RAINBOW MAXX INSTALLATION MANUAL PAGE 1
WARNING
• Luminaires must be installed by a qualied electrician in accordance with all national and local electrical and
construction codes and regulations. Please read through this document entirely before beginning the installation.
• Risk of electric shock- turn power off before inspection, installation or removal.
Notes
• If the external exible cable or cord of this luminaire is damaged, it shall be replaced by a special cord or cord
exclusively available from the manufacturer or his service agent.
Customer Service
Supplied Materials
• For technical assistance please call 800-285-6780 x2 or email [email protected]
Electrical Requirements
• Suitable for wet locations.
• Follow all National Electric Codes (NEC) and local codes.
www.ggled.net
T800.285.6780 E[email protected]
Available Exclusively Through:
Rev Date 20 0421
Rainbow Maxx Series Luminaire(s)
50’ Leader Cable(s)
240W 24VDC LED Power Supply
Arch Mount Brackets & Hardware
1
2
3
4

STRONG. SIMPLE. COMPACT.
RAINBOW MAXX INSTALLATION MANUAL PAGE 2
www.ggled.net
T800.285.6780 E[email protected]
• Mount the Maxx series luminaire using the supplied arch mounting brackets & hardware.
• The brackets are universal (no left or right) and are designed to sit on top of the arch with the U-bolts around
the bottom (see images below).
• There are 3 position holes for mounting and aiming the luminaire in the most desireable location/angle for
your setup.
• IMPORTANT: Maxx series luminaires use directional optics techology. The luminaire must be mounted with the
correct side facing the foam for the desired outcome. There is a large label on the foam side indicating “THIS
SIDE FACING FOAM”.
Mounting
Rev Date 20 0421
Arch Mounting Bracket & Hardware Kits Include the Following:
For Mounting Bracket to Arch
(2) U-Bolts - 3/8” - 16 SS
(4) Nylon Lock Nuts - 3/8” - 16 SS
(4) Flat Washers - 3/8” SS
1
2
3
For Mounting Luminaire to Bracket
(2) Bolts - 5/16 - 18 x 1” SS
(2) Nylon Lock Nuts - 5/16” - 18 SS
(4) Flat Washers - 5/16” SS
1
2
3
]
]

Enclosure
RAINBOW MAXX INSTALLATION MANUAL PAGE 3
STRONG. SIMPLE. COMPACT.
www.ggled.net
T800.285.6780 E[email protected]
Rev Date 20 0421
• DO NOT plug LED xture directly into AC voltage.
• Fixtures require and are supplied with a 24VDC LED power supply.
• LED power supply must be placed in a UL approved enclosure.
Electrical Connection Diagrams
120-277V
Input
(V+)
Brown or
Red
(V+)
Red (V-) Black
(V-)
Blue or
Black
24VDC
Output
HLG-240H-24
Rainbow Maxx

RAINBOW MAXX INSTALLATION MANUAL PAGE 4
STRONG. SIMPLE. COMPACT.
www.ggled.net
T800.285.6780 E[email protected]
Rev Date 20 0421
Controlling The Fixture
Controlling the Rainbow Maxx is simple. There is a single control button on the end of the luminaire opposite the
power input underneath a waterproof cap. The button has three functions and allows the user to change the mode,
cycle through various effects and adjust the speed of the effect. There are two modes: animated or static color.
Static color mode includes the ability to ash the color.
• Single Short Press - A single short press of the control button will cycle through the shows available in the current
mode (animated or static color).
• Single Long Press (2-3 Seconds) - Pressing and holding the control button for 2-3 seconds will change the mode of
the xture from Animated to Static Color or Static Color to Animated. Hold the button down until the xture briey
ashes off to conrm that the mode has changed.
• Double Short Press - A double short press (2 clicks) of the control button allows you to change the speed of the
animation or ash a single color. The speed of the animations are set from the factory at the ideal speed for a given
effect. There are 4 animation speeds and 3 ashing speeds available.
• Power Off Behavior - The luminaire stores the last programmed show into memory so that if it is powered down,
it will start back up to the last show that was active. From the factory, the luminaire is set to default to the rainbow
show when it is rst powered on.
#1: Rainbow - Continuous scrolling 7-color change
#2: Solid Color Change - Rotating solid 9-color change
#3: Blue & Red Scrolling- Blue background with Red
scrolling back and forth
#4: Blue & Green Scrolling- Blue background with Green
scrolling back and forth
#5: Orange & Blue Scrolling- Orange background with
Blue scrolling back and forth
#6: Lime & Pink Scrolling- Lime background with Pink
scrolling back and forth
#7: Green & Red Twitch- Green and Red altering sections
#8: Pink & Lime Twitch- Pink and Lime altering sections
#9: Blue & Red Twitch- Blue & Red altering sections
#1:Rainbow
#2: Blue
#3: Red
#4: Green
#5: Purple (Violet)
#6: Lime
#7: Orange
#8: Cyan
#9: Yellow
#10: Pink
Animated Show Effects Solid Colors (Includes Flashing Effect)
