Owner’s Manual of Generator for
GN12000DCS
GN13000DCS
Green-Power America, LLC

1
Products Service Information
Green-Power America LLC thanks you for choosing a Green-Power America LLC product.
Please register your product within 10 days of purchase to ensure that you receive optimal
service. Always keep copy of your original receipt.
By registering your product, you are protected:
1. You have a record of the product purchase,
2. Customer Service can better serve you on warranty related issues,
3. Green Power America will be able to contact you in the unlikely event that a product
recall notification is necessary.
You can register your product in one of two ways as follows:
Option 1: Go to the Green Power America website at www.green-poweramerica.com/
service and follow the instructions to register online.
Option 2: Fill out the form on the Warranty Card included in the box, and return via
standard mail to Green Power America at 840 9th Street Suite H, Upland CA 91786. Please
note that postage is required to mail the registration form back to Green Power America.
If you still have any questions regarding the usage or operation of your generator after you
have carefully read the manual, or if you have any quality issues during operation, please
call our toll-free service number shown below:
877-834-4218

2
12000W/13000W Dual Fuel Generator
Table of Contents
Topic
Page
Warranty Policy
3
Specifications
6
Safety Guidelines
7
General Precautions
10
Battery
17
Assembly and Installation
18
Operation
21
Inspection, Cleaning, Maintenance and Storage
28
Carbon Monoxide Protecting System
34
General Parts Listing
35
WARNING! READ AND UNDERSTAND ALL SAFETY PRECAUTIONS
IN THIS MUANUAL BEFORE OPERATING. FAILURE TO COMPLY WITH
I INSTRUCTIONS IN THIS MANUAL COULD RESULT IN PERSONAL
INJURY, PROPERTY DAMAGE, AND/OR VOIDING OF YOUR
WARRANTY. GREEN-POWER AMERICA, LLC (HEREINAFTER
IN SHORT “GREEN-POWER” OR “GPA”) WILL NOT BE LIABLE
FOR ANY DAMAGE BECAUSE OF FAILURE TO FOLLOW THESE
INSTRUCTIONS.

3
Owner’s Manual
Green-Power America (GPA) Version 2020-1 1st Revise
WARRANTY POLICY -- GENERATOR
Green-Power America, LLC (GPA)
Two(2)-YEAR LIMITED WARRANTY or One(1)-YEAR LIMITED WARRANTY
Green-Power America, LLC (GPA) provides Two(2)-Year or One(1)-Year (GPD1500 and
GN1750D) limited factory warranty once consumers buy the generator from GPA or any of
GPA partners in the United Sates.
1, Warranty Qualifications
Green-Power America, LLC (GPA) will register this warranty upon receipt of your Warranty Registration Card /
Warranty Registration on Web and a copy of your sales receipt from one of GPA's retail locations as proof of
purchase. GPA strongly recommend consumer keeps the purchasing receipt as a proof.
Please submit your warranty registration and your proof of purchase within ten (10) days of the date of purchase.
2, Clarification of Two(2)-Year Limited Warranty or One(1)-Year Limited Warranty
✓Two(2)-Year Limited Warranty: For household use, from the original date of purchase, the warranty is
clocked and the parts and repairing labor will be free in the 1st year, and parts only will be free in the 2nd
year.
If the product is used for commercial or industrial purpose, including but not limited to be used in commercial
or industrial site, rental and any other types of income earning, the original Two(2)-Year Warranty will be
expired and becomes Ninety(90) days instead, the parts will be free during this period.
✓One(1)-Year Limited Warranty (Apply to GPD1500, GN1750D): For household use only, from the original
date of purchase, the warranty is clocked and the parts will be free in the 1st year.
If the product is used for commercial or industrial purpose, including but not limited to be used in commercial
or industrial site, rental and any other types of income earning, the original One(1)-Year Warranty will be
expired and becomes Thirty(30) days instead, the parts will be free during this period.
✓GPA will provide all parts for replacement in whole lifetime of the product, material cost and
transportation cost will apply if it is beyond of warranty period or not covered by the warranty policy.
3, Repair/Replacement Warranty
GPA warrants to the original purchaser that the mechanical and electrical components will be free of defects in
material and workmanship for a period of the 1st year from the original date of purchase for Two(2)-Year Warranty
items household use. Parts are always free during warranty period. Transportation charges for the unit repair or
replacement under this warranty will be sole responsibility of the consumer. This warranty only applies to the
original purchaser only and is not transferable.
Contact GPA's Service Center and GPA will troubleshoot any issue via phone (Toll-Free: 877-834-4218) or e-mail
([e-mail] ). If the issue is not fixed, GPA will, at its option, authorize evaluation, repair
or replacement of the defective parts or components at a GPA Service Center. GPA will provide you with a case
number

4
12000W/13000W Dual Fuel Generator
for warranty service. Please keep it for future reference. Repairs or replacements without prior authorization, or at
an unauthorized repair facility, will not be covered by this warranty.
4, Return Policy and Procedure
✓Defective Return
If the defective unit can not be repaired by the authorized repair center and the unit was within one (1) year,
GPA will make a decision, on GPA sole options, either replace it with an equivalent or return it to GPA and consumer
will get refund. The refund amount will be determined by the used time as below:
- Within thirty (30) days from the original purchasing date, full amount will be refunded.
- For Two(2)-Year Warranty items household use only, from thirty-one (31 days) but within one (1) year from the
original purchasing date, the refund proportion will be determined by 100% minuses its actual using months divided
by twelve (12).
Formula: Refund Proportion = 100%-number of used month/12*100%
✓Remorse Return
If consumer wants to return due to consumer’s mind changing or any other non-quality reason, which is called
Remorse Return, and the unit is in its original packing condition or consumer opened the original package but
never fill the fuel and/or oil into the unit, and the unit could be repacked properly, within thirty (30) days from the
original purchasing date, GPA will provide a Return Goods Authorization number (RGA #) to the retailer to accept
the return for refund. Consumer will pay the return freight and 15% of the retail price (excluding tax) for re-stock
fee. The consumer should contact the retailer with GPA’s RGA# and will get remaining amount refunded after the
return is received by GPA. The return address will be noted by GPA when the RGA# is provided.
Attention please:
Do Not Return The Unit To The Place Of Purchase even unless the retailer / distributor has a certain agreement
with GPA in written.
All refund will be issued in terms of Credit Memo (CM) to the retailer/distributor, and the consumer will get
refund from the original store.
5, Warranty Exclusions
This warranty does not cover the following repairs and equipment:
✓Normal Wear and Tear
Products with mechanical and electrical components need periodic parts and service to perform well, including but
not limited, filter elements, o-rings, spark plug, rubber mounts, etc. This warranty does not cover repair when
normal use has exhausted the life of a part or the equipment as a whole.
✓Installation, Use and Maintenance
--This warranty will not apply to parts and/or any labor of installation.
--This warranty will not apply to parts and/or any labor if the product is deemed to have been misused, neglected,
involved in an accident, abused, loaded beyond the product's limits, modified, installed improperly or connected
incorrectly to any electrical component.
--Normal maintenance is not covered by this warranty and is not required to be performed at a facility or by a person
authorized by GPA.
* Except as otherwise stipulated in any of the following enclosed Emission Control System Warranties

5
Owner’s Manual
(if applicable) for the Emission Control System: U.S. Environment Protection Agency (EPA), California Air
Resources Board (CARB) and/or Environment Canada (EC).
✓Other Exclusions
This warranty excludes:
–Cosmetic defects such as paint, decals, etc.
–Accessory parts such as starting batteries, tools and storage covers.
–Failures due to acts of God and other force majeure events which beyond the manufacturer's control.
–Problems caused by parts that are not original Green-Power America (GPA) parts.
When applicable, this warranty does not apply to products used for prime power in place of a utility.
6, Limits of Implied Warranty and Consequential Damage
Green-Power America (GPA) disclaims any obligation to cover any loss of time, freight, or any incidental or
consequential claim by anyone due to using this generator. THIS WARRANTY AND THE ATTACHED U.S.
EPA, CARB and/or EC EMISSION CONTROL SYSTEM WARRANTIES (IF APPLICABLE) ARE IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
A unit provided as a replacement will be subject to the warranty of the original unit. The length of the warranty
governing the exchanged unit will remain calculated by reference to the purchase date of the original unit.
This warranty gives you certain legal rights which may change from State to State. Your State
may also have other rights you may be entitled to that are not listed within this warranty.
Contact Information
www.green-poweramerica.com
Customer Service
Mon – Fri 8:00 AM – 5:00 PM (EST)
Toll Free: 1-877-834-4218
Service Email: [e-mail]

6
12000W/13000W Dual Fuel Generator
Specifications
AC electrical
GN12000DCS
GN13000DCS
Voltage/Frequency
120/240V 60HZ
Running Watts
Gasoline/Propane
9,500/8,550
10,500/9,550
Starting Watts
Gasoline/Propane
12,000/10,750
13,000/11,750
Outlet
Two 120V 20A NEMA 5-20
One 120V/240V 50A NEMA 14-50R
One 120V/240V 30A NEMA L14-30R
DC electrical
Outlet
[email protected]
Gasoline engine
Type
4-cycle OHV air-cooled recoil start
Displacement
479cc
Oil capacity
1.2L(40.6oz/1.27qt)
EPA approved
yes
Fuel
Type
Gasoline 87+/Propane
Capacity
(Gas/Recommended
Propane Tank)
6.6 gallons/20lbs
Running time
(hours(approx.) on
1/2 load)
8/5.5 7.5/5.2
Weight
Approximate
weight
212lbs
214lbs

7
Owner’s Manual
Safety Guidelines – Definitions
This manual contains important information that you need to know and
understand in order to protect YOUR SAFETY and to PREVENT
EQUIPMENT PROBLEMS. The following symbols help you recognize this
information. Please read the manual and pay attention to these sections.
Save These Important Safety Instructions!
Read and understand all of these safety instructions. Be
sure to retain them for future use.
WARNING! WARNINGS INDICATE A CERTAINTY OR STRONG
POSSIBILITY OF PERSONAL INJURY OR DEATH IF
INSTRUCTIONS ARE NOT FOLLOWED.
CAUTION: CAUTIONS INDICATE A POSSIBILITY OF
EQUIPMENT DAMAGE IF INSTRUCTIONS ARE NOT
FOLLOWED.
NOTE: NOTES GIVE HELPFUL INFORMATION
WARNING! IMPROPER OPERATION OR MAINTENANCE
OF THIS PRODUCT COULD RESULT IN SERIOUS INJURY
AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL
WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING
THIS EQUIPMENT. WHEN USING AIR TOOLS, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE
THE RISK OF PERSONAL INJURY

8
12000W/13000W Dual Fuel Generator
General Precautions
WARNING! FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN SEVERE INJURY
OR DEATH.
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS CAN ALSO RESULT IN DAMAGE
TO THE TOOL AND/OR THE ITEM YOU ARE WORKING ON.
DANGER
CARBON MONOXIDE
Using a generator indoors WILL KILL YOU IN MINUTES.
This generator is equipped with CO-Seizer™ Carbon Monoxide protecting system which will help
to protect you in safe. Even so, we still strongly suggest you read the warning contents below to
make sure your safety.
Generator exhaust contains high levels of carbon monoxide (CO), a poisonous gas you cannot see
or smell. If you can smell the generator exhaust, you are breathing CO. But even If you cannot
smell the exhaust, you could be breathing CO.
· NEVER use a generator inside homes, garages, crawlspaces, or other partly enclosed areas.
Deadly levels of carbon monoxide can build up in these areas. Using a fan or opening windows
and doors does NOT supply enough fresh air.
· ONLY use a generator outdoors and far away from open windows, doors, and vents. These
openings can pull in generator exhaust.
Even when you use a generator correctly, CO may leak into the home. ALWAYS use a battery-
powered or battery-backup CO alarm in the home.
If you start to feel sick, dizzy, or weak after the generator has been running, move to fresh air
RIGHT AWAY. See a doctor. You could have carbon monoxide poisoning.
WARNING! THE EXHAUST CONTAINS POISONOUS CARBON MONOXIDE GAS THAT
CAN CAUSE LOSS OF CONSCIOUSNESS AND MAY LEAD TO DEATH.
Gasoline and Oil
This product requires oil and fuel. Attempting to start the engine without oil will ruin
the engine and void the warranty. Work in well ventilated area. Keep cigarettes,
flames or sparks away from the work area or where gasoline is stored.
WARNING! GASOLINE IS EXTREMELY FLAMMABLE AND IS EXPLOSIVE UNDER
CERTAIN CONDITIONS. KEEP OUT OF REACH OF CHILDREN.
• Gasoline fuel and fumes are flammable and potentially explosive. Use proper fuel storage and

9
handling procedures. Always have multiple ABC class fire extinguishers nearby.
• Keep the generator and surrounding area clean at all times.
Owner’s Manual
General Precautions (cont’d)
Gasoline and Oil (cont’d)
• Fuel or oil spills must be cleaned up immediately. Dispose of fluids and cleaning materials as per
any local, state, or federal codes and regulations. Store oily rags in a covered metal container.
• Never store fuel or other flammable materials near the generator.
• Do not smoke, or allow sparks, flames or other sources of ignition around the engine and fuel tank.
Fuel vapors are explosive.
• Keep grounded conductive objects, such as tools, away from exposed, live electrical parts and
connections to avoid sparking or arcing. These events could ignite fumes or vapors.
• Do not refill the fuel tank while the engine is running or while the engine is still hot. Do not operate
the generator with known leaks in the fuel system.
• Excessive buildup of unburned fuel gases in the exhaust system can create a potentially explosive
condition. This buildup can occur after repeated failed start attempts, valve testing, or hot engine
shutdown. If this occurs, open exhaust system drain plugs, if equipped, and allow the gases to
dissipate before attempting to restart the generator.
• Use only engine manufacturer recommended fuel and oil.
Fuel: Oil:
Fuel capacity is 6.6 US gallons (25 L). Use regular Oil capacity is 1.33 qt (1.2 L)
unleaded gasoline with a minimum octane rating of 87+.
Hot Components
WARNING! ENGINE AND EXHAUST SYSTEM PARTS BECOME VERY
HOT AND REMAIN HOT FOR SOME TIME AFTER THE ENGINE IS RUN. WEAR
INSULATED GLOVES OR WAIT UNTIL THE ENGINE AND EXHAUST SYSTEM
HAVE COOLED BEFORE HANDLING THESE PARTS.
Power Output
This generator is not designed to power sensitive electronic equipment (including computers and
medical devices) without the addition of an approved line conditioner, which is sold separately.
CAUTION: ATTEMPTING TO POWER SENSITIVE ELECTRONIC EQUIPMENT
WITHOUT THE USE OF AN APPROVED LINE CONDITIONER MAY CAUSE
DAMAGE TO THE EQUIPMENT. GREEN-POWER LLC IS NOT RESPONSIBLE

10
FOR ANY DIRECT OR INDIRECT DAMAGE CAUSED BY FAILURE TO USE AN
APPROVED LINE CONDITIONER.
12000W/13000W Dual Fuel Generator
General Precautions (cont’d)
Work Area
• Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids,
gases, or dust. Generators create sparks which may ignite the dust or fumes.
• Keep bystanders, children, and visitors away while operating a generator. Provide barriers or
shields as needed.
Electrical Safety
• Grounded tools must be plugged into an outlet properly installed and
grounded in accordance with all codes and ordinances. Never remove the
grounding prong or modify the plug in any way. Do not use any adapter
plugs.
• Grounding provides a low-resistance path to carry electricity away from the
user in the event of an electrical malfunction.
• Double insulated tools are equipped with a polarized plug where one blade is wider than the other.
This plug fits in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a qualified electrician to install a polarized outlet. Do not
change the plug in any way. Double insulation eliminates the need for the three-wire grounded
power cord and grounded power supply system.
• Avoid body contact with grounded surfaces such as pipes, radiators, ranges, and refrigerators.
There is an increased risk of electric shock if your body is grounded.
• Do not expose generator to rain or wet conditions. Water entering a generator will increase the
risk of electric shock.
• Do not abuse the power cord. Keep power cords away from heat, oil, sharp edges, or moving parts.
Replace damaged power cords immediately. Damaged power cords increase the risk of electric
shock.
• When operating a power tool outside, use an outdoor extension cord marked “W-A” or “W”. These
extension cords are rated for outdoor use, and reduce the risk of electric shock.

11
Owner’s Manual
General Precautions (cont’d)
Electrical Safety (cont’d)
• All connections and conduits from the generator to the load must only be installed by trained and
licensed electricians, and in compliance with all relevant local, state, and federal electrical codes
and standards, and other regulations where applicable.
• The generator must be earth-grounded for fixed installations in accordance with all relevant
electrical codes and standards before operation.
• Do not attempt to connect or disconnect load connections while standing in water, or on wet or
soggy ground.
• Do not touch electrically energized parts of the generator and interconnecting cables or conductors
with any part of the body, or with any non-insulated conductive object.
• Connect the generator only to a load or electrical system (120 volt) that is compatible with the
electrical characteristics and rated capacities of the generator.
• Before servicing equipment powered by the generator, disconnect the equipment from its power
input.
• Keep all electrical equipment clean and dry. Replace any wiring where the insulation is cracked,
cut abraded or otherwise degraded. Replace terminals that are worn, discolored, or corroded.
Keep terminals clean and tight.
• Insulate all connections and disconnected wires.
• Guard against electric shock. Prevent body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerator enclosures.
Personal Safety
• Stay alert. Watch what you are doing, and use common sense when operating a generator. Do not
use generator while tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating generators may result in serious personal injury.
• Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving
parts.

12
12000W/13000W Dual Fuel Generator
General Precautions (cont’d)
Personal Safety (cont’d)
• Avoid accidental starting. Make sure the power switch is in its “OFF” position, and disconnect the
spark plug wire when not in use.
• Remove adjusting keys or wrenches before turning the generator on. A wrench or a key that is left
attached to a rotating part of the generator may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times.
• Use safety equipment. Always wear eye protection. Wear ANSI approved safety impact eye goggles.
Dust mask, non-skid safety shoes, hard hat, or hearing protection must be used for appropriate
conditions.
• Do not force the generator. Use the correct generator for your application. The correct generator
will do the job better and safer at the rate for which it is designed.
• Do not use the generator if the power switch does not turn it on or off. Any generator that cannot
be controlled with the power switch is dangerous and must be replaced.
Generator Use and Care
Make sure the power switch is in its “OFF” position and disconnect the spark plug wire before making
any adjustment, changing accessories, or storing the generator. Such preventive safety measures
reduce the risk of starting the generator accidentally.
Store idle generators out of reach of children and other untrained persons. Generators are
dangerous in the hands of untrained users.
Maintain generators with care. Do not use damaged generator. Tag damaged generators “Do not use”
until repaired.
Check for misalignment or binding of moving parts, breakage of parts, and any other condition that
may affect the generator’s operation. If damaged, have the generator serviced before using. Many
accidents are caused by poorly maintained generators.
Use only accessories that are recommended by the manufacturer for your model. Accessories that
may be suitable for one generator may become hazardous when used on another generator.

13
Owner’s Manual
General Precautions (cont’d)
Servicing
Maintain labels and name plates on the generator and engine. These carry important information.
If unreadable or missing, contact our service center toll free immediately for a replacement.
Generator service must be performed only qualified repair personnel. Service or maintenance
performed by unqualified personnel could result in a risk of injury.
When servicing a generator, use only identical replacement parts. Follow all appropriate instructions
in this manual. Use of unauthorized parts or failure to follow maintenance instructions may create a
risk of electric shock or injury.
Heart Pacemakers
WARNING! PEOPLE WITH PACEMAKERS SHOULD CONSULT THEIR
PHYSICIAN(S) BEFORE USING THIS PRODUCT. ELECTROMAGNETIC
FIELDS IN CLOSE PROXIMITY TO A HEART PACEMAKER COULD CAUSE
INTERFERENCE TO OR FAILURE OF THE PACEMAKER.
Installation
• If a transfer switch is installed, ensure installation meets all applicable safety, and local and national
electrical codes. Have installation performed by a qualified, licensed electrician and building
contractor.
• All electrical work, including the earth-ground connection, should be completed by a licensed
electrician.
• Any separate fuel storage or generator supply facility must be built or installed in full compliance
with all relevant local, state, and federal regulations.

14
12000W/13000W Dual Fuel Generator
General Precautions (cont’d)
Installation (cont’d)
• If the generator is installed outdoors, it must be weatherproofed and should be soundproofed. It
should not be run outdoors without protection to the generator and wiring conduit.
• The generator might weigh over 100 lbs. Two or more people should assist when moving or lifting
this product. Never lift the generator using the engine or alternator lifting lugs. Connect lifting
equipment to the frame of the generator.
• Before lifting the generator, ensure the lift rigging and supporting structure are in good condition,
and are rated to lift such a load.
• Keep all personnel away from the suspended generator during relocating.
• The supporting floor/ground surface should be level and strong enough to safely hold the weight
of the generator. If the floor/grounded surface is not level, strong cross members should be placed
under the full length of the generator frame at its low side.
• For trailer installation, the generator should be mounted on the center point of the trailer, over
the wheels. The trailer must be capable of supporting the weight of the generator and all contents
(tools, etc.)
• Install sound-and weather-proofing only when it is not raining or snowing to avoid trapping
moisture within the generator’s area.
Mechanical
• Always make sure the power switch is in its “OFF” position. Disconnect the spark plug wire, and
allow the engine to completely cool before carrying out maintenance.
• Check for damaged parts. Before using the generator, any part that appears damaged should be
carefully checked to determine that it will operate properly and perform its intended function.
Check for alignment and binding of moving parts, any broken parts or mounting fixtures, and any
other condition that may affect proper operation technician.
• The generator is designed with guards for protection from moving parts. In any case, care must
still be taken to protect personnel and equipment from other mechanical hazards when working
around the generator.

15
Owner’s Manual
General Precautions (cont’d)
Mechanical (cont’d)
• Do not operate the generator with safety guards removed. While the generator is running, do not
attempt to reach around the safety guard for maintenance or any other reason.
• Keep hands, arms, long hair, loose clothing, and jewelry away from moving parts. Be aware that
when engine parts are moving fast they cannot be seen clearly.
• Keep access doors on enclosures closed and locked when access is not required.
• When working on or around the generator always wear protective clothing including ANSI
approved safety gloves, safety eye goggles, and safety hat.
• Do not alter or adjust any part of the generator that is assembled and supplied by the manufacturer.
• Always follow and complete scheduled engine and generator maintenance.
Chemicals
• Avoid contact with hot fuel, oil, exhaust fumes, and hot solid surfaces.
• Avoid body contact with fuels, oils, and lubricants used in the generator. If swallowed, seek medical
treatment immediately. Do not induce vomiting if fuel is swallowed. For skin contact, immediately
wash with soap and water. For eye contact, immediately flush eyes with clean water and seek
medical attention.
Noise
• Prolonged exposure to noise levels above 68 DBA is hazardous to hearing. Always wear ANSI
approved ear protection when operating or working around the generator when it is running.

16
12000W/13000W Dual Fuel Generator
General Precautions (cont’d)
Extension Cord
If an extension cord (not included) is used, make sure to use only UL approved cords having the
correct gauge and length according to the following table:
Nameplate Amps (@ full load) Cord Lengths
0 ft.- 50 ft.
50 ft.-100 ft.
100 ft.-150 ft.
150 ft.-200 ft.
0 - 5
16 AWG
16 AWG
12 AWG
12 AWG
5.1 - 8
16 AWG
14 AWG
10 AWG
-
8.1 - 12
14 AWG
12 AWG
-
-
12.1 - 15
12 AWG
10 AWG
-
-
15 - 20
10 AWG
10 AWG
-
-

17
Owner’s Manual
Battery
The generator is equipped with electric start system, you need to install the battery properly, when
you replace the battery, The regular battery should be with following specifications: Voltage
12V.lead-acid battery with 17AH, or 12V Li-battery with 1.6AH respectively.
Caution: Connecting or touching the Battery’s positive electrode and negative
electrode directly may cause battery burning and cause damage to the equipment
or even more serious accident!

18
12000W/13000W Dual Fuel Generator
Assembly and Installation
Unpacking
1. Remove the generator and loose parts box from the carton.
2. Compare the Hardware Kit included with the inventory list below.
Loose Parts (Wheel kit and handle)
Check all loose parts against the following list. Contact your dealer toll free at 877.834.4218, if
any of the parts listed below is/are not found.
Hardware Check:
Your wheel should include:
1) Two Handles with bolts, R pin
2) Two axle shaft with washers and pins
3) One generator leg with bolts and nuts
4) Two wheels
Install the Handles
a. Install the handle through the frame and assure two holes are
alignment (Fig 1)
b. Install the pan head pin through the handle and frame (Fig 2)
c. Install R pin through pan head pin to lock it in place (Fig 3)
Install Feet to Frame
a. Place the mounting feet at the bottom of frame and
assure that four holes are alignment , and then Install the
mounting feet to the frame using four bolts and nuts (Fig 4)
Install Wheels
1. Install the axle pin (the long end) through the wheel (Fig 5)
2. Install the big washer outside the wheel(Fig 6)
3. Insert the cotter pin through the washer and wheel (Fig 7)
4. Install the wheel with axle pin through the axle bracket on the frame(Fig
8)
5. Install the hairpin cotter through the axle pin to lock it in place (Fig 9)

19
Owner’s Manual
Installation
NOTE: PRIOR TO POWERING TOOLS AND EQUIPMENT MAKE SURE THE
GENERATOR’S RATED VOLTAGE, WATTAGE AND AMPERAGE CAPACITY IS
ADEQUATE TO SUPPLY ALL ELECTRICAL LOADS THAT THE UNIT WILL
POWER. IF POWERING EXCEEDS THE GENERATOR’S CAPACITY, IT MAY BE
NECESSARY TO GROUP ONE OR MORE OF THE TOOLS AND/OR EQUIPMENT
FOR CONNECTION TO A SEPARATE GENERATOR.
Electrical and other permits may be required for the installation of emergency power systems.
Investigate your local building and electrical codes before installing this unit. Installation must be
completed by licensed contractors.
WARNING! THE GENERATOR WEIGHS APPROXIMATELY OVER 100 POUNDS.
USE CARE AND THE PROPER LIFTING OR HOISTING EQUIPMENT WHEN
MOVING IT TO THE INSTALLATION LOCATION. ALWAYS CONNECT HOIST
LINES TO THE FRAME OF THE GENERATOR.
General Location
• Make sure to locate and install the generator outdoors where cooling air is readily available.
• Install the generator so that the air inlets and outlets are not blocked by obstructions such as
bushes, trees, or snow drifts. Locating it in the path of heavy winds or snowdrifts may require the
placement of a barrier for protection. In normal weather conditions, the air vent should face the
prevailing wind direction.
• Install the generator on a concrete slab or other area where rain drainage or flood waters can not
reach it.
• Generator placement should allow four feet of access to all sides for maintenance.
• Place the generator as close as possible to the electrical tools and equipment being powered to
reduce the length of extension cords.
Battery Connection
Connect the wires to the electrical motor positive electrode and battery positive electrode,
electrical motor negative and battery negative electrode respectively.
During connection, DO NOT touch battery’s positive electrode and negative electrode directly.
