Gantner GL7p Quick guide

www.gantner.com HB_GL7p--EN_12
1
GL7p
Battery-Powered, Door-Mounted Electronic Locker Lock
Identification via RFID (MIFARE®, ISO 15693, NFC, HID iCLASS)
and Optional PIN Code
Installation, Configuration, Operation
Document Version 1.2

GL7p - Battery-powered, door-mounted electronic locker lock
2 HB_GL7p--EN_12 www.gantner.com
©
Copyright 2020 by GANTNER Electronic GmbH
Operating instructions, manuals and software are protected by copyright. All rights are reserved. Copying, duplication, translation,
installation in any electronic medium or machine-readable form in whole or in part is prohibited. The sole exception is represented
by creation of a back-up copy of software for own use as a safeguard, so far as this is technically possible and recommended by us.
Any infringement will render the party committing such infringement liable to compensation payment.
Liability
Any claims against the manufacturer based on the hardware or software products described in this manual shall depend exclusively
on the conditions of the guarantee. Any further-reaching claims are excluded, and in particular the manufacturer accepts no liability
for the completeness or accuracy of the contents of this manual. The right is reserved to make alterations, and alterations may be
made at any time without prior notice being given.
Trademarks
Attention is drawn at this point to markings and registered trademarks used in this manual. All product and company names, which
are mentioned in this manual, are only used for identification and explanation purposes. Some of these names may be trademarks
or registered trademarks of the corresponding company.
Availability
The GL7p is not available in North America (United States, Canada).
Contact
The contact information for questions regarding this product or for general enquiries is listed below:
Contact address of manufacturer
GANTNER Electronic GmbH
Bundesstraße 12
6714 Nüziders, Austria
www.gantner.com/locations

GL7p - Battery-powered, door-mounted electronic locker lock
www.gantner.com HB_GL7p--EN_12 3
Important Information
Dear Customer,
Our aim is to ensure that our product operates with safety and to your complete satisfaction. To achieve this aim, please take
this opportunity to familiarize yourself with the following guidelines.
- Pay attention to the safety messages in this manual. The messages are indicated by the signal words "DANGER",
"WARNING", or "CAUTION", and inform you about hazardous situations and how to avoid them.
- Pay attention to messages indicated by the "NOTICE" signal word. These messages include important information for
avoiding property damage.
- Pay attention to the symbols and safety messages on the product.
- Read all instructions in this manual carefully before installing or operating the product.
- Where not otherwise specifically documented, the appropriate installation, commissioning, operation and maintenance of
the product is the customer’s responsibility.
- Keep this manual in a safe place for quick reference.
Notation of Safety Information and Safety Symbols
This manual includes important safety messages and symbols intended to inform the user about potentially hazardous situations
or important information for the safe and proper use of the described product(s). The safety messages also include directives on
how to avoid hazardous situations. These safety messages and directives must be read and observed.
The structure of the safety messages and the meaning of the symbols used in this manual are described in this section.
1. Safety Messages for Personal Injury
Personal safety messages contain a signal word, describe the nature of the hazard, and indicate how to avoid the hazard.
The safety alert symbol used without a signal word always precedes important safety information that must be read
carefully and the instructions carefully observed. Not doing so may cause personal injury.
Format of safety messages that apply to an entire section:
These safety messages may be used with or without a symbol.
Electrical shock
➔Touching current-conducting parts may result in injury due to electrical shock.
- Do not remove safety protection and covers.
- Do not touch the electrical connections while power is being supplied.
Format of safety messages that are embedded in text and apply to a specific point:
CAUTION! Electrical shock. Never remove safety protection and covers. Do not touch the electrical connections while
power is being supplied.

GL7p - Battery-powered, door-mounted electronic locker lock
4 HB_GL7p--EN_12 www.gantner.com
2. Property Damage Messages
Property damage messages are used to describe potentially hazardous situations that may lead to property damage. These
messages have the same layout as safety messages but use the signal word "NOTICE" instead of “CAUTION”.
Format of property damage messages that apply to an entire section:
Risk of damage to the device and connected devices
Risk of malfunction
- Read the following instructions carefully before installing the device.
- Always adhere to the instructions.
Format of property damage messages that are embedded in text and apply to a specific
point:
NOTE! Risk of damage to the device and connected devices. Read the following instructions carefully before installing the
device.
3. Definition of the Signal Words
Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury.
Indicates information considered important, but not hazard-related (e.g., messages relating to
property damage).
4. Definition of the Safety Symbols
Caution: General Information
This symbol indicates general warnings or cautions that are not related to a particular type of hazard.
Caution: Electrical Shock
This symbol indicates warnings related to electrical hazards (danger due to high voltage).
Prohibited: Do Not Disassemble
This symbol indicates warnings about not disassembling certain components or equipment. Disassembling may
lead to damage or malfunction of the device.
Mandatory Action: General Information
This symbol indicates general information that must be read and followed before proceeding with the
accompanying instructions.
Mandatory Action: Read Instructions
This symbol indicates information referring to an important description in the manual, or other documentation,
which must be read and followed.

GL7p - Battery-powered, door-mounted electronic locker lock
www.gantner.com HB_GL7p--EN_12 5
Important Safety Information
−The installation, commissioning, and servicing of our products must be performed only by suitably trained
personnel. In particular, electrical connections must only be made by correspondingly qualified specialists.
Always observe the relevant installation regulations in accordance with the national Electrical Engineers
Association.
➔Unqualified personnel may potentially perform actions that result in injury due to electrical shock.
−Where not otherwise stated, installation and maintenance work on our products must be carried out when
disconnected from the power supply. This applies in particular to appliances that are normally supplied by
low-voltage current.
➔If the appliance is not disconnected from power, touching terminals or other internal parts of the
appliance may lead to injury due to electrical shock.
−It is prohibited to alter the products (devices, cabling, etc.).
➔Alterations to the products may subsequently result in personal injury, property damage, or damage to
the products.
−Do not remove protective shields and covers.
➔Removing protective shields and covers may result in personal injury or property damage.
−Do not attempt to repair a product after a defect, failure, or damage is detected. In addition, do not put the
product back into operation. In such cases, it is essential to contact your GANTNER representative or the
GANTNER support hotline.
−The installation, commissioning, operation, and maintenance of the product must be carried out in
accordance with the technical conditions of operation as described in the corresponding documentation.
Therefore, it is essential to read the corresponding chapter of this manual and observe the instructions and
information therein.
−If there are still some points that are not entirely clear, please do not take a chance. All queries can be
clarified by your GANTNER representative or by ringing the GANTNER support hotline.
−Directly on receipt of the goods, inspect both the packaging and the product itself for any signs of damage.
Also check that the delivery is complete and includes all accessories, documentation, auxiliary devices,
etc.
−If the packaging or product has been damaged in transport, or should you suspect that it may have a fault,
the product must not be put into service. Contact your GANTNER representative who will endeavor to
resolve the problem as quickly as possible.
−GANTNER Electronic GmbH accepts no responsibility for any injuries or damage caused as a result of
improper use.
Although great care is taken and we are continuously aiming for improvement, we cannot completely exclude the possibility of
errors appearing in our documentation. GANTNER Electronic GmbH therefore accepts no responsibility for the completeness or
the accuracy of this manual. The right is reserved to make alterations at any time without prior notice.
Should you discover any fault with the product or in its accompanying documentation, or you have any suggestions for
improvement, you may confidently inform your GANTNER representative or GANTNER Electronic GmbH directly.
We especially look forward to hearing from you if you want to let us know that everything is functioning perfectly

GL7p - Battery-powered, door-mounted electronic locker lock
6 HB_GL7p--EN_12 www.gantner.com
The GL7p was developed and fabricated under the quality management standard ISO 9001 and GANTNER Electronic GmbH is
also certified according to standard ISO 14001.
This product is in conformity with the following EC directives, including all applicable amendments:
- 2014/53/EU (Radio Equipment Directive)
The complete text of the CE Declaration of Conformity is available on the following internet link:
http://www.gantner.com/en/produkte/downloads-GL7p_jQ690dP3B6
GANTNER is committed to meeting or exceeding the requirements of the RoHS directive (2011/65/EU). The RoHS
directive requires that manufacturers eliminate or minimize the use of lead, mercury, hexavalent chromium,
cadmium, polybrominated biphenyls and polybrominated diphenyl ethers in electrical and electronic equipment sold
in the EU after July 1, 2006.
FCC INFORMATION (U.S.A.)
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that of which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Warning Statement:
[Any] changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Comliance Statement (GL7p.0500, GL7p.150x):
Compliance Statement (GL7p.2500, GL7p.350x):
The GL7p.2xxx and GL7p.3xxx contain a wireless module. For those modules the following applies:
FCC Radio Frequency Exposure:
WARNING: To comply with RF exposure limits the users must keep at least 20 cm separation distance from the
device, except during the identification and operation process at the device (e.g. PIN-code input), which must be
performed as described in this manual.
FCC ID: NC4-GEA1190118A
This device complies with Part 15 of the FCC Rules.
Operation is subject to thefollowing two conditions: (1) This
device must not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
FCC ID: NC4-GEA1190126A
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device must not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
This device contains
FCC ID: QWO-QS9322PLCS
IC: 4460A-QS9322PLCS

GL7p - Battery-powered, door-mounted electronic locker lock
www.gantner.com HB_GL7p--EN_12 7
INDUSTRY CANADA INFORMATION
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes:
1. l’appareil ne doit pas produire de brouillage;
2. l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.
ICES Statement (Canada)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Availability
The GL7p is not available in North America (United States, Canada).
The WEEE symbol on GANTNER products and their packaging indicates that the corresponding material must not
be disposed of with normal household waste. Instead such marked waste equipment must be disposed of by
handing it over to a designated electronic waste recycling facility. Separating and recycling this waste equipment at
the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects
human health and the environment. Please contact your local authority for further details of your nearest electronic
waste recycling facility.

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
8 HB_GL7p--EN_12 www.gantner.com

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
Table of Contents
www.gantner.com HB_GL7p--EN_12 9
TABLE OF CONTENTS
1 INTRODUCTION ............................................................. 11
1.1 About this Manual...................................................................................................................................11
1.2 Chapter Overview...................................................................................................................................11
1.3 Contact & Inquiries .................................................................................................................................11
1.4 Target Group...........................................................................................................................................12
1.5 Formatting...............................................................................................................................................12
1.5.1 Safety-Critical Information....................................................................................................................12
1.5.2 Non-Safety-Critical Information............................................................................................................12
1.5.3 Instructions and Results.......................................................................................................................12
2 GENERAL INFORMATION............................................... 13
2.1 Intended Use...........................................................................................................................................13
2.2 Highlights................................................................................................................................................13
2.3 Functional Description ............................................................................................................................13
2.4 GL7p Variants.........................................................................................................................................14
2.4.1 RFID Technologies ..............................................................................................................................15
2.4.2 Lock Orientation...................................................................................................................................15
2.5 Terminology............................................................................................................................................16
2.6 System Components ..............................................................................................................................17
2.7 GL7p Dimensions and Components.......................................................................................................20
3 INSTALLATION .............................................................. 21
3.1 Target Group...........................................................................................................................................21
3.2 Test Installation.......................................................................................................................................21
3.3 Replacement after a Burglary Attempt ...................................................................................................21
3.4 Operating Conditions..............................................................................................................................21
3.5 Door Width and Thickness......................................................................................................................22
3.6 Latch Types ............................................................................................................................................22
3.7 Definition of the Door Hinge (Right of Left-Hinged Door).......................................................................24
3.8 Installation of the GL7p...........................................................................................................................26
3.8.1 Mounting Holes in the Door..................................................................................................................26
3.8.2 Instructions for Installing the GL7p.......................................................................................................27
3.9 Attaching the Number Plate....................................................................................................................29
4 COMMISSIONING ........................................................... 31
4.1 Target Group...........................................................................................................................................31
4.2 Power Supply..........................................................................................................................................31
4.2.1 Battery Information...............................................................................................................................31
4.2.2 Inserting the Battery.............................................................................................................................31
4.2.3 Replacing the Battery...........................................................................................................................32
4.3 USB Connection .....................................................................................................................................33
5 CONFIGURATION........................................................... 37
5.1 General Information................................................................................................................................37
5.2 Configuration with GAT Config Manager................................................................................................37
5.2.1 Setup for Configuration in GAT Config Manager.................................................................................37
5.2.2 View and Edit the GL7p Configuration Settings...................................................................................39
5.2.3 Upload Configuration Settings to the GAT ECO.Lock 7xxx F/ISO ......................................................40
5.2.4 Updating the GL7p Firmware...............................................................................................................41
5.3 Configuration with the MoLA App...........................................................................................................43

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
Table of Contents
10 HB_GL7p--EN_12 www.gantner.com
5.4 Configuration Settings of the GL7p........................................................................................................ 44
5.4.1 Operating Mode................................................................................................................................... 44
5.4.2 Locker Number.................................................................................................................................... 44
5.4.3 Auto-Unlock......................................................................................................................................... 44
5.4.4 Duration of Use.................................................................................................................................... 45
5.4.5 Locking of Personal Locker without Data Carrier................................................................................ 45
5.4.6 RF Standards ...................................................................................................................................... 45
5.4.7 MASTER Data Carriers....................................................................................................................... 46
5.4.8 Wireless Interface................................................................................................................................ 46
5.4.9 PIN-Code Keypad ............................................................................................................................... 46
5.4.10Configuration Settings Table............................................................................................................... 47
6 OPERATION ................................................................... 51
6.1 Target Group.......................................................................................................................................... 51
6.2 General .................................................................................................................................................. 51
6.3 Operating Modes.................................................................................................................................... 51
6.3.1 Free Locker Mode (with or without Duration of Use Function)............................................................ 52
6.3.2 Free Locker Universal Mode ............................................................................................................... 54
6.3.3 Free Locker Unique Number Mode..................................................................................................... 55
6.3.4 Personal Locker Programming Card Mode......................................................................................... 56
6.3.5 Personal Locker Expiry Date Mode..................................................................................................... 57
6.4 GAT ECO.Basic Set FD......................................................................................................................... 59
6.5 Summary of System Data Carriers........................................................................................................ 59
6.5.1 MASTER Data Carrier......................................................................................................................... 59
6.5.2 OPEN MASTER Data Carrier (Optional Accessory)........................................................................... 60
6.5.3 DELETE MASTER Data Carrier.......................................................................................................... 60
6.5.4 PROGRAM Data Carrier..................................................................................................................... 60
6.5.5 BATTERY Data Carrier ....................................................................................................................... 61
6.5.6 SERVICE Data Carrier........................................................................................................................ 61
6.5.7 APP KEY Data Carrier ........................................................................................................................ 61
6.5.8 BLOCKING Data Carrier (Optional Accessory)................................................................................... 61
6.6 Summary of GL7p Signalization ............................................................................................................ 62
7 CLEANING AND MAINTENANCE .................................... 63
7.1 Cleaning................................................................................................................................................. 63
7.2 Maintenance........................................................................................................................................... 63
7.3 Functional Testing.................................................................................................................................. 63
7.4 Disposal ................................................................................................................................................. 64
8 TECHNICAL DATA ......................................................... 65
8.1 Power Supply......................................................................................................................................... 65
8.2 Reading Field......................................................................................................................................... 65
8.3 Memory and Time Management............................................................................................................ 65
8.4 Control and Display Elements................................................................................................................ 66
8.5 Mechanical............................................................................................................................................. 66
8.6 Interface................................................................................................................................................. 66
8.7 Housing.................................................................................................................................................. 66
8.8 Environmental Conditions...................................................................................................................... 66
8.9 Dimensions ............................................................................................................................................ 67

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
Introduction
www.gantner.com HB_GL7p--EN_12 11
1 INTRODUCTION
1.1 About this Manual
This manual contains all the information necessary for the installation, commissioning, configuration, operation, and
disposal of the GL7p electronic locker locks. The GL7p is available in various variants, all of which are described in
this manual. These are the following variants:
- GL7p.0500
- GL7p.1500, GL7p.1501, GL7p.1502
- GL7p.2500
- GL7p.3500, GL7p.3501, GL7p.3502
In this manual, the terms "GL7p" and "lock" are used to represent all listed locks. If information in the manual only
applies to a specific lock, the product name concerned is used.
This manual provides an overview of how to configure the GL7p using the configuration software GAT Config
Manager. A separate manual is available for GAT Config Manager that explains in detail all functions of the
software. In addition, configuration via the MoLA app is possible. This app can be installed from the Google Play
Store on a mobile device and includes instructions for use.
1.2 Chapter Overview
In chapter 2 "GENERAL INFORMATION", a functional description of the GL7p, the RFID technologies supported by
the device, key terms used in this manual, and a summary of system components can be found.
Chapter 3 "INSTALLATION" contains the measurement diagrams and information required to install the GL7p into
lockers.
Chapter 4. “COMMISSIONING" describes how to put the GL7p into operation and includes information on the
battery used to power the lock and the USB connection used for PC connection and configuration.
In chapter 5 "CONFIGURATION", you will find information on how the lock is configured with the configuration
software GAT Config Manager and with the MoLA App. The main configuration settings for the lock are explained
and a table listing every setting is available here.
In chapter 6. “OPERATION“, the different operating modes of the GL7p are described. The system data carriers
required to maintain the locker system and the LED signaling are also explained in this section.
Chapter 8 "TECHNICAL DATA" contains all the relevant technical information of the different GL7p variants.
1.3 Contact & Inquiries
For all inquiries concerning the GL7p, please contact your local sales partner or one of the GANTNER branch offices
directly. The contact details are available via the following link: www.gantner.com/locations

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
Introduction
12 HB_GL7p--EN_12 www.gantner.com
1.4 Target Group
This manual contains information relevant for the different stages in the operating life of the GL7p. Information
regarding the installation, commissioning, and service/maintenance is separated into corresponding chapters. When
a chapter is intended for a specific audience, this is clarified at the beginning of the chapter.
Information for the following target groups is available in this manual:
- Installation technicians (installation, operation, configuration).
- Service technicians and cleaning personnel (service and maintenance).
- End users of the GL7p (user manual).
Where not explicitly stated, the information in this manual is intended for all target groups in general.
CAUTION! Injury and property/equipment damage. The tasks described in each chapter must only be
performed by the specified target group. Unqualified personnel who perform the described tasks risk personal injury
or damaging property/equipment.
1.5 Formatting
1.5.1 Safety-Critical Information
The following formatting (with example text) is used in this manual to display important, safety-critical information
that must be read and followed.
NOTE! Following on from this signal word in the manual is a reference text that must be read and followed. The
reference text contains important information. Non-observance can lead to damage of the device or associated
equipment.
1.5.2 Non-Safety-Critical Information
The following formatting (with example text) is used in this manual to display important, but not safety-critical
information.
The text accompanying this symbol contains interesting information relevant to the current chapter. You do not
necessarily need to read this text; however, it will help you better understand the information in this section or
provide interesting tips for the described device or the operation of the software.
1.5.3 Instructions and Results
Instructions, which must be completed by the reader, and the results of these instructions are formatted as follows.
►This symbol represents an action or instruction that that must be followed.
oThis symbol represents the result after completing the previous instruction.

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
General Information
www.gantner.com HB_GL7p--EN_12 13
2 GENERAL INFORMATION
2.1 Intended Use
The GL7p may only be used for the convenient electronic locking of lockers in facilities such as leisure facilities,
universities, companies, depots, and other individual company applications. Depending on the device type,
identification at the GL7p is completed using contactless RFID (Radio Frequency Identification) data carriers or via
PIN code. Data carriers that use MIFARE®and ISO 15693 RFID technology are supported by the GL7p.
The GL7p is not available in North Amercia (United States, Canada)!
2.2 Highlights
- Free locker selection, assigned lockers, or rental locker function configurable
- Time-controlled use
- Automatic unlocking function
- Maintenance-free “Low-Power Technology”
- Configuration via PC/computer, data carrier, or NFC
- Recording of the last 150 bookings
- Secure data transmission between locker lock and data carrier
- NFC ready
- Mechanical locking and unlocking (motor) for highest reliability
- Status displayed via the button position and multi-colored LED
- Existing lockers easily retrofitted (compatible with standard locker locks)
- Suitable for left and right-hinged doors, low door heights, and various locker materials
- Optional wireless interface for identification via smartphone
- Emergency power supply when the battery is empty
2.3 Functional Description
The GL7p is installed on the inner side of the locker door and is suitable for most types of locker material, e.g.,
sheet metal, wood, HPL, and solid plastic. The GL7p can be used with left- and right-hinged locker doors alike. The
lock can be mounted both vertically and horizontally, which also makes it suitable for use in lockers with very low
door heights. Due to its mechanical compatibility with standard locker locks and identical locks from other
manufacturers, existing locker installations can be effortlessly upgraded using the GL7p. The existing holes of the
previous standard locks can be directly re-used.
The GL7p is powered by one 3.6 V AA lithium battery (see “8 TECHNICAL DATA”), which provides an operating life
of up to 10 years* (at 10 activations per day and +20 °C room temperature) before requiring replacement. For
configuration, the lock connects to a computer via USB and can then be configured using GAT Config Manager
configuration software. The lock can operate in one of five operating modes thereby providing flexibility for different
locking requirements within a facility.

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
General Information
14 HB_GL7p--EN_12 www.gantner.com
Using a locker
To use a locker, the user closes the door of their locker and while holding the door shut, presses the button of the
GL7p in using their data carrier. The GL7p reads the data carrier information and determines whether the user is
authorized to use the locker. When the user is authorized, the GL7p locks the locker door. The LED signals the
locking action and the button remains in the pressed-in position.
To unlock a previously locked locker, the user presses their data carrier onto the lock button. The GL7p reads the
data carrier and checks that the authorization is valid before automatically unlocking the locker door.
* Different operating modes or configurations can reduce the battery lifespan.
2.4 GL7p Variants
Various options are available for identifying users of the GL7p locker locks. Depending on the variant of the lock
used, one or more of these options can be used.
Variant
RFID 1)
Wireless 2)
PIN Code 3)
Mounting method 4)
GL7p.0500
X
-
-
vertical top | horizontal right | horizontal left
GL7p.1500
X
-
X
vertical top
GL7p.1501
X
-
X
horizontal right
GL7p.1502
X
-
X
horizontal left
GL7p.2500
X
X
-
vertical top | horizontal right | horizontal left
GL7p.3500
X
X
X
vertical top
GL7p.3501
X
X
X
horizontal right
GL7p.3502
X
X
X
horizontal left
1) Identification via radio frequency (13.56 MHz) over a short distance of up to a few centimeters (RFID = Radio-Frequency
Identification). A distinction must be made between the different technologies (e.g., MIFARE Classic, MIFARE Ultralight, ISO
15693, HID iCLASS, NFC). A list of all supported technologies is provided on the next page.
2) Identification via wireless technology (2.402 to 2.480 GHz) over long distances of up to several meters. This option can be
used, e.g., for identification at the lock using a smartphone with a specific app.
3) PIN-code keypad for identification.
4) Alignment of the lock depends on the printing of the PIN-code keypad (see next page).
Table 2.1 –GL7p variants

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
General Information
www.gantner.com HB_GL7p--EN_12 15
2.4.1 RFID Technologies
The following data carriers can be used for RFID identification with the GL7p.
MIFARE®(manufacturer NXP/Infineon)
- MIFARE®Classic (1k and 4k)
- DESFire EV1® and EV2®
- MIFARE Ultralight®
HID iClass
- Reading of unique number only
ISO 15693
- The GL7p operates with all currently known ISO 15693 data carriers.
In addition to the different RFID technologies, data carriers are available in a variety of shapes and sizes. The GL7p
is designed to operate with all different types of data carrier media.
2.4.2 Lock Orientation
For the GL7p variants with a PIN-code keypad, the printing of the PIN-code keypad must be observed (recognizable
by the last digit of the model identifier). The different variants must be mounted as follows.
0 ... vertical top
1 ... horizontal, right-hinged door (i.e., the lock is on the left and the door opens on the left)
2 ... horizontal, left-hinged door (i.e., the lock is on the right and the door opens on the right)
Figure 2.1 –Orientation of the GL7p variants with PIN-code keypad

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
General Information
16 HB_GL7p--EN_12 www.gantner.com
2.5 Terminology
Several key terms that are used often in this manual are defined below.
Computer / PC
These terms refer to all desktop and laptop computers running a Microsoft®Windows®operating system.
Data Carrier
A data carrier is a form of identification media that is used by staff and visitors in a facility for identification. Data
carriers are available in a variety of different forms such as plastic wristbands and chip cards. Data carriers are also
available to suit different RFID technologies (LEGIC, MIFARE®, ISO 15693).
System Data Carrier
Several different types of System Data Carriers are used for programming, service and maintenance tasks. These
data carriers have special functions and as they are essential for operation of the GL7p and have security-related
features, they must be kept in a secure place and be protected against unauthorized use. Most of the System Data
Carriers are included in the GAT ECO.Basic Set FD; however, some must be ordered separately as required.
FID (Company ID) and Site Key
LEGIC systems use the FID number and in MIFARE®systems the site key is used, which is a combination of the
FID and the read and write keys. The FID and site key are unique for every facility. These numbers are encoded in
every data carrier and device used in the facility thereby ensuring that data carriers from one installation cannot be
used in other installations.
GAT Config Manager
GANTNER developed PC software that is used to configure GANTNER devices such as the GL7p. A separate
manual is available and integrated into the software. While the software is open, click on the “Help” drop-down
menu and select “How Do I”.
Lock
General term for the GL7p.
Locker
The term "locker" is used to describe all possible locker applications that can be fitted with a GANTNER electronic
lock. Typical applications include a changing room locker, a deposit box, or a private box.
RFID (Radio-Frequency Identification)
Identification over a short distance using radio frequency. An RFID data carrier is used to identify users in
GANTNER systems.
Wireless
Identification via a wireless interface in the range 2.402 to 2.48 GHz, over which identification and locker operation
from several meters, e.g., via an app on a smartphone, is possible.
User / Guest / Visitor
These general terms refer to the people in a facility who use the locker system with GANTNER locker locks, data
carriers, and other GANTNER devices on a daily basis.

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
General Information
www.gantner.com HB_GL7p--EN_12 17
2.6 System Components
The GL7p locker locking system includes the following system parts. A description of the individual components is
provided on the following page.
Figure 2.1 –Components of the GL7p locker system
3. GL7p.1501
4. GL7p.3501
7. GL7p.1502
7. GL7p.3502
1. GL7p.0500
5. GL7p.2500
11. Batterie 3.6V Lithium SL-860/S
10. GAT ECO.Basic Set FD
13. GL7p Button Plate
2. GL7p.1500
6. GL7p.3500
9. GL7p Battery CoverKey
12. GAT Key Tag F Open
Master
14. GL7p Number Plate
15. GL7p Number Sticker

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
General Information
18 HB_GL7p--EN_12 www.gantner.com
1. GL7p.0500 (Part No. 922728)
Battery lock for MIFARE®and ISO 15693 data carriers, without PIN keypad, without battery.
2. GL7p.1500 (Part No. 922627)
Battery lock for MIFARE®and ISO 15693 data carriers, with PIN keypad, vertical mounting, without battery.
3. GL7p.1501 (Part No. 922425)
Battery lock for MIFARE®and ISO 15693 data carriers, with PIN keypad, mounting on right-hinged door, without
battery.
4. GL7p.1502 (Part No. 922526)
Battery lock for MIFARE®and ISO 15693 data carriers, with PIN keypad, mounting on left-hinged door, without
battery.
5. GL7p.2500 (Part No. 922324)
Battery lock for MIFARE®and ISO 15693 data carriers, with wireless interface, without PIN keypad, without
battery.
6. GL7p.3500 (Part No. 922223)
Battery lock for MIFARE®and ISO 15693 data carriers, with wireless interface, with PIN keypad, vertical mounting,
without battery.
7. GL7p.3501 (Part No. 922021)
Battery lock for MIFARE®and ISO 15693 data carriers, with wireless interface, with PIN keypad, mounting on
right-hinged door, without battery.
8. GL7p.3502 (Part No. 922122)
Battery lock for MIFARE®and ISO 15693 data carriers, with wireless interface, with PIN keypad, mounting on left-
hinged door, without battery.
9. GL7p Battery CoverKey (Part No. 749230)
Tool for opening the battery compartment.
10.GAT ECO.Basic Set FD (Part No. 1100550)
Set for the configuration and maintenance of the GL7p system. Contains configuration software, USB charging
cable, 3 MASTER data carriers, 5 system data carriers with special functions, and a battery compartment key.
See section "6.4 GAT ECO.Basic Set FD" for more information on the GAT ECO.Basic Set FD.
11.Batterie 3.6V Lithium SL-860/S (Part No. 914430)
GANTNER approved battery for the GL7p. Alternative = Tadiran TL-4903/S
12.GAT Key Tag FD Open Master (Part No. 1100369)
Optional data carrier. Not included in the GAT ECO.Basic Set FD. MIFARE data carrier that can open every GL7p
locker in the assignedsystem (=master key function) instead of aMASTER data carrier. Incontrast to the MASTER
data carrier, this data carrier can only unlock a locker but not lock it again. See section "6.5.2 OPEN MASTER
Data Carrier (Optional Accessory)" for more information.
13.GL7p Button Plate (Part No. 748633) –included with the GL7p
Self-adhesive number plate, thickness 0.8 mm, white unprinted, for attaching to the button.
14.GL7p Number Plate (Part No. 1103180)
Self-adhesive number plate, thickness 0.8 mm, white with lasered locker number (standard font), can be attached
to the button instead of the number plate Part No. 748633.

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
General Information
www.gantner.com HB_GL7p--EN_12 19
15.GL7p Number Sticker
Self-adhesive button sticker that can be attached to the accompanying GL7p Button Plate (Part No. 748633).
Printable with a customer-specific design. This item is available in sheets of 50 stickers with pre-printed numbers
in the following number ranges:
- GL7p Number Sticker 001-050 (Part No. 1103040)
- GL7p Number Sticker 051-100 (Part No. 1103041)
- GL7p Number Sticker 101-150 (Part No. 1103042)
- GL7p Number Sticker 151-200 (Part No. 1103043)
- GL7p Number Sticker 201-250 (Part No. 1103044)
- GL7p Number Sticker 251-300 (Part No. 1103045)
- GL7p Number Sticker 301-350 (Part No. 1103046)
- GL7p Number Sticker 351-400 (Part No. 1103047)
- GL7p Number Sticker 401-450 (Part No. 1103048)
- GL7p Number Sticker 451-500 (Part No. 1103049)

GL7p - Battery-powered, door-mounted electronic locker lock GL7p
General Information
20 HB_GL7p--EN_12 www.gantner.com
2.7 GL7p Dimensions and Components
1. LED status indicator
7. Fixing nut
2. Button (a = “unlocked”, b = “locked”)
8. Spacer sleeve
3. Latch
4. Front part
5. Rear part
6. Mounting thread (M19x1)
9. Screw for anti-rotation protection
10. Battery compartment cover
11. Battery compartment key
Figure 2.2 –GL7p dimensions and components (dimensions in mm –inches shown in brackets)
