Gaggia semi automatic User manual

CARE SHEET
Like a car, your espresso machine is an investment whose performance and longevity depend on proper care and
operation. To help ensure that you get the most out of your machine, we have outlined several key maintenance
procedures that will help to keep it brewing and steaming properly. The following information applies to most of
our Semi-Automatic espresso machines, unless indicated otherwise.
Group Head Cleaning:
Tools Required:
• Flat-Head Screwdriver
• Phillips Head Screwdriver
• Needle Nose Pliers
• A Sti-Bristled Brush
• Gaggia Decalcifying Solution
1. Remove the water tank, drip tray and grid, portalter, and power cord.
2. Lay the machine on its back.
3. Locate the shower screen. It is where you lock the portalter into place.
4. Remove the shower screen, it is fastened into the group head with a Phillips head screw in the center. Once the
screen is out, the 3/4 inch-thick aluminum shower holding plate is exposed. It is held in place by two 5mm Allen
bolts.
5. The shower holding plate should just drop out after you remove the Allen screws. If it does not, use a large
at-blade screwdriver to gently pry out the shower holding plate. Be careful not to damage the ridge that the
shower screen ts up into. If you do, a new holding plate is available.
Sometimes, the shower holding plate may really be stuck. To remove a plate that is stuck, you can use a pair of
needle-nose pliers. Open the pliers and stick the points into the holes where the Allen bolts were, then turn hard.
This should free the shower holding plate. Clean out any build-up that you see using a sti brush and some
descaling solution – the same kind you would use to descale the machine.
6. You should now be able to remove the group gasket. It is a large black rubber ring.
7. Once the parts are removed, use a sti brush and some descaler, like Gaggia Decalcier, to clean any build up in
the group head. You can also soak all metal parts in the descaler to remove tough stains and build up. DO NOT
soak any plastic pieces in the descaler, as it can compromise their integrity. This is also a good time to soak the
portlter head and coee baskets.
8. Once everything is clean, make sure you thoroughly rinse o any descaler or other detergent that you used dur-
ing the cleaning process.
9. Reassemble the group head and test to make sure it has been put back together correctly.

CARE SHEET
PAGE 2
Group Gasket Replacement:
The group gasket is a rubber gasket that rests inside of the group head of a semi-automatic espresso machine and
creates a seal to prevent leaks. Over time, the gasket becomes worn through use, which can lead to leaking during
the brewing process. When this happens, the group gasket must be replaced to ensure that the machine continues
to function properly. The following tutorial outlines the process of properly replacing a worn group gasket.
Tools Required:
• Number 2 Phillips Head screwdriver
• 5mm Allen Key
• Flat blade screwdriver
• Needle nose pliers
• Screw
1. Begin by removing the water reservoir, the portalter, the drip tray, the drip pan, the water reservoir cover, and
the pipe that drains into the drip tray.

CARE SHEET
PAGE 3
2. When all of these parts have been removed, lay the machine down on its back.

CARE SHEET
PAGE 4
3. Before removing the group gasket, the shower screen and the shower holding plate must be removed before-
hand. The shower screen is held in place by a number 2 Phillips-head screw, and the plate behind it by a set of
5mm Allen screws. Remove the shower screen, followed by the holding plate.

CARE SHEET
PAGE 5
4. If the shower screen plate does not fall out of the machine once the Allen screws have been removed, it may
need to be gently pried out. A at-head screwdriver or knife works well for this purpose. If the plate still will not
come out, a pair of needle nose pliers can be inserted into the holes for the Allen screws and turned until the
plate comes loose.
5. With the screen and plate removed, the group gasket will now be accessible.
Depending on the state of the gasket, one of several methods may be employed in its removal. Most commonly
though, the gasket can be removed by prying it from the group head. The gasket should be removed from the in-
side out (pry from the inside of the circle outward, not from the outer edge).
Alternatively, if the gasket cannot be pried loose, a screw and a pair of pliers can be used to remove it. Drive the
screw securely into the gasket using a screwdriver, taking care not to go all the way through.

CARE SHEET
PAGE 6
6. When the screw is secure, grasp it (with pliers if necessary) and pull until the gasket comes out.
7. After the gasket has been removed, make sure the surface inside of the group head is free of any debris or any-
thing else that could block the new gasket.
8. Insert your new gasket and replace the shower screen and shower screen plate. Once you have returned all of
the machine’s components to their proper places, lock the portalter into the group head. Remove it and lock it
several more times to help secure the gasket.
Steam Wand Cleaning & Assembly:
In order to ensure the performance quality of your Pannarello Wand, regular maintenance is necessary to prevent
milk residue from building up and impeding its functionality. It is important to clean your wand after each use,
with particular attention being paid to the air intake hole as you will no longer be able to create froth if it becomes
clogged.

CARE SHEET
PAGE 7
Gaggia Pannarello Wands are made out of ve components. The cap nut, the inner wand, a small plastic gasket, a
large rubber gasket, and the frothing sleeve. The following steps outline how to remove a Pannarello wand.
1. To remove the Pannarello Wand, begin by sliding the frothing sleeve o of the inner wand.

CARE SHEET
PAGE 7
2. To remove the inner wand, grasp it between your thumb and forenger and with your opposite hand, unscrew
the cap nut which holds it in place.
3. When the nut has been fully unscrewed, you will be able to slide the inner wand o of the steam arm, when you
do, take care not to lose the small plastic gasket located between the inner wand and the cap nut.
4. There is a second, larger rubber gasket that often remains lodged inside of the inner wand after removal. This
gasket can be pried out of the inner wand with the use of a small screwdriver or a similar tool.
5. Remove the cap nut and you can begin cleaning the Pannarello Wand.

CARE SHEET
PAGE 8
When you have cleaned your wand and it comes time to replace it, begin by sliding the cap nut, back onto the
steam arm, followed by the small gasket, and then the large gasket.
6. With the gaskets and cap nut in place, slide the inner wand back up the arm and back into the cap nut.
7. Tighten the cap nut until the inner wand is secure and replace the frothing sleeve. When everything is back in
place, gently tug on the wand to make sure that it is secure and won’t slide o during frothing.
8. There may be some slight variation in the designs of the wands that come with each machine, but the process
outlined above applies to all varieties of Pannarello Wands currently oered by Gaggia.

CARE SHEET
PAGE 9
Decalcifying:
Tools Required:
• Gaggia Decalcifying Solution
• One container that will hold the same amount of liquid as your water reservoir
• Another small container to catch water from the group head
1. Remove the machine’s water reservoir and empty all of the liquid from it.
2. Mix or dilute your Gaggia Decalcier according to the directions in a separate container.
3. Fill the reservoir with the solution.
4. Reattach the water reservoir to the machine.
5. Turn the machine on.
6. Set a large container underneath the steam wand to collect the decalcifying solution.
7. Set another container underneath the brew spout to collect more of the decalcifying solution.
8. Set the machine up so that hot water will be dispensed from the steam wand when the steam valve is opened.
9. Start the machine so the solution begins owing from the steam arm.
10. Allow about 2 oz of solution to be dispensed from the steam arm.
11. Stop the ow and close the steam valve.
12. Now, press your brewing button and allow about 2 oz to of solution to be dispensed from the group head.
13. Allow the machine to sit for the amount of time specied on the cleaner packaging. This is typically two to ve
minutes.
14. Repeat steps 10 - 14 until all of the decalcifying solution has drained into the containers.
15. Remove the containers and discard the liquid that has been collected.
16. Rinse the water reservoir thoroughly and then ll it with the type of water you usually use for brewing.
17. Re-attach the reservoir to the machine.
18. Rinse the decalcifying solution out of the machine by allowing a continuous ow of water from the steam arm
until the water tank is empty, or nearly empty. Close the knob when the process is complete.
19. Rell your water tank and place it back onto the espresso machine.
20. Press the brew button to dispense 2-4 oz of water from the group head to ush this area clean.
The decalcifying process is now complete. If you are unsure if all of the descaling solution has been ushed from
your machine, you can use baking soda to test if the acids from the solution are still present in the water.
