Furniture Tree Sammie Bunk User manual

Sammie Bunk Instructions
Step 1.
Open up hardware pack, group
the same parts together.
Step 2.
There are a lot of pieces so be sure you
have everything you need before you
start assembling. Keep them tidy.
Step 5.
Repeat this process
with the safty rails. Do
not over tighten.
Step 6.
The bunk can be
attached with the
ladder either end.
Decide what end suits
and fasten with the M6
x35mm to upright rails.
Step 7.
Fit all the
safty rails with
Uprights using
your M6 x35mm.
Step 8.
Go through
and tighten all
joinings with
your allen key.
Do not over
tighten.
Free phone: [phone]
www.furnituretree.co.nz
Step 4.
Place dowel into holes
and the M6 x100mm
through the bunk ends
and place barrel nut
in the holes in the rail.
Bring together and
hand tighten. Do this on
all four corners on both
the top and the bottom
bunk.
Step 3.
Firmly but,
gently, hammer
the dowels all
the way into the
end of the rails.

Step 11.
Place wood pin in
holes on top of the
bottom bunk. Place
top bunk on top. You
will need another
person for this.
Step 13.
Repeat this process
on the other side to
complete the ladder.
Step 12.
Fit ladder steps to
ladder rails with the
screw holes facing
down. Make sure
the dowels are as far
into the ladder rails
as possible. Screw
together using pilot
holes.
Step 14.
And finally place the
ladder on the bed
side rail and screw
into place
To find video instructions go here:
http://furnituretree.co.nz/index.php/help-faq
Step 9.
You should now have two
beds that look like this.
Step 10.
Place the slats on
bunks pull them out to
the staps so that they
are taut. Screw them
into place firmly but,
do not over tighten. If
you over tighten the
screws will rip out of
the timber.
