Game Winner FSGWSF1022 User manual

6V Low Boy / VP Digital
Control Unit
Model # : FSGWSF1022 (HU2222501-GW)
Please keep this instruction manual for future reference
HU2222501-GW–ENG Pg.1 20160317-V2
Customer Service: [phone], 8:00am to 5:00pm, Pacific Standard Time,
Monday thru Friday
-------- OR --------
Customer Service: [phone], 7:00am to 12:00am CST daily
Live Chat at: www.academy.com
Email: [e-mail]
(Made in China)

Warnings -------------------------------------------------------
Tools required ------------------------------------------------
Parts List -------------------------------------------------------
Hardware List -------------------------------------------------
Product diagram ---------------------------------------------
Assembly Instructions -------------------------------------
How to install the battery ---------------------------------
How to operate the timer ---------------------------------
Testing the feeder -------------------------------------------
Warranty -------------------------------------------------------
Table of Contents Page
3
4
5
5
6
7-8
9
10
11
12-13
HU2222501-GW–ENG Pg.2 20160317-V2
NOTE: Before beginning assembly of product, make sure all
parts are present. Compare parts with package content list
and hardware contents. If any part is missing or damaged do
not attempt to assemble the unit. Contact customer service
for replacement parts.

Warnings
PAY ATTENTION to these statements when reading this manual and the
information contained can save your life.
DANGER : Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING : Be alert to the possibility of serious bodily injury if the
instructions are not followed. Be sure to read and carefully follow all of the
messages.
CAUTION : Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
READ AND FOLLOW ALL SAFETY STATEMENTS, WARNINGS, ASSEMBLY
INSTRUCTIONS AND USE & CARE DIRECTIONS BEFORE ATTEMPTING TO
ASSEMBLE. KEEP THIS MANUAL FOR FUTURE REFERENCE.
REFER TO THE IMAGES IN THIS MANUAL FOR VISUALIZATION OF THE
ASSEMBLY PROCESS IN ADDITION TO READING THE INSTRUCTIONS.
SOME PARTS CONTAIN SHARP EDGES. SHARP POINTS OR EDGES CAN
SCRATCH, POKE, OR PUNCTURE. WEAR APPROPRIATE CLOTHING AND
SAFETY GLOVES DURING ASSEMBLY.
THE 6V RECHARGEABLE BATTERY (NOT INCLUDED) SHOULD HAVE A
COMPLETE CHARGE PRIOR TO THE FIRST TIME OF OPERATION. THIS
REQUIRES A MINIMUM OF AT LEAST SIX (6) HOURS OF CHARGING.
THE PROPER SPACING BETWEEN THE SPIN PLATE AND THE FUNNEL IS
3/8 INCH. THIS IS VERY IMPORTANT FOR SERVICE FREE OPERATION.
TO TEST YOUR FEEDER FOLLOW THE INSTRUCTIONS IN THE TIMER
MANUAL. DO NOT TEST FEEDER WHEN IT CONTAINS FEED. TEST
FEEDER WHEN EMPTY ONLY! TESTING THE FEEDER WHILE IT CONTAINS
FEED WILL CAUSE FEED TO BE DISCHARGED AT A HIGH VELOCITY AND
COULD RESULT IN BODY INJURY. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY RESULT IN SERIOUS INJURY OR DEATH!
HU2222501-GW –ENG Pg.3 20160317-V2

Tools Required
1
Adjustable
Wrench
HU2222501-GW–ENG Pg.4 20160317-V2

13
Funnel
1pc
14
Timer Kit
1pc
15
Mounting Bracket
2pcs
26
Digital Timer
1pc
J
Hex. Bolt (M6x20)
10pcs
K
Flat Washer (dia. 6mm/18)
2pcs
L
Butterfly Nut (M6)
2pcs
M
Flange Nut (M6)
2pcs
R
Wing Nut
1PC
Parts List - Timer Kit Set –Component and Hardware
!! Components and Hardware are packed INSIDE the Timer Kit Set
package!!
SP4 - Bushing
HU2222501-GW–ENG Pg.5 20160317-V2

Product Diagram
HU2222501-GW–ENG Pg.6 20160317-V2
R
13
14
15
M
L
K
R
J
26

Assembly Instructions (Funnel and Timer Kit )
Step 1:
Attach Funnel (#13) to the
bottom of hopper using bolts
(J, M6x20).
Step 2:
Attach Mounting bracket
(#15) to the Timer Kit (#14)
using bolts (J, M6x20),
flange nut (M, M6), washer
(K, 6mm) and butterfly nuts
(L, M6).
Hardware :
#J –4pcs
Hardware :
#J –2pcs #K –2pcs
#L –2pcs #M –2pcs
#R –1pc
HU2222501-GW–ENG Pg.7 20160317-V2
13
J
R

Assembly Instructions (Funnel and Timer Kit )
Step 3:
Attach the Mounting brackets
(#15) to the bottom of the
hopper using bolts (J, M6x20)
Step 4:
If the feeder is equipped
with a varmint guard,
attached it back to the
bottom of Deer Feeder.
Hardware :
#J –4pcs
HU2222501-GW–ENG Pg.8 20160317-V2
J
15
14

HOW TO INSTALL BATTERY
CAUTION
REMOVE TIMER KIT COVER AND INSTALL A 6V RECHARGEABLE
BATTERY (NOT INCLUDED) BY ATTACHING RED ALLIGATOR CLIP TO
THE POSITIVE TERMINAL (+) AND BLACK ALLIGATOR CLIP TO THE
NEGATIVE (-) TERMINAL.
WARNING
THE 6V RECHARGEABLE BATTERY (NOT INCLUDED) SHOULD HAVE A
COMPLETE CHARGE PRIOR TO FIRST TIME OPERATION. REFER TO
USER INSTRUCTION OF THE BATTERY.
CONNECTING THE BATTERY IN ANY OTHER WAY WILL PERMANENTLY
DAMAGE YOUR UNIT. TAKE EXTREME CARE TO MAKE THIS
CONNECTION PROPERLY. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY RESULT IN SERIOUS INJURY OR DEATH.
HU2222501-GW–ENG Pg.9 20160317-V2

HOW TO OPERATE THE TIMER
CAUTION
HOW TO OPERATE THE TIMER
READ THE OPERATION MANUAL INCLUDED IN THE TIMER KIT UNIT.
ATTENTION
IF USING THE GAME WINNER TIMER #FSGWSF1004 AS A REPLACEMENT
TIMER, IT WILL WORK WITH EITHER 6 OR 12 VOLT MOTORS.
****** GAME WINNER MOTORS ARE 6 VOLT. ******
ATTENTION
THE PROPER SPACING BETWEEN THE SPIN PLATE AND THE FUNNEL IS
3/8 INCH (0.953 cm). THIS IS VERY IMPORTANT FOR SERVICE- FREE
OPERATION.
3/8” / 0.953 cm
HU2222501-GW–ENG Pg.10 20160317-V2

Testing the Feeder
WARNING
THE 6V RECHARGEABLE BATTERY ( NOT INCLUDED) SHOULD HAVE A
COMPLETE CHARGE PRIOR TO FIRST TIME OPERATION. REFER TO
USER INSTRUCTION OF THE BATTERY.
TO TEST YOUR FEEDER FOLLOW THE INSTRUCTIONS IN THE TIMER
MANUAL. DO NOT TEST FEEDER WHEN IT CONTAINS FEED. TEST
FEEDER WHEN EMPTY ONLY! TESTING THE FEEDER WHILE IT
CONTAINS FEED WILL CAUSE FEED TO BE DISCHARGED AT A HIGH
VELOCITY AND COULD RESULT IN BODY INJURY. FAILURE TO FOLLOW
THESE INSTRUCTIONS MAY RESULT IN SERIOUS INJURY OR DEATH!
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
- THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
- THE DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
DO NOT USE THIS UNIT AROUND POWER GENERATING EQUIPMENT
(TRANSFORMERS, GENERATORS, SUBSTATIONS, ETC) AND/OR POWER
TRANSMISSION EQUIPMENT (POWER LINES). FAILURE TO FOLLOW
THESE INSTRUCTIONS MAY RESULT IN SERIOUS INJURY OR DEATH.
HU2222501-GW–ENG Pg.11 20160317-V2

Warranty Information
1. Manufacturer warrants this Product to be free from defects in workmanship and
materials for a period of 90 days from the date of purchase, PROVIDED claims
are submitted, in writing, with proof of purchase.
2. If any part of this item fails because of a manufacturing defect within the
Limited Warranty Period, Manufacturer offers to replace such part(s) provide
that such parts have not been improperly repaired, altered, or tampered with or
subject to misuse, abuse or exposed to corrosive conditions. This Limited
Warranty is, however, subject to certain limitations, exclusions, time limits and
exceptions (Hereinafter “Conditions”) as listed below. Read these Conditions
carefully.
3. This Limited Warranty shall be limited to the replacement or repair of any part(s)
which Manufacturer determines, after reasonable examination, to have been
defective at the time of manufacturing and manufacturer’s obligation(s) shall be
limited to replacement, if any, of defective part(s) which shall be shipped at
Original Purchaser’s expense to Original Purchaser’s designated shipping
address.
4. This Limited Warranty is given to and covers the ORIGINAL PURCHASER
ONLY and such coverage terminates 90 days from the date of purchase.
5. DAMAGE LIMITATION WARNING: IN NO EVENT SHALL MANUFACTURER
BE LIABLE FOR ANY INCIDENTIAL OR CONSEQUENTIAL DAMAGES,
INCLUDING (BUT NOT LIMITED TO) LOSS OF USE OF THE PRODUCT,
LOSS OF TIME, INCONVENIENCE, EXPENSES FOR TRAVEL,
TRANSPORTATION, LODGING EXPENSES, LOSS OF FOOD, LOSS BY
DAMAGE TO PERSONAL PROPERTY OR LOSS OF INCOME, PROFITS OR
REVENUE.
6. MANUFACTURER’S OBLIGATION: Manufacturer’s liability shall be limited to
the delivery of a good, merchantable Product and, if necessary, the repair or
replacement, at manufacturer’s option, of any defective part or unit.
7. TRANSFER LIMITATIONS: This Limited Warranty is not assignable or
transferable. It covers only the original purchaser.
8. RESERVED RIGHT TO CHANGE: Manufacturer reserves the right to make
changes or improvements to products it produces in the future without
imposing on itself any obligations to install the same improvements in the
products it has previously manufactured.
9. This Limited Warranty gives the Original Purchaser specific legal rights but
there may be other rights which vary by jurisdiction.
10. This warranty does not cover the following items:
- Chips or scratches on porcelain or painted surfaces
- Rust or corrosion is not deemed a manufacturing or materials defect
- Discoloration or loss of paint due to handling during assembly, heat or
cleaning products. Paint may require touch up.
- Stainless steel discoloration or corrosion
- Consumables such as batteries
- Damages caused by wild game
HU2222501-GW–ENG Pg.12 20160317-V2

Warranty Information
IF CUSTOMER SERVICE IS NECESSARY:
The Original Purchaser is responsible for shipping and handling charges of
the returned item(s) and replacement parts, if any.
All parts to be replaced will need to be shipped before replacement items
will be sent.
Follow the Customer Service Representative’s instructions exactly. If a
return is necessary, it must be packed carefully and shipped prepaid.
Should you encounter any problem
or
Obtaining replacement parts
CALL US FIRST.
Do not return product to the store.
WE CAN HELP.
Rankam Metal Products Manufactory Ltd.
1618 W. Rosecrans Ave.,
Gardena, CA90249
USA
Please contact Rankam Customer Service at [e-mail]
or at 1-888-837-1380, Mon to Fri, 8:00 a.m. –5:00 p.m. Pacific Standard Time.
