Gainbridge GT3012 User manual

1/ 12
Magnetic &Portable GPS tracker with Installation in Seconds
GT3012

2/ 12
Content
1. GT3012 FEATURES .................................................................................................................................................. 4
KEY FEATURES:.................................................................................................................................................................... 4
APPLICATION: ..................................................................................................................................................................... 4
HARDWARE SPECIFICATIONS .................................................................................................................................................. 4
2. PRODUCT IMAGE .................................................................................................................................................... 5
3. BUTTON OPERATION............................................................................................................................................... 5
3.1 BUTTON OPERATION FOR GPS FUNCTION........................................................................................................................... 5
4. INSTALLATION MANUAL.......................................................................................................................................... 5
4.1 SIM CARD PRE-INSTALLATION,SPECIFICATION NOTE ............................................................................................................. 5
4.2 SIM CARD INSTALLATIONS AND REMOVAL .......................................................................................................................... 6
5. WHAT TO DO TO MAKE THE DEVICE BE ONLINE ...................................................................................................... 6
6. OPERATION COMMANDS GUIDE............................................................................................................................. 6
6.1 SET APN ..................................................................................................................................................................... 6
6.2 REGISTERING THE “MASTER”CONTROLLER......................................................................................................................... 6
6.3 EMERGENCY TAKEOVER FUNCTION..................................................................................................................................... 7
6.4 CHANGING THE PASSWORD.............................................................................................................................................. 7
7. MOTION DETECTED ALERT ...................................................................................................................................... 7
7.1 VIBRATION SENSITIVITY ................................................................................................................................................... 7
7.2 SMS OR CALL ALERT SETTINGS ....................................................................................................................................... 7
8. SMS LOCATION QUERY............................................................................................................................................ 8
8.1 SMS: *LOCATE* ........................................................................................................................................................... 8
8.2 SMS: *LOCATEADDRESS*................................................................................................................................................ 8
8.3 SMS: *LOCATEMAP*..................................................................................................................................................... 8
9. WEBSITE TRACKING ................................................................................................................................................ 8
9.1 ROUTETRACK ................................................................................................................................................................ 9
9.1.1 By button........................................................................................................................................................... 9
9.1.2 By SMS............................................................................................................................................................... 9
9.2 CHECK FUNCTION .......................................................................................................................................................... 9
9.3 TRACK OFF................................................................................................................................................................... 9
10. DEEP SLEEP ........................................................................................................................................................... 9
10.1 SMS: *SLEEP*1-99* ................................................................................................................................................ 10
10.2 SMS: *SLEEPOFF*..................................................................................................................................................... 10
11. GEOFENCING........................................................................................................................................................10
11.1 SET THE GEOFENCE .................................................................................................................................................... 10
11.2 DISABLE THE GEOFENCE .............................................................................................................................................. 10
12. STATUS QUERY .....................................................................................................................................................10
13. MULTI CONTROLLER.............................................................................................................................................10
14. DEVICE INFORMATION.........................................................................................................................................10
15. BRANDING SETTINGS ...........................................................................................................................................11

3/ 12
16. COMMAND SETTING LIST.....................................................................................................................................11

4/ 12
GT3012 USER GUIDE
1. GT3012 Features
Designed to survive in the harsh conditions, delivering regular and accurate location records using
state of the art GPS over the cellular network, the GT3012 delivers superb performance less
expensively than ever before. Built to exacting specifications, the GT3012 is weatherproof and
durable. With the built-in super-magnets in the case, make it an ideal manager for remote and
un-powered installations such as heavy construction equipment, RV’s and vehicles of all
descriptions. With its super-magnet case, the GT3012 can be installed under a vehicle for a quick
and accurate covert tracking installation.
Flexible in its programming options, the GT3012 can be easily reprogrammed via SMS by the user
to set and reset it’s scheduled and motion detected location reporting. The GT3012 also supports a
deep sleep function, and with its internal 2200mAh rechargeable Lithium-Ion battery, can wait for a
month in a true “sleeping standby” for motion or vibration to wake it into pre-programmed periodic
location reporting when it starts moving.
Key Features:
■Quad Band GSM, Enable to Work Worldwide
■U-Blox GPS Chip, 50 Channels, Accuracy:10m
■Weather-Proof; Industrial Strength Magnet
■Magnetic Mount Allow to Attach and Remove from Any Metal Surface Easily
■Circular Geo-fencing, Remote Listen-in
■Tracking on Movement/ Standby on Motionless
■Different Report Basing on Movement/Motionless
■2200mAh Battery, Max 90 Days Standby (1 report per day),
Capacity 2200mAh, 8800mAh, 15400mAh Optional
■Multiple Power Saving Mode Available
■SMS/GPRS Tracking and Query
■Address, Position, Map Link Available on Query
■Size: 105x 60x 23mm (LxWxH)
Application:
■Vehicles, Container, Mobile Assets, Trailer, Non-Powered Equipments etc...
Hardware Specifications
Size: 105mm x 60mm x 23mm
Storage Temp: -40 to 85°C
Operating Temp: -10 to 55°C
GPS: U-BLOX G6010-ST, 50 channels
Antennae: Internal
Frequency: L1 1575.42 MHz
Position Accuracy: <5m
Sensitivity: Tracking: –161dBm
Cold starts: –148dBm

5/ 12
Hot starts: –156dBm
Cold start: <27s
Warm Start: <5s
Hot Start: 1s
A-GPS: AssistNow Online and AssistNow Offline services,
OMA SUPL compliant
GPRS: MTK 6223D
Quad band; 850/900/1800/1900 MHz
GPRS Class 12
Antennae: Internal
Power: Rechargeable, 2200mAh, Lithium-Ion Battery
Built-in Vibration/motion sensing
2. Product Image
3. Button Operation
3.1 Button Operation for GPS function
NOTE: “button” presses must be less than 3 seconds each in all uses
This control button is at the middle top of the device
a. On: Press power button 5 times. Both blue and green indicating light will be on for 30 seconds.
b. Off: Press power button 3 times. Indicating light will keep flashing for 10 seconds
c. Reset: Press power button 10 times to reset all settings
4. Installation Manual
4.1 SIM Card Pre-installation, specification note
a. GSM Sim Only
b. SIM card should have its GPRS function enabled.
c. SMS request will function only if Caller ID function is enabled.
d. If SIM card is locked via PIN, please unlock SIM.

6/ 12
4.2 SIM Card Installations and Removal
b. Open waterproof rubber
c. Insert SIM card into the SIM slot, metal face up, clipped corner to the right.
d. Green light is flashing for couple second and turn to on always on
e. Call the device SIM number and it is supposed to get through without answer.
f. Ensure the waterproof rubber is closed after SIM installation
5. What to do to make the device be online
5.1. Get a GSM card, only 2G GSM card can work with this tracker.
5.2. Check with the service provider and get the APN for the SIM card.
5.3. Set the APN to the device.
Send SMS to the SIM card in the tracker: *apn*xxx*(“*“is included)
5.4. Register the master controller.
Send SMS to the SIM card in the tracker: *master*123456*+1XXXXXXXXXXXX*
Note: +1 is the country code, xxxxxxxxx is the phone no. which will receive alert or message
from the tracker, you can replace it with your own mobile phone no.
5.5. Set the uploading interval.(refer to part 9)
Send SMS: *routetrack*99*
Or SMS: *check*0-99*
Or SMS: *checkm*10-999*
5.6. Log in the tracking web: gps.gaintrace.com with user name and password.
The user name is the registered phone no.
For example:
If your master controller no. is [phone]
Then your login account would be: 005512345678910
Default Password: 123456
6. Operation Commands Guide
6.1 Set APN (VERY IMPORTANT AND MUST BE DONE 1ST)
For the device to send data to the server, this command MUST be enabled.
SMS: *apn*AXXX*BXXX*CXXX* This command sets the telecom Access Point Name. BXXX
refers to user name, CXXX refers to password.
If there is no user name and password required, send as *apn*AXXX*
If there is user name but no password required, send as *apn*AXXX* BXXX*
APN information can be checked on local telecom website.
You will receive the following text: " APN is set to XXX. User name: XX. Password: XX”
6.2 Registering the “Master” Controller
SMS to the device: *master*123456*+1XXXXXXXXXXXX*, (For instance, master controller
phone number is +1XXXXXXXXXXXX. +1 refers to the country code. XXXXXXXXXXXX is the
cellphone number. Please make sure country code is included, and digit 0 is not needed before cell
phone number)
Device Response: " Cell Phone # xxxxxxxxxx is set to master controller, the password is 123456.”
(The device has a default password of “123456” to initially program in your PDA/Phone.
NOTE: The device will ONLY listen and respond to instructions from this number unless you choose
to turn on the multi controller function and open the device to any cell phone number see NO.13 for

7/ 12
details.
6.3 Emergency takeover function
With the proper password, any phone number could takeover of full functionality under emergency
situation.
SMS: *master*123456*+1XXXXXXXXXXX * (For instance, master controller phone number is
+1XXXXXXXXXXX. +1 refers to the country code.
XXXXXXXXXXXX is the cellphone number. Please make sure country code is included, and 0 is not
needed before cell phone number)
You will receive back a text that says: "Master controller change is successful for
+1XXXXXXXXXXX, the new master controller is +1XXXXXXXXXXXX."
6.4 Changing the Password
SMS: *password*654321* (654321 refers to new password)
You will receive the following text: " The password change is successful for +1XXXXXXXXXX. The
new password is 654321."
7. Motion Detected Alert
The Master Controller will receive an alert (call or SMS) once the device detects vibration indicating
possible motion.
7.1 Vibration sensitivity
The device you have purchased is equipped with a sensitive Vibration detection system. Since
certain applications are more sensitive to external vibration sources, the sensor has variable
sensitivity settings. The unit comes from the factory pre-set to #1, on a scale of 1-5, with 1 being the
most sensitive. If you notice you are getting excessive false movement alerts (like when a heavy
truck drives by), you can simply send the following SMS to the unit, and reset the variable:
SMS: *sensitive*1-5* (where X = 1-5, 1 being the most sensitive, 5 the least)
1=3seconds continued vibrating
5=15seconds continued vibrating
Default setting is 1 (per the explanation above)
Device Response: “Vibration sensitivity is set to 1-5.”
7.2 SMS or CALL Alert Settings
The Alert function(s) can be set accordingly with the following SMS commands. The system default
setting is call alert.
SMS: *alertoff*
Device Response: “System has ended alert function.”
SMS: *smsalert*
Device Response: “System has entered SMS alert function.”
SMS: *callalert*
Device Response: “System has entered call alert function.”
Note:
* By Default, the Alert System automatically initiates a notification to the Master Controller when the
motion sensor is activated after 3 minutes of non-movement, indicating vibration that may indicate

8/ 12
motion.
* Call alert will call master controller 2 times when motion is detected.
*Moving (motion) alert can only be turned off by SMS.
8. SMS Location Query
The GPS module establishes location and creates an event, which is sent immediately. The data
packet returned via SMS includes battery level and any applicable alert mode. User can track the
device location via SMS whenever, wherever.
8.1 SMS: *locate*
This command “Pings” the unit from the master controller for a spot location report delivered via
SMS back to the Master Controller.
Device Response: You will receive back a text include latest information of latitude, longitude, date,
time and ranking. And you can find this location in details from the tracking website.
8.2 SMS: *locateaddress*
Device Response: You will receive back a text include rough address information of the device.
Tracking website is not required.
8.3 SMS: *locatemap*
Device Response: You will receive back a text message with a Google maplink, click the link in
order to view the location through cell phone browser. It is suitable for smart phone user only. * Note:
Device will start positioning once it is powered on, location data will be saved and retained in
memory every minute automatically. If GPS positioning fails, the nearest GSM cell tower data will
be saved instead
9. Website Tracking
The GT3012 is purchased with an account on the http://gps.gaintrace.com website. Tracking data,
per the default and variable settings is transmitted via GPRS to the server where it is viewable from
ANY web browser, where the user has unlimited access to the full suite of reports and data
displayed on Google Maps.
Tracking Website Login ID: Master controller phone number. It's the same number as 5.2.
Tracking Website Login Password: Default as 123456. For new password please see 5.3 for details
For example:
If your master controller no. is [phone]
Then your login account would be 005512345678
Default Password:123456
Recommended Web browsers are Chrome, Firefox or cell phone default browser.
There are different tracking modes that can be selected by SMS command. Route Track and
Interval Track.
NOTE: The default setting is OFF due to GPRS data and extra power is required for each tracking
mode.

9/ 12
9.1 Routetrack
9.1.1 By button
Press On button at the back of the device to turn on routetrack function, LED flashes 5 times
indicates routetrack function is on.
9.1.2 By SMS
SMS: *routetrack*1-99* (1-98 represents hours of accumulated data, 99 means always on)
Device Response: “System has entered routetrack function for *XX* hours.” If you sent 99 the
device responds: “Routetrack function is set to always on.”
9.1.2.1 Routetrack data Collecting Interval
SMS: *rsampling*1-999* (1-999 represents seconds of data collecting interval, default as 10
seconds)
9.1.2.2 Routetrack data Uploading Interval
SMS: *rupload*60-999* (60-999 represents seconds of data uploading interval, default as 60
seconds, minimum rate should not be less than 60)
SMS: *routetrackoff*
Device Response: “System has ended routetrack function.”
9.2 Check Function
This check function allows for Power savings over route track of 30%-60% by controlling sampling
frequency and data upload interval. The device can be set to collect location data regularly and
uploaded to server at appointed interval. Initiate the start of interval tracking with a SMS command.
SMS: *check*0-99* (0-99 represents hours of data upload interval, default as *check*0*)
SMS: *checkm*10-999* (10-999 represents minutes of data upload interval)
SMS: *checkoff*
Device Response: “Notice: System has ended check function.”
Noted: Check function is able to work with routetrack command at the same time.
9.3 Track Off
This turns OFF the GPRS data upload function. System will exit tracking function once receiving the
track off command, no matter which tracking mode it is in.
SMS: *trackoff*
Device Response: “System has ended the tracking function.”
10. Deep Sleep
The Deep Sleep function enables the GT3012 to be available for long working periods needed,
tracking remotely when either the timer wakes the unit or motion is detected. The GSM and GPS
are both off during deep sleep, with only the timer drawing power. Since both the radio and GPS are
off, the

10 / 12
device requires a minute or two to establish a location and send the first record upon waking.
10.1 SMS: *sleep*1-99* (1-99 represents hours of deep sleep period.)
Device Response: “System is going to enter deep sleep function, data will be uploaded every XXX
hours.”
10.2 SMS: *sleepoff*
Device Response: “System has ended deep sleep function.”
11. Geofencing
The device is equipped with an automatic GeoFencing function that will, on command set a
01-99km radius “bubble” around the device. Movement within this area is ignored. Crossing outside
can become an SMS alert. To set the GeoFence, from the master controller;
11.1 Set the Geofence
SMS *fence*1-99*
Device Response: “The GeoFence is set. Radius is set to XXX km”
Movement that exits the geofence will be immediately texted to the master controller as a
“GeoFence Exit Alert.”
11.2 Disable the Geofence
SMS *fenceoff*
Device Response: “The Geofence is disabled.”
It should be noted, that if you disable the SMS, Movement Alert and the Movement Call Alert; but
have the GeoFence Alert in place, the first message notifying you of movement will be the
GeoFence Exit.
12. Status query
SMS: *status*
System Health and status check. Returns text message indicating various system diagnostics
13. Multi Controller
This allows any SMS enabled cell device to query the unit for location, status, etc.
SMS: *multiquery*
“Multi query feature enabled.”
SMS: *multiqueryoff*
The unit will now only respond to the Master controller.
Device Response: to the Master Controller: “Multi query feature disabled.”
14. Device Information
SMS: *about*
You will receive a text message include software edition information and device’s serial number.

11 / 12
15. Branding Settings
Send a command enable you to use your own brand in the reply text message. It is default as Null
This is a factory command. Only manufacturer is able to send this command.
SMS: *brd*XXX* (XXX refers to the new brand name)
Device Response: “XXX inform: The new brand name is set.”
16. Command Setting List
Function
SMS Command
Description
APN Setting
*apn*AXXX*BXXX*CXXX*
This command sets the telecom
Access Point Name. BXXX refers to
user name, CXXX refers to password.
Master Setting
*master*123456*+1XXXXXXX*
+1 refers to the country code.
XXXXXXXX is the cell phone number.
Please make sure country code is
included, and 0 is not needed before
cell phone number
Password Changing
*password*654321*
Original password is default as 123456.
654321 refers to new password.
Vibration Sensitivity
Setting
*sensitive*1-5*
1 being the most sensitive, 5 the least.
Default setting is 1.
Alert Setting
*callalert*
Call alert will call master number 2 times
when motion is detected after 3 minutes
non-movement.
*smsalert*
SMS notification will sent to master
number when motion is detected after 2
minutes non-movement.
*alertoff*
End Call/SMS alert
LLC Query
*locate*
Latest information of latitude, longitude,
date, time and ranking.
Address Query
*locateaddress*
Address information of current location.
Google Map Search
*locatemap*
Google Map link with current location.
Routetrack Setting
*routetrack*1-99*
1-98 represents hours of accumulated
data, 99 means always on.
Routetrack Sampling
*rsampling*1-999*
1-999 represents seconds of data
collecting interval, default as 10
seconds.
Routrack Upload
*rupload*60-999*
60-999 represents seconds of data
uploading interval, default as 60
seconds, minimum rate should not be
less than 60.
Routetrack Off
*routetrackoff*
End routetrack function.
Check Function
Setting
*check*0-99*
0-99 represents hours of data upload
interval, default as *check*0*
*checkm*10-99*
10-99 represents minutes of data
upload interval

12 / 12
*checkoff* / *check*0*
End check function
Deep Sleep Setting
*sleep*1-99*
1-99 represents hours of deep sleep
period.
* sleepoff*
End Deep Sleep function.
GeoFence Setting
*fence*1-99*
1-99 represents 01-99km radius
“bubble” around the device.
*fenceoff*
End Geofence function
Status query
*status*
Check system status
Multi Controller
*multiquery*
Enable multi controller function
*multiqueryoff*
End multi controller function
Device Information
*about*
Software edition information and
device’s serial number.
