FX LAB G002GKA User manual
G002GKA
Bubble Machine
With Remote Control (MkII)
Instruction Manual
IMPORTANT
Installer and Users please note:
These instructions should be read carefully and left with the user of the product for future
reference.
BEFORE USE
You must inspect the product including its power supply for any signs of damage. If the product
is damaged, DO NOT use it, and contact your supplier immediately.
PRODUCT SAFETY
This machine uses a wheel on a motorised axis. The wheel rotates through the liquid reservoir to
create bubbles.
WARNINGS
• This item can be used by children aged 8 years and above, and by persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision and instruction concerning the use of the item in a safe way and
understand the hazards involved.
• Children should be supervised to ensure that they do not play with the item.
• Do not place on carpet or other soft surfaces.
• Do not point the bubble output towards sensitive electronic equipment.
• Do not put anything apart from bubble uid in the tank (except when cleaning as described in
MAINTENANCE section).
• Do not move the unit whilst it is operating. Disconnect from the power supply and empty
the tank before moving.
• For indoor use only.
• Do not use in bathrooms, or in wet or damp locations.
• Arrange the cable so that it cannot cause a trip hazard.
• The unit must be disconnected from the power supply before lling or emptying the tank.
• Do not allow uid to enter the rear of the unit. If uid does accidentally enter the rear of the unit
disconnect it from the power supply & clean thoroughly before use.
• Do not overll the tank.
• Clean any overow/spillages immediately with a damp cloth.
• Fluid may cause spots/bleaching on cloth/upholstery etc.
• Warn other users & room occupants oors and hard surfaces may become slippery when in use.
• Do not drink the bubble uid.
• Disconnect the power supply from the mains when not in use.
• Do not leave this item unattended when switched on.
• Do not leave uid in the tank when not in use.
Note:
After prolonged use, the oor immediately in front of the unit may become slippy.
GENERAL SAFETY REQUIREMENTS
Domestic wiring must be tested periodically by a qualied electrician at least once every 10 years
or at every change of occupancy.
For oce and retail premises, and buildings such as village halls, the wiring must be inspected at
least once every 5 years.
It is recommended that all building be tted with smoke alarms (it is mandatory for new buildings).
OPERATION
To operate:
Place the G002GKA on a rm at surface. Ensure that the bubble outlet (at the front) is not
obstructed. Alternatively, the appliance may be suspended from the attached hanging bracket.
The unit must be suspended in a horizontal position and not tilted. Plug the power supply into a
13 Amp mains socket and attached to lead to the unit via the 12V socket on the rear of the unit.
Mode: Always on
Move the switch on the rear panel to position I. The unit should now continually function until
switched o
Remote Control Function:
Move the switch on the rear panel to position II
Using the remote control use the on/o buttons to switch the unit on or o.
To Switch Off:
Move the switch to (0) Position
To fill the tank:
Disconnect from its power supply.
Fill the tank (at the front) with Venü Benchmark Bubble Fluid (catalogue numbers: FL801 for a 1
litre bottle or FL805 for a 5 litre bottle) taking care not to allow any uid into the rear of the unit.
To empty the tank:
Disconnect from the power supply
Use a funnel (not provided) and tip the bubble machine forwards and sideways so that the
unused bubble uid ows out of the front corner of the tank taking care not to allow any uid to
run into the back of the unit. Return the unused uid to the bottle. Dry the tank with a cloth or
paper towel before moving or storing away.
MAINTENANCE
Cleaning:
Clean the outside of the unit with a soft damp cloth, with a drop of washing-up liquid.
To clean the appliance:
Empty out any residual bubble uid.
Rinse the tank with water.
If the power supply is damaged, it must be replaced by a like for like product authorised by the
manufacturer.
FAULT-FINDING
Unit Does Not Function:
1) Check the power supply is plugged into a wal socket and the socket is switched on.
2) Make sure the lead is plugged into the socket in the back of the unit and the switch is in the
correct setting.
3) If using the remote control follow the above advice but also check that there is a battery in the
remote control.
PAT TESTING
When used in a workplace, this product must be safety-tested yearly by a qualied electrician
(PAT Tested) in order to comply with the Electricity at Work Regulations.
If hired out, it must be PAT tested prior to each hire.
We recommend that it is PAT tested regularly when used in a domestic environment.
DISPOSAL AND RECYCLING
You must not dispose of this appliance with domestic household waste.
Most local authorities have specic collection system for appliances and disposal is free of
charge to the end-user.
When replacing an existing appliance with a similar new appliance your retailer may take the old
appliance for disposal.
SERVICE WARRANTY
Electrovision guarantees the product free from defects in materials and workmanship for a period
of one year.
Should this unit be operated under conditions other than those recommended, at voltages other
than the voltage indicated on the unit, or any attempts made to service or modify the unit , then
the warranty will be rendered void.
The product you buy may sometimes dier slightly from illustrations. This warranty is in addition
to, and does not aect, your statutory rights.
If you have any problems with this product, please call our Help Desk on (0845) 459 4816. The
help desk is open from 8 am until 1 pm.
TECHNICAL SPECIFICATION
Dimensions:......................................................................................................... 230×215×190 mm
Weight: ........................................................................................................................... 1.7 kg (Net)
Plug in Mains Power Supply: ............................................................................230V in 12V out 6W
Bubble Projection Distance:...............................................................................................Up to 3m
Tank Capacity:..................................................................................................................... 0.6 litres
Remote Control Battery...........................................................................1 x CR2025 (not supplied)
Eective Working Distance.................................................................................................Up to 3m
Electrovision Ltd.,
Lancots Lane, Sutton,
St. Helens, Merseyside.
WA9 3EX
website: www.electrovision.co.uk
