Fusion Signature Series User manual

®
Signature Series Subwoofer
Installation Instructions
Important Safety Information
WARNING
See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.
WARNING
This device must be installed according to these instructions.
Disconnect the vehicle's or vessel's power supply before
beginning to install this device.
CAUTION
Continuous exposure to sound pressure levels over 100 dBA
may cause permanent hearing loss. The volume is typically too
loud if you cannot hear people speaking around you. Limit the
amount of time you listen at high volume. If you experience
ringing in your ears or muffled speech, stop listening and have
your hearing checked.
Always wear safety goggles, ear protection, and a dust mask
when drilling, cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite
side of the surface.
It is strongly recommended that you have your audio system
installed by a professional installer to ensure optimum
performance.
You must read all installation instructions before beginning the
installation. If you experience difficulty during the installation, go
to www.fusionentertainment.com for product support.
After installing the subwoofer, you should run the subwoofer at
low to medium volumes for the first few hours of use. This helps
to improve the overall sound by gradually loosening up the
moving components of the subwoofer, such as the cone, spider,
and surround
Tools Needed
• Electric drill
• Drill bit (size varies based on surface material)
• Phillips screwdriver
• Appropriate saw or utility knife to cut surface material
• 16 AWG (1.31 mm²) or larger speaker wire
• 4.8 mm and 6.3 mm female speaker spade connectors
(recommended)
• 22 AWG (0.33 mm²) or larger wire for the LEDs (sports
models only)
• 4 mm male and female bullet connectors for the LED wires
(recommended, sports models only)
• Wire strippers (optional)
• Crimping tool (optional)
• Electrical tape (optional)
• Marine sealant (optional)
NOTE: For customized installations, additional tools and
materials may be needed.
Mounting Considerations
NOTICE
When mounting the subwoofer in an area exposed to weather or
water, you must mount the subwoofer on a vertical surface. If
you mount the subwoofer on a horizontal surface facing up,
water can gather in and around the subwoofer, causing damage
over time.
If you intend to mount the subwoofer outside the boat, you must
mount it in a location well above the waterline, where it is not
submerged or damaged by docks, pilings, or other pieces of
equipment. When mounted correctly, this subwoofer is rated for
protection from the front of the speaker. Water exposure and
damage to the rear of the subwoofer voids the warranty. This
includes situations when the subwoofer is mounted in a sealed
enclosure, especially if it is exposed to wash down. Using an
enclosure with a port or vent exposed to the outside
environment may allow water to collect and damage the
subwoofer.
You must turn off the audio system before making any
connections to the source unit, amplifier, or speakers. Failure to
do so could result in permanent damage to the audio system.
You should protect all terminals and connections from grounding
and from each other. Failure to do so could result in permanent
damage to the audio system and void the product warranty.
When selecting a mounting location for the subwoofer, observe
these considerations:
• You must select mounting locations that provide sufficient
clearance for the mounting depth of the subwoofer as
specified in the product specifications.
• You should select a flat mounting surface for the best seal.
• You should select a location where the surface material is
thick enough to support the weight of the subwoofer. It's
important to note that when in use, the subwoofer exerts a
pushing and pulling effect on the surface, so if the material is
thin, it can result in excess vibration and negatively affect the
sound quality.
• You should protect the speaker wires from sharp objects and
always use rubber grommets when wiring through panels.
• To avoid interference with a magnetic compass, you should
not mount the subwoofer closer to a compass than the
compass-safe distance value listed in the product
specifications.
Selecting the correct mounting location optimizes the
performance of the subwoofer. FUSION® speakers are designed
to perform in the widest possible range of mounting locations,
but the more you plan the installation, the better the speakers'
sound will be. For more information on subwoofer placement
and specifications, go to www.fusionentertainment.com .
Mounting the Subwoofer
Before mounting the subwoofer, you must choose a location
following the guidelines above.
1Route the speaker wires (and LED wires, if applicable) from
the source to the speaker location.
2Trim the template and make sure it fits in the selected
location.
3Orient the template with the FUSION logo at the bottom of
the template.
4Secure the template to the selected location.
5Using a jigsaw or rotary tool, cut the mounting surface along
the inside of the line on the template.
6Place the subwoofer in the cutout to test the fit.
7If necessary, use a file and sandpaper to refine the size of
the cutout.
December 2019
190-02675-91_0A

8After the subwoofer fits correctly in the cutout, ensure the
mounting holes on the subwoofer line up with the pilot holes
on the template.
9If the mounting holes do not line up, mark the new hole
locations.
10Using an appropriately sized drill bit for the mounting surface
and screw type, drill the holes.
11Remove the template from the mounting surface.
12Connect the subwoofer wires while observing polarity
(Speaker Wiring, page 2).
13If necessary, connect the LED wires to the Sports model
subwoofer (LED Wiring, page 2).
14Place the subwoofer in the cutout.
15Secure the subwoofer to the mounting surface using the
included screws.
NOTE: Do not over tighten the screws, especially if the
mounting surface is not flat.
For the Classic model subwoofer, attach the grille to the front.
Speaker Wiring
When connecting the subwoofer to your stereo or amplifier,
observe these considerations.
• Speaker wire is not included with subwoofer. You should use
16 AWG (1.31 mm²) or larger speaker wire to connect the
subwoofer to the stereo or amplifier.
• The leads on the subwoofer are terminated using male spade
connectors. You should use female spade connectors (not
included) to connect the speaker wire to the leads for the
best connection.
You can use these tables to identify the polarity and spade-
connector sizes of the leads on the subwoofer.
Lead color Polarity Spade connector size
White Positive (+) 6.3 mm
White with a black stripe Negative (-) 4.8 mm
LED Wiring
Connecting the LED Wires
You can control the color of the LEDs by connecting the colored
LED wires to the negative (-) terminal of a 12 VDC power
source. You can splice the negative (-) wire to multiple LED
wires to customize the LED color and tone. You must connect
the black LED wire to the positive (+) terminal of the same
12 VDC power source to complete the circuit.
NOTE: This feature is available only on the sports model.
NOTE: Instead of connecting the LED wires for one dedicated
color, you can install a remote control to turn the LEDs on and
off, change the color, and create lighting effects. See your
FUSION dealer or www.fusionentertainment.com for more
information.
The black wire on the LED cable is terminated with a 4 mm
female bullet connector, and the color wires are terminated with
4 mm male bullet connectors. You can connect these to 4 mm
bullet connectors on your wires (not included), or remove the
bullet connectors to connect to the bare wires instead.
1Connect the positive (+) wire from a 12 VDC power source to
the black wire on the LED cable.
2Connect the negative (-) wire from the same 12 VDC power
source to the colored wire or wires on the LED cable
according to the preferred LED color.
LED Color LED Wire Color
Red Red
Green Green
Blue Blue
Yellow Red and green
Magenta Red and blue
Cyan Blue and green
Cool white Turquoise
Warm white Yellow
NOTE: You can connect the cool white or warm white wire to
change the tone of any LED color combination.
3If necessary , route the positive and negative wires, and
connect them to a 12 VDC power source (Connecting the
LED Wires to Power, page 2).
Connecting the LED Wires to Power
NOTE: This feature is available on only the sports model.
You must connect all 12 Vdc wiring to the LEDs to a 3 A fuse at
the power-source end of the cable. You should connect the
positive (+) power wire to a 12 Vdc power source through an
isolator switch or circuit breaker to turn the LEDs on and off. You
can use the same isolator or circuit breaker controlling the
power supply to your stereo, which allows you to turn the LEDs
and the stereo on and off at the same time.
You should use 22 AWG (0.33 mm²) or thicker wire to connect
the LEDs to the battery.
1Route the positive power (+) and negative ground (-) wires
from the LED-wire connections to the battery.
2Connect the negative wire to the negative (-) battery terminal.
3Connect the positive wire to the positive (+) terminal through
a 3 A fuse and isolator switch or circuit breaker.
Attaching the grille to the Classic Model Subwoofer
NOTE: This feature is available only on the Classic model
subwoofer.
1With the subwoofer mounted, hold the grille with the FUSION
logo at the bottom, at the 6 o'clock position.
2Turn the grille counter-clockwise about 10°, so the FUSION
logo is at the 5 o'clock position.
3Place the grille on the rim of the subwoofer.
4Twist the grille clockwise to secure it.
Speaker Information
True-Marine™ Products
True-Marine products are subjected to rigorous environmental
testing under harsh marine conditions to surpass industry
guidelines for marine products.
Any product that bears the True-Marine stamp of assurance has
been designed for simplicity of use and combines advanced
marine technologies to deliver an industry leading entertainment
experience. All True-Marine products are supported by the
FUSION 3-year worldwide limited consumer warranty.
Registering Your Subwoofer
Help us better support you by completing our online registration
today.
• Go to www.fusionentertainment.com .
• Keep the original sales receipt, or a photocopy, in a safe
place.
2 Signature Series Subwoofer Installation Instructions

Dimension Drawings
Side View
130 mm (5 1/8 in.)
220 mm (8 21/32 in.)
A Sports model subwoofer is shown, but the dimensions are the
same for the Classic model.
Sports Model Front View
275 mm (10 13/16 in.)
247 mm (9 3/4 in.)
Classic Model Back View
275 mm (10 13/16 in.)
247 mm (9 3/4 in.)
Cleaning the Subwoofer
NOTICE
Do not use harsh or solvent-based cleaners on the subwoofer.
Using such cleaners may damage the product and void the
warranty.
When mounted correctly, this subwoofer is rated IP65 for
protection in the harsh marine environment from the front of the
subwoofer. The subwoofer is not designed to withstand high
pressure water spray, which may occur when you wash down
your vessel. Failure to carefully spray-clean the vessel may
damage the product and void the warranty.
1Clean all salt water and salt residue from the grille with a
damp cloth soaked in fresh water.
2Use a mild detergent to remove a heavy buildup of salt or
stains.
Specifications
Max. power 600 W
RMS power 300 W
Sensitivity (1 W/1 m) 87 dB
Frequency response From 30 Hz to 2 kHz
Min. mounting depth (clearance) 133 mm (51/4 in.)
Mounting diameter (clearance) 223 mm (813/16 in.)
Impedance 4 ohms
Amplifier power-rating
recommendation
50 to 400 W RMS, playing
music
Compass-safe distance 520 cm (205 in.)
LED supply voltage (Sports model
only)
From 10.8 to 16 Vdc
LED load current at 14.4 Vdc (Sports
model only)
300 mA
Operating temperature range From 0 to 50°C (from 32 to
122°F)
Storage temperature range From -20 to 70°C (from -4 to
158°F)
Cone material PP cone with Santoprene
rubber surround
Water and dust rating IEC 60529 IP65
Optimum Enclosure Recommendations
Sealed enclosure volume117.2 L (0.6 ft.3)
Ported (vented) enclosure volume245 L (1.6 ft.)3)
Port diameter 104 mm (4 in.)
Port length 265 mm (10 7/16 in.)
連絡地址
製造銷售:台灣國際航電股份有限公司
聯絡地址:新北市汐止區樟樹二路 68 號
電 話:[phone]
客服專線:[phone]
© 2019 Garmin Ltd. or its subsidiaries
Garmin®, the Garmin logo, FUSION®, the Fusion logo, and True-Marine™ are trademarks
of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These
trademarks may not be used without the express permission of Garmin.
1 Fully filled with absorption material.
2 Lined with absorption material.
Signature Series Subwoofer Installation Instructions 3

© 2019 Garmin Ltd. or its subsidiaries www.fusionentertainment.com
