GAI-Tronics PHP400 User manual

Doc. No. 502-20-0130-001 Iss 4. Jan 2016. (CN39819-001)
Installation and User Guide
PHP400 Help Point
VoIP version
48V DC power supply
IMPORTANT
THIS PRODUCT MUST BE CONFIGURED PRIOR TO
INSTALLATION
PLEASE READ THIS GUIDE FIRST
GAI-TRONICS
A division of Hubbell Ltd.

400mm VoIP Help Point, 48V VoIP. 2
CONTENTS
1. Safety and Care Information.....................................................................................3
2. Product Description and Features ............................................................................3
3. Before Installation.....................................................................................................5
3.1. Opening the Unit...........................................................................................5
3.2. Initial Network set-up ....................................................................................5
3.3. Site requirements..........................................................................................6
4. Installation and dimensions ......................................................................................6
4.1. General.........................................................................................................6
4.2. Units dimensions and weight ........................................................................7
4.3. Opening the Unit...........................................................................................7
4.4. Installation method........................................................................................7
5. Connections .............................................................................................................9
5.1. DC Power connections..................................................................................9
5.2. IMPORTANT SAFETY INFORMATION ........................................................9
5.3. Connections to the VoIP module.................................................................10
6. Cleaning .................................................................................................................11
6.1. Normal Cleaning .........................................................................................11
6.2. Stainless Steel Push-buttons ......................................................................11
6.3. Graffiti.........................................................................................................12
6.4. Anti-Graffiti Coating.....................................................................................12
7. Aftercare.................................................................................................................12
8. Repairs and Spare Parts. .......................................................................................13
9. Technical Specifications .........................................................................................14
10. CE Declaration .......................................................................................................17
11. Licensing Notices ...................................................................................................18

400mm VoIP Help Point, 48V VoIP. 3
1. Safety and Care Information
▲
IMPORTANT:
THIS PRODUCT CAN CONTAIN HAZARDOUS VOLTAGES. IT IS ESSENTIAL
THAT THE WATERPROOF SEAL IS PROPERLY MADE DURING INSTALLATION,
TO ENSURE THAT WATER CANNOT GET INTO THE ENCLOSURE. THE
INGRESS OF WATER CAN CAUSE ACCESSIBLE PARTS OF THE TELEPHONE
TO BECOME LIVE, AND THEREFORE MUST BE PREVENTED AT ALL COSTS.
▲
Please read these instructions thoroughly before starting installation. These
products must be installed by competent personnel familiar with electrical and
network installations.
▲
Re
fer to safety information is section
5.2
if hazardous voltages (eg mains) are
to be connected to this product.
▲
Make sure that correctly
-
sized cable glands are used, and that cables are
securely clamped in the clamps provided. Failure to do so could result in an
unsafe installation.
▲
Take adequate precautions when opening the case or installing.
I
solate
connections elsewhere before opening.
2. Product Description and Features
This manual describes the voice over internet protocol (VoIP) version of the GAI-Tronics
400mm circular Help Point. This product is based on the standard VoIP product range
and has been specifically configured for use on rail platforms, with features including:
•Weather and vandal resistant casing
•Large, palm-operable, vandal resistant buttons
•Internal induction loop
•Raised text and Braille legends
•Wide operating temperature range
•48Vdc powered
•Automatic outgoing call diversion (memory list)
•SIP compatible (RFC3261)
•Real-time alarm reporting via email or Syslog
•Configurable via web page, serial link or download
•4 auxiliary inputs, 2 volt-free contact outputs
Models are available with different pushbutton options.
The Help Point casing is a two-part construction with electronics in both sections. The 2
sections are held together with 4 security screws though the sides, and there are
several cables between the 2 sections. Cable entry points are provided to top and
bottom of the casing. Blanking plugs are provided for unused cable entries.

400mm VoIP Help Point, 48V VoIP. 4
Speaker
Pushbutton
Microphone
Raised text /
Braille legend
Call progress
LED
Security fixings
(4 positions)
Top cable
entry point
Lower cable
entry point
VoIP module
Induction loop
amplifier
Serial
connector
Front section
Rear section
Earth stud
Earth stud
48-12V
DC-DC
converter
Induction loop
audio feed
48V DC
power cable
Earth strap
RJ45
socket
Incoming
power
terminals
Induction
loop coil

400mm VoIP Help Point, 48V VoIP. 5
3. Before Installation
IMPORTANT
THESE UNITS MUST BE CONFIGURED BEFORE THEY ARE INSTALLED.
All units have identical settings as factory defaults, so each one must be individually
configured to give it a unique identity on the network. This may be difficult to do after
the units are installed.
IMPORTANT: After changing the IP address of the telephone you will need to browse
to the new IP address to access the configuration, instead of the default 192.168.1.2.
IMPORTANT: If DHCP is enabled, ensure that there is a suitable DHCP server available
on the network and that you have a means by which to discover the IP address of the
telephone allocated by the DHCP server. There is no other way to access a DHCP
enabled VoIP telephone over the network without being able to find the IP address
allocated by the DHCP server.
3.1. Opening the Unit
To open the case, undo the 4 security screws around the edge of the unit. These screws
are normally Torx type with a centre security pin.
The front section is fitted over the rear section and can be gently lifted clear.
Take care when separating the 2 sections – there are up to 4 cable sets between the
2 halves:
1. Induction loop audio (2 conductors)
2. DC power (2 conductors)
3. Earth cable
4. Ethernet cable (if already through one of the cable entries in the rear section).
These cables are deliberately short, but will allow the front section to sit to the left of the rear
for set-up purposes.
3.2. Initial Network set-up
Factory default settings are:
Item
Default setting
DHCP OFF
IP address 192.168.1.2
Net mask 255.255.255.0
Log in User Name user
Log in Password password
Serial port settings 115200 baud, 8 data bits, 1 stop bit, no
parity, no handshaking.
Hostname Each unit has a unique hostname (set to
the serial number of the main PCB)
These settings must be changed prior to installation: as a minimum the unit must either be
set to DHCP or assigned a unique static IP address.

400mm VoIP Help Point, 48V VoIP. 6
Refer to the VoIP configuration guide 502-20-0119-001 for full details on all settings.
The configuration guide is available from www.gai-tronics.org/support/voip-support/
To configure the unit it must first be powered, but note that the VoIP module itself can be
powered via PoE if required. External power is only necessary because of the induction loop
system.
As a quick guide the 2 most common methods of configuration are:
1. Make a direct network connection to the unit (for example using a crossover cable to
a laptop), then access the unit's web pages by browsing to 192.168.1.2, or
2. Make a serial connection to the unit, enter the login and password, then use CLI
commands such as:
IP SET DHCP ON, or
IP SET ADDRESS ...
IP SET MASK ...
etc.
The current IP settings can be displayed by entering IP SHOW ALL.
3.3. Site requirements
Having configured the unit for the intended network, ensure that the following are available
for installation:
1. Power supply: 48V dc @ 2A.
2. Ethernet connection – 10/100BaseT on CAT5/CAT5e UTP cable, the cable run is
normally limited to 95m.
3. This is normally a two-person installation, due to the size/weight of the unit and due
to the need to connect cables between the 2 sections.
4. Installation and dimensions
4.1. General
IMPORTANT
THIS PRODUCT CAN CONTAIN HAZARDOUS VOLTAGES. IT IS ESSENTIAL
THAT THE WATERPROOF SEAL IS PROPERLY MADE DURING INSTALLATION,
TO ENSURE THAT WATER CANNOT GET INTO THE ENCLOSURE. THE
INGRESS OF WATER CAN CAUSE ACCESSIBLE PARTS OF THE TELEPHONE
TO BECOME LIVE, AND THEREFORE MUST BE PREVENTED AT ALL COSTS.
All possible measures must be taken to ensure water, fluid or dust does not
contaminate the internal components of the unit whilst unpacking, preparing and
installing it in inclement weather conditions or by negligence.
Do not drill any additional holes in the casing. Make sure any unused cable
entry or mounting holes are properly sealed against water or dust ingress.
Failure to do so may result in an unsafe condition and will invalidate your
warranty.

400mm VoIP Help Point, 48V VoIP. 7
4.2. Units dimensions and weight
Overall diameter 405mm
Depth (rear surface to front face) 88mm
Pushbutton height from front face 10mm
Unit weight 6.5kg
Mounting centres 4 x 7mm holes on 145 x 270mm centres,
see drawing 112-11-0081-001 appended to
this manual.
Cable entries 5 off 20mm gland entry points are provided,
with blanking plugs to blank off any that are
not used:
2 x rear
2 x lower
1 x upper (used for aerial)
Positions are detailed on drawing
112-11-0081-001 appended to this manual.
4.3. Opening the Unit
To open the case, undo the 4 security screws around the edge of the unit. These
screws are normally Torx type with a centre security pin.
The front section is fitted over the rear section and can be gently lifted clear.
Take care when separating the 2 sections – there are 4 cable sets between the 2 halves:
5. Induction loop audio (2 conductors)
6. DC power (2 conductors)
7. Earth cable
8. Ethernet cable.
These cables are deliberately short, but will allow the front section to sit to the left of the rear
for set-up purposes if required.
4.4. Installation method
The Help Point is intended for vertical installation to a solid wall or suitable post as detailed
below.
1. Ensure the Help Point has been configured for the network as described in section
3.2.
2. Choose a suitable location for the Help Point, bearing in mind the weight of the unit,
and that the operating button(s) should normally be in the range 1200 – 1400mm
from the ground for ease of access by people in wheelchairs.
3. Mark the wall or surface with fixing centres as shown above. If necessary use the
rear section to help mark the centres. Do not use the rear section as a drilling
template.

400mm VoIP Help Point, 48V VoIP. 8
4. Select fixing screws or bolts appropriate to the type of wall or surface, suitable to
support the unit. Drill fixing holes to suit.
5. Separate the front and rear sections of the Help Point, taking care to disconnect
interconnecting cables as described in section 3.1.
6. Secure the rear section to the wall, making sure that the fixing holes are sealed to
prevent water ingress using nylon washers or other appropriate sealing methods.
7. Bring power and Ethernet cables into the unit through one or both of the cable entry
holes. Cables will normally be contained in conduit, but glands may also be used.
8. The power cable is terminated directly to the terminal block provided, and secured
using the cable restraint.
9. The ethernet cable should be left long enough to allow connection to the front section
(approximately 450mm from entry point) and terminated with an RJ45 plug.
10. Ensure that cable entries are sealed to prevent water ingress. If glands are used do
not over tighten – CAT5 UTP can be damaged by excess tightening. If only one cable
entry is used, the blanking plug fitted to the second position must be left in place.
11. Connect induction loop audio, dc power, ethernet and earth cables to the front
section of the case.
12. Apply power. The LED on the internal PSU should illuminate. After approximately 1
minute the red "heartbeat" LED inside the VoIP module should be visible flashing.
13. Fit the front section over the rear section and secure in place using the 4 security
screws.
+12V
0V
+48V DC
EARTH
0V
EARTH
+48V DC
CAT5
EARTH
INDUCTION LOOP AUDIO
48-12V
DC-DC
AFIL Amp.
Screw
terminals RJ45
socket
Screw
terminal
block
Bullet
connectors
M6
Earth
stud
Front section Rear section
Wiring scheme showing interconnection points between front and rear sections

400mm VoIP Help Point, 48V VoIP. 9
5. Connections
5.1. DC Power connections
Connect a 48V DC power supply to the terminal block as shown
on the connection label.
If a 48V power supply is not available, GAI-Tronics can supply a
suitable unit, see spare parts (section 8).
One power supply cannot supply more than one PHP400 - a
separate, isolated supply must be provided for each unit..
Cabling from the 48V supply to each PHP400 must be sufficient
to provide the required current (2A) without causing a significant
voltage drop over the required distance.
The fuse must always be replaced by the correct type, ie 3.15A
T (20x5mm).
5.2. IMPORTANT SAFETY INFORMATION
Please pay particular attention to the following points if hazardous voltages (>48V) are
to be connected to either of the control outputs:
The circuits that the relay contacts are connected to must be of the same type, i.e. Both
mains, both SELV or both TNV. It is not permissible to mix the types of circuit
connected to these relays.
It is acceptable to connect mains circuits in the frequency range 45 to 65 Hz to these
relays.
For currents up to 3 Amps, the minimum conductor cross sectional area must be 0.75
mm
2
(19awg) for flexible cords, or 1mm
2
(18awg) for other cables. For currents up to 10
Amps, the minimum conductor cross sectional area must be 1 mm
2
(18awg) for flexible
cords, or 1.5mm
2
(16awg) for other cables.
Circuits connected to these relays must be protected against over-current and short
circuit by a suitable method, for example a fuse or circuit breaker rated at less than or
equal to the relay contact rating.
The use of an isolated supply or an RCD is recommended for these circuits.
Cables or cords used must be insulated and and have an overall insulated outer sheath
covering both conductors. They must be appropriately rated and certified. Examples of
suitable ratings for PVC cords are IEC 60227 designation H05 VV-F or H05 VV-F2, or
for rubber insulated cords, IEC 60245 designation H05 RR-F
Always ensure that sufficient clearance is maintained between hazardous
voltages and any accessible conductive parts.

400mm VoIP Help Point, 48V VoIP. 10
Clamp cables by bending tabs
5.3. Connections to the VoIP module
Make the appropriate connections as shown on the diagrams below.
Take particular note of the cable clamping arrangements – all cables must be securely
clamped in the clamps provided.
0V +0V
OP1
OP2 -
IP1 IP2 IP3 IP4
48Vdc
1A-T
Barrier
Clamp (on
secondary
insulation)
Connector Legend
Connection
to Output 1
Connection
to Input 1
Cabling example showing connections to Input 1, Output 1 and external 48Vdc.
48Vdc Connection
0V +0V
OP2
OP1 -
IP1 IP2 IP3 IP4
48Vdc
1A-T
RJ45 Network connector
(under back-box)
Power connections
Input connections
Serial port
Output connections
Clamping position
for power and input
cables
Clamping position
for output cables
Back-box

400mm VoIP Help Point, 48V VoIP. 11
Connection types and ratings:
•LAN connection - RJ45 on Cat5 or Cat5e UTP cable
•All other connections - 0.14mm² to 2.5mm² (26 to 14awg) for rigid/solid cables,
0.14mm² to 1.5mm² (26 to 16awg) for flexible/stranded cable.
Refer to safety information in section 5.2
Output 1 - rating 2A at 250Vac, 2A at 30Vdc
Output 2 - 3A at 250Vac, 1A at 24Vdc
(Note: for Output 1, a continuous current of 2A will cause a 22°C temperature rise to the
PCB area close to the terminals after 10mins. If the current is below 1A this
temperature rise will be less than 5°C. Output 2 will not give any significant temperature
rise up to its rated current of 3A)
Power Connection - 48Vdc from external supply, connected via terminal block in rear
section. Note that the VoIP module itself requires only 100mA from the 48V supply –
the majority of the power is required by the induction loop amplifier fed by the 48-12V
DC-DC converter.
Control inputs - for connection to voltage free contacts only. Internal pull-up resistor
source current = 300uA. These inputs form part of a SELV circuit and precautions must
be taken to prevent hazardous voltages being applied to these circuits
Output 2
Output 1
Common
(for inputs) 48Vdc
1 2 3 4
Inputs
- +
Network
End view of Connectors
6. Cleaning
Recommended cleaning methods are outlined below:
6.1. Normal Cleaning
For normal cleaning we recommend "Virosol", manufactured by Clover products.
Carefully follow manufacturer's instructions for storage, handling and use.
6.2. Stainless Steel Push-buttons
Stainless steel push-buttons, where fitted, should be cleaned regularly especially if the
Help Point is in a marine environment. The stainless steel may show signs of
discolouration or rust – this will not damage the buttons or impair their performance but
may look unsightly and can be cleaned off using normal cleaning agents as above. In
extreme cases a mild abrasive may be necessary.

400mm VoIP Help Point, 48V VoIP. 12
6.3. Graffiti
For graffiti, paint and ink we recommend the use of 3M GR2 graffiti stain remover.
CAUTION: This is a very aggressive chemical. Pay close attention to the manufacturer's
recommendations for storage, handling and use.
6.4. Anti-Graffiti Coating
Where polyurethane anti-graffiti coating or paint has been specified (as an option), it
can be cleaned using Methylated Spirits or Methyl Isobutyl Ketone. Other cleaners can
be used but should be tested on a small area first.
7. Aftercare
The purchase of your GAI-Tronics product does not end our commitment to you.
In addition to our warranty obligations, GAI-Tronics are able to offer various levels of
maintenance packages, installation and commissioning packages and technical support,
from ad-hoc repairs to full maintenance contracts.
By choosing GAI-Tronics as your aftercare provider you are ensured of manufacturer
expertise and ISO 9001-certified quality control standards throughout the life of the
product.
We can also supply a full range of accessories including mounting posts, beacons and
high-volume sounders.
Contact GAI-Tronics for details. www.gai-tronics.co.uk

400mm VoIP Help Point, 48V VoIP. 13
8. Repairs and Spare Parts.
It is recommended that Help Points are returned to GAI-Tronics for service or repair, to
ensure that any repairs are fully tested. In the event of work having to be carried out on
site, the following spare parts are available:
Part No
Descr
iption
Notes
112-02-0081-11W Complete Help Point This is a single button, 48V supply,
VoIP unit. Other configurations are
available
999-02-1075-000 Main VoIP PCB When ordering, specify the part
number of the Help Point that it is for.
999-02-1098-003 Carrier PCB Includes microphone
610-99-0421-000 48-12V DC-DC converter
610-99-0425-001 Mains to 48V Power Supply Mounted external to Help Point
(usually in electrical cabinet). Not
water protected.
500-02-0505-002 Induction loop amplifier Encapsulated module with flying leads

400mm VoIP Help Point, 48V VoIP. 14
9. Technical Specifications
Product features
Power supply Nominal 48Vdc, 1A.
(Voltage range: 36-56V)
Ringer
loudness
80dBA @ 1m
Network 10/100 BaseT Ethernet RJ45, Cat5 or Cat5e UTP
Static IP provisioning or DHCP
Call Control
Signalling
SIP (RFC3261 compliant)
Loose routing
External
inputs
4 auxilliary inputs, volt free, (internal pull-up resistor source current =
300uA)
External
outputs
Ratings:
Output 1 - 2A at 250Vac, 2A at 30Vdc
Output 2 - 3A at 250Vac, 1A at 24Vdc
REFER TO SAFETY INFORMATION IN SECTION 5.2
(Note: for Output 1, a continuous current of 2A will cause a 22°C
temperature rise to the PCB area close to the terminals after 10mins. If
the current is below 1A this temperature rise will be less than 5°C.
Output 2 will not give any significant temperature rise up to its rated
current of 3A)
Codecs &
Audio
G.711 A-Law
G.711 µ-Law
G.722
G.729
G.723.1 MP-MLQ
G.723.1 ACELP
Codec preference sequence
DTMF in-band / out-of-band (RFC2833)
Configurable comfort tones (to emulate national tones)
Configuration Embedded web server
Embedded Telnet server
Configuration file download
Direct serial connection (9 way D type female connector)
Command line interface
SNTP with timezone and daylight saving
Automatic updating via TFTP
Password protection
Monitoring
and Reporting
Real-time over TCP/IP Syslog application or email.
Embedded SMTP client
Automatic fault reporting
Handset integrity monitoring
Call Diversion Configurable call lists (max 20 entries)
Numbers or URIs (with comfort tones)
Divert to next in list if the call fails

400mm VoIP Help Point, 48V VoIP. 15
Environmental limits
Temperature: Operating: -20°C to +60°C (-4°F to 140°F)
Storing: -40°C to +70°C (-40°F to 158°F)
Relative
Humidity
Up to 95% (non-condensing)
Ingress
Protection
IP65 to EN60529:1992 – Degrees of protection provided by enclosures.
Physical characteristics
Casing
material
Front section: Stainless steel
Rear section: Mild steel, zinc coated
Finish: Polyester powder coated
Weight 6.5kg (11lbs).
Dimensions 405mm diameter. 88mm depth. Buttons may protrude a further 10mm
from front face.
Compliance to standards
European
Directives
1999/5/EC – European Radio & Telecommunications Terminal
Equipment Directive.
2011/65/EC - Restriction of the use of certain hazardous
substances in electrical and electronic equipment (recast)
(RoHS 2) Directive
2002/96/EC - Waste Electrical and Electronic Equipment (WEEE) Directive
EMC EN55022 – Information technology equipment. Radio disturbance
characteristics.
EN55024– Information technology equipment. Immunity characteristics.
EN 50121-4 - Railway applications, emission and immunity
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference to radio
or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
•Re-orient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help

400mm VoIP Help Point, 48V VoIP. 16
Safety EN60950-1 – Specification for information technology equipment, including
electrical business equipment.
BS6317:1992 (Clause 13.9) - Specification for simple telephones for
connection to public switched telephone networks run by certain public
telecommunication operators.
EN50371 - Generic standard to demonstrate the compliance of low power
electronic and electrical apparatus with the basic restrictions related to
human exposure to electromagnetic fields (10 MHz - 300 GHz). General
public.
Recycling
Information
The symbol shown here and on the product means that the
product is classed as Electrical or Electronic Equipment and
should not be disposed with other household or commercial waste
at the end of its working life.
The Waste of Electrical and Electronic Equipment (WEEE)
Directive has been put in place to recycle products using best
available recovery and recycling techniques to minimise the impact
on the environment, treat any hazardous substances and avoid
the increasing landfill.
Business users should contact their suppliers and check the terms
and conditions of the purchase contract and ensure that this
product is not mixed with other commercial waste for disposal.

400mm VoIP Help Point, 48V VoIP. 17
10. CE Declaration
A copy of the current CE Declaration of Conformity is available from our website
www.gai-tronics.org/support/certificates-approvals/

400mm VoIP Help Point, 48V VoIP. 18
11. Licensing Notices
The firmware in GAI-Tronics VoIP products contains modules subject to licensing and
copyright as follows:
Module License
u-boot GPL V2
Linux kernel GPL V2
Busybox GPL V2
Opal/PWLib Mozilla Public License V1.1
Modutils GPL V2
MTD GPL V2
NTP David L. Mills Copyright Notice
These licence and copyright notices are available in full from our website at
www.gai-tronics.org/support/voip-support/

400mm VoIP Help Point, 48V VoIP. 19

400mm VoIP Help Point, 48V VoIP. 20
GAI-TRONICS
A division of Hubbell Ltd.
Brunel Drive, Stretton Park
Burton on Trent, DE13 0BZ
England
Tel: [phone], Fax: [phone]
www.gai-tronics.co.uk
The policy of GAI-Tronics is one of continuous improvement, therefore the Company
reserves the right to change specifications without notice
