Gaggenau BSP 221 User manual

Gaggenau Instruction manual
BSP 220/221
Steam oven

2
Table of contents Instructionmanual
Important safety information 3
Causes of damage 4
Environmental protection 5
Environmental protection 5
Tips for saving energy 5
Getting to know the appliance 6
Steam oven 6
Display and operating controls 7
Symbols 7
Colours and display 8
Additional information (and )8
Cooling fan 8
Function selector positions 9
Accessories 10
Special accessories 10
Before using for the first time 10
Setting the language 10
Setting the time format 11
Setting the clock 11
Setting the date format 11
Setting the date 11
Setting the temperature format 11
Setting the water hardness 11
Ending initial set-up 12
Calibration 12
Cleaning accessories 12
Activating the appliance 13
Standby 13
Activating the appliance 13
Operating the appliance 13
Filling the water tank 13
Cooking compartment 14
Inserting accessories 14
Switching on 14
After every use 15
Safety shut-off 15
Timer functions 15
Calling up the timer menu 15
Timer 15
Stopwatch 16
Cooking time 16
End of cooking time 17
Long-term timer 18
Setting the long-term timer 18
Child lock 19
Activate the child lock 19
Deactivating the child lock 19
Basic settings 20
Cleaning and maintenance 22
Cleaning agents 22
Cleaning aid 23
Descaling programme 23
Removing slide-in rails 24
Trouble shooting 25
Power cut 26
Demo mode 26
Replacing the oven light 26
Aftersales service 26
Settings table and tips 27
Vegetables 27
Vegetables – slow steaming 28
Fish – steaming 28
Fish – slow steaming 29
Meat/poultry – low-temperature steaming 30
Meat/sausages – heating up 30
Poultry – Steaming 31
Side dishes 31
Desserts 31
Miscellaneous 32
Regenerating (reheating) 32
Raising dough 32
Defrosting 33
Preserving 34
Extracting juice (soft fruit) 34
Preparing yoghourt 35
Preparing bulky food 35
Additional information on products, accessories,
replacement parts and services can be found at
www.gaggenau.com and in the online shop
www.gaggenau-eshop.com

3
m Important safety information
Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only use
this appliance indoors.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 8 years old and are
being supervised.
Keep children below the age of 8 years old at a
safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment correctly. See description of
accessories in the instruction manual.
Risk of fire!
Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance door
if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of burns!
▯The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
▯Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
▯Hot steam may escape during operation.
Do not touch the ventilation openings.
Keep children away.
Risk of scalding!
▯When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature.
When opening, do not stand too close to
the appliance. Open the appliance door
carefully. Keep children away.
Risk of scalding!
▯The water in the evaporator dish is still hot
even after the appliance has been
switched off. Do not empty the evaporator
dish immediately after switching off the
appliance. Allow the appliance to cool
down before cleaning it.
Risk of scalding!
▯Hot liquid may spill over the sides of the
accessory when it is removed from the
cooking compartment. Remove hot
accessories with care and always wear
oven gloves.

4
Risk of electric shock!
▯Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the
appliance from the mains or switch off the
circuit breaker in the fuse box. Contact the
after-sales service.
Risk of electric shock and serious injury!
▯The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact
with hot parts of the appliance.
Risk of electric shock!
▯Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
▯A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Causes of damage
Caution!
– Do not place anything on the cooking
compartment floor. Do not cover it with aluminium
foil. A build-up of heat could damage the
appliance.
The cooking compartment floor and the
evaporator dish must always be kept clear. Always
place ovenware in a perforated cooking container
or on a wire rack.
– Aluminium foil in the cooking compartment must
not come into contact with the door panel. This
could cause permanent discolouration of the door
panel.
– We recommend you use a mineral water low in
chloride and without added carbonic acid if your
tap water contains large amounts of chloride
(>40 mg/l). You can inquire with your local water
supply company to obtain information about your
tap water.
– Ovenware must be heat and steam resistant.
Silicone baking tins are not suitable for combined
operation with steam.
– Use only original accessories in the cooking
compartment. Rusting material (such as serving
platters or knives and forks) can cause corrosion
in the oven interior.
– Use original small parts (e.g. knurled nuts) only.
Order small parts from our after-sales service if
these should be lost.
– Dripping liquids: When steaming with a
perforated cooking container, always insert the
baking tray, the universal pan or the solid cooking
container underneath. Dripping liquid is caught.
– Do not store moist food in the closed cooking
compartment for long periods. It can lead to
corrosion in the cooking compartment.
– Salt, spicy sauces (e.g. ketchup or mustard) or
salted dishes (e.g. cured roast) contain chloride
and acids. These corrode the surfaces of
stainless steel. Always remove residues
immediately.
– Fruit juice may leave stains in the cooking
compartment. Always remove fruit juice
immediately and wipe the cooking compartment
with a moist and dry cloth.
– The cooking compartment in your appliance is
made of high grade stainless steel. Improper care
can lead to corrosion in the cooking
compartment. Refer to the care and cleaning
instructions in the instruction manual. After every
use, clean the cooking compartment after the
appliance has cooled down. After cleaning, dry
the cooking compartment with the drying
program.

5
– Do not detach the door seal. The appliance door
will no longer close properly if the door seal is
damaged. The fronts of adjacent units could be
damaged. Have the door seal replaced.
– Do not carry or hold the appliance by the door
handle. The door handle cannot support the
weight of the appliance, and could break.
Environmental protection
Unpack the appliance and dispose of the packaging in
an environmentally-responsible manner.
Environmental protection
Tips for saving energy
▯Open the appliance door as little as possible
while cooking.
▯For longer cooking times, you can switch off the
steam oven 10 minutes before the end of the
cooking time and you can use the residual heat to
finish cooking.
▯When steaming, you can cook simultaneously on
several levels. If dishes require different cooking
times, insert the dishes that require the longest
time first.
This appliance is labelled in accordance with
the European Directive 2012/19/EU
concerning used electrical and electronic
appliances (WEEE – waste electrical and
electronic equipment). The guideline
determines the framework for the return and
recycling of used appliances as applicable.

6
Getting to know the appliance
Use this section to familiarise yourself with your new
appliance. The control panel and the individual
operating controls are explained. You will find
information on the cooking compartment and the
accessories.
Steam oven
  

1 Ventilation opening
2 Door seal
3 Water tank
4 Evaporating dish

7
Display and operating controls
These instructions are valid for different versions of
the appliance. There may be minor differences
depending on the appliance model.
All versions of the appliance are operated in an
identical manner.
--------
Symbols
--------
1 Control panel These areas are touch sensitive.
Touch a symbol to select the cor-
responding function.
2 Display The display shows, for example,
current settings and options.
3 Rotary selector You can use the rotary selector to
set the temperature and to make
further settings.
4 Function selector The function selector is used to
select the type of heating, the
cleaning function or the basic set-
tings.



Symbol Function
IStart
ØStop
HPause/End
'Cancel
ŽDelete
™Confirm/save settings
CSelection arrow
(Call up additional information
“Heating up with status indicator
%Edit settings
0Child lock
MCall up timer menu
/Call up long-term timer
°Demo mode

8
Colours and display
Colours
The different colours are used to guide the user in the
relevant setting situations.
Display
The appearance of the symbols, values or the entire
display changes depending on the situation.
Additional information (and )
By touching the (symbol, you can call up additional
information. For example, information on the heating
function set or on the current temperature of the
cooking compartment.
Note: During continuous operation, small fluctuations
in temperature are normal after the oven has heated
up.
The )symbol is displayed for important information
and action prompts.Important information on safety
and operation mode are occasionally shown
automatically. These messages either disappear
automatically after a few seconds or must be
confirmed with ™.
Cooling fan
Your appliance has a cooling fan. The cooling fan
switches on during operation. Depending on the
appliance version, the hot air escapes above or under
the door.
After removing cooked food, keep the door closed
until the appliance cools down. The appliance door
must not be left ajar, as adjoining kitchen furniture
may be damaged. The cooling fan continues to run for
a certain time after operation and then switches off
automatically.
Caution! Do not cover the ventilation slots.
Otherwise, the appliance will overheat.
Orange Initial settings
Main functions
Blue Basic settings
Cleaning
White Values which can be set
Zoom The setting which is currently being
changed is displayed in an enlarged for-
mat.
A cooking time that is coming to an end
is shown in an enlarged format shortly
before running out (e.g. the last 60 sec-
onds of the timer).
Reduced display After a short time, the display is reduced
and only the most important information
is displayed. This function is preset and
can be changed in the basic settings.

9
Function selector positions






Position Function/type of heating Temperature Use
0 Off position
žLight
2[
100% humidity
30 - 100 °C
Default temperature 100 °C
Steaming at 70 °C - 100 °C: For vegetables, fish
and side dishes.
The food is completely surrounded by steam.
3›
Gentle steaming
30 - 100 °C
Default temperature 80 °C
Gentle steaming: For vegetables and fish.
4V
Dough proofing
30 - 50 °C
Default temperature 38 °C
Proofing: For yeast dough and sourdough.
Dough will proof considerably more quickly than
at room temperature. Hot air and steam are com-
bined so that the surface of the dough does not
dry out.
The optimum temperature setting for yeast
dough is 38 °C.
5W
Defrosting
40 - 60 °C
Default temperature 45 °C
For vegetables, meat, fish and fruit.
The moisture gently transfers the heat to the
food. The food does not dry out or lose its
shape.
6d
Reheating
60 - 100 °C
Default temperature 100 °C
For cooked food and baked goods.
Cooked food is gently reheated. The steam
ensures that the food does not dry out.
7e
Low temperature cooking
70 - 90 °C
Default temperature 70 °C
Low temperature cooking for meat.
Gentle slow cooking for a particularly tender
result.
StBasic settings You can customise your appliance in the basic
settings.
¢Cleaning aid You can use the cleaning aid to loosen dirt in the
cooking compartment with steam.
kDescaling programme You can use the descaling programme to loosen
limescale in the cooking compartment.
¥Delete the descaling
hint
Delete the hint in the display after descaling.

10
Accessories
Use only the accessories supplied with the product or
available from the after-sales service. They are
specially designed for your appliance. Ensure that you
always insert the accessories into the cooking
compartment the right way round.
Your appliance is equipped with the following
accessories:
Special accessories
You can order the following special accessories from
your specialist dealer:
Only use the accessories as specified. The
manufacturer accepts no liability if these accessories
are used incorrectly.
Before using for the first time
Here you will find everything you need to do before
using the appliance to prepare food for the first time.
First read the section on Important safety information.
The appliance must be fully installed and connected to
the mains.
After connection to the mains, the "Initial settings"
menu appears in the display. You can now make
settings for your new appliance.
▯Language
▯Time format
▯Time
▯Date format
▯Date
▯Temperature format
▯Water hardness
Notes
‒The "Initial settings" menu appears only when the
appliance is switched on for the first time after
being connected to the mains or when the
appliance has been without electricity for several
days.
After the appliance is connected to the mains, the
GAGGENAU logo is displayed for approx. 30
seconds before the "Initial settings" menu is
automatically displayed.
‒You may change the settings at any time (refer to
the Basic settings section).
Setting the language
The preset language appears in the display.
1Turn the rotary selector to select the required
display language.
2Confirm with ™.
Note: If the language is changed, the system restarts.
This takes a few seconds.
Wire rack
for cookware, cake tins and
casseroles and for roasts
Stainless steel cooking
container, unperforated,
GN Z, 40 mm deep
for cooking rice, pulses and
cereals, for baking cake
baked on trays and for
collecting dripping liquid
during steaming
Stainless steel cooking
container, perforated,
GN Z, 40 mm deep
for steaming vegetables or
fish, for extracting juice and
for defrosting
GN 114 130 Stainless steel cooking container
GN 1/3, perforated, 40 mm deep, 1.5 l
GN 114 230 Stainless steel cooking container
GN 2/3, unperforated, 40 mm deep, 3 l
GN 124 130 Stainless steel cooking container
GN 1/3, perforated, 40 mm deep, 1.5 l
GN 124 230 Stainless steel cooking container
GN 2/3, perforated, 40 mm deep, 3 l
GN 340 230 Cast aluminium roaster GN 2/3,
165 mm high, non-stick coated
GN 410 130 Stainless steel lid, GN 1/3
GN 410 230 Stainless steel lid, GN 2/3
GR 220 046 Wire rack, chrome-plated, with feet
'HXWVFK
6SUDFKH

11
Setting the time format
The two possible formats 24h and AM/PM appear in
the display. The default is the 24h format.
1Use the rotary selector to select the desired
format.
2Confirm with ™.
Setting the clock
The time is shown in the display.
1Set the desired time using the rotary selector.
2Confirm with ™.
Setting the date format
The three possible formats D.M.Y, D/M/Y and M/D/Y
appear in the display. The default is the D.M.Y format.
1Use the rotary selector to select the desired
format.
2Confirm with ™.
Setting the date
The preset date appears in the display. The day
setting is already active.
1Set the day using the rotary selector.
2Touch the Csymbol to switch to the month
setting.
3Set the month using the rotary selector.
4Touch the Csymbol to switch to the year setting.
5Set the year using the rotary selector.
6Confirm with ™.
Setting the temperature format
The two possible formats °C and °F appear in the
display. The default setting is °C.
1Use the rotary selector to select the desired
format.
2Confirm with ™.
Setting the water hardness
"Water hardness" appears in the display.
1Check the mains water with the included
carbonate hardness test: fill the small
measurement tube with mains water up to the 5 ml
mark.
2Add drops of indicator solution until the color
changes from purple to yellow.
Important: count the drops and carefully swing
the measurement tube after every drop until the
liquids have mixed thoroughly. The number of
drops corresponds to the water hardness.
3Use the rotary selector to set the measured water
hardness. The value 12 is set by default.
7LPHIRUPDW
7LPH

'DWHIRUPDW
'DWH
7HPSHUDWXUHIRUPDW

12
4Confirm with ™.
Ending initial set-up
The display shows "Initial set-up complete. Calibrate
the appliance before cooking for the first time".
Confirm with ™.
The appliance enters standby mode and the standby
screen appears. The appliance is now ready to use.
Calibrate the appliance before steaming for the first
time. The appliance sets the boiling point.
Calibration
The boiling point of water depends on barometric
pressure. As air pressure drops with increasing
elevation, the boiling point drops as well. During
calibration, the appliance sets the boiling point to the
pressure conditions at the place where it is installed.
It is important that the appliance steams without
interruption for 20 minutes at 100°C. Do not open the
appliance door during this time.
Notes
‒Calibrate the appliance only when it is cold.
‒During calibration, the appliance generates more
steam than it normally would do.
1Turn the function selector to S.
2Select "Basic settings" using the rotary selector.
3Touch the ™symbol.
4Select "Calibration" using the rotary selector.
5Touch the %symbol.
6Fill the water tank with cold water and touch the
™symbol.
7Remove all accessories from the oven interior and
touch the ™symbol.
8The duration of 20.00 minutes appears. Touch I
to start calibration.
Calibration begins. The elapsing time is shown on the
display.
Note: Do not interrupt calibration. Do not turn the
function selector. Do not open the appliance door.
A message appears in the display once calibration has
ended. Touch ™ to confirm and turn the function
selector to 0.
After moving house
Repeat calibration so that the appliance adapts
automatically to the new installation location.
After resetting to the factory settings
After resetting to the factory settings in the basic
settings menu, you must repeat calibration.
Following a power cut
The appliance saves the calibration settings even in
the event of a power cut or disconnection from the
mains. Recalibration is not necessary.
Cleaning accessories
Before using the accessories for the first time, clean
them thoroughly using hot detergent solution and a
soft cloth.
:DWHUKDUGQHVV

3OHDVHFDOLEUDWHWKHDSSOLDQFH
EHIRUHILUVWFRRNLQJ
,QLWLDOVHWXSFRPSOHWH
&DOLEUDWLRQ

&$/

&$/

13
Activating the appliance
Standby
The appliance goes into standby mode if no function
has been set or the child lock is activated.
The brightness of the control panel is dimmed in
standby mode.
Notes
‒Different displays are available for standby mode.
The default setting is the GAGGENAU logo and
the clock. To change the display, refer to the Basic
settings section.
‒The brightness of the display depends on the
vertical viewing angle. You can adjust the display
using the "Brightness" setting in the basic
settings.
Activating the appliance
To exit standby mode, you can either
▯Turn the function selector,
▯Touch a control panel,
▯Open or close the door.
You can now set the desired function. You can read
about how to set functions in the respective chapters.
Notes
‒When "Standby screen = off" is selected in the
basic settings, you must turn the function selector
to exit standby mode.
‒The appliance returns to the standby screen if you
have not made any settings for a long time after
activation.
‒When the door is open, the interior lighting
switches off after a short time.
Operating the appliance
Filling the water tank
When you open the appliance door, you will see the
water tank on the side.
Caution! Use of unsuitable liquids may damage the
appliance
‒Only use fresh tap water, softened water or
uncarbonated mineral water.
‒If your tap water is very hard, we recommend that
you use softened water.
‒Do not use distilled water, highly chlorinated tap
water (> 40 mg/l) or other liquids.
You can obtain information about your tap water from
your water supplier. The water hardness can be
checked with the test set enclosed.
Fill the water tank before every operation (except for
"Hot air + 30% humidity", "Hot air + 0% humidity" and
"Drying program"):
1Open the appliance door and take out the water
tank (fig. A).
2Fill the water tank with cold water up to the "max"
mark (fig. B).
3Close the tank cover until you feel it engage.
4Slide in the water tank all the way (fig. C).
The tank must be flush with the water tank recess
(fig. D).
$
PD[
%
&'

14
Cooking compartment
The cooking compartment has four shelf positions.
The shelf positions are counted from the bottom up.
Note: You can use up to three insertion levels at the
same time (levels 2, 3 and 4).
Caution!
– Do not place anything on the cooking
compartment floor. Do not cover it with aluminium
foil. A build-up of heat could damage the
appliance.
The cooking compartment floor and the
evaporator dish must always be kept clear. Always
place ovenware in a perforated cooking container
or on a wire rack.
– Do not slide any accessories between the shelf
positions, or they may tip.
Always fully open the appliance door to the stop. In
this position, the open door will not swing back by
itself.
Inserting accessories
The wire rack and the perforated cooking container
feature a locking function. The locking function
prevents the accessories from tilting when they are
pulled out. The accessories must be inserted into the
cooking compartment correctly for the tilt protection
to work properly. When removing accessories, you
must raise them slightly.
When inserting the wire rack, check
▯that the engaging lug (a) is pointing upward
▯that the safety bar on the wire rack is at the back
and facing upwards.
When pushing in the perforated cooking container,
make sure that the recess (a) is pointing to the side.
Switching on
1Set the required heating mode using the function
selector. The chosen heating mode and the
default temperature are displayed.
2If you want to change the default temperature:
set the required temperature with the rotary
selector.
The preheating symbol “ appears on the display.
The bar continuously shows the preheating status.
When the set temperature is reached, a signal sounds
and the preheating symbol “goes off.
Note: The oven interior lighting stays switched off at a
temperature setting below 70°C
Topping up water:
A message appears in the display when the water tank
is empty. Fill the water tank up to the "max" mark and
insert it again.
Switching off:
Turn the function selector to 0.




D
D
D
D

15
After every use
Emptying the water tank.
1Open the appliance door carefully.
Hot steam will escape.
2Remove and clean the water tank.
3Thoroughly dry the seal in the tank cover and the
tank recess in the appliance.
Caution! Do not dry the water tank in the hot cooking
compartment. This will damage the water tank.
Drying the cooking compartment
mRisk of scalding!
The water in the evaporator dish may still be hot. Let it
cool down before emptying it.
1Remove soiling from the cooking compartment as
soon as it has cooled down. Burnt-on remains will
be much harder to remove later.
2Empty the evaporator dish with the included
cleaning sponge.
3Once it has cooled down, wipe out the cooking
compartment and the evaporator dish with the
enclosed cleaning sponge and dry well with a soft
cloth.
4Wipe kitchen units or handles if condensation has
formed on them.
Safety shut-off
For your protection, the appliance is equipped with an
automatic safety shut-off. Any heating process is
switched off after 12 hours if the oven is not operated
in this time. A message appears in the display.
Exception:
The long-term timer has been programmed.
Set the function selector to 0, then the appliance can
be operated again as usual.
Timer functions
You use the timer menu to make the following settings:
ŠShort-term timer
pStopwatch
6Cooking time (not in standby mode)
5Cooking time end (not in standby mode)
Calling up the timer menu
You can call up the timer menu from any mode. Only
from the basic settings, function selector is set to S,
the timer menu is not available.
Touch the M symbol.
The timer menu is displayed.
Timer
The timer runs independently of the other appliance
functions. You can enter a maximum of 90 minutes.
Setting the timer
1Call up timer menu.
The "Timer" Šfunction is displayed.
2Turn the rotary selector to set the required
cooking time.
3Start with I.
7LPHU


16
The timer menu closes and the time begins to count
down. The Šsymbol and the countdown appear in the
display.
A signal sounds once the time has elapsed. Touch the
™symbol to silence.
You can exit the timer menu at any time by pressing
the ' symbol. This erases the settings.
To stop the timer:
Call up timer menu. Touch Cto select the "Timer" Š
function and touch the Hsymbol. To allow the timer to
continue counting down, touch the symbol I.
Switching off the timer early:
Call up timer menu. Touch Cto select the "Timer" Š
function and touch the Žsymbol.
Stopwatch
The stopwatch runs independently of the other
appliance functions.
The stopwatch counts from 0 seconds up to
90 minutes.
It also has a pause function, which enables you to
temporarily stop the clock.
Starting the stopwatch
1Call up the timer menu.
2Touch Cto select the p"Stopwatch" function.
3Touch Ito start.
The timer menu is closed and the timing begins.
The p symbol and the elapsed time are shown in the
display.
Pausing and restarting the stopwatch
1Call up the timer menu.
2Touch Cto select the p"Stopwatch" function.
3Touch the Hsymbol.
The time stops. The symbol changes to IStart.
4Touch Ito start.
The time continues to run. When 90 minutes is
reached, the display pulsates and signal sounds. The
signal stops when you touch the ™symbol. The p
symbol on the display goes out. The process has
finished.
To switch off the stopwatch:
Call up the timer menu. Touch Cto select the p
"Stopwatch" function and touch the Žsymbol.
Cooking time
If you set a cooking time for your meal, the appliance
switches off heating automatically after the selected
time.
You can set a cooking time from 1 minute to 23 hours
59 minutes.
Setting a cooking time
You have set the heating mode and temperature and
you have placed your dish in the oven.
1Touch the Msymbol.
2Use Cto select the 6 "Cooking time" function.

6WRSZDWFK


6WRSZDWFK


17
3Set the desired cooking time using the rotary
selector.
4Press Ito start.
The appliance starts. The timer menu is closed. The
settings for temperature, heating mode, elapsing time
and cooking time end are shown in the display.
During the last minute of the cooking time the
remaining time is displayed in an enlarged format.
The appliance switches off after the cooking time has
elapsed. The 6symbol flashes and a signal sounds.
The signal stops when you touch the ™symbol, open
the appliance door, or switch the function selector
to 0.
Changing the cooking time:
Call up the timer menu. Use Cto select the 6
"Cooking time" function. Change the cooking time
using the rotary selector. Press Ito start.
Clearing the cooking time:
Call up the timer menu. Use Cto select the 6
"Cooking time" function. Clear the cooking time with
Ž. Return to normal operation with '.
Cancelling the entire operation:
Set the function selector to 0.
Note: You can also change the heating mode and
temperature during the cooking time.
End of cooking time
You can delay the cooking time end to a later time.
Example: it is 14:00. The dish requires a cooking time
of 40 minutes. You want it to be ready at 15:30.
Enter the cooking time and delay the cooking time end
until 15:30. The electronics system calculates the start
time. The appliance starts automatically at 14:50 and
switches off at 15:30.
Bear in mind that food which spoils easily should not
be left in the cooking compartment for too long.
Delaying the cooking time end
You have set the heating mode, temperature and
cooking time.
1Touch the Msymbol.
2Use Cto select the 5"Cooking time end"
function.
3Set the desired cooking time end using the rotary
selector.
4Press Ito start.
The appliance switches to standby. The heating mode,
temperature, cooking time and cooking time end
appear in the display. The appliance starts at the
calculated time and switches off automatically when
the cooking time has elapsed.
Note: If the 6symbol flashes: You have not set the
cooking time. Always set the cooking time first.
Once the cooking time has elapsed, the appliance
switches off. The 5symbol flashes and an audible
signal sounds. The signal stops early if you touch the
™symbol, open the appliance door, or set the
function selector to 0.
To change the cooking time end:
Call up the timer menu. Use Cto select the 5
&RRNLQJWLPH
&RRNLQJWLPHHQG



18
"Cooking time end" function. Set the desired cooking
time end using the rotary selector. Press Ito start.
To terminate the whole procedure:
Set the function selector to 0.
Long-term timer
With this function, the appliance maintains a
temperature between 50 und 230°C with the "Hot air"
heating function.
You can keep food warm for up to 74 hours without
having to switch the appliance on or off.
Bear in mind that food which spoils easily should not
be left in the oven for too long.
Note: You must set the long-term timer to "available"
in the basic settings (refer to the Basic settings
section).
Setting the long-term timer
1Set the function selector to ž.
2Touch the /symbol.
The default value 24 hrs at 85 °C appears in the
display. Press Ito start
–or–
Change the cooking time, the cooking time end,
the switch-off date and the temperature.
3Changing the cooking time 6:
Touch the $symbol. Set the required cooking
time using the rotary selector.
4Changing the cooking time end 5:
Touch the Csymbol. Set the required cooking
time end using the rotary selector.
5Changing the switch-off date q:
Touch the Csymbol. Set the required switch-off
date with the rotary selector. Confirm with ™.
6Changing the temperature:
Set the required temperature with the rotary
selector.
7Press I to start.
The appliance starts. / and the temperature appear
in the display.
The oven and display lighting are switched off. The
control panel is locked; no key tone sounds when you
touch the touch keys.
/RQJWHUPWLPHU

19
Once the set time has elapsed, the appliance stops
heating. Turn the function selector to 0.
Switching off:
To end the process, turn the function selector to 0.
Child lock
The appliance has a child lock to prevent children
operating it accidentally.
Notes
‒You must set the child lock to "Available" in the
basic settings (refer to the Basic settings section).
‒If there is a power cut when the child lock is
active, the child lock may be deactivated when the
power supply returns.
Activate the child lock
Prerequisite:
The function selector is set to 0.
Touch and hold the 0symbol for at least 6 seconds.
The child lock is activated. The standby screen
appears. The 0symbol is shown at the top of the
display.
Deactivating the child lock
Prerequisite:
The function selector is set to 0.
Touch and hold the 1symbol for at least 6 seconds.
The child lock is deactivated. You can set the
appliance as usual.

20
Basic settings
Your appliance can be individually adjusted in the
basic settings.
1Turn the function selector to S.
2Select "Basic settings" using the rotary selector.
3Touch the ™symbol.
4Turn the rotary selector to select the required
basic setting.
5Touch the %symbol.
6Set the basic setting using the rotary selector.
7Save with ™or cancel with 'and exit the current
basic setting.
8Turn the function selector to 0to exit the basic
settings menu.
The changes are saved.
Basic setting Permitted settings Explanation
Brightness Level 1, 2, 3, 4, 5*, 6, 7, 8 Sets the display brightness
Standby screen On*/Off
- Clock
- Clock + GAGGENAU logo*
- Date
- Date + GAGGENAU logo
- Clock + date
- Clock + date + GAGGENAU logo
Appearance of the standby screen.
Off: No display. Use this setting to reduce
the standby consumption of your appliance.
On: Several displays can be set, confirm
"On" with ™and use the rotary selector to
select the desired display.
The selection is displayed.
Display screen Reduced* / Standard If set to Reduced, after a brief period only
the most important information is shown.
Touch field colour Grey* / White Selects the colour of the symbols on the
touch fields
Touch field tone Tone 1* / Tone 2 / Off Selects an audible signal for when a touch
field is touched
Touch field tone
volume
Level 1, 2, 3, 4, 5*, 6, 7, 8 Sets the volume of the touch field tone
Preheating signal On* / Off The signal tone sounds when the cooking
compartment has heated up to the required
temperature.
Signal volume Level 1, 2, 3, 4, 5*, 6, 7, 8 Sets the volume of the audible signal
Water hardness 1-18 Use the test kit included to test the water
hardness of your mains water. Set the meas-
ured water hardness.
Calibration Calibrate the appliance Adjusts the boiling point
Time format AM/PM / 24 h* Display the clock in 24 or 12hour format
Time Current time Setting the clock
Clock change Manual* / Automatic Automatically changes the clock to daylight-
savings time. If automatic: Setting the
month, day and week for when the time
should be changed over. To be set for both
summer and winter time.
