G-Power America GN5250DCS User manual

Green-Power America, LLC
We Power Your World!
Owner’s Manual of Generator for
GN5250DCS

Owner’s Manual
1
Products Service Information
Green-Power America LLC thanks you for choosing a Green-Power America LLC product.
Please register your product within 10 days of purchase to ensure that you receive optimal service.
Always keep copy of your original receipt.
By registering your product, you are protected:
1. You have a record of the product purchase,
2. Customer Service can better serve you on warranty related issues,
3. Green Power America will be able to contact you in the unlikely event that a product
recall notification is necessary.
You can register your product in one of two ways as follows:
Option 1: Go to the Green Power America website at www.green-poweramerica.com/
service and follow the instructions to register online.
Option 2: Fill out the form on the Warranty Card included in the box, and return via standard
mail to Green Power America at 840 9th Street Suite H, Upland CA 91786.
Please note that postage is required to mail the registration form back to Green Power America.
If you still have any questions regarding the usage or operation of your generator after you have
carefully read the manual, or if you have any quality issues during operation, please call our
toll-free service number shown below:
877-834-4218

5250W Dual Fuel Generator
2
Table of Contents
Topic
Page
Limited Warranty
3
Specifications
6
Safety Guidelines
7
General Precautions
8
Assembly and Installation
17
Operation
20
Inspection, Cleaning, Maintenance and Storage
25
Carbon Monoxide Shut Off 30
General Parts Listing
31
WARNING! READ AND UNDERSTAND ALL SAFETY PRECAUTIONS
IN THIS MUANUAL BEFORE OPERATING. FAILURE TO COMPLY WITH
INSTRUCTIONS IN THIS MANUAL COULD RESULT IN PERSONAL
INJURY, PROPERTY DAMAGE, AND/OR VOIDING OF YOUR
WARRANTY. GREEN-POWER AMERICA, LLC (HEREINAFTER
IN SHORT “GREEN-POWER” OR “GPA”) WILL NOT BE LIABLE
FOR ANY DAMAGE BECAUSE OF FAILURE TO FOLLOW THESE
INSTRUCTIONS.

Owner’s Manual
3
Limited Warranty
WARRANTY POLICY -- GENERATOR
Two(2)-YEAR LIMITED WARRANTY or One(1)-YEAR LIMITED WARRANTY
Green-Power America, LLC (GPA) provides Two(2)-Year or One(1)-Year (GPD1500 and
GN1750D) limited factory warranty once consumers buy the generator from GPA or any of GPA
partners in the United Sates.
1, Warranty Qualifications
Green-Power America, LLC (GPA) will register this warranty upon receipt of your Warranty Registration Card /
Warranty Registration on Web and a copy of your sales receipt from one of GPA's retail locations as proof of
purchase. GPA strongly recommend consumer keeps the purchasing receipt as a proof.
Please submit your warranty registration and your proof of purchase within ten (10) days of the date of
purchase.
2, Clarification of Two(2)-Year Limited Warranty or One(1)-Year Limited Warranty
Two(2)-Year Limited Warranty: For household use, from the original date of purchase, the warranty is
clocked and the parts and repairing labor will be free in the 1st year, and parts only will be free in the 2nd
year.
If the product is used for commercial or industrial purpose, including but not limited to be used in
commercial or industrial site, rental and any other types of income earning, the original Two(2)-Year
Warranty will be expired and becomes Ninety(90) days instead, the parts will be free during this period.
One(1)-Year Limited Warranty (Apply to GPD1500, GN1750D): For household use only, from the original
date of purchase, the warranty is clocked and the parts will be free in the 1st year.
If the product is used for commercial or industrial purpose, including but not limited to be used in
commercial or industrial site, rental and any other types of income earning, the original One(1)-Year
Warranty will be expired and becomes Thirty(30) days instead, the parts will be free during this period.
GPA will provide all parts for replacement in whole lifetime of the product, material cost and
transportation cost will apply if it is beyond of warranty period or not covered by the warranty policy.
3, Repair/Replacement Warranty
GPA warrants to the original purchaser that the mechanical and electrical components will be free of defects
in material and workmanship for a period of the 1st year from the original date of purchase for Two(2)-Year
Warranty items household use. Parts are always free during warranty period. Transportation charges for the
unit repair or replacement under this warranty will be sole responsibility of the consumer. This warranty only
applies to the original purchaser only and is not transferable.

5250W Dual Fuel Generator
4
Limited Warranty
Contact GPA's Service Center and GPA will troubleshoot any issue via phone (Toll-Free: 877-834-4218) or
e-mail ([e-mail] ). If the issue is not fixed, GPA will, at its option, authorize
evaluation, repair or replacement of the defective parts or components at a GPA Service Center. GPA will
provide you with a case number.
for warranty service. Please keep it for future reference. Repairs or replacements without prior authorization,
or at an unauthorized repair facility, will not be covered by this warranty.
4, Return Policy and Procedure
Defective Return
If the defective unit can not be repaired by the authorized repair center and the unit was within one (1)
year, GPA will make a decision, on GPA sole options, either replace it with an equivalent or return it to GPA and
consumer will get refund. The refund amount will be determined by the used time as below:
- Within thirty (30) days from the original purchasing date, full amount will be refunded.
- For Two(2)-Year Warranty items household use only, from thirty-one (31 days) but within one (1) year
from the original purchasing date, the refund proportion will be determined by 100% minuses its actual using
months divided by twelve (12).
Formula: Refund Proportion = 100%-number of used month/12*100%
Remorse Return
If consumer wants to return due to consumer’s mind changing or any other non-quality reason, which is called
Remorse Return, and the unit is in its original packing condition or consumer opened the original package but
never fill the fuel and/or oil into the unit, and the unit could be repacked properly, within thirty (30) days from
the original purchasing date, GPA will provide a Return Goods Authorization number (RGA #) to the retailer to
accept the return for refund. Consumer will pay the return freight and 15% of the retail price (excluding tax)
for re-stock fee. The consumer should contact the retailer with GPA’s RGA# and will get remaining amount
refunded after the return is received by GPA. The return address will be noted by GPA when the RGA# is
provided.
Attention please:
Do Not Return The Unit To The Place Of Purchase even unless the retailer / distributor has a certain
agreement with GPA in written.
All refund will be issued in terms of Credit Memo (CM) to the retailer/distributor, and the consumer will get
refund from the original store.
5, Warranty Exclusions
This warranty does not cover the following repairs and equipment:
Normal Wear and Tear
Products with mechanical and electrical components need periodic parts and service to perform well,
including but not limited, filter elements, o-rings, spark plug, rubber mounts, etc. This warranty does not
cover repair when normal use has exhausted the life of a part or the equipment as a whole.
Installation, Use and Maintenance

Owner’s Manual
5
Limited Warranty
--This warranty will not apply to parts and/or any labor of installation.
--This warranty will not apply to parts and/or any labor if the product is deemed to have been misused,
neglected, involved in an accident, abused, loaded beyond the product's limits, modified, installed improperly
or connected incorrectly to any electrical component.
--Normal maintenance is not covered by this warranty and is not required to be performed at a facility or by a
person authorized by GPA.
* Except as otherwise stipulated in any of the following enclosed Emission Control System Warranties
(if applicable) for the Emission Control System: U.S. Environment Protection Agency (EPA), California Air
Resources Board (CARB) and/or Environment Canada (EC).
Other Exclusions
This warranty excludes:
–Cosmetic defects such as paint, decals, etc.
–Accessory parts such as starting batteries, tools and storage covers.
–Failures due to acts of God and other force majeure events which beyond the manufacturer's control.
–Problems caused by parts that are not original Green-Power America (GPA) parts.
When applicable, this warranty does not apply to products used for prime power in place of a utility.
6, Limits of Implied Warranty and Consequential Damage
Green-Power America (GPA) disclaims any obligation to cover any loss of time, freight, or any incidental or
consequential claim by anyone due to using this generator. THIS WARRANTY AND THE ATTACHED U.S. EPA,
CARB and/or EC EMISSION CONTROL SYSTEM WARRANTIES (IF APPLICABLE) ARE IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
A unit provided as a replacement will be subject to the warranty of the original unit. The length of the
warranty governing the exchanged unit will remain calculated by reference to the purchase date of the
original unit.
This warranty gives you certain legal rights which may change from State to State. Your State may also have
other rights you may be entitled to that are not listed within this warranty.
Contact Information
www.green-poweramerica.com
Customer Service
Mon – Fri 8:00 AM – 5:00 PM (EST)
Toll Free: 1-877-834-4218
Service Email: [email protected]

5250W Dual Fuel Generator
6
Specifications
AC electrical
Current Output
16A
Running Watts
4250W(GAS)/3800(Propane)
Starting Watts
5250W(GAS)/4750(Propane)
Outlet
Two 120V 20A NEMA 5-20 Receptacle
one 120V/240V 30A NEMA L14-30R Receptacle
DC electrical
Outlet
[email protected]
Gasoline engine
Type
4-cycle OHV air-cooled recoil start
Displacement
223cc
Oil capacity
20.3floz(0.6L)
EPA approved
yes
Fuel
Type
Unleaded gasoline
Capacity
4 gallons
Running time
11.5 hours (approx.) on 1/2 load
Weight
Approximate weight
115lbs.

Owner’s Manual
7
Safety Guidelines – Definitions
This manual contains important information that you need to know and
understand in order to protect YOUR SAFETY and to PREVENT
EQUIPMENT PROBLEMS. The following symbols help you recognize this
information. Please read the manual and pay attention to these
sections.
Save These Important Safety Instructions!
Read and understand all of these safety instructions. Be
sure to retain them for future use.
WARNING! WARNINGS INDICATE A CERTAINTY OR STRONG
POSSIBILITY OF PERSONAL INJURY OR DEATH IF
INSTRUCTIONS ARE NOT FOLLOWED.
CAUTION: CAUTIONS INDICATE A POSSIBILITY OF
EQUIPMENT DAMAGE IF INSTRUCTIONS ARE NOT
FOLLOWED.
NOTE: NOTES GIVE HELPFUL INFORMATION
WARNING! IMPROPER OPERATION OR MAINTENANCE
OF THIS PRODUCT COULD RESULT IN SERIOUS INJURY
AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL
WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING
THIS EQUIPMENT. WHEN USING AIR TOOLS, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE
THE RISK OF PERSONAL INJURY

5250W Dual Fuel Generator
8
General Precautions
WARNING! FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN SEVERE INJURY
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS CAN ALSO RESULT IN DAMAGE
TO THE TOOL AND/OR THE ITEM YOU ARE WORKING ON.
DANGER
CARBON MONOXIDE
Using a generator indoors WILL KILL YOU IN MINUTES.
This generator is equipped with CO-Seizer™ Carbon Monoxide protecting system which will help to protect
you in safe. Even so, we still strongly suggest you read the warning contents below to make sure your
safety.
Generator exhaust contains high levels of carbon monoxide (CO), a poisonous gas you cannot see or smell.
If you can smell the generator exhaust, you are breathing CO. But even If you cannot smell the exhaust, you
could be breathing CO.
· NEVER use a generator inside homes, garages, crawlspaces, or other partly enclosed areas.
Deadly levels of carbon monoxide can build up in these areas. Using a fan or opening windows and doors
does NOT supply enough fresh air.
· ONLY use a generator outdoors and far away from open windows, doors, and vents. These openings can
pull in generator exhaust.
Even when you use a generator correctly, CO may leak into the home. ALWAYS use a battery-powered or
battery-backup CO alarm in the home.
If you start to feel sick, dizzy, or weak after the generator has been running, move to fresh air RIGHT AWAY.
See a doctor. You could have carbon monoxide poisoning.
WARNING! THE EXHAUST CONTAINS POISONOUS CARBON MONOXIDE GAS THAT
CAN CAUSE LOSS OF CONSCIOUSNESS AND MAY LEAD TO DEATH.
Gasoline and Oil
This product requires oil and fuel. Attempting to start the engine without oil will ruin
the engine and void the warranty. Work in well ventilated area. Keep cigarettes,
flames or sparks away from the work area or where gasoline is stored.
WARNING! GASOLINE IS EXTREMELY FLAMMABLE AND IS EXPLOSIVE UNDER
CERTAIN CONDITIONS. KEEP OUT OF REACH OF CHILDREN.
• Gasoline fuel and fumes are flammable and potentially explosive. Use proper fuel storage and handling
procedures. Always have multiple ABC class fire extinguishers nearby.
• Keep the generator and surrounding area clean at all times.

Owner’s Manual
9
General Precautions (cont’d)
Gasoline and Oil (cont’d)
• Fuel or oil spills must be cleaned up immediately. Dispose of fluids and cleaning materials as per any local,
state, or federal codes and regulations. Store oily rags in a covered metal container.
• Never store fuel or other flammable materials near the generator.
• Do not smoke, or allow sparks, flames or other sources of ignition around the engine and fuel tank. Fuel
vapors are explosive.
• Keep grounded conductive objects, such as tools, away from exposed, live electrical parts and connections
to avoid sparking or arcing. These events could ignite fumes or vapors.
• Do not refill the fuel tank while the engine is running or while the engine is still hot. Do not operate the
generator with known leaks in the fuel system.
• Excessive buildup of unburned fuel gases in the exhaust system can create a potentially explosive condition.
This buildup can occur after repeated failed start attempts, valve testing, or hot engine shutdown. If this
occurs, open exhaust system drain plugs, if equipped, and allow the gases to dissipate before attempting to
restart the generator.
• Use only engine manufacturer recommended fuel and oil.
Fuel: Oil:
Fuel capacity is 4.0 US gallons (15 L). Use regular Oil capacity is 20.3fl oz(0.6L)
unleaded gasoline with a minimum octane rating of 90.
Hot Components
WARNING! ENGINE AND EXHAUST SYSTEM PARTS BECOME VERY
HOT AND REMAIN HOT FOR SOME TIME AFTER THE ENGINE IS RUN. WEAR
INSULATED GLOVES OR WAIT UNTIL THE ENGINE AND EXHAUST SYSTEM
HAVE COOLED BEFORE HANDLING THESE PARTS.
Power Output
This generator is not designed to power sensitive electronic equipment (including computers and medical
devices) without the addition of an approved line conditioner, which is sold separately.
CAUTION: ATTEMPTING TO POWER SENSITIVE ELECTRONIC EQUIPMENT
WITHOUT THE USE OF AN APPROVED LINE CONDITIONER MAY CAUSE
DAMAGE TO THE EQUIPMENT. GREEN-POWER LLC IS NOT RESPONSIBLE
FOR ANY DIRECT OR INDIRECT DAMAGE CAUSED BY FAILURE TO USE AN
APPROVED LINE CONDITIONER.

5250W Dual Fuel Generator
10
General Precautions (cont’d)
Work Area
• Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases,
or dust. Generators create sparks which may ignite the dust or fumes.
• Keep by standers, children, and visitors away while operating a generator. Provide barriers or shields as
needed.
Electrical Safety
• Grounded tools must be plugged into an outlet properly installed and
grounded in accordance with all codes and ordinances. Never remove the
grounding prong or modify the plug in any way. Do not use any adapter
plugs.
• Grounding provides a low-resistance path to carry electricity away from the
user in the event of an electrical malfunction.
• Double insulated tools are equipped with a polarized plug where one blade is wider than the other. This plug
fits in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician to install a polarized outlet. Do not change the plug in any way.
Double insulation eliminates the need for the three-wire grounded power cord and grounded power supply
system.
• Avoid body contact with grounded surfaces such as pipes, radiators, ranges, and refrigerators. There is an
increased risk of electric shock if your body is grounded.
• Do not expose generator to rain or wet conditions. Water entering a generator will increase the risk of
electric shock.
• Do not abuse the power cord. Keep power cords away from heat, oil, sharp edges, or moving parts. Replace
damaged power cords immediately. Damaged power cords increase the risk of electric shock.
• When operating a power tool outside, use an outdoor extension cord marked “W-A” or “W”. These
extension cords are rated for outdoor use, and reduce the risk of electric shock.

Owner’s Manual
11
General Precautions (cont’d)
Electrical Safety (cont’d)
• All connections and conduits from the generator to the load must only be installed by trained and licensed
electricians, and in compliance with all relevant local, state, and federal electrical codes and standards, and
other regulations where applicable.
• The generator must be earth-grounded for fixed installations in accordance with all relevant electrical codes
and standards before operation.
• Do not attempt to connect or disconnect load connections while standing in water, or on wet or soggy
ground.
• Do not touch electrically energized parts of the generator and interconnecting cables or conductors with any
part of the body, or with any non-insulated conductive object.
• Connect the generator only to a load or electrical system (120 volt) that is compatible with the electrical
characteristics and rated capacities of the generator.
• Before servicing equipment powered by the generator, disconnect the equipment from its power input.
• Keep all electrical equipment clean and dry. Replace any wiring where the insulation is cracked, cut abraded
or otherwise degraded. Replace terminals that are worn, discolored, or corroded.
Keep terminals clean and tight.
• Insulate all connections and disconnected wires.
• Guard against electric shock. Prevent body contact with grounded surfaces such as pipes, radiators, ranges,
and refrigerator enclosures.
Personal Safety
• Stay alert. Watch what you are doing, and use common sense when operating a generator. Do not use
generator while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while
operating generators may result in serious personal injury.
• Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves
away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.

5250W Dual Fuel Generator
12
General Precautions (cont’d)
Personal Safety (cont’d)
• Avoid accidental starting. Make sure the power switch is in its “OFF” position, and disconnect the spark plug
wire when not in use.
• Remove adjusting keys or wrenches before turning the generator on. A wrench or a key that is left attached
to a rotating part of the generator may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times.
• Use safety equipment. Always wear eye protection. Wear ANSI approved safety impact eye goggles. Dust
mask, non-skid safety shoes, hard hat, or hearing protection must be used for appropriate conditions.
• Do not force the generator. Use the correct generator for your application. The correct generator will do the
job better and safer at the rate for which it is designed.
• Do not use the generator if the power switch does not turn it on or off. Any generator that cannot be
controlled with the power switch is dangerous and must be replaced.
Generator Use and Care
Make sure the power switch is in its “OFF” position and disconnect the spark plug wire before making any
adjustment, changing accessories, or storing the generator. Such preventive safety measures reduce the risk
of starting the generator accidentally.
Store idle generators out of reach of children and other untrained persons. Generators are dangerous in the
hands of untrained users.
Maintain generators with care. Do not use damaged generator. Tag damaged generators “Do not use” until
repaired.
Check for misalignment or binding of moving parts, breakage of parts, and any other condition that may affect
the generator’s operation. If damaged, have the generator serviced before using. Many accidents are caused
by poorly maintained generators.
Use only accessories that are recommended by the manufacturer for your model. Accessories that may be
suitable for one generator may become hazardous when used on another generator.

Owner’s Manual
13
General Precautions (cont’d)
Servicing
Maintain labels and name plates on the generator and engine. These carry important information. If
unreadable or missing, contact our service center toll free immediately for a replacement.
Generator service must be performed only qualified repair personnel. Service or maintenance performed by
unqualified personnel could result in a risk of injury.
When servicing a generator, use only identical replacement parts. Follow all appropriate instructions in this
manual. Use of unauthorized parts or failure to follow maintenance instructions may create a risk of electric
shock or injury.
Heart Pacemakers
WARNING! PEOPLE WITH PACEMAKERS SHOULD CONSULT THEIR
PHYSICIAN(S) BEFORE USING THIS PRODUCT. ELECTROMAGNETIC
FIELDS IN CLOSE PROXIMITY TO A HEART PACEMAKER COULD CAUSE
INTERFERENCE TO OR FAILURE OF THE PACEMAKER.
Installation
• If a transfer switch is installed, ensure installation meets all applicable safety, and local and national
electrical codes. Have installation performed by a qualified, licensed electrician and building contractor.
• All electrical work, including the earth-ground connection, should be completed by a licensed electrician.
• Any separate fuel storage or generator supply facility must be built or installed in full compliance with all
relevant local, state, and federal regulations.

5250W Dual Fuel Generator
14
General Precautions (cont’d)
Installation (cont’d)
• If the generator is installed outdoors, it must be weatherproofed and should be soundproofed. It should not
be run outdoors without protection to the generator and wiring conduit.
• The generator might weigh over 100 lbs. Two or more people should assist when moving or lifting this
product. Never lift the generator using the engine or alternator lifting lugs. Connect lifting equipment to the
frame of the generator.
• Before lifting the generator, ensure the lift rigging and supporting structure are in good condition, and are
rated to lift such a load.
• Keep all personnel away from the suspended generator during relocating.
• The supporting floor/ground surface should be level and strong enough to safely hold the weight of the
generator. If the floor/grounded surface is not level, strong cross members should be placed under the full
length of the generator frame at its low side.
• For trailer installation, the generator should be mounted on the center point of the trailer, over the wheels.
The trailer must be capable of supporting the weight of the generator and all contents (tools, etc.)
• Install sound-and weather-proofing only when it is not raining or snowing to avoid trapping moisture within
the generator’s area.
Mechanical
• Always make sure the power switch is in its “OFF” position. Disconnect the spark plug wire, and allow the
engine to completely cool before carrying out maintenance.
• Check for damaged parts. Before using the generator, any part that appears damaged should be carefully
checked to determine that it will operate properly and perform its intended function. Check for alignment
and binding of moving parts, any broken parts or mounting fixtures, and any other condition that may affect
proper operation technician.
• The generator is designed with guards for protection from moving parts. In any case, care must still be taken
to protect personnel and equipment from other mechanical hazards when working around the generator.

Owner’s Manual
15
General Precautions (cont’d)
Mechanical (cont’d)
• Do not operate the generator with safety guards removed. While the generator is running, do not attempt
to reach around the safety guard for maintenance or any other reason.
• Keep hands, arms, long hair, loose clothing, and jewelry away from moving parts. Be aware that when
engine parts are moving fast they cannot be seen clearly.
• Keep access doors on enclosures closed and locked when access is not required.
• When working on or around the generator always wear protective clothing including ANSI approved safety
gloves, safety eye goggles, and safety hat.
• Do not alter or adjust any part of the generator that is assembled and supplied by the manufacturer.
• Always follow and complete scheduled engine and generator maintenance.
Chemicals
• Avoid contact with hot fuel, oil, exhaust fumes, and hot solid surfaces.
• Avoid body contact with fuels, oils, and lubricants used in the generator. If swallowed, seek medical
treatment immediately. Do not induce vomiting if fuel is swallowed. For skin contact, immediately wash
with soap and water. For eye contact, immediately flush eyes with clean water and seek medical attention.
Noise
• Prolonged exposure to noise levels above 68 DBA is hazardous to hearing. Always wear ANSI approved ear
protection when operating or working around the generator when it is running.

5250W Dual Fuel Generator
16
General Precautions (cont’d)
Extension Cord
If an extension cord (not included) is used, make sure to use only UL approved cords having the correct gauge
and length according to the following table:
Nameplate Amps (@ full load) Cord Lengths
0 ft.- 50 ft.
50 ft.-100 ft.
100 ft.-150 ft.
150 ft.-200 ft.
0 - 5
16 AWG
16 AWG
12 AWG
12 AWG
5.1 - 8
16 AWG
14 AWG
10 AWG
-
8.1 - 12
14 AWG
12 AWG
-
-
12.1 - 15
12 AWG
10 AWG
-
-
15 - 20
10 AWG
10 AWG
-
-

Owner’s Manual
17
Assembly and Installation
Unpacking
1. Remove the generator and loose parts box from the carton.
2. Compare the Hardware Kit included with the inventory list below.
Loose Parts (Wheel kit and handle)
Check all loose parts against the following list. Contact your dealer toll free at 877.834.4218, if any of the
parts listed below is/are not found.
Hardware Check:
Your wheel should include:
1) Two Handles with bolts, R pin
2) Two axle shaft with nuts.
3) Two Split Pin
4) One generator leg with bolts and nuts
5) Two wheels
Install the Handles
a. Install the handle through the frame and assure two holes are alignment (Fig 1)
b. Install the pan head pin through the handle and frame (Fig 2)
c. Install R pin through pan head pin to lock it in place (Fig 3)
Install Feet to Frame
a. Place the mounting feet at the bottom of frame and
assure that four holes are alignment , and then Install the
mounting feet to the frame using four bolts and nuts (Fig 4)
Install Wheels
a. Install the axle pin (the long end) through the wheel (Fig 5)
b. Install the big washer outside the wheel(Fig 6)
c. Insert the cotter pin through the washer and wheel (Fig 7)
d. Install the wheel with axle pin through the axle bracket on the
frame(Fig 8)
e. Install the hairpin cotter through the axle pin to lock it in place
(Fig 9)

5250W Dual Fuel Generator
18
Installation
NOTE: PRIOR TO POWERING TOOLS AND EQUIPMENT MAKE SURE THE
GENERATOR’S RATED VOLTAGE, WATTAGE AND AMPERAGE CAPACITY IS
ADEQUATE TO SUPPLY ALL ELECTRICAL LOADS THAT THE UNIT WILL
POWER. IF POWERING EXCEEDS THE GENERATOR’S CAPACITY, IT MAY BE
NECESSARY TO GROUP ONE OR MORE OF THE TOOLS AND/OR EQUIPMENT
FOR CONNECTION TO A SEPARATE GENERATOR.
Electrical and other permits may be required for the installation of emergency power systems.
Investigate your local building and electrical codes before installing this unit. Installation must be completed
by licensed contractors.
WARNING! THE GENERATOR WEIGHS APPROXIMATELY OVER 100 POUNDS.
USE CARE AND THE PROPER LIFTING OR HOISTING EQUIPMENT WHEN
MOVING IT TO THE INSTALLATION LOCATION. ALWAYS CONNECT HOIST
LINES TO THE FRAME OF THE GENERATOR.
General Location
• Make sure to locate and install the generator outdoors where cooling air is readily available.
• Install the generator so that the air inlets and outlets are not blocked by obstructions such as bushes, trees,
or snow drifts. Locating it in the path of heavy winds or snowdrifts may require the placement of a barrier
for protection. In normal weather conditions, the air vent should face the prevailing wind direction.
• Install the generator on a concrete slab or other area where rain drainage or flood waters can not reach it.
• Generator placement should allow four feet of access to all sides for maintenance.
• Place the generator as close as possible to the electrical tools and equipment being powered to reduce the
length of extension cords.

Owner’s Manual
19
Installation (cont’d)
Supporting and Mounting
Mount the generator on a concrete slab capable of supporting the weight of the generator. The slab must
extend on all sides beyond the frame by at least one foot. Contact a cement contractor for slab specifications
if necessary. Attach the frame to the concrete slab using 3/8” diameter expansion anchor bolts (not supplied).
Grounding
NOTE: IT IS RECOMMENDED THAT ONLY A TRAINED AND LICENSED
ELECTRICIAN PERFORM THIS PROCEDURE
Connect a #6 AWG grounding wire (not included) from the ground connector (8) on the generator to a
grounding rod (not included) that has been driven at least 24 inches deep into the earth. The grounding rod
must be an earth-driven copper or brass rod (electrode) which can adequately ground the generator.
Fuel Tank
Choke Lever
Air Filter
Recoil Start
Oil Plug
Control Panel
Fuel Select Switch
LPG/Propane Inlet
