gabriel Screen Solutions Tone Acoustic Booth User manual

Tone Acoustic
Booth
Assembly
Instructions V1.0

Page 3
Tone Acoustic Booth Assembly Instructions v1.0
2. Left side
panel assembly
5. Rear panel assembly 7. Internal acoustic
panel left
4. Top assembly
3. Right side panel
assembly
8. Internal acoustic
panel right
6. Internal door frame
assembly
Components list
1. Base assembly

Page 5Page 4
Tone Acoustic Booth Assembly Instructions v1.0Tone Acoustic Booth Assembly Instructions v1.0
9. Door 10. Carpet
11. Upholstered side panel x2
13 Interior door
handle
12. Exterior door
handle
38 Pieces
M8 x 40mm Cap head
bolt silver
34 Pieces
M8 x 25mm Washer
silver
8 Pieces
M10 x 16mm CSK socket
head bolt black
6mm Hex key
8mm
Socket
Rubber mallet
Spirit level
14 Shelf bracket
15 Shelf trim
16 Shelf
7 Pieces
M8 x 15mm Washer
silver
Plastic magnet spacer
shims
(2 x 0.5mm; 2 x 1.0mm)
PU floor cushion
3 Pieces
M8 x 140mm cap head
bolt silver
24mm Plywood spacer
Fixings
6 Pieces
Door handle spacer black
Tools required
(not included)
7 Pieces
M8 Bolt cap
3mm Hex key

Page 7
Tone Acoustic Booth Assembly Instructions v1.0
Carefully remove the booth components from the
delivery container and remove protective packaging.
Place the components in a safe place where they can be
free from damage and protect edges from hard surfaces.
01 Unpack the booth components
Heavy!
Two person lift required.

Page 9
Tone Acoustic Booth Assembly Instructions v1.0
03
Page 8
Tone Acoustic Booth Assembly Instructions v1.0
02
Please ensure the base is in the correct location before
assembly, allowing a minimum of 1 meter around the base
and 2.5 meters of height clearence.
8mm Socket
Spirit level
Level the basePosition the base
2
2500mm
1000mm
1000mm
1000mm
1000mm
3
4

Page 11
Tone Acoustic Booth Assembly Instructions v1.0
05
Page 10
Tone Acoustic Booth Assembly Instructions v1.0
04
2 3
4
2
Heavy!
Two person lift required.
2
3
PU floor cushion
Fit left side panel assembly
6mm Hex key
M8 x 40mm cap head bolt
4x
M8 Washer silver
4x
Rubber mallet
Remove foam from side assemblies
Left side assembly
Remove two sections
Right side assembly
Remove three sections
Gently tap the
front edge with
the rubber
mallet to align.
Finger tight
PU floor cushion

Page 13
Tone Acoustic Booth Assembly Instructions v1.0
07
Page 12
Tone Acoustic Booth Assembly Instructions v1.0
06
Heavy!
Two person li required.
4
2
3
2
PU floor cushion
Remove floor access panelFit right side panel assembly
M8 x 40mm cap head bolt
4x
M8 Washer silver
4x
Finger tight
Align the front
edges by
tapping with a
rubber mallet.
PU floor cushion
6mm Hex key
Rubber mallet
Take care
with cables
Remove the panel by
removing 2 x 4mm x
45mm
CSK woodscrews

Page 15
Tone Acoustic Booth Assembly Instructions v1.0
09
Page 14
Tone Acoustic Booth Assembly Instructions v1.0
08
3
10
29
8
7
4
5 6
Support the glass
frame whilst fixing.
Rest the rear panel
on the base assembly
ledge for correct
positioning
Fix with 10 No. M8
x 40mm cap head
bolts and washers
Heavy!
Two person li required.
Fix back panel assembly
6mm Hex key
M8 x 40mm cap head bolt
10x
M8 Washer silver
10x
Fit back panel assembly
Finger tight

Page 17
Tone Acoustic Booth Assembly Instructions v1.0
11
Page 16
Tone Acoustic Booth Assembly Instructions v1.0
10
3
2
8
7
45
6
Fix with 8 No. M8
x 40mm cap head
bolts and washers
Ensure ceiling
cable passes
through cut-out in
right side panel
Heavy!
Two person lift required.
Fix top panel assembly
6mm Hex key
M8 x 40mm cap head bolt
8x
M8 Washer silver
8x
Rubber mallet
Position top panel assembly
Finger ght
Cables

Page 19
Tone Acoustic Booth Assembly Instructions v1.0
13
Page 18
Tone Acoustic Booth Assembly Instructions v1.0
12
3
2
8
7
45
6
2
3 4
Rest the front door
frame panel on the
base assembly
ledge for correct
positioning
View from the rear with the
back panel removed
Fix with 8 No. M8 x 40mm cap
head bolts and washers
Fix with
4 No. M8 x 40mm cap
head bolts,
4 No. M8 x 15 washers
and cap head bolt covers
Fit front door frame panel assembly exterior
6mm Hex key
M8 x 40mm cap head bolt silver
4x
M8 Cap head bolt cover
4x
Fit front door frame panel assembly interior
6mm Hex key
M8 x 40mm cap head bolt silver
8x
M8 Washer silver
8x
Finger ght
4x M8 x 15mm washer

Page 21
Tone Acoustic Booth Assembly Instructions v1.0
15
Page 20
Tone Acoustic Booth Assembly Instructions v1.0
14
2
3
4
Use the plywood
spacer to set the
depth of the side
panels with the front
and back panel edges
to 24mm.
Ensure the depth
is 24mm front and
back, top and bottom
and on both left and
right hand side panel
assemblies.
Once aligned, tighten
all fixings.
Align both sides
Fix the panel with 2
x 4mm x 45mm
CSK woodscrews
2
Tighten all fixings.
Do not over tighten.
24mm Plywood Spacer
Replace floor panelAlign side panels and tighten all fixings
6mm Hex key

Page 22
Tone Acoustic Booth Assembly Instructions v1.0
16
Page 23
Tone Acoustic Booth Assembly Instructions v1.0
17
1
4
2
3
Connect the electric cables
to the top and bottom of the
right hand panel assembly
Connect electric cables Fit the shelf bracket
6mm Hex key
M10 x 16mm CSK bolt
4x

Page 25
Tone Acoustic Booth Assembly Instructions v1.0
19
Page 24
Tone Acoustic Booth Assembly Instructions v1.0
18 Replace foam - right panel assembly Replace foam - left panel assembly
2
32

Page 27
Tone Acoustic Booth Assembly Instructions v1.0
21
Page 26
Tone Acoustic Booth Assembly Instructions v1.0
20
Fit the carpet to
the floor of the
booth, ensuring
the carpet is flat.
Fit the panel with
the pre-applied hook
and loop tape, taking
care over the shelf
bracket.
Push all around the
edges and down the
centre from top to
bottom to ensure the
panel has attached
with hands only.
Fit the carpet Fit the internal right side panel

Page 29
Tone Acoustic Booth Assembly Instructions v1.0
23
Page 28
Tone Acoustic Booth Assembly Instructions v1.0
22
Fit the panel with the
pre-applied hook and
loop tape.
Push all around the
edges and down the
centre from top to
bottom to ensure the
panel has attached
with hands only.
Slide the shelf trim over the shelf supporting bracket.
Place the shelf on the supporting bracket and fix using 4x M10 x 16mm CSK
bolts
6mm Hex key
Fit the internal left side panel Fit the shelf and trim
M10 x 16mm CSK bolt
4x
2

Page 31Page 30
Tone Acoustic Booth Assembly Instructions v1.0Tone Acoustic Booth Assembly Instructions v1.0
24 25
Connect the Z-Bars
to hang the panel.
Connect the Z-Bars
to hang the panel.
Fit the upholstered left side panel Fit the upholstered right side panel

Page 32
26
Tone Acoustic Booth Assembly Instructions v1.0
Page 33
Tone Acoustic Booth Assembly Instructions v1.0
27
Holding the door at 90 degrees
to the booth, lift and drop
down to engage the hinges.
Do not allow the door to close
on to the magnet. Inner door handle
Outer door handle
Heavy!
Two person lift required.
Fit door Fit door handles
6mm Hex key
M8 x 140mm cap head bolt
3x
M8 cap head bolt cover
3x
Door handle spacer
6x
3x M8 x 15mm washer

Page 34
28
2
Tone Acoustic Booth Assembly Instructions v1.0
Page 35
Tone Acoustic Booth Assembly Instructions v1.0
1
3
29
Door should soft
close and hold to
magnet to provide a
good seal.
Door should be easy
to open.
For magnet
adjustment see
STEP 29.
To adjust door seal and magnet closure:
- remove the self-adhesive cover on magnet
- remove the screw and magnet with 3mm allen key
- add or remove plastic spacer shims accordingly
- tighten magnet back into postion with the allen key
- replace self-adhesive cover on the magnet
- check the door seal
4
5
Magnetic
closure
Self-adhesive cover
Plastic shim
Plastic shim
Magnet
M5 x 25mm CSK screw
Magnetic catch assembly
1
4
2
3
5
Test door seal and magnetic catch Adjust door closure and magnetic catch
3mm Hex key
Plastic magnet spacer shims
(0.5mm; 1.0mm)

Tone Acoustic Booth
Assembly Instructions V1.0
Copyright 2022
