Furnware Storg Safna 56 Series User manual

410-418
Min.490
Min.600
Storg Safna
56 Series Waste Bin
ST561.450.235.OGY
A
B
D
E
I
F
H
G
C
Do not use powered screw drivers for adjustment.
FITTINGS
12 of 3.9x13 Self tapping screw pan head
8 of 4x16 Self tapping screw countersunk head
4 of M4x5 Special machine screw
2 of M6x10mm Pan head machine screw
2 of M6 Washer
COMPONENTS
A. Metal frame
B. Kit Grass slides (pair)
C. Slide cover
D. Lid holder (Pair)
E. Lid
F. Door fixing brackets
G. Door bracket cover
H. Stopper
I. Wastebin 35L
MAINTENANCE
Clean with a soft, dry cloth. Avoid using solvents or abrasive.
Plastic waste bins can be washed with warm water and mild detergent.
Allow to dry completely before use.
TOOLS

CLICK!
CLICK!
55
37 Third hole
288
15 474
237
20
32 32
20
490
1
2
Fix the Grass slides (B) and the lid holder (D)
according to the dimensions shown.
Clip the slide Covers (C) into the Grass slides (B).
4 of 3.9x13 Self tapping screw pan head
8 of 4x16 Self tapping screw countersunk head
3Screw the metal frame (A) into the slide cover
(C) by using the specific provided screws.
4 of M4x5 Special machine screw

20 20
112
64
16
16 16
16
32
315
4
5
Attach the door fixing brackets (F) according to
the dimensions shown.
Pre-assemble the M6x10 screws and washers
then mount the door on the slide covers (C) as
shown.
4 of M4x5 Self tapping screw pan head
2 of M6x10mm Pan head machine screw
2 of M6 Washers

8
9
7Adjust the door inclination to the front or to the
back, then tighten the two M6x10 screws.
6Adjust the door up and down by turning the
eccentric screw.
