True RMS Voltage Regulaon is designed around an ultra-low noise eight-tap toroidal autoformer. A microprocessor within the P-6900
AR E monitors the incoming RMS voltage with each cycle, measuring the phase angle in me with the advancing cycle. Most com-
mercial voltage regulators using mulple-tapped transformers switch taps at uncontrolled mes. This creates voltage spikes and clicks
that can leak into audio. When a voltage uctuaon requires correcon by the P-6900 AR E, True RMS Voltage Regulaon advances a
new tap with less stress and in turn avoids distoron to the AC waveform. Hysteresis in the P-6900 AR E circuits avoids the unneces-
sary switching back and forth between the adjacent taps (or “chaer”) found in many commercial voltage regulators. If necessary, True
RMS Voltage Regulaon technology can switch taps as oen as once each cycle and do so with a shorter recovery me than a com-
mercial voltage regulator. In addion, and unlike voltage regulators that employ ferro-resonant transformers, the P-6900 AR E is not
sensive to small errors in line frequency, making it ideal for use with generators.
The P-6900 AR E has nine receptacles on the rear panel and two convenience receptacles on the front panel. All are funconally
interchangeable in terms of voltage regulaon, protecon and ltering. However, there are dierences in the current that can pass
through them. Two front panel and six rear panel IEC 320 female receptacles can provide up to 10 amps capacity; two IEC C-19 female
receptacles provide up to 16 amps capacity; and one C-Form female receptacle provides 30 amps capacity (no combinaon of the
eleven receptacles can supply more than 30 amps). Addionally, the autoformer’s toroidal design assures minimal leakage of stray
magnec elds.
Note: P-6900 AR E is for use with AC voltage only. DC voltages should never be applied. Also, it does not change or regulate line fre-
quency. The output frequency will always be the same as the incoming frequency.
SMP (Series Mul-Stage Protecon) with EVS (Extreme Voltage Shutdown)
Furman’s SMP (Series Mul-Stage Protecon) surge suppression virtually eliminates service calls and costly “down me”. Tradional
surge suppression circuits sacrice themselves when exposed to mulple transient voltage spikes, requiring the dismantling of your
system and repair of your surge suppressor. Not so with Furman’s SMP. With SMP, damaging transient voltages are safely absorbed,

5
FRANÇAIS
ENGLISH ESPAÑOL DEUTSCH РУССКИЙ
clamped, and dissipated. Your connected equipment is protected, while your P-6900 AR E protects itself!
Unique to Furman’s SMP is its unparalleled clamping voltage. While other designs oer clamping voltages that are well above 600
Vpk, Furman’s SMP clamps at 375 Vpk, (266 VAC) even when tested with mulple 6000 Vpk - 3000 amp surges! This unprecedented
level of protecon is only available with Furman’s SMP technology. Addionally, Furman’s trusted EVS (Extreme Voltage Shutdown)
circuitry protects against catastrophic overvoltage condions (such as all-too-frequent accidental connecons to 300+ VAC or an
intermient neutral) by shung o the incoming power unl the overvoltage condion is corrected and the power switch is reset.
LiFT (Linear Filtering Technology)
Furman’s Linear Filtering Technology (LiFT) reduces AC line noise in an even, linear manner across a very wide bandwidth, resulng
in a lower noise oor. Tradional AC lter - condioners have been designed for unrealisc laboratory condions - whether mulple
pole lters or convenonal series mode, prior technologies could actually harm audio and video performance more than they help,
due to the resonant peaking of their anquated, non-linear designs. Under certain condions, these designs can actually add more
than 10 dB of noise to the incoming AC line! Worse sll, lost digital data, the need to re-boot digital pre-sets, or destroyed digital
converters are frequently caused by excessive voltage spikes and AC noise contaminang the equipment ground. Furman’s LiFT
takes a dierent approach, ensuring opmal performance through linear ltering with no contaminaon, or leakage, to ground.
Addional Features
Addionally, the P-6900 AR E oers a laboratory precision dual funcon digital meter that displays incoming voltage in 1-volt steps
and performs as a RMS ammeter measuring current to one tenth of an amp. The voltmeter’s accuracy is ±2.0 volts and features a
tri-color voltage range indicator. This informs the user whether voltage is in or out of a safe range. The ammeter accurately mea-
sures current draw for an instant analysis of system requirements. The accuracy of the current measurement for the ammeter is
beer than +/-0.5A.
The P-6900 AR E is equipped with eleven regulated outlets; two front panel convenience AC outlets and nine rear panel outlets. All
rear panel outlet banks are electrically isolated from each other to minimize cross-talk between components.
The P-6900 AR E’s 30 amp capacity is supplied from a C-form male inlet connector with a cord-end female C-form included (stan-
dard).
SAFETY INFORMATION
To obtain best results from your Furman P-6900 AR E, please read this manual carefully before using.
WARNING
To reduce the risk of electrical shock, do not expose this equipment to rain or moisture. Dangerous high voltages are present inside
the enclosure. Do not remove the cover. Refer servicing to qualied personnel only.
IMPORTANT SAFETY INSTRUCTIONS
(Please read prior to installaon)
1. Please read and observe all safety and operang instrucons before installing your P-6900 AR E. Retain these instrucons for
future reference.
2. Your P-6900 AR E should not be used near water – for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool.
3. Do not place your P-6900 AR E near high heat sources such as radiators, heat registers, stoves, or other appliances that produce
extreme heat.
4. Route the AC power cord and other cables so that they are not likely to be walked on, tripped over, or stressed. Pay parcular at-
tenon to the condion of the cords and cables at the plugs, and the point where they exit your Furman condioner. To prevent risk
of re or injury, damaged cords and cables should be replaced immediately.
5. Clean your P-6900 AR E with a damp cloth only. Do not use solvents or abrasive cleaners. Never pour liquid on or into the unit.
6. This unit shall not be exposed to dripping or splashing liquids and no objects lled with liquids shall be placed on the apparatus
7. This unit shall be connected to a MAINS socket outlet with a protecve earthing connecon.

6
P-6900 AR E OWNER’S MANUAL
8. Your P-6900 AR E should be serviced by qualied service personnel when:
• The power supply cord or the plug has been frayed, kinked, or cut.
• Objects have fallen or liquid has spilled into the unit.
• The unit has been exposed to rain or extreme moisture.
• The unit does not appear to operate normally.
• The “Protecon OK” indicator is not lit.
• The unit has been dropped, or the enclosure has been damaged.
9. Connecng your P-6900 AR E to a grounded AC service outlet is highly recommended. Though not necessary for the product to
funcon, It will help to avoid any possibility of electrical shock if connected equipment fails for any reason.
10. Do not aempt to service your P-6900 AR E beyond what is described in this manual. All other servicing should be referred to
qualied service personnel.
INSTALLATION
Because of the toroidal transformer design, the Furman P-6900 AR E may be posioned near most other equipment without fear
that the other equipment will be disrupted by leakage of a strong 50/60 Hz magnec eld (50Hz is recommended for best operaon).
Nevertheless, suggested rack locaons would be either at the top or boom.
As with any rackmount equipment, be sure to use 10-32 machine screws for mounng in the rack’s tapped holes (this is not a metric
size). In parcular, beware of 10-24 screws, which may t if forced but which will strip the threads. To avoid marring the front panel
nish, use plasc washers under the screw heads.
Rear Rack Mounng:
If you are installing the P-6900 AR E in a rack that has rear as well as front mounng rails, you may easily secure it to the rear of
your rack. Simply remove the securing screws from the side and front porons of the P-6900 AR E’s adjustable rear rack ear and
reinforcement side plate (located on either chassis side), reverse it and re-aach to the P-6900 AR E chassis. (See Figure 1.a, page 10)
OPERATION
Voltage Selecon Switch:
The voltage selecon switch is only read by the regulator during power up. Once the regulator is acve, this switch has no eect on
the output voltage. If the user desires to change the output voltage, adjust the switch to the desired seng and cycle power to the
regulator.
Dimmable/Switchable Digital Voltage and True RMS Current Meter:
Furman’s laboratory precision AC digital voltmeter connually measures incoming voltages within a typical tolerance of +/-2.0VAC. It
should be noted that the voltage reading is determined by the incoming AC source.
The Furman true RMS current meter constantly measures the total circuit AC load, with a typical tolerance of +/-0.5 amp. Because the
meter features True RMS technology, the current readings are accurate regardless of load condions (capacive, inducve, or resis-
ve).
To switch between voltage and current, press the buon labeled “Line Voltage/Current”. To change the display intensity, hold this but-
ton down for two seconds to cycle through the 3 stages of brightness.
Voltage Range Indicator:
This tri-color Voltage Range indicator is located in the lower le corner of the digital voltage meter lens assembly. When the incoming
AC voltage is within a capture range of 180-260V (230V output seng – 190-270 @ 240V output seng) the tri-color indicator will be
green (opmal), indicang the unit is in regulaon. However, if the regulator encounters a temporary transient condion the indicator
will turn amber (cauon). This amber indicaon appears when there are excessive changes or sudden swings at the input (+/-20 volts).
If the incoming voltage is beyond the P-6900 AR E capture range (see above), the indicator will turn red. Red warnings indicate the
incoming voltage is far from opmal and beyond the capture range oering a constant 230V (or 240V switchable). In this condion,
the P-6900 AR E will connue to regulate from the last tap of the autoformer, providing an output voltage as close to 230V (or 240V) as
possible (e.g. an input voltage of 180V would equate to 221V at output – in the 230V switched output seng). When employing the
P-6900 AR E in mission crical applicaons where 230V is the primary concern, the red indicaon is invaluable.

7
FRANÇAIS
ENGLISH ESPAÑOL DEUTSCH РУССКИЙ
Ultra-Low Resistance Magnec Power Switch / Circuit Breaker:
Furman’s Presge Series 30 amp capacity power switch / circuit breaker is specically designed to stand up to the enormous high
in-rush current demands of many power ampliers. If the 30 amp maximum RMS current capacity of the P-6900 AR E is exceeded,
the spring tensioned switch will immediately reset to the “0” posion. You will need to switch back to the “1” posion once the
problem is corrected (typically by eliminang one component), or unl the RMS current does not exceed 30 amps (6900 was @
230VAC).
Total Current Capacity (maximum and minimum load):
The P-6900 AR E can handle loads totaling up to 30 amperes as long as the input voltage is equal to or above 230 volts (or; 240V
with the 240V output seng). For voltages below that level, its capacity must be de-rated at approximately 130 milliamperes per
volt. (See graphs on back page.) As a praccal maer, therefore, to cope successfully with worst-case brownout condions, you
should plan your total load so that it does not exceed approximately 25 amps, or 5800 was. Please note that this refers to the ag-
gregate power requirement of all equipment plugged into the P-6900 AR E, not to each individual item.
Extreme Voltage Shutdown Indicator:
The Extreme Voltage LED indicator is normally o. It is located within the meter lens assembly directly above the blue voltage me-
ters LED’s, though during normal use it will NOT be visible.
The Extreme Voltage indicator monitors a hazard common in the entertainment industry, as well as remote broadcast: wiring faults,
such as accidental connecon to 300+ VAC where 230VAC is expected, or an open series neutral from a mul-phase electrical ser-
vice. The Furman EVS circuit senses voltages that are so high that operaon would be impossible and shuts the power down before
damage can occur.
Upon inially applying power to the P-6900 AR E, the Extreme Voltage indicator will illuminate to a bright red if the input voltage
is above the extreme voltage cuto. When this occurs, power will not be applied to the P-6900 AR E’s outlets. If the unit has been
operang with an acceptable input voltage and subsequently that voltage exceeds 275V, it will shut o power to the outlets and the
Extreme Voltage LED will light.
Note: If the mains power is above the high cuto voltage and has caused the EVS circuit to remove power from the Furman’s outlets,
it cannot restore power without the operator manually turning the unit o, then on again. Avoid turning the unit back on without
rst checking the source of the problem and perhaps changing the AC source.
Protecon OK Indicator:
Although the Furman SMP circuit assures virtually maintenance free protecon from transient voltage spikes and surges, nature has
a way of occasionally creang electrical forces that are beyond the capabilies of any TVSS device to absorb without some degree
of damage (such as a direct lightning hit in an outdoor applicaon). In the rare instance that this occurs, the green “Protecon OK”
LED indicator (located to the lower right of the voltage meter) will not illuminate. If this happens, some level of protecon from
voltage surges will remain, but the Furman’s clamping voltage rang will be compromised. The unit must be returned to Furman.
USB Charger:
The Furman P-6900 AR E’s USB charger provides an easy way to recharge many popular electronic accessories as well as cellular
communicaon devices by simply plugging the re-charge cord into the front panel socket.
Note: As there are currently dierent charging standards for USB devices, some devices may not be compable with our charger.
Isolated Outlet Banks:
The Furman P-6900 AR E features six rear-panel IEC-320 10 Amp outlets in two isolated banks. If you are connecng digital and ana-
log equipment to the P-6900 AR E, it is recommended to connect the analog equipment to “Bank A” and digital equipment to “Bank
B” (or vice-versa) to minimize electrical crosstalk.
TROUBLESHOOTING
1.) Symptom: No power to the AC outlets; “Protecon OK” indicator is not lit.
Possible Cause: Either the AC outlet to which your P-6900 AR E is connected has no AC voltage present, or there has been damage
to the unit’s circuitry.
Acon Needed: Plug the P-6900 AR E into an AC receptacle where a nominal 230 VAC is present. If the problem persists, the inter-
nal circuitry may be damaged and the unit will require factory service (see “Service” secon below).
2.) Symptom: Extreme Voltage indicator lit.

8
P-6900 AR E OWNER’S MANUAL
Possible Cause: Input voltage is above 275 volts causing power to the unit’s outlets to be shut down.
Acon Needed: Correct the line voltage, and then turn the Furman condioner on.
SERVICE
Quesons or issues with your Furman unit should be directed to the Furman Customer Service Department, via email at info@furman-
sound.com. If a unit requires service, it must have an RA number assigned from Furman’s Customer Service Department.
Before returning any equipment for repair, please be sure that it is adequately packed and cushioned against damage in shipment, and
that it is insured. We suggest that you save the original packaging and use it to ship the product for servicing. Also, please enclose a
brief note giving your name, address, phone number and a descripon of the problem. Please display your RA number prominently on
the front of all packages.
5 YEAR LIMITED WARRANTY
SAVE YOUR SALES RECEIPT! The receipt is your proof of purchase and conrms the product was purchased at an authorized Furman
dealer. It will need to be submied to Furman in order to process any warranty claims.
Furman, a brand of Panamax Inc., warrants its P-6900 AR E (the “Product”) as follows:
Furman warrants to the original purchaser of the product that the product sold hereunder will be free from defects in material and
workmanship for a period of ve years from the date of purchase. If the product does not conform to this Limited Warranty during the
warranty period (as herein above specied), purchaser shall nofy Furman of the claimed defects via email (inf[email protected]).
If the defects are of such type and nature as to be covered by this warranty, Furman shall authorize purchaser to return the product
to Furman headquarters. Warranty claims MUST be accompanied by a copy of the original purchase invoice or receipt showing the
purchase date. Shipping charges to Furman headquarters must be prepaid by the purchaser of the product. Furman shall, at its own
expense, furnish a replacement product or, at Furman’s opon, repair the defecve product. Return shipping charges back to purchas-
er will be paid by Furman.
THE FOREGOING IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WAR-
RANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Furman does not warrant against damages or defects arising out of improper use or abnormal handling of the product, or against
defects or damages arising from improper installaon. This warranty shall be cancelable by Furman at its sole discreon if the product
is modied in any way without wrien authorizaon from Furman or Panamax Inc. This warranty also does not apply to products upon
which repairs have been aected or aempted by persons other than pursuant to wrien authorizaon by Furman or Panamax Inc.
THIS WARRANTY IS EXCLUSIVE. The sole and exclusive obligaon of Furman shall be to repair or replace the defecve product in
the manner and for the period provided above. Furman shall not have any other obligaon with respect to the products or any part
thereof, whether based on contract, tort, strict liability or otherwise. Under no circumstances, whether based on this Limited Warranty
or otherwise, shall Furman be liable for incidental, special, or consequenal damages. This Limited Warranty states the enre obliga-
on of Furman with respect to the product. If any part of this Limited Warranty is determined to be void or illegal, the remainder shall
remain in full force and eect.

9
FRANÇAIS
ENGLISH ESPAÑOL DEUTSCH РУССКИЙ
SPECIFICATIONS
MAXIMUM CURRENT: 30 A AT 230V (230V OUTPUT SETTING) OR 30A AT 240V (240V OUTPUT SETTING)
INLET CONNECTOR: CHASSIS MOUNT C-FORM MALE (WITH CORD-END C-FORM FEMALE INCLUDED IN PRODUCT CARTON)
IN REGULATION RANGE: 180 TO 260 VAC (230V OUTPUT SETTING), 50Hz, 190 TO 270 VAC (240V OUTPUT SETTING), 50Hz
OVER VOLTAGE SHUTDOWN: 275 VAC NOMINAL
APPROXIMATE INPUT VOLTAGE CAPTURE RANGE: 174 TO 264VAC
SPIKE PROTECTION MODES: LINE TO NEUTRAL, ZERO GROUND LEAKAGE
SPIKE CLAMPING VOLTAGE: 375 VAC PEAK (266VAC) @ 3,000 AMPS
RESPONSE TIME: 1 NANOSECOND
MAXIMUM SURGE CURRENT: 6,500 AMPS
NOISE ATTENUATION: 10 DB @ 10KHz, 30 DB @ 100 KHz, 50 DB @ 500KHz
POWER CONSUMPTION: 17 WATTS (NO LOAD)
RECEPTACLES (REAR PANEL): TWO C-19 RECEPTACLES, SIX C-13 RECEPTACLES, AND ONE FEMALE C-FORM 30A RECEPTACLE
RECEPTACLES (FRONT PANEL): TWO C-13 RECEPTACLES
DIMENSIONS: 483MM (19”) W X 597MM (23.5”) D X 133.35MM (5.25”) H (MEASURED WITH LINE CORD CONNECTOR IN PLACE)
WEIGHT: 26kg. (57 lbs.)
SAFETY AGENCY: CE
P-6900 AR E FRONT PANEL
P-6900 AR E REAR PANEL
convenience outlets
isolated ac outlet bank a
isolated ac outlet bank b
AC power cord inlet
voltmeter/ammeter toggle
and meter dimmer
(hold to select brightness)
master
power switch
digital LED voltmeter/ammeter and
status indicators
USB
charger
voltage select
230V/240V output
30 amp AC outlet
high current
outlet bank

10
P-6900 AR E OWNER’S MANUAL
AR VOLTAGE AND AR OUTPUT RANGE
REAR RACK EAR MOUNTING (Figure 1.a)
Remove the securing screws from the side and front porons of the P-6900 AR E’s adjustable rear rack ear and reinforcement side
plate (located on either chassis side). Reverse the rack ears and re-aach to the P-6900 AR E chassis (as shown on the right).
