Furniture Pipeline Ames User manual

UNIT WEIGHT: 1.5 LB
WEIGHT CAPACITY PER SHELF/TIER: 5 LB
Decorative Shelf

2
Allen Wrench
Pipe
Fitting
Set Screw
Prior to shipping your unit, each sub-assembly (part) is inspected with great care to ensure that all
fittings (connectors) & pipes are correctly aligned. Means beyond our control may cause parts to
shift or misalign during shipping & handling.
Please ensure that all fittings (connectors) are properly aligned by ma ing small adjustments &
tightening the set screws with the 1/8” Allen Key provided.
Fastening System
Keep in mind, Our unique fastening system provides you with the opportunity tolevel & ma e
small adjustments to your unit, achieving the perfect fit for your home!
Each our design utilizes a simple & effective fastening system to quic ly assemble your unit. To
reduce assembly time, each fitting (connector) has pre-installed set screws (spare set screws are
provided) at EACH pipe entry location. Set screws are tightened using a 1/8” Allen Key, which
safely secures the pipe in place.

3
1.00"
8.00"
6.94"
8.00"
6.94"
5.94"

4
DISCLAIMER:
IMPORTANT WARNINGS AND CAUTIONS!
WARNING: A WARNING alerts you to the possibility of serious in ury or death if you do not follow the
instructions.
CAUTION: A CAUTION alerts you to the possibility of damage or destruction of equipment if you do
not follow the corresponding instructions.
WARNING: Failure to read, thoroughly understand, and follow all instructions can result in serious
personal in ury, damage to equipment, or voiding of factory warranty! It is the installer’s
responsibility to make sure all components are properly assembled and installed using the
instructions provided.
WARNING: Failure to provide adequate structural strength for this component can result in serious
personal in ury or damage to equipment! It is the installer’s responsibility to make sure the structure
to which this component is attached can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the component.
WARNING: Exceeding the recommended weight capacity can result in serious personal in ury or
damage to equipment! It is the installer’s responsibility to make sure that the combined weight of all
components attached to the supporting structure including all items on display does not exceed the
recommended weight!
WARNING: FURNITURE MAY WEIGH IN EXCESS OF 40 LBS! Always use two people and proper lifting
techniques when installing or positioning furniture.
These characteristics occur due to the fact that wood is a natural product and is affected by
weather, cli ate, insects, birds, soil akeup, and natural growth patterns. These
characteristics are apparent and are not to be isinterpreted as defects. Wood is a product of
nature- and as such will display natural characteristics and variances that are unique to each
and every cut. These characteristics are an integral part of the char and beauty of real solid
wood - no two pieces are alike!
We intend to make this instruction manual accurate and complete. However,we make no claim that
the information contained herein covers all details, conditions or variations, nor does it provide for
every possible contingency in connection with the installation or use of this product. The information
contained in this document is subject to change without notice or obligation of any kind. We assume
no responsibility for accuracy, completeness or sufficiency of the information contained in this
document.
Wood Disclaimer: We use natural solid wood products to create quality furniture. However,
wood grain is a product of nature, no two grain patterns are ever exactly alike. This
individualis is one of the ost appealing factors of solid wood products. Soil and cli ate
affect the growth characteristics of wood. The finest woods have certain natural
characteristics that cannot be hidden with a finishing process.

5
[x1]
Flange
1
[x1]
Pipe Elbow Assembly
2
[x1]
Shelf Assembly
3
[x2]
5/16" x 1 7/8" lg.
Screws
4
5
[x1]
1/4" Allen Key
Larger
6
[x1]
1/8" Allen Key
Smaller
NOTE: SMALL ADJUSTMENTS MAY BE NEEDED ON SUBASSEMBLIES DUE TO SHIPPING MOVEMENT
7
[x2]
Plastic Wall
Anchor

6
1
USE PART 6
TO TEMPORARILY
TIGHTEN
PIPE TO
FLANGE
[x1]
FAILURE TO PROPERLY SECURE SHELF TO WALL STUD AS
INSTRUCTED MAY RESULT IN SERIOUS INJURY!
2
1

7
TIGHTEN
SET SCREW
FROM STEP 2
IMPORTANT: FAILURE TO PROPERLY SECURE UNIT TO WALL
AS SHOWN MAY RESULT IN INJURY.
3
6
2

8
1. PLACE THE UNIT IN DESIRED LOCATION AGAINST WALL LINING AT LEAST ONE SIDE UP WITH A STUD.
2. LIGHTLY MARK YOUR WALL USING A PENCIL IN EACH MOUNTING HOLE ON THE FLANGES.
3. REMOVE UNIT FROM WALL AND PREDRILL YOUR MARKED SPOTS USING A 3
16" DRILL BIT.
IF NOT GOING DIRECTLY INTO STUD, USE ANCHOR (ITEM 7). DRILL 5
16" HOLE AND HAMMER
ANCHOR INTO PLACE.
4. REMOVE WALL FLANGE FROM UNIT BY LOOSENING SET SCREW ON PIPE AND MOUNT IT TO WALL
USING SCREWS (PART 4).
5. REFER BACK TO STEP 1 TO REMOUNT REST OF UNIT BACK TO FLANGE. ENSURE SHELF SURFACE IS
LEVEL; TIGHTEN SET SCREW PERMENANTLY THIS TIME.
3
TIGHTEN
SET SCREW
PERMENANTLEY
6

9
WARRANTY
Finishes of Pipes and Fi ings, and all O her Par s and Componen s, Excluding Wood
-1 Year Limited Warranty-
All metal finishes and other parts and components, excluding wood, are warranted to you, the original retail
purchaser, for a one-year period starting from the date of purchase, to be free frommaterial manufacturing
defects. We will pay, within one-year from the date of purchase, reasonable and standard labor rates to repair
or replace the defective parts including the shipping costs from the retailer to and from us or a repair center
designated at no charge to the original retail purchaser.
Finishes of Metal and Metal Components
The Limited Warranty, of "Finishes of Pipes and Fi ings, and all O her Par s and Componen s, Excluding
Wood", does not cover (1) damages resulting from excessive soiling, improper or unapproved cleaning
methods, (2) fading or other damages resulting from exposure to sunlight, (3) damages resulting from
household humidity, or (4) damages resulting from any liquid, including but not limited to alcohol and water
based cleaning products. Any use of improper or unapproved cleaning me hods voids all warran ies of us.
