G.B.C BASIC EDGE 50 User manual

BASIC EDGE 50
INSTRUCTION MANUAL
Versione 07. 2019
Range w.t. 6-60mm (5/21”- 2 3/8”)
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629

2
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
Index
Presentation of the Company and introduction to the Instruction Manual 3
Warranty General Causes 4
Intended use of the BASIC EDGE 50 5
Technical Features 6
Machine Standard Equipment 7
Safety Prescriptions 8
Machine Stability 10
Workplace 10
Emergency Stop 10
Setup 11
Controls 18
Inserts Replacement 21
Warnings and Troubleshooting 24
Installation and use of the Face Mill Speed Regulator 25
Ordinary Maintenance 30

3
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
G.B.C. Industrial Tools S.p.A. is known worldwide for the quality of its machines and acces-
sories for pipe cutting and beveling procedures of any sort and plate beveling machines..
The Headquarters are located in Cazzago San Martino (BS) where are currently operating the
General Management, the sales de-department, as well as the main workshop and the shipping
department.
QUALITY STANDARD—All our machines are assembled according to the highest quality
standard. Since 1996 G.B.C. Industrial Tool S.p.a. has implemented management procedures
in compliance with the quality system regulations UNI EN ISO 9001 (SGS ITALIA S.R.L. N°
IT 96.088 / 1996).
This Manual is supplied together with the machine it makes reference to. The customer may
apply for further copies to G.B.C. Industrial Tools S.p.A. Our company owns the copy-
right of this document and any partial or complete copy or distribution to natural persons or to
corporate bodies is strictly forbid-den unless our prior approval to do so is obtained. G.B.C.
Industrial Tools S.p.A.
informs its customers that any operation carried out on the machines which is not prescribed in
this manual entails the automatic invalidation of the warranty. G.B.C. Industrial Tools
S.p.A.
recommends to contact the Maintenance Service in Torbiato di Adro – Italy prior to proceed
with any modification on the machine.
You are invited to scrupulously adhere to the information written on the identification
tag.
For any further information you are invited to contact us at these numbers:
Tel. +39 - 030 - 7451154
Email : [e-mail]

4
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
G.B.C. guarantees the reliability of the machine and its conformity to the specifications
herewith reported. The warranty covers the machine in its whole for a time period of one
year from the shipment date (ref. Delivery Note) for any flaw not imputable to the user.
The parts subject to wear are excluded from the warranty at sole discretion of G.B.C..
In case of any operational malfunction arising during the warranty period, G.B.C And its
Maintenance Service, hereinafter called MSS, will remedy this inconvenient free of
charge , both for handwork and for eventual replaced parts, except when the malfunction
is directly or indirectly imputable to misuse or alteration. In any case the machine must
not be disassembled or altered before the shipment. The warranty is valid only when the
warranty document is duly signed by G.B.C. and by a G.B.C. official distributor connect-
ed with the MSS maintenance service.
The shipment of the defective material must be performed within 8 (eight) days from the
notification of the defect and/or the claim and/or the request of technical assistance. On
the contrary the warranty will be void. G.B.C. and MSS obligations will cover the defect
resolution, the general maintenance and the inspection of the parts subject of the claim
only. The component replacement is at G.B.C. discretion only. The shipmen to costs
from and to the MSS as well as the direct and indirect costs rising from repair of the
product are at user’s charge. Any warranty repair or extraordinary repair must be execut-
ed by G.B.C. and MSS, otherwise the warranty will be void.
Any ordinary maintenance performed by the customer/user or by any service centre non
recognized or approved by G.B.C. will not be refunded and will make the warranty void.
The warranty is not valid for cases not listed in this certificate or for damage caused by a
misuse of materials, power supply, negligence, unauthorized modifications, atmospheric
events, acts of vandalism, incautious handling and/or transport, use of non original
G.B.C. parts and damage for causes not specified by G.B.C. and for which G.B.C. de-
clines any responsibility. G.B.C. reserves the right to modify and to improve its products
without any obligation to modify equipment and components already supplied. Nobody is
authorized to modify the conditions herewith contained or to issue any on behalf of
G.B.C. The claim terms for defects and/or damages in the material or of the ordered
quantities, are those pre-scribed by the Civil Code; the goods acceptance entails the
buyer to automatically accept the above mentioned warranty clauses.

5
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
THE MACHINE SHOULD BE OPERATED ONLY BY SPECIALIZED OPERATORS WHO HAVE
BEEN DULY TRAINED ON THE UNIT.
GBC’s plate bevellers, can perform a welding
prep bevel on 90° edges. There are several
models available depending by the wall thick-
ness of the plate, usable for on-site jobs and
for workshop daily production purposes.
All machines are equipped with an automatic
feeding system, therefore once they are posi-
tioned and locked on the plate edge (models
for beveling the upside and models for bevel-
ing the down side of the plate), the beveling is
performed automatically, with no need of any
intervention by any operator. These machines
are equipped with a comfortable trolley de-
signed ad-hoc, adjustable in height and partic-
ularly useful when working large plate sheets
so that no overhead cranes or other lifting
devices has to be involved in the process.
GBC’s plate bevelers can be divided in two
typologies::
GBC CHALLENGE (12/15)
Locking Range 6-40mm wall thickness . Ad-
justable beveling angle from 22° to 55°, com-
pletely silent, milling head with toothed edge,
high speed beveling without operator inter-
vention.
BASIC EDGE 50 range w.t. 6-60mm
Adjustable Bevel angle da 0° a 90°, high
speed RPM face mill with inserts, high finish-
ing grade and increased material removal
capacity per pass.

6
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
ELECTRIC
Electric Motor Power W4000
Tension Volt 230 / 400
Frequency Hz 50 / 60
Face Mill Speed rpm 500 ÷ 2500
Face Mill Type Ø50mm - 5 inserts
Bevel Angle Da 10° a 70°
Plate Thickness mm Min. 6 - Max 60
Bevel Diagonal Length mm Min. 0 - Max 50
Travel Speed Mt/min 0 ÷ 1.8
Weight Kg 149
Acoustic Emissions dB 76

7
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
The machine is supplied with:
• Service Tools
• Face Mill with 5 inserts
• Storage Wooden Box
• Instruction Manual
• Drawings
BASIC EDGE 50 Service Tools
Instruction
Manual and Drawings
Storage Box
Face Mill

8
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
G.B.C. Industrial Tools S.p.A. designs and assembles its machines in strict compliance with
the safety regulations provided by the applicable EC directives and by the Italian laws regulat-
ing this matter.
G.B.C. Industrial Tools S.p.A. declines any responsibility for misuse of its machines and their
use when in contrast with the regulation listed hereinafter and with the use and maintenance
instructions hereto.
• Carefully read ALL the following regulations and the instructions herewith attached
before starting any operation.
• Carefully ensure that the operator and the foreman using the machine are fully aware of
all the regulations and all the instructions and that they are qualified to operate the unit.
• Strictly attain to the indications given by the international symbols applies on the ma-
chine and/or on its case.
• Do not perform any maintenance operation when the machine is plugged to the power
supply.
• Before every use, ensure the power supply connections to be conform to the specs given
by our manual.
The authorized operator in any case will not have to disregard the basic safety rules such as:
• Using gloves and goggles (safety gear supplied by the company responsible for the
site or for the building)
• To properly illuminate the working area
• Ensure you are operating in an area which grants free movements (at least 1,5 metres
around the operator)
• Do not replace the control system and do not replace parts with non original spare
parts, and do not project violent water squirts on the machine
• Keep the hands away from hot and sharpened parts.
•
• G.B.C. Industrial Tools S.p.A. remarks that for any non specified circumstances it is
necessary to obtain the authorization of the manufacturer.

9
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
Indicazioni per il trasporto
Shipment Weight kg 149
Shipping Dimensions mm
-
Shipping Weight kg 240
1. Always wear gloves and goggles during every operation
2. Any adjustment or inspection of the machine shall be done with
the unit unplugged from the power source.
3. During the operations the hands of the operator must be kept on
the handles located on the sides of the motor.
4. The Use and Maintenance Manual as well as the drawings will
always supply quick and adequate explanations.
Using properly the safety gear entails the only risks to be generated by the user’s system and not by inborn de-
fects of our machines.
The acoustic emissions are within the limits provided by Machine Directive in force. Proof of this is recorder
and stored by the production department which files all the acoustic tests performer on every single unit.

10
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
Considering the mass of the machine no particular problem has been detected in regard to
the operator safety.
The machine is equipped with an emergency stop button — See the paragraph re-
garding the controls.

11
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
Before starting any setup operation, make sure the machine is clean and that it is not connected to the main
power supply. In particular ensure to clean those areas where you will have to act to make the required
adjustments.
Remember to loosen the locking screws before
adjusting the bevel angle.
N.B. : Keep clean and lubricated the moving
parts of the head.
The angle can be adjusted by simply moving the head of the machine until the desired angle is reached.
The actual angle can be checked on the angle LCD display.
N.B.:Remove the two Transport
Locking Screws to release the
machine head from the base

12
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
Once the bevel angle is set, tighten the locking screws to secure the central body in the selected position.
To increase the pass depth, thus the length of bevel, in first place you will need to loosen the locking nut of
the DEPTH ADJUSTMENT ASSEMBLY.

13
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
- Max Speed during the plate entering phase 0.2m/min
- Max Speed during the plate exiting phase 0.2m/min
- The beveling speed with a fully engaged plate is variable
depending by the bevel angle, depth of the pass and by the
material of the plate.
Now turn the angle adjusting nut , checking the actual depth on the scale that is engraved on the central
block. In the below charts you can see some examples of beveling passes.
45° Angle
Pass Pass Depth ABL
168.49 8.49 12
2616.97 16.97 24
35.02 24.07 24.07 34.05
44.06 29.81 29.81 42.16
53.48 34.73 34.73 49.13
60.44 35.36 35.36 50
For specific settings of the Face Mill RPM, travel speed, type of materials and different angles you are invit-
ed to contact the sales department for and in-depth analysis of your application.
15° Angle
Pass Pass Depth ABL
1623.18 6.21 24
24.19 39.37 10.55 40.76
31.24 44.18 11.84 45.74

14
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
Once the pass depth is set, tighten the locking nut.
Loosen the SECURITY LEVER of the PLATE LOCKING ASSEMBLY.

15
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
The PLATE LOCKING ASSEMBLY can be opened and closed to match the plate thickness by acting on the
hand wheel.
The upper part of the machine can be raised or lowered just by pulling up or pushing down on the handles.

16
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
Adjust the
height of the
unit so that
the plate is
positioned
right between
the rubber
wheel (blue
arrow) and the
flat roller
(yellow ar-
row).
The plate to be beveled should be clean from grease and oil in order to
grant the machine an optimal grip. Any welding cap or imperfections
caused by the oxycut will have to be grinded off for because they may
interfere with the machine travel.
Act on the hand
wheel to raise the
PLATE LOCKING
ASSEMBLY until
it touches the plate
and you feel some
resistance on the
hand wheel. Make
another half turn of
the hand wheel and
tighten the orange
LOCKING LEVER
to secure the posi-
tion of the PLATE
LOCKING AS-
SEMBLY.
Move and position the machine on
the plate using the handles making
sure you are approaching the plate
with the side where the plate detect-
ing sensor is located.
S
I
N
O
While approaching the plate, make sure the wheels of the
trolley are all facing the direction of motion so that they
will not interfere with the linear travel of the unit.

17
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
N.B.
When the plate is locked ensure that it is correclty engaging the PLATE DETECTION SENSOR
otherwise the machine will not start.
Always insert the plate from the side of the sensor because the machine moves from letf to right
(view of the operator being behind the machine).
When the plate is locked in position make sure it is parallel to
the ground.

18
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
23456
If the red light is blinking the machine will not start because you need to change the phase in the power
chord.
If the red light is still the machine is in protection mode. Reset the unit by turning off and on the main
power switch .
7
123456
1 - Emergency Stop
2 - Power Presence
3 - Wrong Phase/ Inverter Alarm
4 - START / STOP Button With Plate Detection Light
5 - Face Mill and Feeding Stop
6 - Feeding Speed Regulator

19
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
Start the machine by pushing the green button as shown in the above picture.
The machine will then start working.
Once the machine is connected to the power source and it is positioned onto the plate as previously explained
the green light will turn on .

20
G.B.C. Industrial Tools S.p.A.
Via Sandro Pertini 41/43 – 25046 Cazzago San Martino (Bs) – Italia – Tel. + 39 030 7451154 – Fax. + 39 030 73 56 629
BASIC EDGE 50
Istruzioni originali—rev.2013—in accordo al 1.7.4 della direttiva macchine 2006/42/CE
In case of emergency push the EMERGENCY STOP BUTTON for an immediate stop of the machine.
Adjust the Face Mill RPM and the Feeding Speed in relation to the material and the pass depth acting of the
potentiometer pointed by the arrow.
