FUYU AMC4030 User manual

User Manual of AMC4030 Motion Controller
AMC4030
Motion Controller
User Manual
（Version 0.2）
CHENGDU FUYU TECHNOLOGY CO.,LTD.

User Manual of AMC4030 Motion Controller
Preface
Thanks for choosing AMC4030 motion controller!
AMC4030 motion controller is developed by FUYU as an economic and general-purpose
controller. To return our customers’ support, we will help you to build your unique control
systems by offering high-quality motion controller, perfect after-sales service and efficient
technical support.
Why To Use This Manual?
By reading this manual, the user can understand the basic structure of the AMC4030 motion
controller, correctly install it and connect the controller to the motor control system, so as to
complete the basic setting or development of the motion control system.
Who Will Use This Manual?
This user manual suits for engineers who have basic knowledge of hardware and some
understanding of control systems.
Main Points of This Maunal
This manual describes in detail the AMC4030 motion controller’s components, installation,
wiring, debugging, electrical parameters, troubleshooting and so on.
Related Documents
For programming the AMC4030 motion controller, please refer to the "AMC4030 Motion
Controller Programming Manual" supplied with the product.
General safety precautions

User Manual of AMC4030 Motion Controller
Please carefully review the following safety precautions to avoid injury and prevent damage
to the product or any products connected to it. To avoid potential hazards, please use this
product according to our instructions.
Use the correct power cable. Please use a power cable that meets the national standard.
Properly connect and disconnect. Firstly, please connect the controller output to the drive
and the motor, then turn on the power. Before turn off the external power supply, please first
disconnect the motor, drive and the controller.
Do not operate when there is a suspicious failure. If you think that the product is damaged,
please let a qualified service representative to check.
Do not operate in a wet / humid environment.
Do not operate in explosive air.
Keep the product surface clean and dry.
To prevent electrostatic damage. Electrostatic discharge (ESD) may cause damage to
components in the motion controller and its accessories. To prevent ESD, please carefully handle
the controller components and do not touch the components on the controller. Do not place the
controller on a surface that may generate static electricity. Transport and store the controller in a
protective electrostatic bag or container.
Chapter 1 Product Overview
1.1 Introduction
FUYU’s AMC4030 motion controller is a cost effective and general-purpose 3-axis motion
controller. We adopt ARM as its CPU core control unit, and use a more efficient algorithm to
perfect its performance. Its main functions are:
1) The AMC4030 controller can control up to 3-axis motors at the same time (stepper
motor or servo motor).
2) AMC4030 controller supports high-speed point motion control, round-trip motion
control, sub-motion control, homing motion control and so on.

User Manual of AMC4030 Motion Controller
3) The AMC4030 controller supports 3-axis linear or circular interpolation motion, and any
2-axis linear or circular interpolation motions.
4) The AMC4030 controller supports backlash compensation
Due to its precise and excellent motion control performance, the controller is particularly suitable
for high-speed travel applications where efficient and smooth point control is required, including
palletizing robots, XYZ stage, packaging lines, CNC machine tools, woodworking machinery,
production assembly lines, electronic processing equipment and other equipment manufacturing
industries.
1.2 Specifications
Item AMC4030
Power Supply DC24V, 2A and above
No of control axis 3
Encoder None
General digital input DC24V, optocouple, 4-way
General digital output DC24V，4- way，Each up to 100mA
Dedicated digital input DC24V，Origin signal input, 3-way
Pulse output frequency (max) 150KHz
Pulse output mode Pulse/Dir
Pulse output value(max) ±2147483647（231）
Acceleration mode S-type / trapezoidal acceleration and deceleration
Bus extension 2-way CAN bus expansion, to achieve multi-controller
cascade control
COM Support customized COM protocol
Operating system WINDOWS XP and above，Memory 2G and above
Size（mm） 150*95*30
Table1-2 Specifications of the controller
1.3 System Configuration of AMC4030
AMC4030 controller has two typical system configurations: independent control system and
hierarchical on-line control system, as shown in chart 1-3.

User Manual of AMC4030 Motion Controller
AMC4030 controller can be connected with PC through a USB cable to build a hierarchical
online motion control sytem. It can also be separated from PC, and build a a stand-alone control
system through the HMI human interaction.
When the AMC4030 is used as an online motion system, the user can edit various motion
control commands through the PC-based software provided by us and realize real-time
monitoring of the control system. The motion controller completes all the motion trajectory
control and the response of the control commands, as well as the detection and response of all
IO signals.
When AMC4030 is used as a independent control system, a separate HMI (such as a touch
screen)is needed.
The motion data is pre-solidified to the control card,then the HMI commands, processing
data and all the IO signal detection and response will be executed and completed via the HMI and
the motion control.
Chapter 2 Instructions for Quick Use
2.1 Open-package Inspection
After unpacking, please carefully check if the product model is consistent with your order. If the
product surface is damaged or product model is wrong, or accessories are missing, please do not
use, and immediately contact the dealer. Standard configurations are as follows:

User Manual of AMC4030 Motion Controller
 AMP4030 controller，1pc；
 USB cable，1unit
 Warranty card，1pc
 Product Qualified Card，1pc
2.2 AMC4030 Interface definition
Table 2-1 Interface Definitions
2.3 AMC4030 Interface Circuit
1) Connect the controller to the drive (stepper driver or servo drive)
The default output mode for each axis of the AMP4030 is pulse / direction mode. The user can
set the output mode to dual pulse mode via the interface function (see the Programming Manual
for details).
Signal Descriptions Signal Descriptions
PE CAN Signal Ground 5V Power output DC5V
CAN1_H CAN1 High-Level Signal DIR1 X-axis direction
CAN1_L CAN1 Low-level Signal PUL1 X-axis pulse
CAN2_H CAN2 High-Level Signal 5V Power output DC5V
CAN2_L CAN2 Low-level Signal DIR2 Y-axis direction
ORG1 X-axis Original position signal PUL2 Y-axis pulse
ORG2 Y-axis Original position signal 5V Power output DC5V
ORG3 Z-axis Original position signal DIR3 Z-axis direction
GND Original point signal ground PUL3 Z-axis pulse
IN1 General input port 1 OUT1 General output port 1
IN2 General input port 2 OUT2 General output port 2
IN3 General input port 3 OUT3 General output port 3
IN4 General input port 4 OUT4 General output port 4
24V_IN 24V Power input USB MINI USB, connect PC
GND 24V Power ground COM COM，connect HMI

User Manual of AMC4030 Motion Controller
Chart 2-3-1 Axis signal wiring diagram
Pulse / direction mode connection diagram:
The pulse output waveform is as follows:
2) Connect to IO port

User Manual of AMC4030 Motion Controller
The AMC4030 input IO port includes a dedicated input port and a general-purpose
input port. The dedicated input is for original position input of each axis. General IO can be
selected according to the actual situation.
Each IO port can be connected to a point switch or a NPN limit switch. The wiring
method is as follows:
3) Connect to general output port
AMC4030 has four general-purpose pull-up output. The pull-up voltage is 24V. All the
output can be connected to relays, optocouplers, etc.. Max single current is 100mA.
2.4 AMC4030 Software and driver installation
When the AMC4030 controller is connected to PC via USB cable, the driver needs to be
installed on PC. Please follow the steps below to complete the installation of the driver.

User Manual of AMC4030 Motion Controller
（1）Download the driver installation package at the official website address:
http://www.fuyuautomation.com/ or contact our sales representative. The file is named as
“ CH341SER.rar ”。
（2）Extract the software and run the installation setup, as shown below, click the button
"install"。
Chart 2-4-1
（3） After installation is complete, click "OK" to complete the driver installation
（4） Open the device manager, double click "port (COM and LPT)", as shown in the red
box, then the installation is successful.
Charter 2-4-3
