Fusion CS-CM50 User manual

COMPONENT SPEAKER SYSTEMS
 CS-CM50 CS-CM60
PeakPower(Watts) 220 240
RatedPower(Watts) 35 40
FrequencyResponse 41Hz-26kHz 35Hz-26kHz
Impedance 4Ohms 4Ohms
Sensitivity 85dB 86dB
ConeMaterial Polypropylene Polypropylene
Tweeter PEI PEI
MountingDepth 43mm(1-11/16”) 45.5mm(1-13/16”)
MountingDiameter 118mm 126mm
 (4-21/32”) (5”)
CS-CM50 CS-CM60
WARNING:Donotdrillmountingholeswithspeakerinplaceasthiscouldallowdrillshavingstodamagethe
voicecoilandvoidyourwarranty.
SPEAKER PARAMETERS
www.fusionelectronics.com
TWEETER
Ø53mm
(2-1/16”)
9mm(11/32”)
20mm(25/32”)
47mm
(1-27/32”)
INSTALLATION GUIDELINES
Ensuretheaudiosystemisturnedoffbeforemakinganyconnections
totheamplier,speakersorsourceunit.Failuretodosocouldresultin
permanentdamagetotheaudiosystem.
Whenwiringthespeakersensurethatthewireisprotectedfromsharp
objectsandalwaysuserubbergrommetswhenwiringthroughmetal
panels.Ensureallterminalsandconnectionsareprotectedfromthe
vehiclechassisandfromeachotherasfailuretodosocouldresultin
permanentdamagetotheaudiosystem.
Whenconnectingthesourceunitandspeakersensureyouconnect
thepositiveandnegativeoutputwirefromthesourceunittothe
correspondingspeakerterminals.Thiswillensuretheaudiosystemwill
beinphase.

1) Ensurethereisadequateclearance&depthforthespeakertobe
 mounted
2) Usethesuppliedtemplatetomarkout&cutthecorrectdiameterhole
3) Drillfourholesforthemountingscrews
4) Seperatethegrillefromtheframe
5) Insertthespeaker&grilleframeandafxwiththescrewsprovided
6) Completeinstallionbyreplacingthegrilleintothegrilleframe

TWEETER (Surface/Angle mount)
To obtain the best performance from the tweeter it should be located on axis to approximately 4” below the rear
view mirror. Select the mount you require and use this as a template to drill the holes to mount or alternatively
if using an adhesive pad ensure the mounting surface is cleaned with a residue free cleaner and stick the
tweeter down. Attach the wires to the speaker terminals.
TWEETER (Flush mount)
Ensure you have adequate depth to mount the tweeter and cut a 47mm hole. Assemble the rear mount with the
spring clamp and press through from the rear of the hole, then attach the front plate to the rear plate as shown
in the illustration. Attach the wires to the speaker terminals.
PUBLISHED BY FUSION ELECTRONICS LIMITED: © Copyright 2010 by FUSION Electronics Limited. All rights reserved. Specications and design are subject to change without notice.
YOU CAN HELP PROTECT THE ENVIRONMENT! Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal center.
RECORD YOUR PURCHASE DETAILS HERE:
SERIAL NUMBER
DATE OF PURCHASE
AFFIX RECEIPT HERE
WARNING: Audio Systems can produce sound levels over 135dB. Continuous exposure to sound pressure levels over 100dB may cause permanent
hearing loss! Please watch for emergency vehicles as warning signals may not be heard. USE COMMON SENSE!
