FXC FXC5024 User manual

FXC5024
User's Manual
naged Switch
Version 1.0 (Sep. 2005)
10/100/1000 L2 Ma

II
Table of Contents
REVISION HISTORY ----------------------------------------------------------------------------------------- IV
ABOUT THIS USER’S MANUAL----------------------------------------------------------------------------- 1
1. INTRODUCTION ----------------------------------------------------------------------------------------- 2
1-1. OVERVIEW OF GEL2-SW24 ------------------------------------------------------------------------------ 2
1-2. FEATURES --------------------------------------------------------------------------------------------------- 4
1-3. VIEW OF GEL2-SW24------------------------------------------------------------------------------------- 6
1-3-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)-------------------------------- 6
1-3-2. User Interfaces on the Rear Panel ---------------------------------------------------------------- 7
1-4. VIEW OF THE OPTIONAL MODULES ---------------------------------------------------------------------- 8
2. INSTALLATION------------------------------------------------------------------------------------------- 9
2-1. STARTING GEL2-SW24 UP------------------------------------------------------------------------------- 9
2-1-1. Hardware and Cable Installation------------------------------------------------------------------ 9
2-1-2. Installing Chassis to a 19-Inch Wiring Closet Rail---------------------------------------------11
2-1-3. Cabling Requirements------------------------------------------------------------------------------11
2-1-3-1. Cabling Requirements for TP Ports--------------------------------------------------------------------- 12
2-1-3-2. Cabling Requirements for 1000SX/LX SFP Module------------------------------------------------- 12
2-1-3-3. Switch Cascading in Topology -------------------------------------------------------------------------- 13
2-1-4. Configuring the Management Agent of GEL2-SW24-------------------------------------------16
2-1-4-1. Configuring the Management Agent of GEL2-SW24 through the Serial RS-232 Port---------- 17
2-1-4-2. Configuring the Management Agent of GEL2-SW24 through the Ethernet Port----------------- 19
2-1-5. IP Address Assignment-----------------------------------------------------------------------------20
2-2. TYPICALAPPLICATIONS ----------------------------------------------------------------------------------25
3. OPERATION OF WEB-BASED MANAGEMENT-----------------------------------------------27
3-1. WEB MANAGEMENT HOME OVERVIEW-----------------------------------------------------------------29
3-1-1. System Information---------------------------------------------------------------------------------32
3-1-2. IP Configuration------------------------------------------------------------------------------------34
3-1-3. Time Configuration---------------------------------------------------------------------------------37
3-1-4. Account Configuration-----------------------------------------------------------------------------40
3-1-5. Management Policy --------------------------------------------------------------------------------41
3-1-6. Virtual Stack-----------------------------------------------------------------------------------------44
3-2. PORT CONFIGURATION------------------------------------------------------------------------------------46
3-2-1.Port Status--------------------------------------------------------------------------------------------46
3-2-2. Port Configuration ---------------------------------------------------------------------------------51
3-2-3. Simple Counter--------------------------------------------------------------------------------------53
3-2-4. Detail Counter --------------------------------------------------------------------------------------55
3-3. MIRROR ----------------------------------------------------------------------------------------------------58
3-4. BANDWIDTH MANAGEMENT-----------------------------------------------------------------------------59
3-5. QOS(QUALITY OF SERVICE) CONFIGURATION ---------------------------------------------------------61
3-6. SNMP CONFIGURATION----------------------------------------------------------------------------------71
3-7. IGMP SNOOPING------------------------------------------------------------------------------------------73
3-8. MAX. PACKET LENGTH -----------------------------------------------------------------------------------75
3-9. DHCP BOOT-----------------------------------------------------------------------------------------------76
3-10. VLAN-----------------------------------------------------------------------------------------------------77
3-10-1. VLAN Mode----------------------------------------------------------------------------------------77
3-10-2. Tag-based Group ----------------------------------------------------------------------------------80
3-10-3. Port-based Group ---------------------------------------------------------------------------------82
3-10-4. Tag Rule --------------------------------------------------------------------------------------------84

III
3-11. MAC TABLE----------------------------------------------------------------------------------------------86
3-12. GVRP CONFIGURATION---------------------------------------------------------------------------------93
3-13. STP CONFIGURATION -----------------------------------------------------------------------------------99
3-13-1. STP Status------------------------------------------------------------------------------------------99
3-13-2. STP Configuration ------------------------------------------------------------------------------ 101
3-13-3. STP Port Configuration ------------------------------------------------------------------------ 103
3-14. TRUNKING CONFIGURATION-------------------------------------------------------------------------- 106
3-15. 802.1X CONFIGURATION------------------------------------------------------------------------------ 113
3-16. ALARM CONFIGURATION------------------------------------------------------------------------------ 123
3-17. CONFIGURATION --------------------------------------------------------------------------------------- 126
3-17-1. Save/Restore ------------------------------------------------------------------------------------- 127
3-17-2. Config File --------------------------------------------------------------------------------------- 130
3-18. DIAGNOSTICS ------------------------------------------------------------------------------------------ 131
3-19. TFTP SERVER ------------------------------------------------------------------------------------------ 134
3-20. LOG------------------------------------------------------------------------------------------------------ 135
3-21. FIRMWARE UPGRADE---------------------------------------------------------------------------------- 137
3-22. REBOOT------------------------------------------------------------------------------------------------- 138
3-23. LOGOUT------------------------------------------------------------------------------------------------- 139
4. OPERATION OF CLI MANAGEMENT ---------------------------------------------------------- 140
4-1. CLI MANAGEMENT ------------------------------------------------------------------------------------- 140
4-1-1. Login ----------------------------------------------------------------------------------------------- 140
4-2. COMMANDS OF CLI------------------------------------------------------------------------------------- 142
4-2-1. Global Commands of CLI ----------------------------------------------------------------------- 143
4-2-2. Local Commands of CLI------------------------------------------------------------------------- 149
5. MAINTENANCE------------------------------------------------------------------------------------------- 229
5-1. RESOLVING NO LINK CONDITION --------------------------------------------------------------------- 229
5-2. Q&A------------------------------------------------------------------------------------------------------ 229
APPENDIX A TECHNICAL SPECIFICATIONS ------------------------------------------------------ 230
APPENDIX B NULLMODEM CABLE SPECIFICATIONS---------------------------------------- 234

IV
Revision History
Date Revision
09/01/2005 V1.00

1
About this user’s manual
In this user’s manual, it will not only tell you how to install and connect your
network system but configure and monitor the FXC5024 (written as GEL2-SW24
instead) through the built-in CLI and web by RS-232 serial interface and Ethernet
ports step-by-step. Many explanation in detail of hardware and software functions
are shown as well as the examples of the operation for web-based interface and
command-line interface (CLI).
Overview of this user’s manual
 Chapter 1 “Introduction” describes the features of GEL2-SW24
 Chapter 2 “Installation”
 Chapter 3 “Operation of Web-based Management”
 Chapter 4 “Operation of CLI Management”
 Chapter 5 “Maintenance”

2
1. Introduction
1-1. Overview of GEL2-SW24
GEL2-SW24, a 24-port Gigabit L2 Managed Switch, is a standard switch that
meets all IEEE 802.3/u/x/z Gigabit, Fast Ethernet specifications. The switch
included 22-Port 10/100/1000Mbps TP and 2-Port Gigabit TP/SFP Fiber
management Ethernet switch. The switch can be managed through RS-232 serial
port via directly connection, or through Ethernet port using CLI or Web-based
management unit, associated with SNMP agent. With the SNMP agent, the network
administrator can logon the switch to monitor, configure and control each port’s
activity in a friendly way. The overall network management is enhanced and the
network efficiency is also improved to accommodate high bandwidth applications. In
addition, the switch features comprehensive and useful function such as QoS
(Quality of Service), Spanning Tree, VLAN, Port Trunking, Bandwidth Control, Port
Security, SNMP/RMON, IGMP Snooping capability via the intelligent software. It is
suitable for both metro-LAN and office application.
In this switch, Port 23, 24 includes two types of media --- TP and SFP Fiber
(LC, BiDi LC…); this port supports 10/100/1000Mbps TP or 1000Mbps SFP Fiber
with auto-detected function. 1000Mbps SFP Fiber transceiver is used for high-
speed connection expansion.
10/100/1000Mbps TP is a standard Ethernet port that meets all IEEE
802.3/u/x/z Gigabit, Fast Ethernet specifications. 1000Mbps SFP Fiber transceiver
is a Gigabit Ethernet port that fully complies with all IEEE 802.3z and 1000Base-
SX/LX standards.
1000Mbps Single Fiber WDM (BiDi) transceiver is designed with an optic
Wavelength Division Multiplexing (WDM) technology that transports bi-directional
full duplex signal over a single fiber simultaneously.
For upgrading firmware, please refer to the Section 3-21 or Section 4-2-2 for
more details. The switch will not stop operating while upgrading firmware and after
that, the configuration keeps unchanged.

3
• Key Features in the Device
QoS: Support Quality of Service by the IEEE 802.1P standard. There are two
priority queue and packet transmission schedule.
Spanning Tree:
Support IEEE 802.1D, IEEE 802.1w (RSTP: Rapid Spanning Tree
Protocol) standards.
VLAN:
Support Port-based VLAN and IEEE802.1Q Tag VLAN. Support 256 active
VLANs and VLAN ID 1~4094.
Port Trunking:
Support static port trunking and port trunking with IEEE 802.3ad LACP.
Bandwidth Control:
Support ingress and egress per port bandwidth control.
Port Security:
Support allowed, denied forwarding and port security with MAC address.
SNMP/RMON:
SNMP agent and RMON MIB. In the device, SNMP agent is a client
software which is operating over SNMP protocol used to receive the
command from SNMP manager (server site) and echo the corresponded
data, i.e. MIB object. Besides, SNMP agent will actively issue TRAP
information when happened.
RMON is the abbreviation of Remote Network Monitoring and is a branch of
the SNMP MIB.
The device supports MIB-2 (RFC 1213), Bridge MIB (RFC 1493), RMON
MIB (RFC 1757)-statistics Group 1,2,3,9, VLAN MIB (802.1Q, RFC2674),
Ethernet MIB (RFC 1643) and so on.
IGMP Snooping:
Support IGMP version 2 (RFC 2236): The function IGMP snooping is used
to establish the multicast groups to forward the multicast packet to the
member ports, and, in nature, avoid wasting the bandwidth while IP
multicast packets are running over the network.

4
1-2. Features
The GEL2-SW24, a standalone off-the-shelf switch, provides the
comprehensive features listed below for users to perform system network
administration and efficiently and securely serve your network.
• Hardware
• 22 10/100/1000Mbps Auto-negotiation Gigabit Ethernet TP ports
• 2 10/100/1000Mbps TP or 1000Mbps SFP Fiber dual media auto sense
• 400KB on-chip frame buffer
• Jumbo frame support
• Programmable classifier for QoS (Layer 4/Multimedia)
• 8K MAC address and 4K VLAN support (IEEE802.1Q)
• Per-port shaping, policing, and Broadcast Storm Control
• IEEE802.1Q-in-Q nested VLAN support
• Full-duplex flow control (IEEE802.3x) and half-duplex backpressure
• Extensive front-panel diagnostic LEDs; System: Power, TP Port1-24: LINK/ACT,
10/100/1000Mbps, SFP Port 23,24: SFP(LINK/ACT)
• Management
•Supports concisely the status of port and easily port configuration
•Supports per port traffic monitoring counters
• Supports a snapshot of the system Information when you login
• Supports port mirror function
• Supports the static trunk function

5
• Supports 802.1Q VLAN
• Supports user management and limits three users to login
• Maximal packet length can be up to 9216 bytes for jumbo frame application
• Supports DHCP Broadcasting Suppression to avoid network suspended or
crashed
• Supports to send the trap event while monitored events happened
•Supports default configuration which can be restored to overwrite the current
configuration which is working on via web browser and CLI
• Supports on-line plug/unplug SFP modules
• Supports Quality of Service (QoS) for real time applications based on the
information taken from Layer 2 to Layer 4, such as VoIP
• Built-in web-based management and CLI management, providing a more
convenient UI for the user
• Supports port mirror function with ingress traffic
•Supports rapid spanning tree (802.1w RSTP)
• Supports 802.1X port security on a VLAN
• Supports user management and only first login administrator can configure the
device. The rest of users can only view the switch
• SNMP access can be disabled and prevent from illegal SNMP access
• Supports Ingress, Non-unicast and Egress Bandwidth rating management with
a resolution of 1Mbps
• The trap event and alarm message can be transferred via e-mail and mobile
phone short message
• Supports diagnostics to let administrator knowing the hardware status
•Supports external loopback test to check if the link is ok
• TFTP for firmware upgrade, system log upload and config file import/export
• Supports remote boot the device through user interface and SNMP
• Supports network time synchronization and daylight saving
• Supports 120 event log records in the main memory and display on the local
console

1-3. View of GEL2-SW24
1-3-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)
There are 24 TP Gigabit Ethernet ports and 2 SFP fiber ports for optional
removable modules on the front panel of the switch. LED display area, locating on
the left side of the panel, contains a Power LED, which indicates the power status
and 24 ports working status of the switch.
Fig. 1-1 Full View of GEL2-SW24
Fig. 1-2 Front View of GEL2-SW24
Po wer Indication LED
Gi
g
abit Ethernet Port
TP Port Status Indication LEDs
RESET Button:
RESET button is used to
reset the management
system.
SFP Fiber Port
Fiber Port Status Indication LEDs
6
