Futon Life Tri-fold with Arms User manual

Parts List:
#cotter pins #clevis pins
#stretchers
The Tri$fold with Arms
Laying out all the parts and hardware and identifying
each part as shown may help as you assemble your frame!
NOTE: This frame and The Bi$fold with Arms share similar
assembly instructions for the arms and stretchers!
#arm assemblies
#sliders
%conformats
&allen wrench
%barrel nuts
&slat rack assembly with three sections

Assembly Instructions:
1
Lower the slat rack into
the frame as shown!
Line up the slide rollers
to the grooves in
the arms!
2
3
Lay out the arms and stretchers
as shown!Insert the barrel nut
into the stretcher with the
groove in the barrel nut facing
you!Next"connect the stretchers
to the arms by screwing the
conformat through the arm into
the stretcher and into the barrel
nut!You can use a screwdriver
to align the barrel nut with the
conformat screw!Follow this
process with the other 'holes"
there are #holes per corner!
NOTE: Do not tighten the
conformat screws"make sure
the frame is kept loose!
Lay out the slat rack
flat and attach the
slide rollers to each
end of the middle
section with a clevis
pin and cotter pin!

Once the deck is lined
up and in place"
tighten the stretchers!
CAUTION:
Over tightening can
damage the stretcher!
4
You can now fold your
frame into the sitting
position and place the
futon mattress on it!
5
Note: Some frames have small
fold down legs to support the
slat rack corners!
