Galanz GLHD38WEA5C User manual

Model# GLHD38WEA5C
HEAT PUMP DRYER INSTRUCTION MANUAL
Thank you for purchasing a Galanz product. Please read this manual carefully for correct usage and safety,
and keep for future reference. For service, support and warranty information, call 800-562-0738.
© 2021 Galanz Canada Ltd.

CONTENT
CONTENTS
1
6
8
13
23
IMPORTANT SAFETY WARNINGS
INSTALLATION INSTRUCTIONS ....................................................................
OPERATING INSTRUCTIONS ........................................................................
SERVICE INSTRUCTION ................................................................................
WARRANTY ....................................................................................................
..........................................................

IMPORTANT SAFETY WARNINGS
1
IMPORTANT SAFETY WARNINGS
The following instructions will help guide you through the initial
steps of setting up your dryer for use. Please note that every
section of this manual provides important information regarding
the preparation and use of your dryer, and it is important that you
review this entire manual before proceeding with any installation
or use More detailed instructions concerning electrical
connections, gas connections, and exhaust requirements are
provided in other parts of this manual.
NOTE
Leveling legs should be secured. All four legs should be on a
solid, even floor and properly leveled as shown in this manual. If
dryer is not level, laundry may not be able to accurately detect
the moisture level in the clothes. When leveling, please be
cautious to avoid injury.
STEP 1 Warnings and Instructions
Following are some warnings and instructions on what to look
out for when connecting and using the dryer. More detailed
information about electrical connections can be found in the
"Electrical connections" section of the manual. This section, as
well as the rest of this manual, must be thoroughly reviewed
before taking any steps to install or use the dryer. Ensure that
power, voltage and other electrical requirements match the type
of dryer.
The 4-wire connection system is used for the installation and use
of (mobile) houses, and local regulations do not allow the
equipment to be grounded through a neutral point. For additional
instructions on how to connect a clothes dryer to a power supply,
refer to the electrical connection section of this manual for a
clothes dryer.
DRYER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual
and on vour appliance.
Always read and obey all safety nessage.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or
hurt you and others.
All safety messages will follow the safety alert symbol and
either the word "DANGER" or "WARNING."These words
mean:
DANGER
WARNING
You can be killed or seriously
injured it you don't immediately
follow instructions.
You can be killed or seriously
injured if you don't follow
instructions.
All safety messages will tell you what the potential hazard is, tell you
how to reduce the chance of injury, and tell you what can happen if
the instructions are not followed.
WARNING - "Risk of Fire"
- Clothes dryer installation must be performed by a qualified installer.
- Install the clothes dryer according to the manufacturer's instructions
and local codes.
- To reduce the risk of severe injury or death, follow all installation
instructions.
- Save these instructions.

IMPORTANT SAFETY WARNINGS
IMPORTANT SAFETY WARNINGS
2
WARNING-To reduce the risk of fire, electric
shock, or injury to persons when using your
appliance, follow basic precautions, including the
following
Read and understand thoroughly this safety instructions before
use. The items indicated here are very important safety.
precautions, which must be followed. Any failure and losses
caused by ignoring the above mentioned items and cautions
mentioned in the operation and installation instruction are not
covered by our warranty and any liability.
The appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Children of less than 3 years should be kept away unless
continuously supervised.
The rear surface of appliance shall be placed against a wall.
Possible Electric Shock
Disassembly, repair or modification can’t be carried out by
people other than professional maintenance staffs.
The household electrical supply system (the current ,the voltage,
the cable)such as a fuse with the specifications and safety details
provided refer to “normal load” poeration.
If the supply cord is damaged ,it must be replaced by the
manufacturer ,its service agent or similarly qualified persons in
order to avoid a hazard.
Don’t disconnect the power plug by pulling the supply cord.
Hold the power plug with your hand.
Don’t use the supply cord when connection of the power plug
and the supply cord is loose.
Don’t touch the power plug with wet hands .Wipe dust or water
drops over the power plug off with dry cloth.
Don’t over-bend the supply cord or put it under heavy weight.
Don’t use the supply cord /socket /power plug if it is damaged
or broken.
Possible Explosions
Don’t put combustible liquid such as gasoline, petrol and
alcohol into the appliance or nearby.
Don’t put clothes with that liquid into the appliance.
Don’t connect / disconnect the power plug when leakage of
gas or other combustible gas occurs.
Fire Accidents/Short Circuit Or Electric
Leakage May Occur.
Do not install the appliance close to fire sources or heat sources.
Do not rest any burning candles or cigarettes on the appliance.
Do not install the appliance in areas prone to damp or rainfall as
water on the electrical
components can damage the appliance and/or cause accidents.
Do not install the dryer in places under direct sunshine, lest the
plastic components and rubber components become aged.
Do not use water jets on the appliance when cleaning it.
In order to avoid danger of fires caused by excessive drying, do
not use the appliance to dry the following items: Cushions, quilts
and the like (these items accumulate heat).

IMPORTANT SAFETY WARNINGS
IMPORTANT SAFETY WARNINGS
3
When using stain remover on your laundry, ensure you run an
extra rinse cycle prior to loading the tumble dryer.
Ensure all pockets are empty prior to loading laundry into the
tumble dryer.
Items that have been soiled with substances such as cooking
oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine,
waxes and wax removers should be washed in hot water with an
extra amount of detergent before being dried in the tumble dryer.
Ensure the openings in the base are not obstructed by carpets.
The hot air discharge from the dryer cannot e shared with other
exhaust passages from devices that burn gases or other fuels.
Warning
In the appliance enclosure or in the built-in structure, keep
ventilation openings clear of obstruction.
Do not damage the refrigerant circuit.
Never stop a tumble dry before the end of the drying cycle
unless all items are quickly removed and spread out so that the
heat is dissipated.
The appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that
is regularly switched on and off by a utility Read and understand
thoroughly this safety instructions before use.
Do not dry articles that have been previously cleaned in, washed
in, soaked in, or spotted with gasoline, dry-cleaning solvents, or
other flammable or explosive substances, as they give off
vapours that could ignite or explode.
Do not allow children to play on or in the appliance.
Close supervision of children is necessary when the appliance
is used near children.
Before the appliance is removed from service or discarded,
remove the door to the drying compartment.
Do not reach into the appliance if the drum is moving.
Do not install or store this appliance where it will be exposed to
the weather.
Do not tamper with controls.
Do not repair or replace any part of the appliance or attempt
any servicing unless specifically recommended in the user-
maintenance instructions or in published user-repair instructions
that you understand and have the skills to carry out.
Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric softener
or product.
Do not use heat to dry articles containing foam rubber or
similarly textured rubber-like materials.
Clean lint screen before or after each load.
Keep area around the exhaust opening and adjacent surrounding
areas free from the accumulation of lint, dust, and dirt.
Do not place items exposed to cooking oils in your dryer. Items
contaminated with cooking oils may contribute to a chemical
reaction that could cause a load to catch fire. To reduce the risk
of fire due to contaminated loads, the final part of a tumble
dryer cycle occurs without heat (cool down period). Avoid
stopping a tumble dryer before the end of the drying cycle
unless all items are quickly removed and spread out so that the
heat is dissipated.
Save these instructions

IMPORTANT SAFETY WARNINGS
IMPORTANT SAFETY WARNINGS
4
Personal Injury May Occur
This machine is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
To avoid danger to children, ensure all packaging is disposed
of safely.
Ensure children under 3 years of age are supervised.
Wait until the drum has stopped completely prior to removing
laundry from the dryer.
Children and pets should be kept away when the dryer is
working to ensure they do not
become trapped. Always check the drum carefully before
closing the door.
Other Instructions
This appliance is designed for domestic use .It must not be
used for purposes other than those for which it was designed.
Only wash fabrics which are designed to be machine dried .
Follow the instruction on each garment label.
Any electrical work required to install this appliance should be
carried out by a qualified electrician or competent person.
If the machine is situated on a carpeted floor ,please adjust the
feet in order to allow air to circulate freely under the appliance.
Do not climb onto the dryer or rest heavy objects / heating
devices or items with water or liquid leakage on the dryer, lest
deformation of the face panel and the plastic component occur.
Any objects such as coins, safety pins, nails, screws, stones or
any other hard, sharp material can cause extensive damage and
must not be placed into the machine.
After having installed the appliance ,check that it is not pressing
or standing on its electrical supply cable, or vent hose.
Items such as foam rubber (latex foam), shower caps,
waterproof textiles ,rubber backed articles and clothes or pillows
fitted with foam rubber pads should not be dried in the tumble
Always unplug the appliance after use ,clean and maintenance.
Do not overload the appliance .See the relevant section in the
user manual.
Clothes which are dripping wet should not be places in the dryer.
Garments which have been in contact with volatile petroleum
products should not be machine dried. If volatile cleaning fluids
are used ,care should be taken to ensure that the fluid is
removed from the garment before placing in the machine.
Never use the tumble dryer if the power supply cable, the
control panel ,the working surface or the base are damaged so
that the inside of the tumble dryer is accessible.
The tumble dryer is not be used if industrial chemicals have
been used for cleaning.
The lint must not to be allowed to accumulate around the
tumble dryer.
Do not dry unwashed items in the tumble dryer.
Fabric softeners or similar products should be used as specified
by the fabric softener instructions.
The final pat of a tumble dryer cycle occurs without heat (cool
down cycle) to ensure that the items are left at a temperature
that ensures that the items will not be damaged.

IMPORTANT SAFETY WARNINGS
IMPORTANT SAFETY WARNINGS
5
That exhaust air must not be discharged into a flue which is used
for exhausting fumes from appliances burning gas or other fuels.
That the appliance must not be installed behind a lockable door,
a sliding door or a door with a hinge on the opposite side to hat
of the tumble dryer ,in such a way that a full opening of the
tumble dryer door is restricted.
Machine must be placed in a clean place ,no water ,ice and
combustible materials there .
To keep vibration and noise to a minimum when the dryer is in
use ,it should be placed on a firm, level surface.
If the tumble dryer is not completely leveled ,need to adjust the
front feet up :to lower the dryer by turning anti-clockwise and to
ascend it by turning clockwise till the appliance will not shake.
Adequate ventilation has to be provided to avoid the back flow
of gases into the room from appliances burning other fuels,
including open fires.
Remove all objects from pockets such as lighters and matches.
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer. The items
become warm, causing an oxidation reaction in the oil.
Oxidation creates heat. If the heat cannot escape, the items
can become hot enough to catch fire.
Piling, tacking or storing oil affected items can prevent heat from
escaping and so create a fire hazard.
If it is unavoidable that fabrics that contain vegetable or cooking
oil or have been contaminated by hair care products be placed
in a tumble dryer they should first be washed in hot water with
extra detergent - this will reduce, but not eliminate, the hazard.
Contains fluorinated greenhouse gases covered by the Kyoto
Protocol.
Hermetically sealed system.
Do not vent gases into the atmosphere.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
Read all instructions before using the dryer.
Before the dryer is removed from service or discarded, remove
the doors to the drying compartment.
Do not reach into the dryer if the drum is moving.
Do not tamper with controls.
Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric softener
or product. Clean lint screen before or after each load.
The interior of the appliance should be cleaned periodically by
qualified service personnel.
Prior to the first use of this appliance, use all-purpose cleaning
products or a solution of detergent and water. with a damp cloth
to remove from the inside of the dryer drum/drying compartment
any dust or dirt that may have accumulated in the inside of the
dryer. Plug in your dryer after reviewing the following parts on your
dryer’s Electrical Requirements.
STEP 2 Preparation of the Dryer
STEP 3 Confirming Heat Source Operation
Close the door to the dryer drum/drying compartment and, after
completing all steps in this manual for proper installation of this
dryer, start the dryer on a heat setting, as described more fully in
the operating instructions that accompany the dryer.
STEP 4 Additional Instructions for Installation
The following instructions are applicable to installations of the
dryer in a manufactured or mobile home.

INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
6
Any installation in a manufactured or mobile home must comply
with the Manufactured Home Construction and Safety Standards
Title 24 CFR, Part 32-80 or Standard CAN/CSA Z240 MH and
local codes and ordinances.
If you are uncertain whether your proposed installation will comply
with these standards, please contact a service and installation
professional for assistance.
Electrical Requirements for Electric Dryer.
1) The electrical connection for an electric dryer must be a 4-wire
connection.
More detailed information concerning the electrical connection is
provided at the manual section entitled.
Install the clothes dryer according to the manufacturer's
instructions and local codes and local codes .
Stacking Kit
In order to stack this dryer, an Galanz stacking kit is required.
Dryer
Washer
1"
(25mm)
5"
(127mm)
2"-5"
(50mm-127mm)
1"
(25mm)
This dryer may only be stacked on top of an Galanz washer.
DO NOT attempt to stack this dryer on any other washer, as
damage, injury or property damage could result.
INSTALLATION INSTRUCTIONS
TOOLS AND PARTS
Installation Requirements
Gather the required tools and parts before starting installation
Tools Needed:
Flat-blade screwdriver
Min. 8" long
screwdriver
TORX®T20®†
#2 Phillips screwdriver
1/4" and 5/16" nut driver
(recommended)
Channel locks Wire stripper (direct wire
installations)

7
Warning
Certain internal parts are intentionally not grounded and may
present a risk of electric shock only during servicing. Service
Personnel-Do not contact the following parts while the appliance
is energized: Motor.
To reduce the risk of fire, this appliance must be fastened or
otherwise secured to an uncovered concrete floor.
Service Personnel-Do not contact the following parts while the
appliance is energized: Motor.
Adjustable wrench that
opens to 1" (25 mm) or
hex-head socket wrench
Pliers
Utility knife
Tape measure
Level
STACKING THE WASHER AND DRYER (OPTIONAL)
This dryer can be stacked on Galanz washer with stacking kit
(GLSK24WE01) sold separately.
The maximum weight the shelf can support is 26 lbs. (12 kg).
DRYER DIMENSIONS
23.4"
33.4"
1 " 1 "
25.9"
42.8"
0.5"
Front view Side View
2 "
5 "
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
The stacked washer/dryer must be installed directly on the floor
and not elevated with a pedestal.
Max.26lbs
Stacking kit×1
Bracket×2Screw×6
Stacking Kit (GLSK24WE01) Contents

OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
8
Product Overview
1.Control Panel
2.Water Tank
3.Fluff Filter
4.Door
5.Condenser Cover
6.Adjustable Legs
5
1
34
2
6
Control Panel
1. Programme Selection Knob 2. Time
5. Wrinkle Release 6. Buzzer 7. Delay Start 8. Start/Pause
9. Indicator Lights: Drainage container/ Fluff filter
3. Child Lock 4. Dry Level
12345678 9
Delicates
Ensure that the electrical connections comply with the installation
instructions.
Remove the polystyrene block and any material from the drum.
Before using your tumble dryer for the first time, we recommend that
you place a few damp cloths inside the appliance and dry for 30
minutes .There may be dust inside a brand new tumble dryer.
Open the door
Place the laundry in the drum, one item at a time,
shaking them out as much as possible.
Close the door. Please check the laundry does not
get caught between the door and filter.
First Use
Daily Use
Select The Required Programme
Turn the program selector dial to
the required program.
The corresponding function lights
is on.
The program will be switched off
if you have not pressed any button
for 10 minutes.
Wear
Delicates
Attention
Some thick clothes ( jeans, big towel ). Because of the material
characteristics, some place hard to dry. If you find that they are
not completely dry at the end of the program.
It is recommended to use the “Time” program to dry again.
Denim

OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
9
The buzzer can be selected during normal use. Press the
“Buzzer” button to turn off the buzzer and corresponding light.
Press once again to activate the buzzer and corresponding light.
A sound will be emitted.
The “Buzzer” key is pressing Wrinkle release and Delay Start at
the same time for 3 second. When the buzzer is on, if you press
the “buzzer” button once more, the buzzer will be switched off.
Automatic Controlled Drying
You can choose different programme base on your different
clothes materials. The device has the function with sensor the
moisture in order to automatically adjust the drying time for
optimal drying. This automatic control system is fit for most
programme except Air Dry, Refresh and Time Dry.
Time Controlled Drying
Programme Option Buttons
Depending on the programme, different functions can be
combined. These must be selected after choosing the desired
programme and before depressing the Start/Pause button. When
these buttons are pressed, the corresponding indicator lights
comes on. When they are pressed again, the lights go out.
Select Buzzer
You can choose the time of drying according to the actual
situation, the knob is turned to the Time, and you can also
increase it to the desired time by pressing the Time button. To
cancel a program which is running, turn the program selector
dial to "off ". At the end of drying, turn the selector dial to “off ”
to switch the machine off before removing the laundry.
Before you start the machine, you can choose the dry level. The
dry level is divided into three grades. ( Heavy Strong
Normal )
This option is only suitable to the five programs: Daily, Cotton,
Synthetic, Bulky Item, Towel.
24
Delay cancelled
Select the Dry level
Select Wrinkle Release
Wrinkle Release is a default setting at the end of each
programme. Longer Anti-crease can be selected while the
programme is in standby or running.
Select Delay start
This button allows you to delay the starting of the program by 24
hours max. This option must be selected after having selected
the program and before pressing Start/Pause to start the
program. Every time the button is pressed ,the time is increased
by 1 hour.
The countdown begins after you have pressed the Start/Pause
button. The corresponding light illuminates when you have
pressed this button. All indicator lights go out except Delay Start
pilot light.
Display
The display shows the following information :After you have
selected the program, its duration (in hours and minutes) appears
on the display. It is calculated automatically on the basis of the
maximum load accepted for each type of fabric and of the required
degree of drying. When the program starts, the remaining time is
displayed every 1 minutes.

OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
10
Delay Start
If you have selected a delay time by means of the relevant button,
the display shows it, The countdown is displayed hour by hour.
Once you press the “Start / Pause” button ,the appliance will start
the delayed process. If you want to check the selected program,
press the “ Delay Start”button again. It shows the duration of the
previously selected program.
Incorrect Option Selection
If you select an option that is not compatible with the program
you have selected, the display shows ErS (error).
If you select other program because of incorrect operation while
the program is running, the display shows ErS (error).
Select Start/Pause
Select the required programme options and press the Start/Pause
button to commence drying. The dryer will pause after pressing
the button again or opening the door while the programme is
running. When the machine is suspended, Programme Selection
Dial and other keys are invalid except Start/Pause, Wrinkle release
and Buzzer keys. To re-start the programme, press the Start/Pause
button once again.
Indicator Lights
These lights indicate the following functions:
Drying light “ ”
the drying phase.
Cooling light “ ” This light indicates that the appliance is in
the cooling phase. At the end of drying, there is a two minutes
cooling phase to cool the laundry.
End of programme light “ ” This light is on at the end of the
cooling phase.
This light indicates that the appliance is in
Anti-creasing light “ ” This light is on when anti-creasing
programme is selected.
Filter light “ ” It comes on every cycle to remind you that the
filter must be cleaned at the end of the programme.
Child Lock light “ ” This light indicated the appliance is locked.
Buzzer light “ ” This light is on when buzzer programme is
selected.
Delay Start light “ ” This light is on when delay start
programme is selected.
Drying Type light, this light is on when drying programme is
selected depending on the rotating speed of dryer.
Tank full light “ ” It comes on after each program and also
when the water tank is full. which remind you to empty the water
container.
Note! Empty the water container after each program to avoid the
alarm when use in next time.
At The End Of The Program
All drying programmes end with 2 minutes cooling phase. If the
laundry is not removed at the end of the cycle, the dryer runs
wrinkle release phase (default: 10 minutes, select: 120 minutes).
If you do not remove the laundry, the dryer will stop automatically
at the end of the wrinkle release phase. The display shows “End”
and the buzzer sounds for 15 seconds when the buzzer function
is on. To finish,turn the programme selector dial to off.
“Child Lock” Function
When the machine is on, press meantime “Time” and “Dry level”
button the system will lock all the buttons. Then all buttons are
for several seconds, invalid except “off ”. If you want to make the
appliance to return to the normal state ,then press “Time” and
“Dry level” button for several seconds meantime again. The

OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
11
function will be released in the following cases:
Open the door during operation
Take out filter drawer during operation
Water tank full
You can set again the “Child Lock” function when you restart the
machine.
After Each Use
Important!
If the drying program has to be stopped before it reaches the end,
we recommend that you turn the program selector dial to position
“Refresh” and wait until the end of this cooling phase before
removing the laundry.
This will avoid a build-up of heat inside the appliance.
To do this first turn the dial to “off ” and then to “Refresh” and
depress the“Start” button.
Modifying the Program
To change a program which is running, first cancel it by turning
the programme selector dial to “off ”. Select the new program
and press the “Start” button.
Attention: According to "-" for the dormant state;
standby mode, 10 minutes later, without any operation,
enter a dormant state.
controller shows "End", 10 minutes later ,without any
operation, enter a dormant state.
Before Loading Laundry
Never tumble dry the following: Particularly delicate items such as
net curtains, woolen, silk, fabrics with metal trim, nylon tights, bulky
materials such as anoraks, blankets, eiderdowns, sleeping bags,
May be tumble died
Normal drying (high temperature)
Delicate drying (low temperature)
Do not tumble dry
Close pillowcases and covers with fasteners to prevent small
laundry items getting tangled inside them.
Close press studs, zips, hooks, tie belts and apron strings. Sort
laundry according to type and degree of drying required.
Do not over-dry laundry, this avoids creasing and saves energy.
Avoid drying dark clothes with light coloured fluffy items such
as towels as they could attract fluff.
The laundry must be thoroughly spun before tumble drying.
Easy-care items, e. g. shirts, should be briefly pre-spun before
drying.
Knitted textiles ( Delicates ) may shrink a little drying. Please do
not over-dry items of this type.
It is advisable to allow for shrinkage when choosing the size of
new purchases.
You can also put starched items into your dryer. However, to
achieve the desired starched effect, choose the programme
“Iron dry”. To remove any starch residues, wipe out the internal
drum after drying with a moist cloth and then rub it dry.
To avoid a static charge when drying is completed, use either a
fabric softener when you are washing the laundry or a fabric
conditioner specifically for tumble dryers.
feather quilts and any items containing rubber foam or materials
similar to rubber foam.
Always follow the instructions on garment labels:

OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
12
Make sure that no metal objects are left in the
laundry (e.g. hair clips, safety pins, pins)
Button up pillowcases ,close zip fasteners ,hooks and poppers.
Tie any belts or long tapes. To avoid laundry becoming tangled:
Close zips ,button up duvet covers and tie loose ties or ribbons
(e.g.of aprons). Turn items with double-layered fabrics inside out
(e.g.with cottonlined anoraks ,the cotton layer should be
outermost) .These fabrics will then dry better. Remove all objects
from pockets such as lighters and matches .
Maximum Loads
Recommended loads are indicated in the program charts:
General rules: drum full but not too tightly packed;
drum no more than half full;
drum no more than
quarter full.
Try to load the maximum capacity of the machine as small loads are
uneconomical.
Cotton, linen:
Synthetics:
Delicate fabrics and woollens:
Remove the laundry when the dryer has finished drying.
If individual items are still damp after drying, set a brief post-
drying time, but at least 30 minutes, this will be necessary
particularly for multilayered items (e.g. collars, pockets, etc.)

SERVICE INSTRUCTION
13
SERVICE INSTRUCTION
Course
Mixed Fabrics
Normal
Perm Press
Heavy Duty
Towels
Wool
Denim
Air Dry
Refresh
Description of programme
It is used for drying clothes made of daily mixed
materials.
Blend materials usual clothes and so on. It is
possible to choose different drying strength.
Chemical fiber products and so on. It is possible
to choose different drying strength.
Mainly used for drying cotton children's clothing,
drying intensity is relatively strong. Used to dry
bulky clothing such as bath towels.
Towel. It is possible to choose different drying
strength.
Knitted sweater and so on.
Mainly used for drying denim clothes.
Using cold air to dry clothes and remove the smell.
The clothes are deodorizing and fresh, and the
intensity of drying is weak. The machine 4kg dries
depend on the display time, regardless of the
drying level.
Time Dry
Drying thick or multi-layered textiles, the machine
dries depend on the display time, regardless of the
drying level. e.g. terry towelling items. For drying
individual items of laundry or for small volumes.
Notice: For drying bathrobe and towel, the max load must not
exceed 4kg.
Delicates
Extra Dry
Shirts
Active Wear
Mainly dry cotton clothes. Drying strength is strong.
Mainly used to dry a small number of shirts, avoid
the process of to cotton and linen drying too much.
It is mainly used for drying sportswear.
It is mainly used for drying underwear. The program
is set to avoid the situation of drying up due to the
small size and easy to reach the humidity sensor.
Bulky Mainly used for drying large loads, such as sheets,
bedspreads, etc.

SERVICE INSTRUCTION
SERVICE INSTRUCTION
14
Care and Cleaning
You must DISCONNECT the appliance from the electricity
supply, before you can carry out any cleaning or maintenance
work.
Don’t clean the dryer by directly spraying water onto the dryer.
Don’t clean the dryer with benzene, thinner, alcohol, or acetone.
Otherwise, it may cause discoloration, deformation, damage.
electric shock or fire.
When cleaning the product , be sure to unplug the power cord.
During the drying cycle, the control panel or the door may
accumulate moisture.
Control Panel
Clean with a soft, damp clothes .Do not use abrasive substances.
Don’t spray cleaners directly on the panel.
The control panel finish may be damaged by some laundry pre-
treatment soil and stain remover products.
Apply such products away from your dryer and wipe up any spills
or over spray immediately.
Stainless Steel Tumbler
To clean the stainless steel tumbler, use a damp cloth with a
mild, non-abrasive cleaner
Remove the cleaner residue and dry with a clean cloth.
suitable for stainless steel surfaces.
Cleaning the Door
Clean periodically the interior part of the door to
remove any fluff. Accurate cleaning
correct drying.
ensures
The enter dryer has a high-gloss finish. Clean with a soft, damp
cloth. Don’t use abrasive
Protect the surface from sharp objects as they may scratch or
damage the finish.
Don’t place any heavy or sharp objects or a detergent box on
the dryer. Keep them on the purchased pedestal or in a
separate storage box.
substances.
Dryer Exterior
Warning Do Not Use The Appliance Without Filter.
Open the loading door.
Remove the lint filter by putting it up and
open the lint filter.
Clean lint, fibre, and cotton raveling by hand
or with a soft piece of cloth.
Close the lint filter and place it back into its
housing.
A layer can build up on the filter pores that can cause clogging
of the filter after using the dryer for a while .Wash the lint filter
with warm water to remove the layer that builds up on the lint
filter surface .Dry the lint filter completely before reinstalling it.
The lint trap has to be cleaned frequently.
Cleaning The Filter Filter case
Clean the inner surface of the strainer and
charging door after each drying.
Warning
Water Container Emptied
Water container collects all of the water from condenser. Water
container need to be emptied after every drying cycle. If the

SERVICE INSTRUCTION
SERVICE INSTRUCTION
15
water container is full, an active programme will break off
automatically. the light will comes on and the buzzer sounds.
In order to continue the programme, the water container must
first be emptied.
1.Pull out water container
2.Tip water into pool
3.Pull the water container in dryer
4.Press the Start/Pause button
Water-tank
Humidty Sensor
In the movement process, this device is used for
induction clothing humidity, it means that it must
be carried on cleaning. Major cause of clean is
must scour out the calcium oxide boiler which on
the sensor surface up. Clean the sensor in the
tumbler (See picture).
Clean the Filter Drawer
Lint and fibre that could not be captured by the lint
filter are blocked in the filter drawer behind the cover.
Clean the filter drawer after each drying process.
There is a two-level filter in the filter drawer.
The first level is the filter drawer sponge and the
second level is the filter cloth.
Press the button to open the cover.
Unlock the fixer.
Pull out the filter drawer.
Clean lint ,fiber and cotton raveling on the filter
cloth by hand or with a soft piece of cloth.
Warning
Certain internal parts are intentionally not grounded and may
present a risk of electric shock only during servicing. Service
Personnel-Do not contact the following parts while the
appliance is energized: Motor.
When you notice a layer that may lead clogging on the filter
cloth, please clean the layer by washing in warm water. Let the
filter cloth dry thoroughly before installing back the filter drawer.
Wash the filter drawer sponge by hand to remove the fiber and
lint on the surface.
After washing the sponge. squeeze it by hand and remove the
excess water.
Well-dry the sponge before storing it.
Clean the Evaporator
Clean the lint accumulated on the fins of the
evaporator located behind the filter drawer
with a vacuum cleaner or a soft brush.
You can also clean by hand provided that you wear protective
gloves. It is recommended to clean it at least twice every month.
Warning
Never attempt to clean with bare hands.
Evaporator fins can harm your hand.
IMPORTANT :
If you call out an engineer to a fault listed below, or to repair a fault
caused by incorrect use or installation, a charge will be made even if
the appliance is under guarantee.

SERVICE INSTRUCTION
SERVICE INSTRUCTION
16
Specification and Parameters
760
55 ± 10%
595X630X850mm
120/240V, 60Hz
Power(left-on mode)(W)
Power(off mode)(W)
Programme time at full load(min)
0.36
0.4
220
Ambient temperature range 5~35(°C)
Capacite (cu.ft.)
Dimensions(W*D*H)
Rated Voltage (AC V/Hz)
Rated power (W)
Weight(kg)
23.4X24.8X33.5inch
41~95(°F)
3.8
IMPORTANT:
Unpacking: All packing must be removed before using the appliance.
Check accessory: Open the accessory bag and check the accessories.
Should the appliance be moved, it must be transported vertically.
The appliance must not be built-in.
Procedure
A separate earth is required by some local rules. In that case, you need buy
grounding wire, clips and screws.
It is dangerous to alter the specifications or attempt to modify this product in
any way.
Care must be taken to ensure that the appliance does not stand on the
electrical supply cable.
Any electrical work required to install this appliance should be carried out by
a qualified electrician or competent person.
wire
Drainpipe
Manual
1
1
Accessory Name Quantity

SERVICE INSTRUCTION
SERVICE INSTRUCTION
17
Troubleshooting
Drum light does
not work (option)
Observe recommended loading volumes.
The sediment on humidity sensor.
Drying cycle ends
shortly after
programme starts.
"END" light
illuminated.
Drying cycle lasts an
unusually long time.
Select a different program the next time
you dry (see “Drying programs” section).
Clean lint filter.
Wrong programme selected.
Filter clogged.
Incorrect volume of laundry.
Drying results
unsatisfactory
Mains plug is not plugged in.
Loading door is open.
Have you pressed the button?
Plug in at main socket.
Close loading door.
Press the button again.
Dryer does
not work
Light bulb is defective.
Not enough washing loaded or
washing loaded is too dry for
selected programme.
Load volume is too big. Reduce load volume.
Reduce light bulb.
Select higher drying level
(e. g. Heavy instead of Strong).
Malfunction Troubleshooting Solution
If you are unable to identify or solve the problem, contact our service centre.
Before you call, make a note of the model, serial number and purchase date of
your machine: the Service Centre will require this information.
Grounding Instruction
This appliance must be grounded. In case of failure or damage, grounding can provide
a minimum resistance to reduce the possibility of electric shock. The power cord has
grounding wire with device and power cord with plug. Plug must be inserted into a
properly installed and grounded socket(in accordance with all local rules and standards).
Water Discharge
It's not necessary to discharge the
condensed water to the tank, it can
be drained out directly. change
drainpipe. Pull out the water pipe by
means of the arrow
direction, Then install
the drainpipe. Such
as the pliers can be
used if it is difficult to
do.
Unpacking your dryer
Caution!
Before using the machine, the
packaging foam must be removed
from the drum.
1.Open the loading door.
2.Pull off adhesive strips from inside
machine on top of drum.
3.Remove the two packaging foam
from the machine.
two packaging foam

18
SERVICE INSTRUCTION
SERVICE INSTRUCTION
Adjustable screw
Check across the Corner
When press on the edge, the machine should
not shake up and down. (please check two
direction) when press on the top frame (across
the corner), the dryer shakes, need to re-adjust
the adjustable feet.
Do not put stacks of blanket or a rope on the floor, which could
generate some heat and affect the machine running.
IMPORTANT :
The hot air emitted by the tumble dryer can reach temperature of up
to 60°C.The appliance must therefore not be installed on floors which
are not resistant to high temperatures
Electrical Connection
Any electrical work required to install this appliance should be carried
out by a qualified electrician or competent person.
THIS APPLIANCE MUST BE GROUNDED.
Warning
The manufacturer declines any liability should this safety
measure not be observed.
Before switching on, make sure the electricity supply voltage
is the same as that indicated on the appliance's rating plate.
Should the plug need to be replaced for any reason, proceed
as described below.
The wires in the mains lead are coloured in accordance with
the following code:
Green and Yellow-Earth
Blue-Neutral
Brown-Live
The wire coloured green and yellow must be connected to the
terminal marked with the letter or by the earth symbol or
coloured green and yellow.
Warning
A cut off plug inserted into a socket is a serious
safety (shock) hazard.
Ensure that the cut off plug is disposed of safely.
Permanent connection in the case of permanent
connection it is necessary that you install a
double pole switch.
The switch must not break the yellow and green
earth cable at any point
Packaging Materials
The materials marked with the symbol are recyclable .
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene
This means that they can be recycled by disposing of them
properly in appropriate collection containers.
Old machine
Use authorized disposal sites for your old appliance. Help to
keep your country tidy!
The symbol on the product or on its packaging indicates
that this product may not be treated as household waste.
Instead it should be taken to the appropriate collection point for
the recycling of electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and
human health, which could otherwise be caused by
