G.R.A.S. 41AC-3 User manual
Instruction Manual
G.R.A.S 41AC-3 CCP Outdoor Microphone with
RemoteCheck for Community & Airport Noise
www.gras.dk
LI0152– 4 July 2017
2LI0152 – 4 July 2017
Revision History
Revision Date Description
1 26 August 2014 First edition
2 4 July 2017 42AG substituted for the obsolete 42AB
Copyright Notice
© 2014, 2017 G.R.A.S. Sound & Vibration A/S
http://www.gras.dk
Any technical documentation that is made available by G.R.A.S. is the copyrighted work of
G.R.A.S. and is owned by G.R.A.S.
The content in this document is subject to change without notice. G.R.A.S. Sound & Vibration A/S
is not liable or responsible for any errors or inaccuracies that may appear in this document.
Trademarks
Any product names mentioned in this document may be trademarks or registered trademarks of
their respective companies and are hereby acknowledged.
3
LI0152 – 4 July 2017
Contents
Introduction.................................................................................. 4
Delivered Items............................................................................. 4
Installation .................................................................................. 6
System Integration ...................................................................... 12
Accessories ................................................................................ 14
Specifications ............................................................................. 14
Calibration, Warranty and Service................................................... 18
4LI0152 – 4 July 2017
Introduction
The G.R.A.S. 41AC-3 CCP Outdoor Microphone for Community & Airport Noise is a precision
microphone set (IEC 61672-1) for monitoring community noise and the noise of overhead
aircraft.
It can be used for monitoring of noise with 90 degrees of incidence, typically community noise.
With the proper correction data, it can be used for 0 degrees of incidence, typically noise from
overhead aircraft. A USB flash drive with correction data is part of the delivery.
It is waterproof, rated at IP-55, and can operate unattended over a wide range of weather condi-
tions and temperatures for a very long period, i.e. a year or longer.
It uses a G.R.A.S. 40AE-S2 1/2” Prepolarized Free-field Microphone, High Sensitivity and a
G.R.A.S. 26CA 1/2’’ CCP Standard Preamplifier with BNC Connector.
It has TEDS according to IEEE1451.4 template UDID 127-0-0-0U.
Important. The 40AE-S2 microphone and its protective grid have been modified for the 41AC-3.
Therefore, microphone and grid cannot be replaced by standard items.
Delivered Items
1/2" Prepolarized Free-Field Microphone, High Sensitivity 40AE-S2
1/2’’ CCP Standard Preamplifier with BNC Connector 26CA
O-ring for preamplifier OR2038
USB flash drive with correction data for 0° (resolution: 1/12 octave)
Wind Screen AM0378
Top cone -
Upper housing -
Lower housing -
1” pole mount adapter RA0286
Tripod Adapter GR1096
Tripod thread adapter SK0017
5
LI0152 – 4 July 2017
41AC-3 is delivered preassembled except for the windscreen and thread adapter.
2-piece
1” pole mount
adapter RA0286
Lower housing
Windscreen
AM0378
Top cone
Preamplfier 26CA
Upper housing
½" microphone
40AE-S2
Tripod and thread
adapter SK0017
O-ring OR2038
Fig. 1. The parts of 42AC-3.
6LI0152 – 4 July 2017
Installation
Mounting 41AC-3 on Tripod or Pole Mount Adapter
The 41AC-3 is designed for permanent installation and therefore comes with an adapter for
mounting on a 1” pole. See Fig. 2 and Fig. 3, 3. The 41AC-3 ’s housing is attached to the
mounting fittings with a M18 x 1.5 thread.
Two-piece pipe adapter with
1” pipe thread (ISO 228/1-G1)
M18 x 1.5
GR1096 Tripod
thread adapter
with SK0017 1/4”
threaded bushing
Tripod thread adapter
with 3/8” thread (without
1/4” bushing)
Fig. 2. The 41AC-3 lower housing’s thread and adaptor for tripod or pole mount.
7
LI0152 – 4 July 2017
Removing the Preamplifier
As delivered, the microphone set is mounted inside the housing. To attach the cable, you must
remove the top, remove the microphone and pull out the preamplifier.
1. Unscrew the top cone from the housing.
2. Set it aside and ensure that it is protected from dirt and moisture.
3. Remove the microphone from the preamplifier and set it aside. Ensure that it is protected from
dirt and moisture.
4. Push at the top of the preamplifier to make it slide down through the tube.
13
24
Fig. 3. Removing the top cone and releasing the preamplifier.
8LI0152 – 4 July 2017
Connecting the Cable to the Preamplifier and Remounting the Microphone Set
1. Connect the cable to the preamplifier.
2. Push the preamplifier up through the lower and upper housing.
3. To expose the thread for the microphone, ensure that the preamplifier is pushed up as far as it
will go.
4. Mount the microphone onto the preamplifier and tighten lightly.
1 32 4
Fig. 4. Connecting the cable and securing the microphone set.
9
LI0152 – 4 July 2017
Mounting the Top Cone
When the microphone has been mounted on the preamplifier, you can mount the top cone.
1. Screw on the top cone.
2. Ensure that the top cone is properly fastened.
1 2
6
5
Fig. 5. Mounting the upper housing and the top cone.
10 LI0152 – 4 July 2017
Mounting the Windscreen
The windscreen is glued onto a plastic tube that ensures that it can be positioned correctly:
• When pushed down, the windscreen tube is prevented from going too far by the upper hous-
ing’s conical shape.
• When the windscreen is pushed as far down as it will go, it will be kept in place by a locking
groove. Because of this, it cannot be dislocated unintentionally, and incorrect measurements
due to an incorrectly positioned windscreen are avoided.
1. Slide the tube down over the top cone.
2. Ensure that the tube is pushed as far down as it will go.
1 2
End
stop
Locking
groove
Top of microphone
(diaphragm)
Fig. 6. Mounting the wind screen.
11
LI0152 – 4 July 2017
Disassembly
You can disassemble the 41AC-3 by reversing the procedure described on the preceding pages.
The windscreen tube is held in place by a locking mechanism. Therefore, some force must be
applied to slide the tube back up.
1. Push at the end of the windscreen tube with a finger nail or a piece of hard plastic.
Caution. Do NOT pull at the foam as this could cause it to deform or loosen it from the tube.
2. Unscrew the top cone.
3. Unscrew the microphone.
4. Slide the preamplifier downwards and disconnect the cable.
3
4
1 2
Push
3 4
13
24
1 32 4
Fig. 7. Removing the wind screen and disconnecting the cable.
12 LI0152 – 4 July 2017
System Integration
TEDS
41AC-3 has TEDS accoording to IEEE1451.4 template UDID 127-0-0-0U.
Setting the 41AC-3 for 90 or 0 Degrees of Incidence
The 41AC-3 is designed to be mounted vertically, as described in the previous sections. Mounted
in this way, it can be set up for measurement at either 90 degrees or 0 degrees of incidence.
The correction data contained on the USB flash drive that is part of the delivery must be used if
the 41AC-3 is used for 0 degrees of incidence. The correction data are measured with a resolu-
tion of 1/12 octave.
Polarization Voltage = 0 V
41AC-3 uses a prepolarized microphone with a 26CA 1/2’’ CCP Preamplifier and must be
connected to a CCP input of an analyzer.
Distance to the Ground
When mounted on a pipe or tripod, the distance from the bottom of the microphone to the ground
reflecting surface must be at least 20 cm/7.9” to minimize the influence of ground reflections on
the sound field.
Replacing Microphone and/or its Protective Grid
The 40AE-S2 microphone and its protective grid are designed specifically for the 41AC-3. Only
the 40AE-S2 will ensure the stated measurement results and water protection.
Therefore neither microphone nor its protective grid can be replaced with standard items.
Verification and Calibration
An acoustic in-situ verification or a calibration in a laboratory with a pistonphone or a sound
calibrator requires that windscreen and top cone are dismantled. How to do this is shown in Fig.
7. Calibration can be performed using a Sound Calibrator or a Pistonphone. The G.R.A.S. 42AP
Intelligent Pistonphone is recommended because of its built-in thermometer and barometer. The
Sound Calibrator/Pistonphone must be fitted with a coupler for ½-inch microphones.
Refer to the manual for your sound calibrator or pistonphone for further information.
Maintenance
Depending on local conditions, the windscreen must be cleaned or replaced. How often must be
determined by visual inspection and knowledge of local weather conditions.
O-ring OR2038 (see page 5) must be lubricated with silicon grease at regular intervals.
Without lubrication it must be replaced once a year.
When under power, the preamplifier emits heat. This heat is part of the 41AC’s protection against
moisture, and therefore the power to the 41AC should be turned on permanently.
13
LI0152 – 4 July 2017
Accessories
Intelligent Pistonphone 42AP
Pistonphone 42AA
Multifunction Sound Calibrator 42AG
3 m BNC - BNC Cable AA0035
10 m BNC - BNC Cable AA0037
30 m BNC - BNC Cable AA0038
Customized length BNC - BNC Cable AA0039-CLXXXX
Specifications
Dynamic range lower limit (microphone thermal noise) 17 dB(A)
Dynamic range upper limit 138 dB
Set sensitivity @ 250 Hz (±2 dB) 50 mV/Pa
Compliance IEC 61672-1
Polarization voltage 0 V
Power supply 2 - 20 mA
Temperature range, operation -30 to 70 / -22 to 158
Connector type BNC
TEDS IEEE1451.4 template UDID 127-0-0-0U
CE/RoHS compliant/WEEE registered Yes/Yes/Yes
Water Resistance IP55
295 mm/11/ in
343 mm/13/ in
12 mm// in
1”pipe thread (ISO 228/1-G1)
Fig. 8. When mounted on a pipe, the top of the 41AC will be elevated 343 mm above the pipe.
14 LI0152 – 4 July 2017
Frequency Response and Directional Response
-20
-15
-10
-5
0
5
1000 10000
dB
Frekvens
41AC
Typical frequecy responce
90° incidence
0° incidence
0° incidence with correction
IEC expanded lim+
IEC expanded lim-
IEC lim +
IEC lim -
0° incidence
0° incidence with corr.
IEC 61672-1 tolerance +
IEC 61672-1 tolerance -
90° incidence
Typical Frequency Response
Frequency [Hz]
Amplitude (dB)
IEC 61672-1 accept. limit +
IEC 61672-1 accept. limit -
Fig. 9. Typical frequency response.
0
0,5
1
1,5
2
2,5
3
3,5
4
4,5
5
1000 10000
Acceptance limits for deviations of directional response
41AC w. windscreen
0º incidencs Lim dev ±30º
0° incidence
90° incidence
Lim w. uncertanty ±30º
Lim dev ±30º
Frequency [Hz]
Amplitude (dB)
±30° Directional Response Measurements
0° and 90° Incidence
0° incidence
90° incidence
IEC 61672-1 tolerance
IEC 61672-1 acccept. limit
Fig. 10. ±30˚ directional response at 0° and 90° incidence.
15
LI0152 – 4 July 2017
Frequency [Hz]
Amplitude (dB)
0
2
4
6
8
10
12
14
1000 10000
Acceptance limits for deviations of directional response
41AC w. windscreen
0º incidence Lim dev ±90º
0° incidence
90° incidence
Lim w. uncertanty ±90º
Lim dev ±90º
±90° Directional Response Measurements
0° and 90° Incidence
0° incidence
90° incidence
IEC 61672-1 tolerance
IEC 61672-1 acccep. limit
Fig. 11. ±90˚ directional response at 0° and 90° incidence.
0
2
4
6
8
10
12
14
16
18
20
1000 10000
Acceptance limits for deviations of directional response
41AC w. windscreen
0º incidence Lim dev ±150º
0° incidence
90° incidence
Lim w. uncertanty ±150º
Lim dev ±150º
Frequency [Hz]
Amplitude (dB)
±150° Directional Response Measurements
0° and 90° Incidence
0° incidence
90° incidence
IEC 61672-1 tolerance
IEC 61672-1 acccept. limit
Fig. 12. ±150˚ directional response at 0° and 90° incidence.
16 LI0152 – 4 July 2017
Calibration, Warranty and Service
Calibration
Before leaving the factory, all G.R.A.S. products are calibrated in a controlled laboratory environ-
ment using traceable calibration equipment.
An individual test certificate stating the sensitivity and frequency response is included with each
product.
Warranty
All G.R.A.S. products are made of high-quality materials that will ensure life-long stability and
robustness. The 41AC-3 is delivered with a 5-year warranty.
The windscreen comes with a 6-month warranty, this warranty covers defective workmanship only
and not the effects of normal use.
Damaged diaphragms in microphones can be replaced.
The warranty does not cover products that are damaged due to negligent use, an incorrect power
supply, or an incorrect connection to the equipment.
Service and Repairs
All repairs are made at G.R.A.S. International Support Center located in Denmark. Our Support
Center is equipped with the newest test equipment and staffed with dedicated and highly skilled
engineers. Upon request, we make cost estimates based on fixed repair categories. If a product
covered by warranty is sent for service, it is repaired free of charge, unless the damage is the
result of negligent use or other violations of the warranty. All repairs are delivered with a service
report, as well as an updated calibration chart.
WEEE directive:
2002/96/EC
CE marking directive:
93/68/EEC
Manufactured to conform with:
RoHS directive:
2002/95/EC
G.R.A.S. Sound & Vibration continually strives to improve the quality of our products for our customers; therefore, the
specifications and accessories are subject to change without notice.
Table of contents
Other G.R.A.S. Microphone manuals
