GAI-Tronics 12562-109 Manual

Pub. 42003-236C
GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA
610-777-1374 800-492-1212 Fax: [phone]
VISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS
GAI-TRONICS®
AHUBBEL LCOMPAN Y
Voice Annunciation PCBA Field
Installation Kit
MODEL 12562-109
Confidentiality Notice
This manual is provided solely as an operation, installation, and maintenance guide and contains sensitive
business and technical information that is confidential and proprietary to GAI-Tronics. GAI-Tronics
retains all intellectual property and other rights in or to the information contained herein, and such
information may only be used in connection with the operation of your GAI-Tronics product or system.
This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party.
General Information
The Model 12562-109 Voice Annunciation (VA) PCBA Field Installation Kit consists of a printed circuit
board assembly (PCBA), two lithium AA batteries, and three standoffs for mounting the VA PCBA to
the Main PCBA. The kit is designed to be used only in the following GAI-Tronics RED ALERT®Series
Emergency Telephones:
393-00x393AL-00x394AL-00x396-00x
397-00x397-00xCB 397-00xRT 397-00xTP
398-00x398-00xCB 398-00xRT 398-00xTP
Electrostatic Discharge (ESD) Protection
Your telephone may have an earth ground terminal provision. If so, ensure that it is connected to ground
in accordance with all local safety regulations and the National Electrical Code (NEC). Grounding has to
be ensured for safe and stable communications. Do not use long and coiled ground wires. Trim ground
wires to the required length. Use a star configuration whenever possible.
Installation
Removing the Front Cover
Use the Model 233-001 Security Screwdriver (Torx T-25 security tip) to remove the four (or six,
depending on the telephone model) front cover security screws, and remove the front cover after
disconnecting the telephone line.

Pub. 42003-236C
MODEL 12562-109 VOICE ANNUNCIATION PCBAFIELD INSTALLATION KIT Page 2 of 2
f:\standard ioms - current release\42003 kit manuals\42003-236c.doc
02/13
Installing the Voice Annunciation PCBA
1. Insert the three nylon standoffs on the existing Main PCBA in the locations shown in Figure 1.
2. Align the plugs on the Voice Annunciation PCBA standoffs with the Main PCBA as shown in Figure
1 and snap in standoffs.
3. Install the two AA lithium batteries in the correct +/−orientation.
4. Reconnect the telephone line.
5. Refer to Pub. 42004-438, RED ALERT®Installation Manual (“Voice Annunciation Option” section)
for set-up and playback instructions.
6. Use the Model 233-001 Security Screwdriver (Torx T-25 security tip) to re-install the four (or six,
depending on the telephone model) front cover security screws (10–12 in-lbs. of torque
recommended).
Figure 1. Installation of 12562-109 Voice Annunciation PCBA to Existing PBCA
